RFD-CSNGFField Controller Win EC7

Leica CS20 User Manual Version 1.0 English CS20, Introduction 2 Introduction PurchaseCongratulations on the purchase of a Leica CS20. This manual contains important safety directions as well as instructions for setting up the product and operating it. Refer to "1 Safety Directions" for further information. Read carefully through the User Manual before you switch on the product. Product identifica- tion The type and serial number of your product are indicated on the type plate. Always refer to this information when you need to contact your agency or Leica Geosystems authorised service workshop. Trademarks• Windows is a registered trademark of Microsoft Corporation in the United States and other countries • SD Logo is a trademark of SD-3C, LLC. • Bluetooth ® is a registered trademark of Bluetooth SIG, Inc. All other trademarks are the property of their respective owners. Validity of this manual This manual applies to the CS20 field controller and CTR20 expansion pack. Differences between the various models are marked and described. Available documentation Refer to the following resources for all CS20 documentation/software: • the Leica USB documentation card • https://myworld.leica-geosystems.com NameDescription/Format CS20 Quick Guide Provides an overview of the product together with tech- nical data and safety directions. Intended as a quick reference guide. 99 CS20 User Manual All instructions required in order to operate the product to a basic level are contained in the User Manual. Provides an overview of the product together with tech- nical data and safety directions. -9 NameDescription/Format Leica Captivate Technical Reference Manual Overall comprehensive guide to the product and apps. Included are detailed descriptions of special soft- ware/hardware settings and software/hardware func- tions intended for technical specialists. -9 CS20, Introduction 3 myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers a wide range of services, information and training material. With direct access to myWorld, you are able to access all relevant services whenever it is convenient for you, 24 hours a day, 7 days per week. This increases your efficiency and keeps you and your equipment instantly updated with the latest information from Leica Geosystems. ServiceDescription myProductsAdd all Leica Geosystems products that you and your company own. View detailed information on your products, buy additional options or Customer Care Packages (CCPs), update your products with the latest software and keep up-to-date with the latest documentation. myServiceView the service history of your products in Leica Geosystems Service Centres and detailed information on the services performed on your products. For your products that are currently in Leica Geosystems Service Centres view the current service status and the expected end date of service. mySupportCreate new support requests for your products that will be answered by your local Leica Geosystems Support Team. View the complete history of your Support and view detailed information on each request in case you want to refer to previous support requests. myTrainingEnhance your product knowledge with the Leica Geosystems Campus - Information, Knowledge, Training. Study the latest online training material or download training material on your products. Keep up- to-date with the latest News on your products and register for Semi- nars or Courses in your country. myTrustedSer- vices Offers increased productivity while at the same time providing maximum security. • myExchange With myExchange you can exchange any files/objects from your computer to any of your Leica Exchange Contacts. • mySecurity If your instrument is ever stolen, a locking mechanism is available to ensure that the instrument is disabled and can no longer be used. CS20, Table of Contents 4 Table of Contents In this manualChapterPage 1Safety Directions 6 1.1General Introduction6 1.2Definition of Use7 1.3Limits of Use7 1.4Responsibilities8 1.5Hazards of Use8 1.6Laser Classification11 1.6.1General11 1.6.2DISTO11 1.7Electromagnetic Compatibility EMC12 1.8FCC Statement, Applicable in U.S.13 2Description of the System 15 2.1Overview15 2.2Terminology15 2.3System Concept16 2.3.1Software Concept16 2.3.2Power Concept17 2.3.3Data Storage Concept17 2.4CS Components18 3User Interface 19 3.1Keyboard19 3.2Operating Principles21 3.3LED Indicators on CS2021 4Operation 22 4.1Equipment Setup22 4.1.1Fixing the CS to a Holder and Pole22 4.1.2Fixing a Hand Strap to the CS23 4.1.3Fixing the Utility Hook to the CS24 4.1.4Replacing the Display Foil on the CS24 4.1.5Inserting and Removing a SIM Card25 4.1.6Setting up for Usage of Long Range Bluetooth Expan- sion Pack CTR2026 4.1.7Connecting to a Personal Computer27 4.1.8Enabling WLAN in Windows EC729 4.2Batteries30 4.2.1Operating Principles30 4.2.2Changing the Battery30 4.2.3Charging the Battery31 4.3Power Functions31 4.4Working with the Memory Device32 4.4.1Working with the SD Card32 4.4.2Working with a USB Memory Stick33 4.5Using the Digital Camera33 4.6Using the Camera Flash Light as Torch34 CS20, Table of Contents 5 5Care and Transport 35 5.1Transport35 5.2Storage35 5.3Cleaning and Drying35 6Technical Data 37 6.1CS20 Technical Data37 6.2CTR20 Technical Data38 6.3Conformity to National Regulations39 6.3.1CS2039 6.3.2CTR2041 7Software Licence Agreement 42 Appendix APin Assignments and Sockets 43 A.1CS2043 CS20, Safety Directions 6 1Safety Directions 1.1General Introduction DescriptionThe following directions enable the person responsible for the product, and the person who actually uses the equipment, to anticipate and avoid operational hazards. The person responsible for the product must ensure that all users understand these directions and adhere to them. About Warning Messages Warning messages are an essential part of the safety concept of the instrument. They appear wherever hazards or hazardous situations can occur. Warning messages... • make the us…

Text truncated - open the document above for the full version.

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com FCC Heerbrugg, 04 Februar 2015 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburg, PA 15262-0001 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: RFD-CSNGF including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Please contact us if you have any additional questions. Best regards Hannes Juen Christian Gerber Manager Quality Engineering R&D Electronics Design Leica Geosystems AG Leica Geosystems AG

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com FCC Heerbrugg, 04. Februar 2015 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburg, PA 15262-0001 Request for Confidentiality Leica Geosystems AG - FCC-ID: RFD-CSNGF , FCC Part 15 Certification Gentlemen, In accordance with 0.459 of CFR 47, Leica Geosystems AG hereby requests confidentiality of -Operational Description (11_CS20NGF OpDes.pdf) -Block Diagrams (12_CS20NGF BlkDia.pdf) -Schematics (13_CS20NGF Schem.pdf) -Parts List (16_CS20NGF PartsLst.pdf) attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Leica Geosystems AG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. There are special tools necessary to open the products and the internal design is not publicly accessible. Since the design is a basis from which future technological products will evolve, Leica Geosystems AG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Hannes Juen Christian Gerber Manager Quality Engineering R&D Electronics Design Leica Geosystems AG Leica Geosystems AG

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com FCC Heerbrugg, 04 Februar 2015 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburg, PA 15262-0001 Short Term Confidentiality Request for the mobile device "CS20NGF" FCC ID: RFD-CSNGF Gentlemen In accordance with 0.457 and 0.459 of CFR 47, Leica Geosystems AG hereby requests for ‘Short Term Confidentiality’ of all -Internal Photos (09_CS20NGF IntPho.pdf) -External Photos (08_CS20NGF ExtPho.pdf) -Test set-up photos (10_CS20NGF TSup.pdf) -User Manual (15_CS20NGF UserMan.pdf) attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Leica Geosystems AG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Leica Geosystems AG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Please contact us if you have any additional questions. Best regards Hannes Juen Christian Gerber Manager Quality Engineering R&D Electronics Design Leica Geosystems AG Leica Geosystems AG

External Photos page 1 Model No.:CS20 3.75G, CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS FCC ID: RFD-CSNGF IC: 3177A-CSNGF Project No.: G0M-1406-3917

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrug Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com 1 Label 1 for CS20 3.75G Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrug Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com 2 Label 1 for CS20 3.75G GNSS Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrug Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com 3 Label 1 for CS20 3.75G Disto Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrug Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com 4 Label 1 for CS20 3.75G Disto GNSS Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrug Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com 5 Label 2

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Phone +41 71 727 31 31 07_CS20NGC LabelLoc.docx Label 1 Label 2

Internal Photos page 1 Model No.:CS20 3.75G, CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS FCC ID: RFD-CSNGF IC: 3177A-CSNGF Project No.: G0M-1406-3917 Internal Photos page 2 Model No.:CS20 3.75G, CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS FCC ID: RFD-CSNGF IC: 3177A-CSNGF Project No.: G0M-1406-3917

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com Declaration concerning Antenna Specification It is hereby declared that the product Model No.: CS20 3.75G, CS 20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS FCC ID: RFD-CSNGF fulfills the requirement in FCC test relating to the antenna type. 1 BT/WLAN The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: Pulse / W3008C Type of antenna: ceramic chip soldered into the PCB Peak Gain of the antenna: 2.2 dBi Frequency range: 2400-2483.5 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. 2 GSM / UMTS / CDMA The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: Ethertronics / P522303 Type of antenna: Isolated Magnetic Dipole permanently attached (soldered into the PCB) Peak Gain of the antenna: 2.8 dBi Frequency range: 824-2170 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Direct Phone: +41 71 727 3894 E-Mail: [email protected] 2/2 3 LR-BT The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: Leica Geosystems / 805684 Type of antenna: inverted-F permanently attached (built into the housing) Peak Gain of the antenna: 1 dBi Frequency range: 2400-2480 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Leica Geosystems Address: Heinrich-Wild-Strasse City: Heerbrugg ZIP / Postal code: 9435 Country: Switzerland Place: Heerbrugg Date: 05.02.2015 Signature:

Test Report No.: G0M-1406 -3917-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany SAR TEST REPORT FCC 47 CFR Part 2.1093 Industry Canada RSS-102 RF-Exposure evaluation of portable equipment Report Reference No. .................... : G0M-1406-3917-TFC093SR-V01 Testing Laboratory ........................ : Eurofins Product Service GmbH Address ............................................ : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation .................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ........................... : Leica Geosystems AG Address ............................................ : Heinrich Wild Strasse 9435Heerbrugg SWITZERLAND Test specification: Standard ........................................... : FCC 47 CFR Part 2 §2.1093 FCC OET Bulletin 65 Supplement C 01-01 IEEE Std. 1528-2003 IEEE Std. 1528 - 2013 IC RSS-102 Issue 5 Safety Code 6 (2015) Non-standard test method..............: None Test scope.............. ....................... : complete Radio compliance test Equipment under test (EUT): Product description Field Controller Win EC7 Model No. CS20 3.75G Additional Model(s) CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS Brand Name(s) Leica Geosystems Hardware version V5.0 Firmware / Software version 1.0 Contains FCC-ID: RFD-CSNGF IC: 3177A-CSNGF Test result Passed Page 1 of 108 Page 2 of 108 Test Report No.: G0M-1406 -3917-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Version History Version Issue Date Remarks Revisedby 01 2015-04-28 Initial Release Page 3 of 108 Test Report No.: G0M-1406 -3917-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 6 1.1 Equipment photos 8 1.2 Equipment setup photos 11 1.3 Reference Documents 14 1.4 Supporting Equipment Used During Testing 15 1.5 Supported standalone operating modes 16 1.6 Conducted Power Values 17 1.7 Standalone Operational Mode Test Exclusion 20 1.8 Supported concurrent (multi-transmitter) operating modes 21 1.9 Supported use cases 22 1.10 Radio Test Modes 23 1.11 Test Positions 24 1.12 Test Equipment Used During Testing 25 2 RESULT SUMMARY 26 3 DEFINITIONS 27 3.1 Controlled Exposure 27 3.2 Uncontrolled Exposure 27 3.3 Localized SAR 27 4 LOCALIZED SAR MEASUREMENT EQUIPMENT 28 4.1 Complete SAR DASY5 Measurement System 28 4.2 Robot Arm 30 4.3 Data Acquisition Electronics 30 4.4 Isotropic E -Field Probe ≤ 3 GHz 31 4.5 Isotropic E-Field Probe ≤ 6 GHz 32 4.6 Test phantom and ositioned 33 4.7 System Validation Dipoles 34 5 SINGLE-BAND SAR MEASUREMENT 35 5.1 General measurement description 35 5.2 SAR measurement description 35 5.3 Reference lines and points for Handsets 36 5.4 Test positions relative to the Head 37 5.5 Test positions relative to the human body 38 5.6 Measurement Uncertainty 39 Page 4 of 108 Test Report No.: G0M-1406 -3917-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 6 TEST CONDITIONS AND RESULTS 40 6.1 Recipes for Tissue Simulating Liquids 40 6.2 Test Conditions and Results – Tissue Validation 41 6.3 Test Conditions and Results – System Validation 44 6.4 Test Conditions and Results – Standalone SAR Measurement 46 6.1 Test Conditions and Results – Multi -transmitter SAR Result 48 ANNEX A Calibration Documents 51 ANNEX B System Validation Reports 92 ANNEX C SAR Measurement Reports 102 Page 5 of 108 Test Report No.: G0M-1406 -3917-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1 Equipment (Test item) Description Description Field Controller Win EC7 Model CS20 3.75G Additional Model(s) CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS Brand Name(s) Leica Geosystems Serial number None Hardware version V5.0 Software / Firmware version 1.0 Contains FCC-ID RFD-CSNGF Contains IC 3177A-CSNGF Equipment type End product Prototype or production unit Identical Prototype Device category Handset Environment General public Radio technologies GSM, UMTS, WLAN, Bluetooth Operating frequency ranges GSM 850: 824 MHz - 849 MHz PCS 1900: 1850 MHz - 1910 MHz WLAN IEEE 802.11 b, g, n: 2400 MHz - 2483.5 MHz (20MHz) Bluetooth Low Energy: 2400 MHz – 2483.5 MHz Bluetooth: 2400 MHz - 2483.5 MHz Bluetooth LR: 2400 MHz - 2483.5 MHz Number of antennas 3 Antenna (WLAN/Bluetooth/Bluetooth Low Energy) Type integrated Model W3008C Manufacturer Pulse Gain 2.2dBi Antenna (GSM/UMTS) Type integrated Model P522303 Manufacturer Ethertronics Gain 2.8dBi Antenna (Bluetooth LR) Type integrated Model 805684 Manufacturer Leica Geosystems Gain 1dBi Power supply V NOM 11.1 V DC AC/DC-Adaptor Model AEL40US15 Vendor XP Power Input 100 ...240 V AC Output 15 V DC Page 6 of 108 Test Report No.: G0M-1406 -3917-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Accessories None Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435Heerbrugg SWITZERLAND Page 7 of 108 Test Report No.: G0M-1406 -3917-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.3 Reference Documents Document KDB Publication 447498 : Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Polices KDB Publication 648474 : SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas KDB Publication 648474 : Review and Approval Policies for SAR Evaluation of Handsets with Multiple Transmitters and Antennas KDB Publication 865664 : SAR measurement procedures for devices operating between 100 MHz to 6 GHz KDB Publication 941225: SAR Measurement Procedures for 3G Devices KDB Publication 941225: 3GPP R6 HSPA and R7 HSPA+ SAR Guidance KDB Publication 941225: Recommended SAR Test Reduction Procedures for GSM/GPRS/EDGE KDB Publication 9412…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 182 FCC TEST REPORT FCC 47 CFR Part 22H Industry Canada RSS-132, Issue 3 Cellular Telephones Operating in the Bands 824-849MHz and 869-894MHz FCC 47 CFR Part 24E Industry Canada RSS-133, Issue 6 2GHz Personal Communication Services Report Reference No. ..................... : G0M-1406-3917-TFC224GS-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address ............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address ............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR Part 22H, 47 CFR Part 24E RSS-132, Issue 3 : 2013-01, RSS-133, Issue 6 : 2013-01 SRSP-503 Issue 7 : 2008-09, SRSP-510 Issue 5 : 2009-02 RSS-Gen, Issue 4, 2014-11, ANSI/TIA-603-C-2004 Equipment under test (EUT): Product description Field Controller Win EC7 Model No. CS20 3.75G Additional Model(s) CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS Brand Name(s) Leica Geosystems Hardware version V5.0 Firmware / Software version 1.0 FCC-ID: RFD-CSNGF IC: 3177A-CSNGF Test result Passed Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 182 Version History Version Issue Date Remarks Revised by 01 2015-04-22 Initial Release Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 182 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment External 7 1.2 Photos – Equipment internal 8 1.3 Photos – Test setup 10 1.4 Supporting Equipment Used During Testing 11 1.5 Test Modes 12 1.6 Test Equipment Used During Testing 13 1.7 Sample emission level calculation 14 2 RESULT SUMMARY 15 3 TEST CONDITIONS AND RESULTS 16 3.1 Test Conditions and Results – Occupied Bandwidth 16 3.2 Test Conditions and Results – Effective radiated power / Equivalent isotropic radiated power 30 3.3 Test Conditions and Results – Transmitter radiated emissions 32 3.4 Test Conditions and Results – Receiver radiated emissions 35 ANNEX A Transmitter radiated spurious emissions 37 ANNEX B Receiver radiated spurious emissions 169 Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 182 1 Equipment (Test item) Description Description Field Controller Win EC7 Model CS20 3.75G Additional Model(s) CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS Brand Name(s) Leica Geosystems Serial number None Hardware version V5.0 Software / Firmware version 1.0 FCC-ID RFD-CSNGF IC 3177A-CSNGF Equipment type End product Equipment classification Portable Device (Human Body distance < 20 cm) Radio type Transceiver Radio technology GSM850 / GSM1900 Operating frequency range GSM850 : TX = 824 - 849 MHz, RX = 869 - 894 MHz GSM1900 : TX = 1850 - 1910 MHz, RX = 1930 - 1990 MHz Assigned frequency band Cell. Service Block A & B : 824 - 849 MHz & 869 - 894 MHz Broadband PCS : 1850 - 1910 MHz & 1930 - 1990 MHz Main test frequencies GSM850 F LOW CH : 128 UL: 824.2 MHz CH : 128 DL: 869.2 MHz F MID CH : 188 UL: 836.2 MHz CH : 188 DL: 881.2 MHz F HIGH CH : 251 UL: 848.8 MHz CH : 251 DL: 893.8 MHz Main test frequencies GSM1900 F LOW CH : 512 UL: 1850.2 MHz CH : 512 DL: 1930.2 MHz F MID CH : 661 UL: 1880.0 MHz CH : 661 DL: 1960.0 MHz F HIGH CH : 810 UL: 1909.8 MHz CH : 810 DL: 1989.8 MHz Supported transmission modes GSM, GPRS, E-GPRS Modulations GSM, GPRS : GMSK Multislot class 12 Number of antennas 1 Radio module Type GSM module Model PHS8-P Manufacturer Gemalto HW Version B1 SW Version 03.001 FCC-ID QIPPHS8-P IC 7830A-PHS8P Antenna Type integrated Model P522303 Manufacturer Ethertronics Gain 2.8dBi Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 182 Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Power supply V NOM 11.1 VDC V MIN N/A V MIN N/A AC/DC-Adaptor Model N/A Vendor N/A Input N/A Output N/A Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 182 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments SIM Radio communication tester R&S CMU200 SIM : Simulator (Not Subjected to Test) Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 182 1.5 Test Modes Mode # Description GSM850 General conditions: EUT powered by battery. Active data call to communication tester. Radio conditions: Mode = GPRS Connection = Packet Data Modulation = GMSK Slot configuration = 1 up Power level = Maximum (Gamma 3) GSM850 General conditions: EUT powered by battery. Active data call to communication tester. Radio conditions: Mode = E-GPRS Connection = Packet Data Modulation = GMSK Slot configuration = 1 up Power level = Maximum (Gamma 6) GSM1900 General conditions: EUT powered by battery. Active data call to communication tester Radio conditions: Mode = GPRS Connection = Packet Data Modulation = GMSK Slot configuration = 1 up Power level = Maximum (Gamma 3) GSM1900 General conditions: EUT powered by battery. Active data call to communication tester Radio conditions: Mode = E-GPRS Connection = Packet Data Modulation = GMSK Slot configuration = 1 up Power level = Maximum (Gamma 5) Test Report No.: G0M-1406-3917-TFC224GS-V01 Eurofins Product Service GmbH St…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1406-3917-TFC224WC-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 114 FCC TEST REPORT FCC 47 CFR Part 22H Industry Canada RSS-132, Issue 3 Cellular Telephones Operating in the Bands 824-849MHz and 869-894MHz FCC 47 CFR Part 24E Industry Canada RSS-133, Issue 6 2GHz Personal Communication Services Report Reference No. ..................... : G0M-1406-3917-TFC224WC-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address ............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address ............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR Part 22H, 47 CFR Part 24E RSS-132, Issue 3 : 2013-01, RSS-133, Issue 6 : 2013-01 SRSP-503 Issue 7 : 2008-09, SRSP-510 Issue 5 : 2009-02 RSS-Gen, Issue 4, 2014-11, ANSI/TIA-603-C-2004 Equipment under test (EUT): Product description Field Controller Win EC7 Model No. CS20 3.75G Additional Model(s) CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS Brand Name(s) Leica Geosystems Hardware version V5.0 Firmware / Software version 1.0 FCC-ID: RFD-CSNGF IC: 3177A-CSNGF Test result Passed Test Report No.: G0M-1406-3917-TFC224WC-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 114 Version History Version Issue Date Remarks Revised by 01 2015-04-22 Initial Release Test Report No.: G0M-1406-3917-TFC224WC-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 114 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment External 7 1.2 Photos – Equipment internal 8 1.3 Photos – Test setup 10 1.4 Supporting Equipment Used During Testing 11 1.5 Test Modes 12 1.6 Test Equipment Used During Testing 13 1.7 Sample emission level calculation 14 2 RESULT SUMMARY 15 3 TEST CONDITIONS AND RESULTS 16 3.1 Test Conditions and Results – Occupied Bandwidth 16 3.2 Test Conditions and Results – Effective radiated power / Equivalent isotropic radiated power 23 3.3 Test Conditions and Results – Transmitter radiated emissions 25 3.4 Test Conditions and Results – Receiver radiated emissions 27 ANNEX A Transmitter radiated spurious emissions 29 ANNEX B Receiver radiated spurious emissions 101 Test Report No.: G0M-1406-3917-TFC224WC-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 114 1 Equipment (Test item) Description Description Field Controller Win EC7 Model CS20 3.75G Additional Model(s) CS20 3.75G GNSS, CS20 3.75G Disto, CS20 3.75G Disto GNSS Brand Name(s) Leica Geosystems Serial number None Hardware version V5.0 Software / Firmware version 1.0 FCC-ID RFD-CSNGF IC 3177A-CSNGF Equipment type End product Equipment classification Portable Device (Human Body distance < 20 cm) Radio type Transceiver Radio technology WCDMA FDDII / WCDMA FDDV Operating frequency range FDDII : TX = 1850 MHz - 1910 MHz, RX = 1930 MHz - 1990 MHz FDDV : TX = 824 MHz - 849 MHz, RX = 869 MHz - 894 MHz Assigned frequency band Cell. Service Block A & B : 824 - 849 MHz & 869 - 894 MHz Broadband PCS : 1850 - 1910 MHz & 1930 - 1990 MHz Main test frequencies FDDV F LOW CH : 4133 UL: 826.6 MHz CH : 4358 DL: 871.6 MHz F MID CH : 4175 UL: 835 MHz CH : 4400 DL: 880 MHz F HIGH CH : 4232 UL: 846.4 MHz CH : 4457 DL: 891.4 MHz Main test frequencies FDDII F LOW CH : 9263 UL: 1852.6 MHz CH : 9663 DL: 1932.6 MHz F MID CH : 9400 UL: 1880.0 MHz CH : 9800 DL: 1960.0 MHz F HIGH CH : 9537 UL: 1907.4 MHz CH : 9937 DL: 1987.4 MHz Supported transmission modes HSDPA, HSUPA Modulations QPSK Number of antennas 1 Radio module Type GSM module Model PHS8-P Manufacturer Gemalto HW Version B1 SW Version 03.001 FCC-ID QIPPHS8-P IC 7830A-PHS8P Antenna Type integrated Model P522303 Manufacturer Ethertronics Gain 2.8dBi Test Report No.: G0M-1406-3917-TFC224WC-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 114 Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Power supply V NOM 11.1 V DC V MIN N/A V MIN N/A AC/DC-Adaptor Model N/A Vendor N/A Input N/A Output N/A Test Report No.: G0M-1406-3917-TFC224WC-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 114 1.4 Supporting Equipment Use…

Text truncated - open the document above for the full version.
