RFZMTUSBMP3 & DIGITAL RECORDER WATCH

TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: XONIX HOLDINGS LIMITED FCC ID: RFZMTUSB REPORT #: X\XONIX_RFZ\1990HT4\1990HT4TestReport.doc COVER SHEET Test Report Product Name: MP3 & DIGITAL RECORDER WATCH FCC ID: RFZMTUSB Applicant: XONIX HOLDINGS LIMITED 1B-4B, 2F, HOP LITE INDUSTRIAL CENTRE N0. 3-5 WANG TAI ROAD KOWLOON BAY, HONG KONG Date Receipt: NOVEMBER 30, 2004 Date Tested: JANUARY 4, 2004 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: XONIX HOLDINGS LIMITED FCC ID: RFZMTUSB REPORT #: X\XONIX_RFZ\1990HT4\1990HT4TestReport.doc TABLE OF CONTENTS APPLICANT: XONIX HOLDINGS LIMITED FCC ID: RFZMTUSB TABLE OF CONTENTS LIST TEST REPORT: PAGE 1-6......TEST EQUIPMENT LIST PAGE 7........TEST PROCEDURES PAGE 8........RADIATION INTERFERENCE TEST DATA PAGE 9........POWER LINE CONDUCTED INTERFERENCE TEST DATA PAGE 10-11....POWER LINE CONDUCTED PLOTS EXHIBITS: BLOCK DIAGRAM SCHEMATIC USERS MANUAL LABEL SAMPLE LABEL LOCATION EXTERNAL PHOTOGRAPHS INTERNAL PHOTOGRAPHS TEST SET UP PHOTOGRAPH TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: XONIX HOLDINGS LIMITED FCC ID: RFZMTUSB REPORT #: X\XONIX_RFZ\1990HT4\1990HT4TestReport.doc Page 1 of 11 EMC Equipment List Device Manufacturer Model Serial Number Cal/Char Date Due Date or Status 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/12/06 3/10-Meter OATS TEI N/A N/A Listed 3/27/04 3/26/07 Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 9/23/03 9/23/05 Tan Tower RF Preselector HP 85685A 3221A01400 CAL 9/23/03 9/23/05 Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 9/23/03 9/23/05 Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 9/23/03 9/23/05 Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 Blue Tower RF Preselector HP 85685A 2620A00294 CAL 4/27/04 4/27/06 Blue Tower Quasi- Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Silver Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 CAL 3/22/04 3/22/06 Silver Tower RF Preselector HP 85685A 2926A00983 CAL 3/22/04 3/22/06 Silver Tower Quasi- Peak Adapter HP 85650A 3303A01844 CAL 3/22/04 3/22/06 Silver Tower Preamplifier HP 8449B 3008A01075 CAL 3/22/04 3/22/06 Biconnical Antenna Electro- Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Biconnical Antenna Eaton 94455-1 1096 CAL 8/17/04 8/17/06 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 BiconiLog Antenna EMCO 3143 9409-1043 No Cal Required Log-Periodic Antenna Electro- Metrics LPA-25 1122 CAL 8/26/04 8/26/06 Log-Periodic Antenna Electro- Metrics LPA-30 409 CAL 3/4/03 3/4/05 Log-Periodic Eaton 96005 1243 CAL 5/8/05 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: XONIX HOLDINGS LIMITED FCC ID: RFZMTUSB REPORT #: X\XONIX_RFZ\1990HT4\1990HT4TestReport.doc Page 2 of 11 Device Manufacturer Model Serial Number Cal/Char Date Due Date or Status Antenna 5/8/03 Dipole Antenna Kit Electro- Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/04 Dipole Antenna Kit Electro- Metrics TDA-30/1-4 153 CAL 9/26/02 9/26/05 Double-Ridged Horn Antenna Electro- Metrics RGA-180 2319 CAL 2/17/03 2/17/05 Horn Antenna *(at 3 meters) Electro- Metrics EM-6961 6246 CAL 3/31/03 3/31/05 Horn Antenna *(at 10 meters) Electro- Metrics EM-6961 6246 CAL 6/4/03 6/4/05 Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/03 Harmonic Mixer with Horn Antenna Oleson Microwave Labs M08HW/A F30425-1 CHAR 4/25/03 4/25/05 Harmonic Mixer with Horn Antenna Oleson Microwave Labs M12HW/A E30425-1 CHAR 4/25/03 4/25/05 LISN Electro- Metrics ANS-25/2 2604 CAL 8/27/04 8/27/06 LISN Electro- Metrics EM-7820 2682 CAL 3/12/03 3/12/05 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 7/16/04 7/16/06 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CAL 7/16/04 7/16/06 Oscilloscope Tektronix 2230 300572 CAL 7/3/03 7/3/05 System One Audio Precision System One SYS1-45868 CHAR 4/25/02 4/25/04 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/04 AC Voltmeter HP 400FL 2213A14499 CAL 7/19/04 7/19/06 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/03 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/03 Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/04 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/04 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: XONIX HOLDINGS LIMITED FCC ID: RFZMTUSB REPORT #: X\XONIX_RFZ\1990HT4\1990HT4TestReport.doc Page 3 of 11 Device Manufacturer Model Serial Number Cal/Char Date Due Date or Status Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/04 Multimeter Fluke FLUKE-77-3 79510405 CHAR 9/26/01 9/26/03 Peak Power Meter HP 8900C 2131A00545 CAL 7/2/03 7/2/05 Power Sensor Agilent Technologies 84811A 2551A02705 CAL 7/2/03 7/2/05 Power Meter HP 432A 1141A07655 CAL 4/15/03 4/15/05 Power Sensor HP 478A 72129 CAL 4/15/03 4/15/05 Power Meter And Sensor Bird 4421-107 & 4022 0166 & 0218 CAL 4/16/03 4/16/05 Digital Thermometer Fluke 2166A 42032 CAL 7/19/04 7/19/06 Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/04 Thermometer Extech 4028 14871-2 CAL 3/7/03 3/7/05 Hygro-Thermometer Extech 445703 0602 CAL 10/4/02 10/4/04 Frequency Counter HP 5352B 2632A00165 CAL 8/3/04 8/3/06 Frequency Counter HP 5385A 2730A03025 CAL 3/7/03 3/7/05 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 Out of Service Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 5/12/02 5/12/04 Signal Generator HP 8640B 2308A21464 CAL 8/26/04 8/26/06 Sweep Generator Wiltron 6648 101009 CAL 4/15/03 4/15/05 Sweep Generator Wiltron 6669M 007005 CAL 3/3/03 3/3/05 Modulati…
