RGE-COMIGOBOX1IP Set Top Box

©Comigo Ltd. 2012 All rights reserved Revision: 0.4 For more information contact: [email protected] Date: 11-Nov-2012 The information contained within this document is subject to change without notice. All trademarks and copyrights contained in this document are owned by their respective trademark and copyright holders. Datasheet Comigo’s comprehensive, feature rich, most advanced Smart TV platform considerably enhances the TV experience by uniquely extending viewing across all types of handheld devices, thereby opening up revolutionary personalization and interactive socialization capabilities. The Comigo Box version 1.b is an Android based platform designed to turn any TV into a Smart and Social TV. The smart Set-Top-Box (STB) can stream video and audio content from IPTV channels, OTT video distribution, VOD stores, external USB hard drives and content stored on a home network. The STB can be operated with a simple remote control or via a Smartphone or Tablet using iOS and Android applications. HARDWARE CPU: ARM Cortex A9 @ 800MHz DRAM: 512MByte DDR2 Embedded eMMC Flash: 8GByte Internal Flash: up to 32GByte using a full- size SD card (not user accessible) Front indicators: Power and Status LEDs Rear indicators: Network Link and Status LEDs for both wired and wireless connections SOFTWARE OS: Android 2.3.4 (Gingerbread) UI: Comigo Smart TV Platform DLNA Middleware: optional, based on specific requests CONNECTIVITY LAN: RJ-45 with 10/100Base-T connection WLAN: 802.11b/g/n with external antenna USB 2.0 Host: • 3 x User accessible external ports for external HDD, DiskOnKey/Thumb drives and other peripherals • 1 x Internal port for optional RC RF receiver Video output: HDMI 1.3 with CEC and HDCP support Audio output: Optical SPDIF AUDIO and VIDEO FORMATS Resolution: up to 1920x1080p Video: MPEG-1 MP/HL, MPEG-2 MP/HL, MPEG-4 Part 2 ASP, WMV/VC-1 SP/MP/AP, H.264 [email protected], RealVideo 8/9/10, M-JPEG and JPEG ©Comigo Ltd. 2012 All rights reserved Revision: 0.4 For more information contact: [email protected] Date: 11-Nov-2012 The information contained within this document is subject to change without notice. All trademarks and copyrights contained in this document are owned by their respective trademark and copyright holders. Video containers: MPEG, MPE, MPG, M2V, ISO, TS, VOB, DAT, AVI, MKV, MP4, MOV, 3GP, 3GPP, FLC, WMV, TS, FLV, RM Subtitles: SRT, SUB, IDX, PGS Audio CODECs: AAC, AC-3 (Dolby Digital 5.1), ADPCM, AMR-NB, MIDI, MP2, MP3, MSADPCM, PCM, RV40, Vorbis, WMA, AAC+ (HEAAC v1), eAAC+(HE-AAC v2) Supported file formats: mkv, wmv, mpg, mpeg, dat, avi, mov, iso, mp4, rm and jpg, mp3, 3gp, TS SECURITY and DRM Optional: based on customer specific requirements POWER External supply: 5V@2A (100-240V, 50/60Hz, wall wart with region appropriate plug) Power consumption: 5.5W (max) (without external HDD) REMOTE CONTROL Multiple options supported: • Simple Infrared (IR) with TV RC learning capability • Combo RF (2.4GHz) and IR RC with QWERTY keyboard, gyro-mouse and TV RC learning capability • Android and iOS applications for Smartphones and Tablets DIMENSIONS and WEIGHT LxWxH: 190x160x30 mm (with Wi-Fi antenna in folded position) Weight: • STB (w/o accessories): 330g • External power supply: 110g CERTIFICATIONS RoHS, CE, FCC, EN 55022, 55024 & 61000 (Region specific certifications available upon request) ©Comigo Ltd. 2012 All rights reserved Revision: 0.4 For more information contact: [email protected] Date: 11-Nov-2012 The information contained within this document is subject to change without notice. All trademarks and copyrights contained in this document are owned by their respective trademark and copyright holders. FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must be co‐located for operating in conjunction with any other antenna or transmitter.

DATE : Dec 12, 2012 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint _ Shenzhen Timeway Technology Consulting Co., Ltd. East 5/Block 4, Anhua Industrial Zone, No.8,Tairan Rd. CheGongMiao, FuTian District, Shenzhen City, Guangdong Province, China_, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Comigo Ltd. 15 HaPardes St., Yarkona 45915, Israel Dated this Dec 12, 2012 By: Motty Lentzitzky Signature Printed Title: Manager On behalf of : Comigo Ltd. Telephone: +972-9-771-5090

DATE : Dec 12, 2012 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: RGE-COMIGOBOX1 Product Name: IP Set Top Box Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Dec 12, 2012 By: Motty Lentzitzky Signature Printed Title: Manager On behalf of : Comigo Ltd. Telephone: +972-9-771-5090

Outside view Outside view

IP Set Top Box Model: Comigo Box 1.b FCC ID: RGE-COMIG OBOX 1 Rating: DC5.0V, 2A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Comigo Ltd.

FCC ID Label Location

Inside view Inside view Inside view

Maximum Permissible Exposure Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 , ︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 , ︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100000 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density MPE Calculation Method E (V/m) = (30*P*G) 0.5 /d Power Density: Pd (W/m 2 ) = E 2 /377 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = (30*P*G) / (377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Calculated Result and Limit Antenna Gain: 5.59dBi Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.622 13.08 20.324 0.0146 1 Compiles Note: the worse case was recorded.

ISO/IEC17025Accredited Lab. Report No: FCC TW1212070 File reference No: 2012-12-13 Applicant: Comigo Ltd. Product: IP Set Top Box Trademark: N/A Model No: Comigo Box 1.b Test Standards: FCC Part 15 Subpart C, Paragraph 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4FCC Part 15 Subpart C, Paragraph 15.247 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: Dec 13, 2012 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO., LTD 5/F,Block 4, Anhua Industrial Zone.,No.8 TaiRan Rd.CheGongMiao, FuTian District, Shenzhen, CHINA. Tel (755) 83448688 Fax (755) 83442996 Report No: 1212070 Page 2 of 102 Date: 2012-12-13 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAL. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAL-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAL/AC01:2002 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:1999 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC- Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-02. Report No: 1212070 Page 3 of 102 Date: 2012-12-13 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 5 1.5 Test Duration.................................................................................................... 5 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 9 3.1 Summary of Test Results..................................................................................... 9 3.2 Test Standards.................................................................................................. 9 4.0 EUT Modification............................................................................................. 9 5.0 Power Line Conducted Emission Test...................................................................... 10 5.1 Schematics of the Test........................................................................................ 10 5.2 Test Method and Test Procedure............................................................................ 10 5.3 Configuration of the EUT.................................................................................... 10 5.4 EUT Operating Condition....................................................................…

Text truncated - open the document above for the full version.

Conducted Emissions Radiated Emissions
