RID-BT-821GBluetooth Satellites Position Receiver

Bluetooth GPS+GLONASS (GNSS) Receiver BT-821G User Manual Ver 1.0 __________________________________________________________________________________________ Page 1 of 11 Table of Content 1. Product Information .......................................................................................... 3 1.1 Product Description ........................................................................................ 3 1.2 Product Features ............................................................................................ 3 1.3 Product Specifications .................................................................................... 4 2. Hardware Description ....................................................................................... 5 2.1 Top View and Bottom View ............................................................................ 5 2.2 LED Behaviors ............................................................................................... 6 2.3 Power Button .................................................................................................. 6 2.4 Power-saving function .................................................................................... 6 3. Package Contents ............................................................................................ 7 4. Getting Started ............................................................................................... 8 Step 1: Charging Battery .................................................................................... 8 Step 2: Turn on the power .................................................................................. 9 Step 3: Wait for GNSS fixed ............................................................................... 9 Step 4: Connect to your Bluetooth-enabled devices ........................................... 9 Step 5: Start Navigation Software ....................................................................... 9 5. Troubleshooting ............................................................................................. 10 Bluetooth is unable to connect ............................................................................ 13 GNSS cannot be positioned ................................................................................ 13 __________________________________________________________________________________________ Page 2 of 11 1. Product Information 1.1 Product Description BT-821G is a high performance Bluetooth GNSS receiver. It uses MTK high performance chipset that supports 99 search channels and 33 simultaneous tracking channels. BT-821G build-in a high-performance antenna and ensures excellent signal reception. BT-821G takes advantage of the Bluetooth technology to offer hassle free installation. It connects wirelessly to your Bluetooth enabled smart phone, laptop, tablet PC, or other devices. BT-821G uses a high capacity rechargeable lithium ion battery which can last for up to 24 hours of continuous operation. BT-821G is the best companion of your tablet PC, smart phone, or other portable devices for navigation purposes. 1.2 Product Features ˇ MTK high performance chipset ˇ Extreme fast TTFF at low signal level ˇ Bluetooth enabled ˇ High capacity rechargeable battery ˇ NMEA-0183 compliant protocol (GGA, GSA, GSV, RMC) RTCM ˇ GPS, GLONASS, SBAS (WAAS, EGNOS, GAGAN, and MSAS), QZSS supported ˇ Satellite positioning indication(Green LED) ˇ Battery status indication(Red/Amber LED) ˇ Bluetooth connecting indication(Blue LED) __________________________________________________________________________________________ Page 3 of 11 1.3 Product Specifications GNSS chipset Frequency GPS 1575.42 MHz & GLONASS 1608 MHz Chipset MTK high performance chipset Code C/A Code Protocol NMEA 0183 (Default: GGA, GSA, GSV, RMC) RTCM Available Baud Rate 38400 Channels 99 search channels and 33 simultaneous tracking channels Antenna Built-in Antenna Sensitivity Acquisition:-148dBm(cold)/-163dBm(hot) Tracking:-165dBm Cold Start < 35 seconds Warm Start < 35 seconds Hot Start < 1 second Reacquisition 0.1 second, average Accuracy Position:3m (2D RMS) / 2.0m with DGPS Velocity: < 0.1m/s Maximum Altitude ＜ 18,000 meter Maximum Velocity ＜ 515 meter/second Maximum Acceleration ＜ 4G Update Rate 1 Hz DGPS WAAS, EGNOS, MSAS, GAGAN Bluetooth Version 2.0 Range 10 Meter (Class 2) Support Profile SPP Profile Physical Characteristics Dimensions 43mm X 24.5mm X 73.6mm Weight 80 g (battery included) DC Characteristics Power Supply 5.0Vdc Battery Rechargeable Li-ion, 1100mAH 0r 1700mAH Battery Life Up to 24 Hours Environmental Range Humidity Range 5% to 95% non-condensing Operation Temperature -10°C to 60°C 0°C to 45°C while charging Storage Temperature -20°C to 70°C __________________________________________________________________________________________ Page 4 of 11 2. Hardware Description 2.1 Top View and Bottom View __________________________________________________________________________________________ Page 5 of 11 2.2 LED Behaviors Bluetooth LED (Blue) Status Description Blink once per three seconds Not linked Blink once per second Linked GNSS LED (Green) Status Description Blink once per second Position fixed Steady on Position not fixed Power LED (Red/Amber) Status Description Red light steady on Battery low Red light Off Battery good Amber light steady on(charging) Battery charging Amber light Off(charging) Battery charging finish 2.3 Power Button Action Function Press and hold the button for 1 second while off Power turned on Press and hold the button for 1 second while on Power turned off 2.4 Power-saving function When BT-821G doesn’t connect to charger and turning on, if the Bluetooth is not connected to any devices within 10 minutes, BT-821G will turn off the power automatically, and all the LED will go off simultaneously. __________________________________________________________________________________________ Page 6 of 11 3. Package Contents ˇ BT-821…
