GTR-128/GTR-129 Motorcycle/ Vehicle Tracker Quick Start Guide GlobalSat WorldCom Corporation 16F., No. 186, Jian 1 st Rd, Zhonghe Dist., New Taipei City 23553, Taiwan Tel: 886.2.8226.3799/ Fax: 886.2.8226.3899 [email protected] www.globalsat.com.tw USGlobalSat Incorporated 14740 Yorba Court Chino, CA 91710 Tel: 888.323.8720 / Fax: 909.597.8532 [email protected] www.usglobalsat.com 2 CONTENT 1. Introduction ........................................................................................................................ 3 1.1 Introduction ............................................................................................................... 3 1.2 Features ..................................................................................................................... 3 1.3 Hardware specification ............................................................................................ 4 1.4 Appearance ................................................................................................................ 5 1.5 LED indicator ............................................................................................................. 5 1.6 Cable description ...................................................................................................... 6 1.7 Accessories ................................................................................................................ 7 1.7.1 Standard Items ........................................................................................................... 7 1.7.2 Optional Items ............................................................................................................ 8 12V/24V Relay .................................................................................................................... 8 2 Operation .............................................................................................................................. 9 2.1 Install the SIM card ................................................................................................. 9 2.2 Connect the Main Power ........................................................................................ 11 2.3 Switch on/off Tracker ............................................................................................. 11 2.4 Fix the device .......................................................................................................... 12 3 Installation.......................................................................................................................... 14 3.1 Installing the Emergency button ......................................................................... 14 3.2 Connecting ignition detection line on car .......................................................... 15 3.3 Connecting Relay .................................................................................................... 16 3.4 Installation reminder ............................................................................................. 17 3 1. Introduction 1.1 Introduction GTR-128/GTR-129 is designed as a durable and multi-functional GPS/GSM/GPRS tracker. It integrates highly sensitive GPS module and quad-band GSM communication module with a powerful microcontroller that fits into a compact enclosure. The device is capable of being waterproof and ideal for use in a motorcycle, golf carts and vehicles. It is small in size and low in cost for covert and efficient tracking device. It provides real-time GPS positions anytime and anywhere with an open view to the sky, and offers precise positioning, and reports vehicle status to the server with necessary information shown on the map. Benefits such as enhanced fleet management, improved vehicle safety, emergency response, are all accomplished through the implementation of the GTR-128/GTR-129 system. The built-in GSM and GPS antennas are for easy installation without hassle. 1.2 Features
New generation GPS module.
Compact and Waterproof IP67 design
Built-in high sensitivity GPS/GSM antennas.
Quad-Band GSM System
Built-in motion sensor
AGPS support
Support communication protocols- SMS/TCP/UDP.
Multiple I/Os support: 1 Digital Input for custom function, 1 Digital input for optional Emergency button, 1 Analog Input for fuel sensor, 1 Digital Output for Relay, 1 Digital Input for ACC detection.
Configuration and Firmware update via Over-The-Air
Alert functions including Power low/ Over speed/ Movement alarms
Tracking by preferred interval, scheduling and Geo-fence
With magnet (GTR-128) or double side tape (GTR-129) for easy installation
Multiple power solution 4 1.3 Hardware specification Item Description Model GTR-128 GTR-129 Back-up Battery No back-up battery, but magnetic mount instead Li-Polymer 320mAh Unit Weight 77g 78.5g Temperature Operation -30°C ~ + 70°C -30°C ~ + 60°C (0°C ~ + 45°C for charging) Storage -40°C ~ + 70°C -40°C ~ + 60°C Dimension 61 mm X 38 mm X 19 mm GPS receiver high performance GPS chipset Communication Quad-Band GSM (850/900/1800/1900 MHz) GPS Antenna Built-in patch ceramics antenna GSM Antenna Built-in Pi-Fa antenna Protocol SMS/GPRS (TCP/UDP) Power +9~36 V Built-in Memory 32 Mb Emergency Input Negative trigger x 1 Ignition (ACC) Input Positive trigger x 1 Digital Input Port Negative trigger x 1 Digital Output Port Negative trigger x 1 (300 mA) Fuel sensor Input Port Analog Input x 1( 0~28V), 12 bits resolution Sensor Motion sensor Humidity 5% to 95% Non-Condensing 5 1.4 Appearance 1 LED 2 For fixing device with Velcro tape 3 Hook for screw/ unscrew back cover 1.5 LED indicator Normal mode: LED status Description Red blinking Device is being boot and SIM card not ready Red solid SIM card ready, but GSM not registered Yellow solid GSM registered, but GPRS not connected Green solid GSM registered, and GPRS connected Hiding mode: Device would blink red light while it is booting up. After completing the…
