RIDBT-332Bluetooth GPS Receiver

1 User Manual Bluetooth GPS Receiver BT-332 Ver 1.0 2 1. BT-332 at a glance 1.1 Appearance and Function 1. Power LED 2. GPS Status LED 3. Bluetooth Status LED 4. Power Button 5. Power Jack 1.2 How to change battery Figure 1, Open the cover of battery 3 Figure 2, Take out the battery with pull tag Figure 3, Put new battery into BT-332 4 Figure 4, Fit battery into BT-332 Figure 5, Slide the cover of battery to close Figure 6, Slide the cover of battery to close 5 1.3 Accessories BT-332 Car charge adapter 2. Introduction The BT-332 is a GPS receiver with Bluetooth interface and built-in active antenna for high sensitivity to tracking signal. Based on the SiRF star III Low power chip set and supports all functions (Single Sat updates in reduced visibility, Superior urban canyon performance, FoliageLock for weak signal tracking, etc.). The BT-332 is well suited to system integrations including PDA, Smart phone, Tablet PC and Notebook PC with Bluetooth devices. It satisfies a wide variety of applications that are purposes in automotive and outdoor recreation navigation systems. 2.1 Package Before you start up, make sure that your package includes following items. If any item is missing or damaged, please contact your dealer immediately. ‹ Bluetooth GPS Receiver ‹ A CD with the User Manual and the Testing Program. ‹ DC Car Power Charger 6 2.2 Power Switch Power on: Press the power button 1 second until the GPS status LED is on. Power off: Press the power button 1 second until the GPS status LED is off. 2.3 Power Jack The power jack lets you to connect either a DC car power charger (included) or AC power charger (included) to recharge the internal battery. Please note that the adapter rating 5V, 1.2 A, positive pole center. 2.4 LED Function Bluetooth Status LED (Blue): Blinking (Slowly) ---- Not connected to any Bluetooth device. Blinking (Quickly) ---- Connected to other Bluetooth device. GPS Status LED (Green): Blinking ---- GPS position is fixed Steady light ---- GPS position is not fixed Battery Status LED (Red/Yellow): Red ---- Battery power is critically low. Charge it immediately. Yellow ---- Battery is charging now. LED off ---- Battery is partially full or fully charged. 2.5 Power-saving Function When you start the power of the Bluetooth GPS Receiver BT-332, if the Bluetooth is not connected to any devices within 10 minutes, BT-332 will turn off the power automatically, and all the LED will go off simultaneously. 7 3. Specification 3.1 System Specification Electrical Characteristics (Receiver) Frequency L1, 1575.42 MHz C/A Code 1.023 MHz chip rate Channels 20 all-in-view tracking Tracking Sensitivity -159 dBm Accuracy Position Horizontal 10m 2D RMS (SA off) WAAS enabled 5m 2D RMS (SA off) Time 1 micro-second synchronized to GPS time Velocity 0.1m/sec 95% (SA off) Datum Datum WGS-84 Acquisition Rate Hot start 1 sec., average (with ephemeris and almanac valid) Warm start 38 sec., average (with almanac but not ephemeris) Cold start 42 sec., average (neither almanac nor ephemeris) Reacquisition 0.1 sec. average (interruption recovery time) Protocol GPS Output Data NMEA 0183 protocol, and supports command: GGA(1sec), GSA(1 sec), GSV(5 sec), RMC(1sec) ( VTG and GLL are optional) GPS transfer rate 38400,N,8,1 Dynamic Condition Acceleration Limit Less than 4g Altitude Limit 18,000 meters (60,000 feet) max. Velocity Limit 515 meters/sec. (1,000 knots) max. Jerk Limit 20 m/sec**3 Power Voltage Built-in rechargeable battery(1650 mAh) and 5V DC input charging circuit Operation Time 15 hr. After fully recharged, in continuous mode >20 hr in trickle power mode Physical Characteristics Dimension 72.5mm x 40.4mm x 26mm Weight 80 g Temperature Operating -20°~ 60°C Storage -30°~ 80°C Humidity Up to 95% non-condensing 8 3.2 Bluetooth Specification ● Bluetooth V2.0 Compliant ● Supply Voltage : 2.8V ~ 3.3V ● Frequency Range : 2.402 ~ 2.480 GHz ● Receiver Sensitivity : -80 dBm ● Transmit Power : Class 2 ● Transmitting Range : 10 m (Depends on environment) ● Power Consumption : 45 mA (Typical) 4. Usage 4.1. For PDA with built-in Bluetooth (1) Turn on the power switch in BT-332. (2) Please refer to the user manual of PDA to enable the Bluetooth of PDA connecting to the BT-332. Some PDAs may need the Bluetooth passkey, the passkey is “0000”. (3) Check the number of COM port used by Bluetooth. (4) Run the suitable mapping/navigation software and select the correct COM port & baud rate: 38400. 4.2. For PDA with Bluetooth Compact Flash card (1) Turn on the power switch in BT-332. (2) Please refer to the user manual of Bluetooth Compact Flash card to enable it connects to the BT-332. Some Bluetooth devices may need the Bluetooth passkey, the passkey is “0000”. (3) Check the number of COM port used by Bluetooth. (Example COM 6). (4) Running the suitable mapping/navigation software and select the correct COM port & baud rate: 38400. 4.3. For Notebook with Bluetooth device 9 (1) Turn on the power switch in BT-332. (2) Please refer to the user manual of Bluetooth device to enable it connects to the BT-332. Some Bluetooth devices may need the Bluetooth passkey, the passkey is “0000”. (3) Check the number of COM port used by Bluetooth. (Example COM 6). (4) Running the suitable mapping/navigation software and select the correct COM port & baud rate: 38400. Note: The Bluetooth device in most of the applications have an “auto-detect” feature that you do not need to select the Baud Rate. 5. How to test your Bluetooth GPS Receiver? The testing program only supports the Microsoft Windows CE & Pocket PC based PDA platform. 1. Run the “GPSinfo.exe” to execute the installation procedure of testing program (via PC and ActiveSync). 2. Run the “GPS Information” program from “Start → Program files” of PDA. Here is the description of “GPS Information” testing program : User must select COM port , Baud Rate (38400) and click the [Star GPS] button to start receiving GPS data. Note: The Bluetooth device in most of the applications have a…

Text truncated - open the document above for the full version.

GlobalSat Technology Corporation 2-1F,No.16,Chien 8 Road Far East Century Park,Chung Ho City FCC ID: RIDBT-332 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely GlobalSat Technology Corporation Luwalk Lee/ Hardware Engineer TEL: 886-2-8226-3799 ext: 216 FAX: 886-2-8226-3899 E-mail: [email protected]

GlobalSat Technology Corporation 2-1F,No.16,Chien 8 Road Far East Century Park,Chung Ho City Authorization Letter Date: 2006/03/13 To whom it may concern: We, the undersigned, DELL INC. hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by ADT within the scope of this authorization shall have the same effects as our own. This authorization shall expire six months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, GlobalSat Technology Corporation Luwalk Lee/ Hardware Engineer TEL: 886-2-8226-3799 ext: 216 FAX: 886-2-8226-3899 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID : RIDBT-332 Label Location

Page 3 Page 4 Page 5 Page 6 Page 7

FCC ID: RIDBT-332 Report No.: RF950224L17 Technical Description The transmitter of the EUT (Bluetooth GPS Receiver) is powered by 3.7Vdc from batteries or 12Vdc and 24Vdc from Car charger. The antenna is chip antenna without antenna connector. This device is a Frequency Hopping device with 79 hopping frequencies. The other instruction, please have a look at the users manual.

FCC ID: RIDBT-332 Report No: SA950224L17 1 RF EXPOSURE REPORT REPORT NO.: SA950224L17 MODEL NO.: BT-332 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: GlobalSat Technology Corporation ADDRESS: 2-1F,No.16,Chien 8 Road Far East Century Park,Chung Ho City,Taipei, Taiwan, R.O.C.. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: RIDBT-332 Report No: SA950224L17 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: RIDBT-332 Report No: SA950224L17 3 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: RIDBT-332 Report No: SA950224L17 4 5 Conclusion No Evaluation Required if power is below this threshold: F(GHz)mW Low2.402 High2.480 24.585 Maximum measured transmitter power: Pout (dBm)Pout (mW) Conducted Power4.532.838 EIRP Power6.534.498 *Note: The antenna is Omni-directional Chip antenna with 2dBi gain Threshold for no SAR evaluation is 24.585mW Transmitter power is 4.498mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold

Report No.: RF950224L171Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF950224L17 MODEL NO.: BT-332 RECEIVED: Feb. 24, 2006 TESTED: Mar. 20 ~ Mar. 22, 2006 ISSUED: Mar. 24, 2006 APPLICANT: GlobalSat Technology Corporation ADDRESS: 2-1F,No.16,Chien 8 Road Far East Century Park,Chung Ho City,Taipei, Taiwan, R.O.C.. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 74 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. NO. 2177-01 Report No.: RF950224L172Report Format Version 2.0.4 TABLE OF CONTENTS 1.CERTIFICATION.................... .................... .................... .................... ........4 2.SUMMARY OF TEST RESULTS.................... .................... .................... ........5 2.1MEASUREMENT UNCERTAINTY...............................................................................6 3.GENERAL INFORMATION.................... .................... .................... .................7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................7 3.2 DESCRIPTION OF TEST MODES ..............................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .........................................................9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................10 3.3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ...........................................12 3.3.4 DESCRIPTION OF SUPPORT UNITS ......................................................................12 4. TEST TYPES AND RESULTS.................... .................... ...............................13 4.1 CONDUCTED EMISSION MEASUREMENT ............................................................13 4.2 RADIATED EMISSION MEASUREMENT .................................................................13 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................................13 4.2.2 TEST INSTRUMENTS...............................................................................................14 4.2.3 TEST PROCEDURES ...............................................................................................15 4.2.4 DEVIATION FROM TEST STANDARD......................................................................15 4.2.5 TEST SETUP.............................................................................................................16 4.2.6 EUT OPERATING CONDITIONS ..............................................................................16 4.2.7 TEST RESULTS ........................................................................................................17 4.3 NUMBER OF HOPPING FREQUENCY USED .........................................................30 4.3.1 LIMIT OF HOPPING FREQUENCY USED................................................................30 4.3.2 TEST INSTRUMENTS...............................................................................................30 4.3.3 TEST PROCEDURES ...............................................................................................30 4.3.4 DEVIATION FROM TEST STANDARD......................................................................31 4.3.5 TEST SETUP.............................................................................................................31 4.3.6 TEST RESULTS ........................................................................................................31 4.4 DWELL TIME ON EACH CHANNEL .........................................................................34 4.4.1 LIMIT OF DWELL TIME USED ..................................................................................34 4.4.2 TEST INSTRUMENTS...............................................................................................34 4.4.3 TEST PROCEDURES ...............................................................................................34 4.4.4 DEVIATION FROM TEST STANDARD......................................................................34 4.4.5 TEST SETUP.............................................................................................................35 4.4.6 TEST RESULTS ........................................................................................................35 4.5 CHANNEL BANDWIDTH ...........................................................................................43 4.5.1 LIMITS OF CHANNEL BANDWIDTH ........................................................................43 4.5.2 TEST INSTRUMENTS...............................................................................................43 4.5.3 TEST PROCEDURE..................................................................................................43 Report No.: RF950224L173Report Format Version 2.0.4 4.5.4 DEVIATION FROM TEST STANDARD......................................................................44 4.5.5 TEST SETUP.............................................................................................................44 4.5.6 EUT OPERATING CONDITION.................................................................................44 4.5.7 TEST RESULTS ........................................................................................................44 4.6 HOPPING CHANNEL SEPARATION.........................................................................50 4.6.1 LIMIT OF HOPPING CHANNEL SEPARATION ........................................................…

Text truncated - open the document above for the full version.

Report No.: RF940224L1772Report Format Version 2.0.4 5. PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
