RIDBTH-818BLUETOOTH Headset

1 BTH-818 Bluetooth Earphone User Manual ver 1.04 1. BTH-818 feature and specification 1.1 Interpretation BTH-818 is a Bluetooth earphone that has call-in number display and support HandsFree Profile and HeadSet Profile. And this handbook is provided for Bluetooth cellular phone that has both HandsFree Profile and HeadSet Profile. 1.2 Features z The operating distance is over 10m. z The operating time is over seven hours. z The standby time is 300 hours. z Use rechargeable lithium battery and can detect low-level voltage of battery. z Convenient operation interface. z Can store ten different call-in numbers. z Can store ten different phone book recordings. z Five call-in ring options. z Mute-call function. z Setup/time display. z Able to make pairing memory to five Bluetooth devices. z Complete parts, easy to operate. 1.3 Specification Standard Bluetooth V1.1 Operation Range 10 meters (33 feet) Audio Codec 15 bits resolution, S/N > 60dB Frequency 2.4 GHZ-2.4835 GHZ ISM Band Dimension: (L)72mm*(W)26mm * (H)16mm Connection Point-to-point Weight 35g (including battery) Talk time 7hrs Standby time 300 hrs Output Power 0 Dbm (class II) Security 128 bits encryption Power Consumption 40mA working, 1mA standby Battery Rechargeable Li-ion polymer 300mAh Charging 5V DC, 100~240V AC adapter Charging time 2~3 hrs Operating Temperature -10~55°C Storage Temperature -20~60°C Certification CE, FCC, BQB LCD 1/16 duty cycle 5V. Headset passkey 0000 2 2. BTH-818 appearance and pushbutton descriptions: 2.1 Pushbutton descriptions Figure 1 Switch key Pickup and hang-up key Volume increasing key Volume decreasing key Earphone switch operating key, identical to key in operating function. 2.2 Outer connecting operation Insert the outer connecting earphone from headset input plughole. There is a key in the earphone line with operating function identical to key. Refer to Figure 2 and Figure 3. 3 Figure 2 Figure 3 Headset button 4 2.3 Load distribution method Figure 4 Figure 5 5 2.4 Symbols displayed Meanings of symbols represented Battery state Turn off external ring voice. Graphic display of calling and phone book. Graphic display of unanswered call. Turn on Bluetooth. Bluetooth is online. Graphic display of time 3. Operation method: 3.1 First time in use 3.1.1 The first time to recharge the BTH-818 When initially using this product, charge the battery 2-3 hours. User can charge this product over normal computer’s UBS interface or household recharger. Regarding the recharging method refers to Figure 6 and Figure 7. Battery symbol status: If symbol is flashing, it means this product is in charging state. means the battery is full in energy level. means battery level is weak. 6 Figure 6 Figure 7 3.1.2 Time setup Before using BTH-818 product, set up system time. The setting procedure is interpreted as below: Enter the menu Æ Set System Æ Time Æ press to select time column Æ press or to modulate time and key to confirm time selected. 3.2 Booting To boot up BTH-818 product, press for three seconds, and after hearing two beeps the booting procedure is accomplished. After that, it will display the cellular phone pattern number now has been under pair, such as the one displayed in Fig. 8 that is T610 cellular phone, which means the default cellular phone model is T610. And if there is no any cellular phone under pair connection yet, it then will display “No Device” string. 7 Figure 8 3.3 Power off To turn off BTH-818 product, press for three seconds, and after hearing two beeps the power is turned off. 3.4 Option menu operation: Option key operation 3.4.1 Enter the menu Press both and buttons concurrently to enter into the menu. 3.4.2 Menu operation Press button to move up. Press button to move down. Press button to make sure it. Press button to quit the option. 3.4.3 Menu configuration There are three main options: Set Ring, Device MGT and Set System; After entering into each of the options, use and button to select specific option. Press key and we can enter into one option among them; press to quit this option. Description: SetRing: option to set up calling ring. Device MGT: pairing management. Set System: set up system parameter. 8 3.5 Pairing management BTH-818 must incorporate with Bluetooth cellular phone in use. Before using it we must make pair to Bluetooth cellular phone. The operation regarding Bluetooth cellular phone refers to cellular user handbook. 3.5.1 Pairing Step1. Enter into pairing model Enter option menu Æ Device MGT Æ select Pairing-HF or Pairing-HS option Æ enter into pairing model and the “Paring...“ string shows up, indicated in Figure 9. Description: BTH-818 can support Headset and HandsFree profile Bluetooth. Most cellular phones provided in the market can support HandsFree Profile; only small portion of cellular phone products can support HeadSet profile. Before making pair, make sure what the cellular profile BTH-818 is supported. Figure 9 Step 2. Use Bluetooth cellular phone to look for the paired BTH-818 Bluetooth earphone; the paired PIN Code is “ 0000”. Regarding the details of operating Bluetooth cellular, please see the Bluetooth user handbook. Step 3. After the pairing process is complete, there will be one “beep” arisen and system has jumped out of the pairing model. 3.5.2 Set up default pairing device Enter option menu Æ Device MGT Æ Management Æ select the paired devicesÆDefaultÆpress to complete the setup. Description: BTH-818 will memorize the cellular after accomplishing the pairing process. It can at most memorize five different devices. While applying this function we can set up the default cellular phone to be connected. In anytime booting BTH-818 it will display the default device pattern name. Refer to Section 3.2. 3.5.3 Delete pairing device Enter option menu Æ Device MGT Æ Management Æ select the paired devices Æ Delete Æ press to complete the deleting process. 9 3.6 Use call list and phone book Call list is the call-in numbers stored in BTH-818, displayed in Fig 11. The…

Text truncated - open the document above for the full version.

Letter of authorization RF_500_03 Globalsat Technology Corporation 16F, No. 186, Jian Yi Road., Far East Century Park, Chung Ho City ,Taipei Hsien, Taiwan To: SGS Taiwan Ltd. 134, Wu Kung Rd. Wuku Industrial Zone Taipei County, Taiwan. Subject: letter of authorization Reference number: ###### Date: Jun. 16, 2005 We, Globalsat Technology Corporation 16F, No. 186, Jian Yi Road., Far East Century Park, Chung Ho City ,Taipei Hsien, Taiwan Tel: 886-2-8226-3799 Fax: 886-2-8226-3899 declare that: SGS Taiwan Ltd. is authorized to complete and sign all concerned documents needed for the application (BLUETOOTH Headset ) on our behalf. The approval and all originating responsibilities will remain with us. ___________________________ Mason Chao/ Hardware Engineer Globalsat Technology Corporation

Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 2 EXTERNAL PHOTOGRPHS OF EUT Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Front View of EUT Back View of EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: Globalsat Technology Corporation FCC ID: RIDBTH-818 FCC ID: RIDBTH-818 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 3 INTERNAL PHOTOGRPHS OF EUT Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Open View of EUT Internal of EUT – 1 Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal of EUT – 2 Internal of EUT – 3

Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 1 of 60 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Product Name: BLUETOOTH HEADSET Brand Name: N/A Model Name: BTH-818 FCC ID: RIDBTH-818 Report No.: EF/2005/40007 Issue Date: Jun. 20, 2005 FCC Rule Part: §15.247 Prepared for: Globalsat Technology Corporation 16F, No. 186, Jian Yi Road., Far East Century Park, Chung Ho City ,Taipei Hsien, Taiwan Prepared by: SGS Taiwan Ltd. No. 134, Wu Kun g Rd., Wuku Industrial Zone, Taipei County, Taiwan. Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 2 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA VERIFICATION OF COMPLIANCE Applicant: Globalsat Technology Corporation 16F, No. 186, Jian Yi Road., Far East Century Park, Chung Ho City ,Taipei Hsien, Taiwan Taiwan R.O.C Equipment Under Test: BLUETOOTH HEADSET Brand Name: N/A FCC ID Number: RIDBTH-818 Model No.: BTH-818 Model Difference: N/A File Number: EF/2005/40007 Date of test: Apr. 20, 2005 ~ May. 05, 2005 Date of EUT Received: Apr. 18, 2005 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. The test data, data evaluation, test proce- dures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247 The test results of this report relate only to the tested sample identified in this report. Test By: Date Jun. 20, 2005 Alex Hsieh Prepared By: Date Jun. 20, 2005 Eva Kao Approved By: Date Jun. 20, 2005 Vincent Su Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 3 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Version Version No. Date 00 Jun. 20, 2005 Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 4 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Table of Contents 1. GENERAL INFORMATION .........................................................................................................7 1.1. Product Description ............................................................................................................................7 1.2. Related Submittal(s) / Grant (s) ..........................................................................................................7 1.3. Test Methodology ...............................................................................................................................7 1.4. Test Facility.........................................................................................................................................7 1.5. Special Accessories .............................................................................................................................7 1.6. Equipment Modifications....................................................................................................................7 2. SYSTEM TEST CONFIGURATION ............................................................................................8 2.1. EUT Configuration .............................................................................................................................8 2.2. EUT Exercise ......................................................................................................................................8 2.3. Test Procedure.....................................................................................................................................8 2.4. Configuration of Tested System..........................................................................................................9 3. SUMMARY OF TEST RESULTS ...............................................................................................10 4. DESCRIPTION OF TEST MODES ............................................................................................10 5. CONDUCTED EMISSION TEST................................................................................................11 5.1. Standard Applicable ..........................................................................................................................11 5.2. EUT Setup.........................…

Text truncated - open the document above for the full version.

Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 61 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 1 PHOTOGRPHS OF SET UP Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 62 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Radiated Emission Set up Photo Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 63 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Conducted Emission Set up Photo (Adaptor) Conducted Emission Set up Photo (Adaptor) Report No EF/2005/40007 ID: RIDBTH-818 Issue Date: Jun. 20, 2005 Page: 64 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Conducted Emission Set up Photo (USB) Conducted Emission Set up Photo (USB)
