RIR400121PDA

AquaLink ® Wireless Handheld Remote For use with AquaLink PDA, RS and Z4 Systems ENGLISH H0511400_REVD INSTALLATION AND OPERATION MANUAL WARNING FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed, where such state or local requirements exist. In the event no such state or local requirement exists, the maintainer must be a professional with sufficient experience in pool equipment installation and maintenance, so that all of the instructions in this manual can be followed exactly. Before installing this product, read and follow all warning notices and instructions that accompany this product. Failure to follow warning notices and instructions may result in property damage, personal injury, or death. Improper installation and/or operation will void the warranty. Improper installation and/or operation can create unwanted electrical hazard which can cause serious injury, property damage, or death. Page 2 ENGLISH Wireless Handheld Remote | Installation and Operation Manual Page 3 ENGLISH Wireless Handheld Remote | Installation and Operation Manual TABLE OF CONTENTS Section 1. Important Safety Instructions ...................................4 Section 2. Product Description ...................................................7 2.1 Basic Functions ...........................................................................7 2.2 Remote and Transceiver J-box Dimensions ................................7 Section 3. Installation ..................................................................8 3.1 T ransceiver J-Box Connection to Power Center PCB .................8 3.2 Handheld Remote Installation .....................................................9 3.3 Changing the Frequency Channel ...............................................9 Section 4. Handheld Remote Operation..................................... 10 4.1 Menus and Functions ..................................................................11 4.1.1 Pool Mode/Spa Mode .........................................................11 4.1.2 Pool Heater/Spa Heater ......................................................11 ICON LEGEND: - Indicates a warning that if not followed could result in injury or death. - Indicates a caution that if not followed could result in property or equipment damage or failure. -Indicates a note that requires special attention for proper equipment operation. - Indicates optional equipment that may not be available or installed on every equipment configuration. Page 4 ENGLISH Wireless Handheld Remote | Installation and Operation Manual SECTION 1. IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: ATTENTION This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada license-exempt RSS Standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver . • Connect the equipment to an electrical source on a circuit dif ferent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Modifications made to this equipment, which are not authorized by the manufacturer, may void the user’s authority to operate this equipment. WARNING To reduce the risk of injury, do not remove the suction fittings of your spa or hot tub. Never operate a spa or hot tub if the suction fittings are broken or missing. Never replace a suction fitting with one rated less than the flow rate marked on the equipment assembly. WARNING Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above the normal body temperature of 98.6°F (37°C). The symptoms of hyperthermia include dizziness, fainting, drowsiness, lethargy, and an increase in the internal temperature of the body. The effects of hyperthermia include: 1) unawareness of impending danger; 2) failure to perceive heat; 3) failure to recognize the need to exit spa; 4) physical inability to exit spa; 5) fetal damage in pregnant women; 6) unconsciousness resulting in a danger of drowning. Page 5 ENGLISH Wireless Handheld Remote | Installation and Operation Manual WARNING Risk of electric shock, which could result in severe injury or death - Install the power center at least five (5) feet (1.52m) from the inside wall of the pool and/or hot tub using non-metallic plumbing. Can…

Text truncated - open the document above for the full version.

External Photos

inch inch MODEL NO.: 400121

Internal Photos

FCC ID: RIR400121 1 INTERTEK TESTING SERVICES Analysis Report The equipment under test (EUT) is a J-BOX operating at 915.95MHz – 927.00MHz. The EUT was powered by AC 120V, 60Hz. For more detail information pls. refer to the user manual. Modulation Type: FSK Antenna Type: Integral antenna Antenna Gain: 2dBi The nominal conducted output power specified: 7dBm (Tolerance: +/- 2dB) According to the KDB 447498: Th e maximum conducted output power for the EUT is 7.76dBm in the frequency 915.95MHz which is within the production variation. The minimum conducted output power for the EUT is 7.82dBm in the frequency 927.00MHz which is within the production variation. The maximun conducted output power specified is 9dBm = 7.94mW The source- based time-averaging conducted output power = 7.94 * Duty cycle mW< 9.94 (Duty Cycle < 100%) T he SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (0.927) mW = 15.6 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing.

AV Factor

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. TRF no.: FCC 15C_Tx_b Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Website: www.china.intertek-etlsemko.com Zodiac Pool Systems, Inc Application For Certification FCC ID: RIR400121 J-BOX Model: 400121 Report No.: 150616009SZN-002 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [ 10-1-14] Prepared and Checked by: Approved by: Sign on file Jenner Liu Engineer Andy Yan Senior Project Engineer Date: November 30, 2015 INTERTEK TESTING SERVICE TRF no.: FCC 15C_TX_b FCC ID: RIR400121 Report No.: 150616009SZN-002 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: Summary of Tests EXHIBIT 2: General Description EXHIBIT 3: System Test Configuration EXHIBIT 4: Measurement Results EXHIBIT 5: Equipment Photographs EXHIBIT 6: Product Labeling EXHIBIT 7: Technical Specifications EXHIBIT 8: Instruction Manual EXHIBIT 9: Confidentiality Request EXHIBIT 10: Miscellaneous Information EXHIBIT 11: Test Equipment List INTERTEK TESTING SERVICES TRF no.: FCC 15C_TX_b FCC ID: RIR400121 Report No.: 150616009SZN-002 ii MEASUREMENT/TECHNICAL REPORT J-BOX Model: 400121 FCC ID: RIR400121 This report concerns (check one) Original Grant X Class II Change Equipment Type: DTS - Digital Transmission System Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-01-14] Edition] provision. Report prepared by: Jenner Liu Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, Block D, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Phone: (86 755) 8614 0639 Fax: (86 755) 8614 6751 INTERTEK TESTING SERVICES TRF no.: FCC 15C_TX_b FCC ID: RIR400121 Report No.: 150616009SZN-002 iii Table of Contents 1.0 Summary of Test results ............................................................................................................................. 2 2.0 General Description ...................................................................................................................................... 4 2.1 Product Description ..................................................................................................................................... 4 2.2 Related Submittal(s) Grants ....................................................................................................................... 5 2.3 Test Methodology ........................................................................................................................................ 5 2.4 Test Facility .................................................................................................................................................. 5 3.0 System Test Configuration ......................................................................................................................... 7 3.1 Justification .................................................................................................................................................. 7 3.2 EUT Exercising Software ........................................................................................................................... 7 3.3 Special Accessories .................................................................................................................................... 7 3.4 Measurement Uncertainty .......................................................................................................................... 8 3.5 Equipment Modification .............................................................................................................................. 8 3.6 Support Equipment List and Description ................................................................................................. 8 4.0 Measurement Results ................................................................................................................................ 10 4.1 Maximum Conducted Output Power at Antenna Terminals ...................................................................... 10 4.2 Minimum 6 dB RF Bandwidth .................................................................................................................. 11 4.3 Maximum Power Density Reading ...............................................................…

Text truncated - open the document above for the full version.

Radiated Emission (Up to 1GHz) Radiated Emission (Above 1GHz)

Conducted Emission
