Installation and Operation Manual Manuel d’installation et d’utilisation Manual de instalación y operación AquaLink ® Wireless Handheld Remote For use with AquaLink PDA, RS and Z4 Systems WARNING FOR YOUR SAFETY – This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions in this manual can be followed exactly. Before installing this product, read and follow all warning notices and instructions that accompany this product. Failure to follow warning notices and instructions may result in property damage, personal injury, or death. Improper installation and/or operation may void the warranty. Improper installation and/or operation can create unwanted electrical hazard which may cause serious injury, property damage, or death. ATTENTION INSTALLER – This manual contains important information about the installation, operation and safe use of this product. This information should be given to the owner/operator of this equipment. Page 2 ENGLISHJandy ® AquaLink ® Wireless Handheld Remote | Installation & Operation Manual Table of Contents Section 1. Important Safety Instructions ......................................4 Section 2. Product Overview .........................................................6 2.1 Compatibility ...............................................................................6 2.2 Basic Functions ...........................................................................7 2.3 Remote and Transceiver J-Box Dimensions ...............................8 Section 3. Installation .....................................................................8 3.1 Transceiver J-Box Connection to Power Center PCB ................9 3.2 Handheld Remote Installation ...................................................10 3.3 Changing the Frequency Channel .............................................11 Section 4. Handheld Remote Operation .....................................13 4.1 Menus and Functions ................................................................14 4.2 Pool Mode/Spa Mode ...............................................................14 4.3 Pool Heater/Spa Heater ............................................................14 Page 3 Jandy ® AquaLink ® Wireless Handheld Remote | Installation & Operation Manual ENGLISH This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ISED Canada Regulatory Statement This device contains license/exempt transmitter(s)/receiver(s) that comply with Innovation, Sceince and Economic development Canada's license-exempt RSS(s). Operation is subject to the following two conditions: (1)this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. • •Consult the dealer or an experienced radio/TV technician for help. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. SAVE THESE INSTRUCTIONS FCC Statement Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Page 4 ENGLISHJandy ® AquaLink ® Wireless Handheld Remote | Installation & Operation Manual Section 1. Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: WARNING To reduce the risk of injury, do not remove the suction fittings of your spa or hot tub. Never operate a spa or hot tub if the suction fittings are broken or missing. Never replace a suction fitting with one rated less than the flow rate marked on the equipment assembly. Risk of electric shock, which could result in severe injury or death - Install the power center at least five (5) feet (1.52 m) from the inside wall of the pool and/or hot tub using non-metallic plumbing. Canadian, Australian, and European installations must be at least three (3) meters from the water. •Children should not use spas or hot tubs without adult supervision. •Do not use spas or hot tubs unless all suction guards are installed to prevent body and hair entrapment. •People using medications and/or having an adverse medical history should consult a physician before using a spa or hot tub. A terminal bar marked “GROUND” is provided within the power center. To reduce the risk of electrical shock, connect this terminal bar to the grounding terminal of your electr…

Text truncated - open the document above for the full version.

Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules To whom it may concern, This letter is to certify that Zodiac Pool Systems LLC (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated below. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Zodiac Pool Systems LLC Contact Name : Philip Escobedo Address : 2882 Whiptail Loop # 100, Carlsbad, CA 92010, USA Telephone No : 760-599-9600 Email : [email protected] FCC ID Applicant FRN : 0022286959 Signature: ________ Date: _______February 27, 2023_________ : RIRB0324300

Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: Zodiac Pool Systems LLC FCC ID: To whom it may concern, Zodiac Pool Systems LLC (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ Philip Escobedo Regulatory Compliance Manager Zodiac Pool Systems LLC February 27 th , 2023 RIRB0324300

February 27th, 2023 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Zodiac Pool Systems LLC FCC ID: RIRB0324300 and RIRB0324100 To Whom It May Concern: We, Zodiac Pool Systems LLC, hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number RIRB0324300 and RIRB0324100 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is . The Limited Agency Agreement expires on (never), unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Philip Escobedo Regulatory Compliance Manager February 27 , 202 3

Attention: Certification reviewer RE: Request for Confidentiality FCC ID: RIRB0324300 To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] Schematics Block Diagrams Operational Description Tune‐up Procedure Parts List Internal Photos (see note) Users Manual (see note) Note 1: Internal Photos may be held confidential 1) if the circuit board or internal components are not accessible to users. For example, it is acceptable if the circuit board is enclosed in epoxy. 2) Also, it is acceptable if the device is not accessible to the public, for example, a device mounted on the top of a large tower (or in a fenced enclosure) such that it is only serviceable by professional designated technicians under a Non-Disclosure Agreement (NDA). All sales for these devices must be under a NDA restricting the disclosure of the propriety information, including internal photos. Users Manual may be held confidential only when the manual contains proprietary technical information intended for professional technicians obligated under a NDA. All sales and distribution of the user’s manual must be under a NDA that restricts the disclosure of the information. In the application cover letter requesting permanent confidentiality the following additional description and the NDA exhibit is required: 1. Describe in detail how internal photos and/or users manual information are controlled to prevent them from becoming public or disclosed to unauthorized persons. 2. Describe how public access is restricted for products serviceable by professional designated technicians. 3. A statement that all sales of the non-consumer device will be under a NDA to include third party sales and that the final user of the device is subject to the NDA. 4. Provide an example of the NDA between the grantee and a purchaser. The request for confidentiality must Note 2: For scanning receiver, the schematics, block diagrams, operational description, tune‐up procedure, parts list and internal photos are always held permanently confidential. Short‐term Confidentiality [Complete this section if short‐term confidentiality is requested] Request to withhold from public review for a period of [please enter 1 to 180] days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept short‐term confidential for a period above from the date of the grant [Select one or more of items below that are not selected in the list above, as appropriate ] Schematics Block diagrams Operational Description Tune‐up Procedure Parts List Test Setup Photos External Photos Internal Photos Users Manual Rationale for request for confidentiality: We have invested considerable time and materials in research and development to produce the referenced product. Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Short‐term confidentiality: Disclosure of the short‐term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. If you have questions or need further information, please contact the undersigned. Sincerely, ________________ Philip Escobedo Regulatory Compliance Manager December 6 th , 2022

3.55” 2.8” 6.8” PDA Label Size HVIN Label –0.75” x 0.25” FCC ID:RIRB0324300 IC:10837A-B0324300

915.95MHz-927MHz ANT RF Chip

INTERTEK TESTING SERVICES RF Exposure The Equipment Under Test (EUT) is a PDA operating at 915.95MHz – 927.00MHz. The EUT was powered by DC 3.0V (UM-3 / R6 / AA 1.5V*2). For more detailed features description, please refer to the user’s manual. Antenna Type: Integral antenna Modulation Type: FSK Antenna Gain: 0.17dBi The nominal conducted output power specified: 7.0 dBm (±2dB) The nominal radiated output power (e.i.r.p) specified: 7.17dBm (±2dB) According to the KDB 447498: The maximum conducted output power for the EUT is 7.96dBm in the frequency 921.80MHz which is within the production variation. The minimum conducted output power for the EUT is 7.90dBm in the frequency 915.95MHz which is within the production variation. The maximum conducted output power specified is 9dBm= 7.943mW The SAR Exclusion Threshold Level: 푃 th (mW) = ERP 20cm * (푑/20cm) 푥 (X= ) = 1891.08 * (0.5/20) 1.48 mW = 7.99 mW Since max. conducted output power and effective radiated power (ERP) is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: RIRB0324300

Zodiac Pool Systems LLC TEST REPORT SCOPE OF WORK FCC TESTING–400120 REPORT NUMBER 221021001SZN-001 ISSUE DATE [REVISED DATE] 10 April 2023 [---------------------] PAGES 33 DOCUMENT CONTROL NUMBER FCC ID 247_b © 2017 INTERTEK Intertek Report No.: 221021001SZN-001 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, Shenzhen, P.R. China. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 33 FCC ID 247_b TEST REPORT 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, Shenzhen, P.R. China. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 www.intertek.com Zodiac Pool Systems LLC Application For Certification FCC ID: RIRB0324300 PDA Model: 400120 902 MHz - 928MHz Transceiver Report No.: 221021001SZN-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-21] Prepared and Checked by: Approved by: Allen Qin Ryan Chen Engineer Project Engineer Date: 10 April 2023 Intertek Report No.: 221021001SZN-001 Version: 01-November-2017 Page: 2 of 33 FCC ID 247_b TEST REPORT MEASUREMENT/TECHNICAL REPORT This report concerns (check one) Original Grant X Class II Change Equipment Type: DTS - Part 15 Digital Transmission Systems (Wi-Fi transmitter portion) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-01-21] Edition] provision. Report prepared by: Allen Qin Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, Shenzhen, P.R. China. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6661 Intertek Report No.: 221021001SZN-001 Version: 01-November-2017 Page: 3 of 33 FCC ID 247_b TEST REPORT Table of Contents 1.0 Summary of Test Results ............................................................................................... 4 2.0 General Description ...................................................................................................... 5 2.1 Product Description ........................................................................................................... 5 2.2 Related Submittal(s) Grants ............................................................................................... 5 2.3 Test Methodology .............................................................................................................. 5 2.4 Test Facility ........................................................................................................................ 5 3.0 System Test Configuration ............................................................................................ 6 3.1 Justification ........................................................................................................................ 6 3.2 EUT Exercising Software ..................................................................................................... 6 3.3 Special Accessories ............................................................................................................ 6 3.4 Measurement Uncertainty ................................................................................................. 7 3.5 Equipment Modification .................................................................................................... 7 3.6 Support Equipment List and Description .......................................................................... 7 4.0 Measurement Results ................................................................................................... 8 4.1 Maximum Conducted Output Power at Antenna Terminals ................................................. 8 4.2 Minimum 6 dB RF Bandwidth ............................................................................................ 9 4.3 Maximum Power Density Reading ................................................................................... 12 4.4 Out of Band Conducted Emissions ................................................................................... 15 4.5 Out of Band Radiated Emissions ...................................................................................... 21 4.6 Transmitter Radiated Emissions in Restricted Bands ........................................................ 22 4.7 Field Strength Calculation ................................................................................................ 23 4.8 Radiated Spurious Emission ............................................................................................. 24 4.9 Radiated Emissions from Digital Section…

Text truncated - open the document above for the full version.

Unit11， 12/F, BLK B Veristrong ind. Ctr, 34-36 Au Pui Wan Street, Fo Tan Shatin, N.T. HK Tel: 852 2345 0215 Fax: 852 27978191 Email: [email protected] No.: AN03445 CUSTOMER’S NAME : 客户名称 CUSTOMER’S MODEL NO . : 客户型号 CUSTOMER’S PART NO. : 客户料号 PRODUCT NAME : 产品名称 OUR MODEL NO. : 本公司型號 NO. 1 2 3 4 Please fax back this brefile page with authorized signature and company chop as customer’s approval on samples,Thanks! (如果此产品得到您的确认,请传回本页给我们.) 客户签名 Customer Si gnCustomer 1 Product Drawing (产品图) Specification of Product (规格书内容) Capability Test Report (性能测试报告) Company Chop 客户公章 Bondale Electronics Ltd. 1 This Specification is Composed of Under Listed (Samples be attached) 本规格书由以下内容组成(样品另附)： Website: www.bondale.com 金 进 Items(项目)Pages(页码) G-RA0025179005-SZ478 Certificate Of Conformance ROHS(环保证明书) 博 钜 电 子 有 限 公 司 COVER OF SPECIFICATION 规 格 书 共 7 页 1 3 Total pages(包含本页) Rubber Antenna E02520 Unit11， 12/F, BLK B Veristrong ind. Ctr, 34-36 Au Pui Wan Street, Fo Tan Shatin, N.T. HK Tel: 852 2345 0215 Fax: 852 27978191 Email: [email protected] TO: DATE: File NO.: AN03445 Customer Part No. : Bondale Part No. : Description : Rubber Antenna G-RA0025179005-SZ478 is fully comply with the EU directive 2011/65/EU, (EU)2015/863 and packaging directive 94/62/EC and that its content of hazardous substances is below the values as listed: ROHS critical values: *Cadmium(Cd)under 100 ppm Generallyunder 1,000 ppm Products that contain Copper alloy components under 40,000 ppm Product that contain Steel alloy components under 3,500 ppm Product that contain aluminum alloy components under 4,000 ppm *Mercury (Hg)under 1,000 ppm *Hexavalent Chormium (Cr6+)under 1,000 ppm *PBBsunder 1,000 ppm *PBDEsunder 1,000 ppm *DEHPunder 1,000 ppm *BBPunder 1,000 ppm *DBPunder 1,000 ppm *DIBPunder 1,000 ppm Packaging directive 94/62/EC critical values: *Packaging (Pb + Cd +Hg +Cr6+ ) under 100 ppm Expemted below: If the above mentioned item is reprocessed by customer, we wouldn’t promise and assure the content of hazardous substances of the product item. On behalf of Bondale Electronics Ltd. ROHS green chop and GPMS spokesman sign(Rohs綠色印章+ GPMS負責人簽名): Yours sincerely, ---GREEN PRODUCT MANAGEMENT SYSTEM (GPMS)--- ---綠色產品管理系統--- *Lead (Pb) Website: www.bondale.com Bondale Electronics Ltd. 博 钜 电 子 有 限 公 司 Be Exempted 2023-03-10 金 进 CERTIFICATE OF CONFORMANCE ROHS We, Bondale Electronics ltd. assured that the above mentioned item: G-RA0025179005-SZ478 E02520 潘卫青 PROJECTION ( 視角 ) 未注尺寸偏差 線性尺寸L 未注明公差 版次 14/03-23 陆 东 (棕色) 該段浸錫 透明PVC膠管 注 : 1. 工作頻率為:915±15MHz. 2.同軸線線芯外露部分套一截透明 PVC膠管以保護芯线,長度為15.0 +5.0 -0.0 mm 3. 為重點管控尺寸. 4. 為做FAI尺寸. 5.客户PARTNO:E02520 该铜管要在与同轴线焊锡后按照图纸所示角度折弯 焊锡 根据实际情况把透明PVC胶管的长度由48.0 +5.0-0.0 改为15.0 +5.0-0.0 MM. 曹新学 用客户机壳重新调试频率,芯线长度由 改为 . 陸 東 应客户要求,将频率由915±10MHz改为915±15MHz. 陸 東 Customer : 金 进 Specification No.: AN03445 Model No.: G-RA0025179005-SZ478 1, Application The antenna specified in this specification is applicable for the radio-communication 2, Dimensions As per Drawing No. G-RA0025179005-SZ478attached. 3, Materials As specified in drawing No. G-RA0025179005-SZ478 4, Electrical Characteristics i) Resonate Frequency : 915±15 MHz ii) Impedance : 50 ohm Nominal iii) Radiation Pattern : Omni Directional iv) Polarization : Vertical v) Standing Wave Ratio (S.W.R): 2.0 or less vi) Insulation resistance : 500 M ohm at DC 500V 5, Others: Any modification of this specification has to be agreed by us Prepared By:Checked By:Approval: RUBBER ANTENNA SPECIFICATION Specification NO.: AN03445 Model NO.: G-RA0025179005-SZ478 Capability Test Report 增益测试 增益测试数据 900MHz -0.7444.52% 905MHz -0.2150.13% 910MHz 0.0952.26% 915MHz 0.2251.99% 920MHz 0.1750.81% 925MHz -0.0248.42% 930MHz -0.2845.44% 频率 增益(dBi)效率 增益测试
