RIZEH1117Electronic Ballast

ID Label Label FCC ID: RIZEH1117

ID Label/Location Label Location Information Specifications: Text is Black or white in color and is left justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Refer to the below arrow. FEB-1-13-120-EH-S-A FEB-2-13-120-EH-S-A FEB-1-26-120-EH-S-A

Internal Photos EUT of FEB-1-13-120-EH-S-A - Uncovered View EUT of FEB-1-13-120-EH-S-A - PCB View (1) EUT of FEB-1-13-120-EH-S-A - PCB View (2) EUT of FEB-2-13-120-EH-S-A - Uncovered View EUT of FEB-2-13-120-EH-S-A - PCB View (1) EUT of FEB-2-13-120-EH-S-A - PCB View (2) EUT of FEB-1-26-120-EH-S-A - Uncovered View EUT of FEB-1-26-120-EH-S-A - PCB View (1) EUT of FEB-1-26-120-EH-S-A - PCB View (2)

Note: This test report is specially limited to the use of the above client company and the product model only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 18 REPORT For ALKI Electronics Technology Corporation 7F, No 48, Lane 10, Ji-Hu Road, Nei-Hu Dist, Taipei, Taiwan, R. O. C FCC ID: RIZEH1117 December 2, 2003 This Report Concerns: Original Report Equipment Type: Electronic Ballast Test Engineer: Jandy Su Report Number RSZ03111704 Test Date: November 27, 2003 Reviewed By: Hans Mellberg Prepared By: Bay Area Compliance Lab Corp. ShenZhen Suite C, 41-D Electronics Science & Technology Building, No. 2070 Shennanzhong Rd ShenZhen, Guandong 518031, P.R. China Tel: (755) 83296449 Fax: (755) 83273756 ALKI Electronics Technology Corporation FCC ID: RIZEH1117 Report # rsz03111704.doc Page 2 of 12 FCC Part 18 Report TABLE OF CONTENTS 1 - GENERAL INFORMATION..................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..............................................................................3 1.2 OBJECTIVE.............................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S).......................................................................................................................3 1.4 TEST METHODOLOGY............................................................................................................................................3 1.5 TEST FACILITY.......................................................................................................................................................3 1.6 TEST EQUIPMENT LIST AND DETAILS.....................................................................................................................4 1.7 EXTERNAL I/O CABLING........................................................................................................................................4 2 - SYSTEM TEST CONFIGURATION.....................................................................................................................5 2.1 JUSTIFICATION.......................................................................................................................................................5 2.2 SCHEMATICS / BLOCK DIAGRAM...........................................................................................................................5 2.3 EQUIPMENT MODIFICATIONS.................................................................................................................................5 2.4 CONFIGURATION OF TEST SYSTEM.........................................................................................................................5 2.5 TEST SETUP BLOCK DIAGRAM...............................................................................................................................6 3 - CONDUCTED EMISSIONS TEST DATA............................................................................................................7 3.1 MEASUREMENT UNCERTAINTY..............................................................................................................................7 3.2 EUT SETUP............................................................................................................................................................7 3.3 SPECTRUM ANALYZER SETUP................................................................................................................................7 3.4 TEST PROCEDURE..................................................................................................................................................7 3.5 CONDUCTED EMISSIONS TEST DATA......................................................................................................................8 3.6 TEST RESULT.........................................................................................................................................................9 3.7 PLOT(S) OF CONDUCTED EMISSIONS TEST DATA...................................................................................................9 ALKI Electronics Technology Corporation FCC ID: RIZEH1117 Report # rsz03111704.doc Page 3 of 12 FCC Part 18 Report 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The ALKI Electronics Technology Corporation’s model FEB-1-13-120-EH-S-A /FEB-2-13-120-EH-S-A/ FEB-1-26-120-EH-S-A or the “EUT” as referred to in this report is Electronic Ballast. They measure approximately 10.0cm L x 5.5cm W x 3.0cm H, rated input voltage: AC 120 V/60Hz. The test data gathered are from the EUT described above, serial numbers 110141, 110148, 110156. These EUT were provided by the manufacture samples. 1.2 Objective The following test report is prepared on behalf of ALKI Electronics Technology Corporation in accordance with Part 2, Subpart J, and Part 18, Subparts A, B, and C of the Federal Communication Commissions rules and regulations. The objective is to determine compliance with FCC rules. 1.3 Related Submittal(s)/Grant(s) No Related Submittals. 1.4 Test Methodology All measurements contained in this report were conducted with MP-5, FCC Methods of Measurements of Radio Noise Emissions from ISM Equipment, February 1986. American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 Meters. 1.5 Test Facility…

Text truncated - open the document above for the full version.

Test Setup Photos Conducted Emission of FEB-1-13-120-EH-S-A – Front View Conducted Emission of FEB-1-13-120-EH-S-A – Side View Conducted Emission of FEB-2-13-120-EH-S-A – Front View Conducted Emission of FEB-2-13-120-EH-S-A – Side View Conducted Emission of FEB-1-26-120-EH-S-A – Front View Conducted Emission of FEB-1-26-120-EH-S-A – Side View
