DWC-102 User Manual Wireless Door/Window Contact PCB Layout Tamper switch Zone setup Installation & Notice Open the case and remove the batter y activation strip. Mount the sensor on the door frame and the magnet on the door. Make sure the magnet is on the right side of the transmitter Place the transmitter in the desired location, mount the magnet no more than 1cm away from the transmitter and secure the transmitter and magnet with double-sided tapes or screws. Avoid mounting sensors in areas with a large quantity of metal or electrical wiring, such as a furnace or utility room. The DWC-102 is a Door/Window Contact that can be installed on doors, windows, and any other objects that open and close. The sensor transmits signals to the control panel when a magnet mounted near the sensor is moved away. It will also transmit alert signal to the control panel in case of low batter y. External input for wired accessor y is available at the N/C interface. The tamper protection ensures that sabotage attempts to move the contact will result in an alarm activation. Introduction Product Overview TransmitterMagnet LED indicator Specifications -10°C~+55°C 71 x 34 x 17.5mm 51 x 12 x 13.5mm DC 1.5V (AA 1.5V LR6 Batter y x 1 pc) 315MHz (±75KHz) ≤ 35uA ≤ 10mA Power supply Static current Alarm current Transmitting distance Radio frequency Housing material ABS plastic Operating temperature Transmitter dimensions (LxWxH) Magnet dimensions (LxWxH) Relative humidity ≤80% (non-condensing) ≤80m (in open area) AA 1.5V LR6 LED Indication LED flashes once: Door/window is opened and transmitter sends signal to the control panel. Flash once per 3 seconds: Low power indication, please change batter y as soon as possible. (User will get aler t SMS about the low batter y if the door contact is connected to the GSM alarm system.) Ver : DWC-102-EN-1405-V5.0 2014 Chuango. All rights reser ved. NOTE: Tamper will be triggered no matter the door/window contact is armed or disarmed. FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment..
