RLS-STAVL1212GPS Vehicle Tracking Device

CAREU UCAN User Guide Version: 1.0 Reference No.: AVL-CU-UC-00-1210UEN Date: June 1, 2012 SYSTEMS & TECHNOLOGY CORP. General Information If any breakdown occurs due to the operation of the described product or users’ improper handling in accordance with the instructions of the document, S&T shall be liable for the General Conditions based on the delivery of the described product and the content of the document. This product is not designed for the use of life support appliances, devices or systems and thence a malfunction of the product might reasonably be expected to make personal injury. S&T customers using or selling this product for such applications will take the risk on their own; therefore, it must be agreed S&T will be fully indemnified from any damages due to illegal use or resale. All information in this document is subject to change without notice at any time. Disclaimer The information, specification, images and photos in this user guide are subject to change without notice and without obligation to notify any person of such revision change. Copyright This user guide, including all photographs, illustrations and software, to name a few, is protected under international copyright laws, with all rights reserved. This document contains confidential, restricted and proprietary information that it has been exclusively prepared for the internal use of certain designated S&T employees, and may not be duplicated or distributed, in whole or in part, without the prior written consent of S&T’s authorized delegates. Any illegal copying and disclosure of the document are absolutely prohibited, and violators are liable to the damages caused. © Systems & Technology Corp. All Rights Reserved Table of Contents Chapter 1 Introduction ................................................................................................... 1 1.1 Features....... ........................................................................................................ 1 1.2 Scope ................................................................................................................... 1 1.3 About CAREU UCAN ........................................................................................... 1 1.4 Hardware Architecture ......................................................................................... 2 1.5 Related Document ............................................................................................... 2 Chapter 2 Taking a Tour of CAREU UCAN ................................................................... 3 2.1 Dimensions .......................................................................................................... 3 2.2 PIN Assignment.................................................................................................... 3 Chapter 3 Getting Started with CAREU UCAN............................................................. 5 3.1 Hardware Installation ........................................................................................... 5 3.2 USB Device Driver Installation ............................................................................. 6 3.3 Device Configuration.......................................................................................... 12 3.4 Communication Settings .................................................................................... 16 3.5 GPS Tracking Configurations............................................................................. 17 3.6 Firmware Upgrade ............................................................................................. 18 Chapter 4 Technical Specification .............................................................................. 19 Chapter 5 Regulation.................. .............................................................................. 22 CAREU UCAN - User Guide Chapter 1 1 Chapter 1 Introduction 1.1 Features Thank you for purchasing CAREU UCAN GPS Vehicle Tracker, a plug-and-use device for tracking and vehicle status diagnostics. ● SMS, GPRS TCP/UDP, USSD, FTP communications ● Plug-and-use design and cost effectiveness ● DTC OBD II error codes ● GSM/GPRS simultaneously ● Real-time tracking (Time, Distance Interval or Intelligent Mode, and Heading) ● Firmware upgrade over the air (via GPRS from FTP) ● Journey report wireless download ● Battery low alert ● Geofence reports ● Mileage reports ● User-defined reports ● Up to 100,000 data logs 1.2 Scope This document will guides you to start the CAREU UCAN Vehicle Tracker. However, as this document contains basic device configuration only, please see the CAREU UCAN Protocol Document for the advanced information. 1.3 About CAREU UCAN Designed with the latest GPS technology, the CAREU UCAN delivers positioning message by GSM wireless transmission to GIS platform, and then helps back-end users proceed with the analysis and the applications of vehicle transport, management, anti-theft, security and tracking. A microcontroller can probe location and command data at regular intervals, derive actions from location, peripheral and control data, and execute such actions. Peripheral data indicates the status of various peripherals connected to and/or controlled by the device. Among the best features of the CAREU UCAN Vehicle Tracker, in particular, they transmit data in ASCII mode (Intellitrac X Series compatible mode) or binary mode. CAREU UCAN - User Guide 2 Chapter 1 The firmware in the device applies intelligent filtering to overcome coverage limitations for both GPS and GSM/GPRS networks. Motion sensor controls the status of the device, whether in sleep, idle or fully-powered mode, and thereby controls the amount of current consumed by the device. The device supports over-the-air firmware upgrade to deliver additional functionality without physically touching the device once installed. 1.4 Hardware Architecture As hardware is concerned, the CAREU UCAN is comprised of a micro-controller, regulator, …

Text truncated - open the document above for the full version.

17-7F, No.79, Hsin Tai Wu Road, Sec.1, Hsichih Rev. 1/1/03 Date: August 8, 2012 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: RLS-STAVL1212 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Parts List Tune up Procedure Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Name: Jesse Hsieh Company: SYSTEMS & TECHNOLOGY CORP. Tel: +886-2-26981599 ﹟316 Fax:+886-2-26981211 E-mail: [email protected]

17-7F, No.79, Hsin Tai Wu Road, Sec.1, Hsichih August 8, 2012 Power of Attorney AUTHORIZATION LETTER AUTHORIZATION LETTERAUTHORIZATION LETTER AUTHORIZATION LETTER To whom it may concern: We, the undersigned SYSTEMS & TECHNOLOGY CORP. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, Name: Jesse Hsieh Company: SYSTEMS & TECHNOLOGY CORP. Tel: +886-2-26981599 ﹟316 Fax:+886-2-26981211 E-mail: [email protected]

17-7F, No.79, Hsin Tai Wu Road, Sec.1, Hsichih Date: August 8, 2012 Federal Communications Commission Authorization and Evaluation Division 7345 Oakland Mills Road Columbia MD 21046 SUBJECT: FCC Application for FCC ID: RLS-STAVL1212 To Whom It May Concern: We, SYSTEMS & TECHNOLOGY CORP., hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely yours, Jesse Hsieh SYSTEMS & TECHNOLOGY CORP. Fax: +886-2-26981211 Tel: +886-2-26981599 ﹟316 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID: RLS-STAVL1212

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

Report No.: SA120223C11 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA120223C11 MODEL NO.: UCAN FCC ID: RLS-STAVL1212 RECEIVED: Feb. 23, 2012 TESTED: Jun. 18, 2012 ISSUED: Jul. 04, 2012 APPLICANT: SYSTEMS & TECHNOLOGY CORP. ADDRESS: 18-5F, No.79, Hsin Tai Wu Road, Sec. 1, Hsichih District, New Taipei City, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA120223C11 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................... 3 1. CERTIFICATION ........................................................................................................... 4 2. RF EXPOSURE ............................................................................................................. 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................................ 5 2.2 MPE CALCULATION FORMULA ................................................................................... 5 2.3 CLASSIFICATION ......................................................................................................... 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ................................. 6 Report No.: SA120223C11 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120223C11 Original release Jul. 04, 2012 Report No.: SA120223C11 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: GPS Vehicle Tracking Device MODEL: UCAN BRAND: CAREU APPLICANT: SYSTEMS & TECHNOLOGY CORP. TESTED: Jun. 18, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: UCAN) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Jul. 04, 2012 Ivonne Wu / Senior Specialist APPROVED BY : , DATE: Jul. 04, 2012 Gary Chang / Technical Manager Report No.: SA120223C11 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120223C11 6 of 6 Report Format Version 5.0.0 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER MODE MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) GSM850 32.610 0.5 20 0.407 0.55 GSM1900 29.560 0.3 20 0.193 1

Report No.: RF120223C11 1 of 29 Report Format Version 5.0.0 FCC TEST REPORT (PART 22) REPORT NO.: RF120223C11 MODEL NO.: UCAN FCC ID: RLS-STAVL1212 RECEIVED: Feb. 23, 2012 TESTED: Jun. 18, 2012 ISSUED: Jul. 04, 2012 APPLICANT: SYSTEMS & TECHNOLOGY CORP. ADDRESS: 18-5F, No.79, Hsin Tai Wu Road, Sec. 1, Hsichih District, New Taipei City, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120223C11 2 of 29 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 3 1 CERTIFICATION ........................................................................................................ 4 2 SUMMARY OF TEST RESULTS ................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY .............................................................................. 5 2.2 TEST SITE AND INSTRUMENTS ............................................................................... 6 3 GENERAL INFORMATION ......................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ........................................................................... 7 3.2 CONFIGURATION OF SYSTEM UNDER TEST ......................................................... 8 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................................ 8 3.4 TEST ITEM AND TEST CONFIGURATION ................................................................ 9 3.5 EUT OPERATING CONDITIONS .............................................................................. 10 3.6 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................... 10 4 TEST TYPES AND RESULTS................................................................................... 11 4.1 OUTPUT POWER MEASUREMENT ........................................................................ 11 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT ...................................................... 11 4.1.2 TEST PROCEDURES .............................................................................................. 11 4.1.3 TEST SETUP ........................................................................................................... 12 4.1.4 TEST RESULTS ....................................................................................................... 13 4.2 FREQUENCY STABILITY MEASUREMENT ............................................................ 14 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT ......................................... 14 4.2.2 TEST PROCEDURE ................................................................................................. 14 4.2.3 TEST SETUP ........................................................................................................... 14 4.2.4 TEST RESULTS ....................................................................................................... 15 4.3 OCCUPIED BANDWIDTH MEASUREMENT ............................................................ 16 4.3.1 TEST PROCEDURES .............................................................................................. 16 4.3.2 TEST SETUP ........................................................................................................... 16 4.3.3 TEST RESULTS ....................................................................................................... 17 4.4 BAND EDGE MEASUREMENT ................................................................................ 18 4.4.1 LIMITS OF BAND EDGE MEASUREMENT .............................................................. 18 4.4.2 TEST SETUP ........................................................................................................... 18 4.4.3 TEST PROCEDURES .............................................................................................. 18 4.4.4 TEST RESULTS ....................................................................................................... 19 4.5 CONDUCTED SPURIOUS EMISSIONS ................................................................... 20 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT .................... 20 4.5.2 TEST PROCEDURE ..............................................…

Text truncated - open the document above for the full version.

Report No.: RF120223C11-1 1 of 28 Report Format Version 5.0.0 FCC TEST REPORT (PART 24) REPORT NO.: RF120223C11-1 MODEL NO.: UCAN FCC ID: RLS-STAVL1212 RECEIVED: Feb. 23, 2012 TESTED: Jun. 18, 2012 ISSUED: Jul. 04, 2012 APPLICANT: SYSTEMS & TECHNOLOGY CORP. ADDRESS: 18-5F, No.79, Hsin Tai Wu Road, Sec. 1, Hsichih District, New Taipei City, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120223C11-1 2 of 28 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 3 1 CERTIFICATION ........................................................................................................ 4 2 SUMMARY OF TEST RESULTS ................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY .............................................................................. 5 2.2 TEST SITE AND INSTRUMENTS ............................................................................... 6 3 GENERAL INFORMATION ......................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ........................................................................... 7 3.2 CONFIGURATION OF SYSTEM UNDER TEST ......................................................... 8 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................................ 8 3.4 TEST ITEM AND TEST CONFIGURATION ................................................................ 9 3.5 EUT OPERATING CONDITIONS .............................................................................. 10 3.6 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................... 10 4 TEST TYPES AND RESULTS................................................................................... 11 4.1 OUTPUT POWER MEASUREMENT ........................................................................ 11 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT ...................................................... 11 4.1.2 TEST PROCEDURES .............................................................................................. 11 4.1.3 TEST SETUP ........................................................................................................... 12 4.1.4 TEST RESULTS ....................................................................................................... 13 4.2 FREQUENCY STABILITY MEASUREMENT ............................................................ 14 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT ......................................... 14 4.2.2 TEST PROCEDURE ................................................................................................. 14 4.2.3 TEST SETUP ........................................................................................................... 14 4.2.4 TEST RESULTS ....................................................................................................... 15 4.3 OCCUPIED BANDWIDTH MEASUREMENT ............................................................ 16 4.3.1 TEST PROCEDURES .............................................................................................. 16 4.3.2 TEST SETUP ........................................................................................................... 16 4.3.3 TEST RESULTS ....................................................................................................... 17 4.4 BAND EDGE MEASUREMENT ................................................................................ 18 4.4.1 LIMITS OF BAND EDGE MEASUREMENT .............................................................. 18 4.4.2 TEST SETUP ........................................................................................................... 18 4.4.3 TEST PROCEDURES .............................................................................................. 18 4.4.4 TEST RESULTS ....................................................................................................... 19 4.5 CONDUCTED SPURIOUS EMISSIONS ................................................................... 20 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT .................... 20 4.5.2 TEST PROCEDURE ........................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION (PART 22) RADIATED EMISSION TEST 2 ERP POWER TEST 3 (PART 24) RADIATED EMISSION TEST 4 EIRP POWER TEST
