RLS-STAVL1450GPS Vehicle Tracking Device

CAREU U1 PLUS User Gu CAREU U1 PLUS User Guide Version: 0.1 Reference No.: AVL Date: 2014/12/26 SYSTEMS & TECHNOLOGY COR General Information If any breakdown occurs due to the operation of the described product or users’ improper handling in accordance with the instructions of the document, S&T shall be liable for the General Conditions based on the delivery of the described product and the content of the document. This product is not designed for the use of life support appliances, devices or systems and thence a malfunction of the product might reasonably be expected to make personal injury. S&T customers using or selling this product for such applications will take the risk on their own; therefore, it must be agreed S&T will be fully indemnified from any damages due to illegal use or resale. All information in this document is subject to change without notice at any time. Disclaimer The information, specification, images and photos in this user guide are subject to change without notice and without obligation to notify any person of such revision change. Copyright This user guide, including all photographs, illustrations and software, to name a few, is protected under international copyright laws, with all rights reserved. This document contains confidential, restricted and proprietary information that it has been exclusively prepared for the internal use of certain designated S&T employees, and may not be duplicated or distributed, in whole or in part, without the prior written consent of S&T’s authorized delegates. Any illegal copying and disclosure of the document are absolutely prohibited, and violators are liable to the damages caused. © Systems & Technology Corp. All Rights Reserved Table of Contents Chapter 1 introduction. ..................................................................................... 1 1.1Features........................................................................................................ 1 1.2 Scope ........................................................................................................... 1 1.3 Overview ..................................................................................................... 1 1.4 Hardware Architecture ................................................................................ 3 1.5 Related Document ....................................................................................... 3 Chapter 2 Taking a Tour of CAREU U1 PLUS ................................................... 4 2.1 Dimensions .................................................................................................. 4 2.2 PIN Assignment ............................................................................................ 4 Chapter 3 Getting Started with CAREU U1 PLUS ............................................ 6 3.1 Device Configuration.................................................................................... 6 3.2 Communication Settings .............................................................................. 9 3.3 GPS Tracking Configurations ...................................................................... 10 3.4 Firmware Upgrade ..................................................................................... 12 Chapter 4 Technical Specification ................................................................ 13 Chapter 5 Regulation ................................................................................... 16 Chapter 6 Safety Information....................................................................... 17 1 Chapter 1 introduction. Designed with the latest GPS technology, the CAREU U1 PLUS delivers positioning message by wireless transmission to GIS platform, and then helps back-end users proceed with the analysis and the applications of vehicle transport, management, anti-theft, security and tracking. A microcontroller can probe location and command data at regular intervals, derive actions from location, peripheral and control data, and execute such actions. Peripheral data indicates the status of various peripherals connected to and/or controlled by the device. Among the best features of the CAREU U1 PLUS Vehicle Tracker, in particular, they transmit data in ASCII mode (Intellitrac X Series compatible mode) or binary mode. 1.1 Features ● SMS,GPRS/UMTS/HSPA TCP/UDP, USSD, FTP ● Real-time tracking (Time, Distance Interval or Intelligent Mode, and Heading) ● Firmware upgrade over the air ( form FTP) ● Journey report wireless download ● Battery low alert ● Geofence reports ● Mileage reports ● User-defined reports ● 6-Axis Sensor ● NMEA-0183 Output for Navigation ● GPS Antenna Destroyed Alarm ● CAN BUS interface (optional) ● 10/100 Ethernet (optional) 1.2 Scope This document will guides you to start the CAREU U1 PLUS Vehicle Tracker. However,as this document contains basic device configuration only, please see the CAREU U1 PLUS Protocol Document for the advanced information. 1.3 Overview Device Overview 2 1. GPS LED 2. GSM LED 3. Power Connector 4. RS-485/CAN Connector 5. I/O Connector 6. Serial Connector 7. GSM Antenna Connector 8. GPS Antenna Connector 9. Reset Switch 10. RJ45 Connector 11. Remote Receiver Connector 3 1.4 Hardware Architecture As hardware is concerned, the CAREU U1 PLUS is comprised of a micro-controller, regulator, GPS receiver, 2G/3G modem, G-Force sensor, flash memory data storage. ● Users can connect PC's Hyper Terminal to the diagnostic setting port for the AVL configuration. ● G-Sensor is for car accident prevention, car tow-away warning and power management. FLASH I/O SENSOR MCU GPS RS232 Powe Modem 1.5 Related Document CAREU U1 PLUS Protocol Document 4 Chapter 2 Taking a Tour of CAREU U1 PLUS 2.1 Dimensions Dimensions (L x W x H): 72mm x 108mm x 31mm 2.2 PIN Assignment 1 24 3 24 31 6 59 8 7 10 13 12 11 16 15 14 SERIAL PORTI/OPOWER 4 31 6 5 28 7 10 921 20 19 18 17 RS-485 / CAN 24 23 22 PWR Connector Pin# Signal Name Description IO Electrical Cha…
