RMYAP1000FP06UHF TV AMPLIFIER

NicomUsa, Inc 2626 Southport Way suite “B” National City, CA 91950 Tel. (619) 477-6298 Fax. (619) 477-6296 To: TIMCO ENGINEERING From: Dario Piagentini Re: Confidentiality Request Date: 6/14/07 RE: Confidentiality Request regarding application for certification of FCC ID: RMYAP1000FP06 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics 2453AUT5 Schematics.pdf Block Diagram 2453AUT5 Block Diagram.pdf Circuit Description 2453AUT5 Circuit Description.pdf Tuning Procedure 2453AUT5 Tuning Procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Thank you Dario Piagentini Vice-President NicomUsa, Inc

NICOM USA, INC. FCC ID: RMYAP1000FP06 EXTERNAL PHOTOS

Rear panel 1 2 3 4 5 6 9 8 7 DESCRIPTION 1Breaker 2Power supply socket 3Auxiliary socket 4 Fuse: Drive 5A Control 1A Fan 3.15A 5RS485 Socket 6Exciter socket 7Telemeasuring socket 8RF Input connector 9RF Output connector FCC Label Location

NICOM USA INC. FCC ID: RMYAP1000FP06 INTERNAL PHOTOS – AMPLIFIER

FCC PART 73 AND IC BETS-4 TEST REPORT APPLICANT Nicom USA Inc. 2626 Southport Way Suite B National City, CA 91950 FCC ID RMYAP1000FP06 IC CERTIFICATION 4788A-AP1000 MODEL NUMBER AP1000 PRODUCT DESCRIPTION UHF TV TRANSMITTER AMPLIFIER DATE SAMPLE RECEIVED March 23, 2006 DATE TESTED March 31, 2006 TESTED BY Mario R. de Aranzeta C.E.T. APPROVED BY Mario R. de Aranzeta TIMCO REPORT NO. 2435AUT5 TestReport.doc TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM APPLICANT: NiCom USA Inc. FCC ID: RMYAP1000FP06 IC CERT #: 4788A-AP1000 REPORT: W:\N\Nicom\2453aut5\EXTRA\2435AUT5 TestReport.doc Page 4 of 20 TABLE OF CONTENTS GENERAL INFORMATION......................................................... 3 EMC EQUIPMENT LIST.......................................................... 4 TEST PROCEDURE.............................................................. 5 VIDEO FREQUENCY RESPONSE.................................................... 6 VIDEO CHANNEL ATTENUATION CHARACTERISTICS................................... 7 DIFFERENTIAL PULSE AND GAIN................................................. 8 ENVELOPE DELAY.............................................................. 9 MEASUREMENT PROCEDURE AND TEST SETUP....................................... 10 AUDIO CHANNEL OCCUPIED BW.................................................. 11 AUDIO DISTORTION........................................................... 12 MEASUREMENT PROCEDURE AND TEST SETUP....................................... 13 AUDIO FREQUENCY RESPONSE................................................... 14 AUDIO CHANNEL RESIDUAL AM NOISE............................................ 15 AUDIO CHANNEL RESIDUAL FM NOISE (S/N)...................................... 16 FREQUENCY STABILITY........................................................ 17 SPURIOUS EMISSIONS AT THE ANTENNA TERMINALS................................ 18 FIELD_STRENGTH_OF_SPURIOUS_EMISSIONS....................................... 19 TEST SETUP................................................................. 20 APPLICANT: NiCom USA Inc. FCC ID: RMYAP1000FP06 IC CERT #: 4788A-AP1000 REPORT: W:\N\Nicom\2453aut5\EXTRA\2435AUT5 TestReport.doc Page 3 of 20 GENERAL INFORMATION EUT SPECIFICATION The test results relate only to the items tested. FCC ID RMYAP1000FP06 Model Number AP1000 IC Cert # 4788A-AP1000 Product Description 1000W Amplifier NTSC Video and audio transmitter Operating Frequency 480 MHz (UHF channel 15) Max. output power 1000W conducted Type of Modulation 6M25C3F (NTSC format) Primary Power 220 Vac/60Hz EUT Power Secondary Power 110 Vac/ 60 Hz Prototype Pre-Production Test Item Production Fixed Mobile Type of Equipment Portable Antenna NONE Antenna Connector DIN Modifications to DUT None Test Exercise Continuous transmit mode of operation Test Standards ANSI C63.4-2003 APPLICANT: NiCom USA Inc. FCC ID: RMYAP1000FP06 IC CERT #: 4788A-AP1000 REPORT: W:\N\Nicom\2453aut5\EXTRA\2435AUT5 TestReport.doc Page 4 of 20 EMC EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A Listed 3/20/07 3/19/10 3-Meter OATS TEI N/A N/A Listed 1/11/06 1/10/09 Biconnical Antenna Eaton 94455-1 1057 CAL 12/12/05 12/12/07 Biconnical Antenna Eaton 94455-1 1096 CAL 10/11/06 10/11/08 Biconnical Antenna Electro- Metrics BIA-25 1171 CAL 4/29/05 4/29/07 Tan Tower Quasi-Peak Adapter HP 85650A 330A01690 CAL 12/8/05 12/8/07 Tan Tower RF Preselector HP 85685A 3221A01400 CAL 12/7/05 12/7/07 Tan Tower Spectrum Analyzer HP 8566B OPT462 31388A07786 3144A20661 CAL 12/7/05 12/7/07 Tan Tower Pre- Amplifier HP 8449B-H02 3008A00372 CAL 12/8/05 12/8/07 LISN Electro- Metrics ANS-25/2 2604 CAL 10/5/06 10/5/08 LISN Electro- Metrics EM-7820 2682 CAL 4/28/05 4/28/07 Log-Periodic Antenna Eaton 96005 1243 CAL 12/14/05 12/14/07 APPLICANT: NiCom USA Inc. FCC ID: RMYAP1000FP06 IC CERT #: 4788A-AP1000 REPORT: W:\N\Nicom\2453aut5\EXTRA\2435AUT5 TestReport.doc Page 5 of 20 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. POWER LINE CONDUCTED INTERFERENCE: The procedure used was ANSI STANDARD C63.4- 2003 using a 50uH LISN. Both lines were observed with the UUT transmitting. The bandwidth of the spectrum analyzer was 10 kHz with an appropriate sweep speed. The ambient temperature of the UUT was 76°F with a humidity of 55%. BANDWIDTH 6 dB: The measurements were made with the spectrum analyzer's resolution bandwidth (RBW) = 1 MHz and the video bandwidth (VBW) = 3 MHz and the span set as shown on plot. POWER OUTPUT: The RF power output was measured at the antenna feed point using a peak power meter. ANTENNA CONDUCTED EMISSIONS: The RBW = 100 kHz, VBW = 300 kHz and the span set to 10.0 MHz and the spectrum was scanned from 30 MHz to the 10 th Harmonic of the fundamental. Above 1 GHz the resolution bandwidth was 1 MHz and the VBW = 3 MHz and the span to 50 MHz. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 using an Agilent spectrum receiver with pre-selector. The bandwidth (RBW) of the spectrum receiver was 100 kHz up to 1 GHz and 1 MHz above 1 GHz with an appropriate sweep speed. The VBW above 1 GHz was 3 MHz. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The ambient temperature of the UUT was 76°F with a humidity of 55%. APPLICANT: NiCom USA Inc. FCC ID: RMYAP1000FP06 IC CERT #: 4788A-AP1000 REPORT: W:\N\Nicom\2453aut5\EXTRA\2435AUT5 TestReport.doc Page 6 of 20 VIDEO FREQUENCY RESPONSE RULES PART NO.: 73.687 and BETS-4 TEST PROCEDURE: A sine wave was varied through the video range. The data recorded is relative to the 200 kHz sideband amplitude. TEST DATA: Frequency MHz Sidebands MHz Relative Output (dBc) 472.50 -4.75 <-60…
