FCC ID: RNX20002A Technical Description : The brief circuit description is listed as follows : - Q1 and associated circuit act as RF Amplifier. - IC1, Y1, Y2 and associated circuit act as Superheterodyne FM Receiver (49.860 MHz). - Q4 and associated circuit act as Wave Shaping and Amplifier Circuit. - IC2 and associated circuit act as Decoder. - Q2 and associated circuit act as Motor Driver for Main Motor. - IC3 and associated circuit act as Motor Driver for Tail Motor. - Q3, R21, R22 and associated circuit act as Low Voltage Detect ion Circuit. - DW1 and associated circuit act as Voltage Regulator. Antenna Used : A permanent wire antenna has been used.

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited • The evaluation data of the report will be kept for 3 years from the date of issuance. FCC ID : RNX20002A Jasman Asia Limited Application For Certification (FCC ID: RNX20002A) Superheterodyne Receiver Sample Description : Flight Factory Spin Blade RC Indoor Helicopter Model : 20002 Asst. #: 20000 0517784 BC/at August 30, 2005 INTERTEK TESTING SERVICES FCC ID: RNX20002A i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: RNX20002A ii MEASUREMENT/TECHNICAL REPORT Jasman Asia Limited - MODEL: 20002 FCC ID: RNX20002A August 30, 2005 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Superheterodyne Receiver (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart B for intentional radiator Report prepared by: Billy Chow Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG Phone: 852-2173-8502 Fax: 852-2742-9149 INTERTEK TESTING SERVICES FCC ID: RNX20002A iii Table of Contents 1.0 General Description................................................................................................. 2 1.1 Product Description............................................................................................... 2 1.2 Related Submittal(s) Grants .................................................................................. 2 1.3 Test Methodology................................................................................................. 3 1.4 Test Facility .......................................................................................................... 3 2.0 System Test Configuration ...................................................................................... 5 2.1 Justification ........................................................................................................... 5 2.2 EUT Exercising Software ...................................................................................... 5 2.3 Support Equipment List and Description................................................................ 5 2.4 Equipment Modification......................................................................................... 6 2.5 Special Accessories.............................................................................................. 6 3.0 Emission Results ..................................................................................................... 8 3.1 Field Strength Calculation ..................................................................................... 9 3.2 Radiated Emission Configuration Photograph ..................................................... 10 3.3 Radiated Emission Data...................................................................................... 11 4.0 Equipment Photographs ........................................................................................ 14 5.0 Product Labelling................................................................................................... 16 6.0 Technical Specifications........................................................................................ 18 7.0 Instruction Manual ................................................................................................. 20 8.0 Miscellaneous Information.................................................................................... 22 8.1 Emissions Test Procedures................................................................................. 23 8.1 Emissions Test Procedures (cont'd) .................................................................... 24 INTERTEK TESTING SERVICES FCC ID: RNX20002A iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf INTERTEK TESTING SERVICES FCC ID: RNX20002A 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: RNX20002A 2 1.0 General Description 1.1 Product Description The equipment under test (EUT) is a receiver for a RC Indoor Helicopter operating at 49.860 MHz which controlled by a crystal. The EUT is powered by a 3.7V rechargeable Li-Ion battery. The EUT has an ON/OFF switch and a connector for charging the internal battery when connects to the corresponding battery charger. After switched on the EUT, it can be controlled to lift up, lift down, turning clockwise and turning anti-clockwise directions by the controller. The brief circuit description is saved with filename: descri.pdf 1.2 Related Submittal(s) Grants This is a single application for certification of a receiver. The transmitter for this receiver is authorized by Certification procedure with FCC ID: RNX20002. INTERTEK TESTING SERVICES FCC ID: RNX20002A 3 1.3 Test Methodology The radiated emission measurements were performed according …
