ROU000038 inch PAD

Model: 800P11B 800P11B (MTK8377) CONTENTS Special Features .........................................................1 Important Safety Attentions .......................................2 Accessories List .........................................................6 Buttons and Ports .......................................................7 Installation Instruction ...............................................9 Micro SD Card Installation and Uninstallation .............9 SIM/USIM Card Installation and Uninstallation ..........11 Connecting the Tablet to PC .....................................12 QuickStart .................................................................13 Battery Charging ......................................................13 Power-on .................................................................13 Unlocking .................................................................13 Locking ....................................................................13 Power-off .................................................................14 Volume Adjustment ..................................................14 Touch Screen Operation ...........................................14 Introduction to the Home Screen of PAD....................15 Basic Operation Method ...........................................16 System Time and Date Setting .................................17 Input Method Selection ............................................18 Application ................................................................18 Browser ...................................................................18 Video Player ............................................................22 Music Player ............................................................24 Image Player ...........................................................25 File manager ............................................................26 Call functions ...........................................................28 Messaging................................................................30 Camera ....................................................................30 E-mail ......................................................................32 800P11B (MTK8377) System Settings ........................................................33 Set the Wi-Fi Network...............................................33 Set Bluetooth ...........................................................35 Set the Mobile Traffic Warning ..................................37 Set the Virtual Private Network (VPN) .......................38 Set the Portable Hotspot ..........................................38 Connect and Set the Mobile Network ........................39 Audio profiles ...........................................................39 Display .....................................................................40 Storage ....................................................................40 Battery .....................................................................40 Apps ........................................................................40 Location access .......................................................41 Security ....................................................................41 Language & input .....................................................42 Backup & reset .........................................................42 ACCOUNTS .............................................................42 Date & time ..............................................................43 Scheduled power on & off .........................................43 Accessibility .............................................................43 Developer options ....................................................43 About tablet ..............................................................43 Troubleshooting ........................................................44 Important Statements ...............................................45 Technical Specifications ...........................................47 800P11B (MTK8377) Special Features 1. Includes a LED backlit screen with a high resolution ratio. 2. Includes a capacitive touch screen with high sensitivity, supporting multi-touch. 3. Employs ARM Cortex A9 core, with CPU dominant frequency at 1.0GHz, 4. Employs the Google Android4.1 system. 5. A built-in Wi-Fi module supports the 802.11 b/g/n wireless standard. 6. Built-in bluetooth module. 7. Built-in 0.3 Mega Pixel front camera and 2 Mega Pixel rear camera, which can have the functions of video chatting, photographing and shooting. 8. Support WCDMA, GSM, GPRS, EDGE; HSPA Internet calls. 9. Includes a built-in speaker with high quality. 10. Supports output of high-fidelity stereo headphone; 11. A built-in 3-axis gravity sensor supports the screen to auto rotate in 4 directions; 12. Integrate A/V hard decoder, allow playing mainstream A/V formats on the market. 13. A built-in lithium battery with high capacity. 1 800P11B (MTK8377) Important Safety Attentions Thank you for purchasing our high performance and multi-function tablet PC. It will bring you a better visual and aural experience. To make sure safety, extend the service life of the product, and give full play to the best performance of the product, please read all the instructions and nameplates carefully, follow the safety attentions, and keep the user manual for future use. Medical Device Electromagnetic wave produced by the device in working condition may interfere with the normal work of implantable medical devices or personal medical devices like pacemaker, embedding cochlea, hearing-aid, etc. If you are using the above mentioned medical devices, please consult with the manufacturer for the conditions or limitations of using the product. Hearing Protection Use careful with the earphone maybe possible excessive sound pressure from earphones and headphones can cause hearing loss. Please plug the ea…

Text truncated - open the document above for the full version.

Updated on 2005/02/07 by Kally Chan DECLARATION OF IDENTITY Hereby we: SHENZHEN KTC TECHNOLOGY CO.,LTD Northern Wuhe Road,Gangtou,Buji,Longgang,Shenzhen,China (Name of Manufacturer) Basic Model Number: 800P11B Basic Brand Name: / Basic Product Name: 8’’ PAD Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): 800P***(800: express screen size is 8 inches;"P":express Pad; * can be any alphanumeric represent different customer code or the sales area, not affect the product performance ) New / Additional Brand Name(s): / Except the following(s) : The appearance of color， Model Number Signature with Company Chop : Printed Name : Leon DATE:2013-07-09

Shenzhen KTC Technology Co.,Ltd Northern Wuhe Road, Gangtou, Buji, Longgang, Shenzhen, China To: SIEMIC, INC. 775 Montague Expressway. Milpitas, CA 95035, USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen KTC Technology Co.,Ltd. to act as a Certification Body for certifying for the following project(s): Product description: 8′′ PAD model name: 800P*** FCC ID: ROU00003 We affirm that between SIEMIC and Shenzhen KTC Technology Co., Ltd, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: name / title: Leon Zheng /Certification Engineer address: Northern Wuhe Road, Gangtou, Buji, Longgang, Shenzhen, China Date:2013/7/13

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 3.0 Shenzhen KTC Technology Co.,Ltd Northern Wuhe Road, Gangtou, Buji, Longgang, Shenzhen, China Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID:ROU00003 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description BOM Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Leon Zheng /Certification Engineer address: Northern Wuhe Road, Gangtou, Buji, Longgang, Shenzhen, China Date:2013/7/13

宽69.8mmX高6.6mm 黑色后壳 银色 800P11B 24.8mm 800P11B后壳丝印 8.0" PAD 800P11B 8.0" PAD 800P11B 34mm 69.80 mm 6.6 mm

BT,WIFI antenna GSM,WCD MA,GPS antenna

Compliance Certification Services Inc. Date of Issue: August 16, 2013 Report No .: C130718S01-SF-R2 Page 1 of 32 GSM 850-Body-Rear-CH128............................................................................................................... 2 GSM 850-Body-Edge1-CH128............................................................................................................ 3 GSM 850-Body-Edge2- CH128........................................................................................................... 4 GSM 850-Body-Edge3-CH128............................................................................................................ 5 GSM 850-Body-Edge4-CH128............................................................................................................ 6 GSM 850-Body-Edge4-CH190............................................................................................................ 8 GSM 850-Body-Edge4-CH251............................................................................................................ 9 GPRS 850-Body-Rear-CH128............................................................................................................11 GPRS 850-Body-Edge1-CH128........................................................................................................ 13 GPRS 850-Body-Edge2-CH128........................................................................................................ 14 GPRS 850-Body-Edge3-CH128........................................................................................................ 15 GPRS 850-Body-Edge4-CH128........................................................................................................ 16 PCS1900-Body-Rear-CH512............................................................................................................. 18 PCS1900-Body-Edge1-CH512.......................................................................................................... 20 PCS1900-Body-Edge3-CH512.......................................................................................................... 21 PCS1900-Body-Edge4-CH512.......................................................................................................... 22 GPRS1900-Body-Rear-CH512.......................................................................................................... 23 GPRS1900-Body-Edge1-CH512....................................................................................................... 25 GPRS1900-Body-Edge3-CH512....................................................................................................... 26 GPRS1900-Body-Edge4-CH512....................................................................................................... 27 WCDMA Band V-Body Rear-CH4233.............................................................................................. 28 WCDMA Band V-Body Edge1-CH4233.......................................................................................... 30 WCDMA Band V-Body Edge3-CH4233.......................................................................................... 31 WCDMA Band V-Body Edge4-CH4233.......................................................................................... 32 Compliance Certification Services Inc. Date of Issue: August 16, 2013 Report No .: C130718S01-SF-R2 Page 2 of 32 Test Laboratory: Compliance Certification Services Inc. Date: 7/26/2013 GSM 850-Body-Rear-CH128 DUT: 8' PDA; Type: 800P11B; Serial: 353478058678930 Communication System: Generic GSM; Communication System Band: GSM850; Frequency: 824.2 MHz;Duty Cycle: 1:8.30042 Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.944 S/m; ε r = 55.694; ρ = 1000 kg/m 3 Room Ambient Temperature: 23.1°C; Liquid Temperature: 21.7°C Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration: • Probe: EX3DV4 - SN3820; ConvF(9.07, 9.07, 9.07); Calibrated: 12/10/2012; • Sensor-Surface: 2mm (Mechanical Surface Detection) • Electronics: DAE4 Sn679; Calibrated: 1/16/2013 • Phantom: ELI v4.0; Type: QDOVA001BB; Serial: TP:xxxx • DASY52 52.8.5(1059); • SEMCAD X Version 14.6.8 (7028) CH128/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.590 W/kg CH128/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 5.446 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 0.761 W/kg SAR(1 g) = 0.467 W/kg; SAR(10 g) = 0.280 W/kg Maximum value of SAR (measured) = 0.609 W/kg Compliance Certification Services Inc. Date of Issue: August 16, 2013 Report No .: C130718S01-SF-R2 Page 3 of 32 Test Laboratory: Compliance Certification Services Inc. Date: 7/26/2013 GSM 850-Body-Edge1-CH128 DUT: 8' PDA; Type: 800P11B; Serial: 353478058678930 Communication System: Generic GSM; Communication System Band: GSM850; Frequency: 824.2 MHz;Duty Cycle: 1:8.30042 Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.944 S/m; ε r = 55.694; ρ = 1000 kg/m 3 Room Ambient Temperature: 23.1°C; Liquid Temperature: 21.7°C Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY Configuration: • Probe: EX3DV4 - SN3820; ConvF(9.07, 9.07, 9.07); Calibrated: 12/10/2012; • Sensor-Surface: 2mm (Mechanical Surface Detection) • Electronics: DAE4 Sn679; Calibrated: 1/16/2013 • Phantom: ELI v4.0; Type: QDOVA001BB; Serial: TP:xxxx • DASY52 52.8.5(1059); • SEMCAD X Version 14.6.8 (7028) CH128/Area Scan (6x5x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.0214 W/kg CH128/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 2.797 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 0.0380 W/kg SAR(1 g) = 0.023 W/kg; SAR(10 g) = 0.015 W/kg Maximum value of SAR (measured) = 0.0316 W/kg Compliance Certification Services Inc. Date of Issue: August 16, 2013 Report No .: C130718S01-SF-R2 Page 4 of 32 Test Laboratory: Co…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: C130718S01-SF-R2 FCCID: ROU00003 Date of Issue :August 16, 2013 Page 1 of 86 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. ANSI/IEEE Std. C95.1-1999 In accordance with the requirements of FCC Report and Order: ET Docket 93-62, and KDB 865664 FCC SAR TEST REPORT For Product Name: 8''PDA Brand Name: N/A Model No.: 800P***(800:express screen size is 8 inches;"p":express Pad;* can be any alphanumeric represent different customer code or the sales area, not affect the product performance) Series Model: N/A Test Report Number: C130718S01-SF-R2 Issued for SHENZHEN KTC TECHNOLOGY CO.,LTD Northern Wuhe Road,Gangtou,Buji,Longgang,Shenzhen,China Issued by Compliance Certification Services Inc. Kun shan Laboratory No.10 Weiye Rd., Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China TEL: 86-512-57355888 FAX: 86-512-57370818 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. Compliance Certification Services Inc. Report No: C130718S01-SF-R2 FCCID: ROU00003 Date of Issue :August 16, 2013 Page 2 of 86 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Revision REPORT NO. Date Page Revised Contents Original C130718S01-SF July 30, 2013 N/A N/A 1 C130718S01-SF-R1 August 1, 2013 Page1 Page4 Pa ge5 Revise Product Name,Model Name,Applicant and Manufacturer 2 C130718S01-SF-R2 August 16, 2013 Page5 Revise The FCC ID 2 C130718S01-SF-R2 August 16, 2013 Page41 Revise the signal generator calibration information 2 C130718S01-SF-R2 August 16, 2013 Page32 Page33 Add WIFI and BT conducted RF power 2 C130718S01-SF-R2 August 16, 2013 Page34Add WIFi and BT antenna location 2 C130718S01-SF-R2 August 16, 2013 Page35 Page36 Add WIFI and BT test reduction 2 C130718S01-SF-R2 August 16, 2013 Page39 Page40 Pa ge41 Add Simultaneous RF exposure evaluation for WIFI and BT Compliance Certification Services Inc. Report No: C130718S01-SF-R2 FCCID: ROU00003 Date of Issue :August 16, 2013 Page 3 of 86 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) ........................................................... 4 2. EUT DESCRIPTION....................................................................................................................5 3. MAXIMUM RF OUTPUT POWER AMONG PRODUCTION UNITS.............................................................. 6 4. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC................................ 7 5. TEST METHODOLOGY.............................................................................................................. 7 6. TEST CONFIGURATION ............................................................................................................ 7 7. DOSIMETRIC ASSESSMENT SETUP........................................................................................ 8 7.1 MEASUREMENT SYSTEM DIAGRAM ...........................................................................................................9 7.2 SYSTEM COMPONENTS.............................................................................................................................10 8. EVALUATION PROCEDURES ................................................................................................. 13 9. MEASUREMENT UNCERTAINTY............................................................................................ 17 10. EXPOSURE LIMIT .................................................................................................................... 18 11. EUT ARRANGEMENT .............................................................................................................. 19 12. MEASUREMENT RESULTS..................................................................................................... 20 12.1 TEST LIQUIDS CONFIRMATION ...............................................................................................................20 12.2 LIQUID MEASUREMENT RESULTS ..........................................................................................................21 12.3 PROBE CALIBRATION PROCEDURE .......................................................................................................22 12.4 SYSTEM PERFORMANCE CHECK...........................................................................................................27 12.5 EUT TUNE-UP PROCEDURES AND TEST MODE....................................................................................29 12.6 SAR TEST CONFIGURATIONS..................................................................................................................34 12.7 EUT SETUP PHOTOS ................................................................................................................................37 12.8 SAR MEASUREMENT RESULTS...............................................................................................................38 12.9 SAR MULTI XMITER ASSESSMENT .........................................................................................................39 13. EUT PHOTO ............................................................................................................................. 42 14. EQUIPMENT LIST & CALIBRATION STATUS........................................................................ 45 15. FACILITIES...................................…

Text truncated - open the document above for the full version.

FCC ID: ROU00003 Keyway Testing Technology Co., Ltd. Report No. 13KWE07786F Page 1 of 67 FCC TEST REPORT for Shenzhen KTC Technology Co., Ltd. 8′′ PAD Model Number: 800P***(* can be A-Z or 0-9 or blank to denote various customer demand) FCC ID: ROU00003 Prepared for : Shenzhen KTC Technology Co., Ltd. Address : Northern Wuhe Road, Gangtou, Buji, Longgang, Shenzhen, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 13KWE07786F Date of Test : Jul. 10~ 17, 2013 Date of Report : Jul. 22, 2013 FCC ID: ROU00003 Keyway Testing Technology Co., Ltd. Report No. 13KWE07786F Page 2 of 67 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY.............................................................................................................4 2. GENERAL PRODUCT INFORMATION ............................................................................5 2.1. Product Function .......................................................................................................5 2.2. Description of Device (EUT) ......................................................................................5 2.3. Difference between Model Numbers..........................................................................6 2.4. Independent Operation Modes ..................................................................................6 3. TEST SITES .....................................................................................................................7 3.1. Test Facilities.............................................................................................................7 3.2. List of Test and Measurement Instruments................................................................8 4. TEST SET-UP AND OPERATION MODES......................................................................9 4.1. Principle of Configuration Selection ...........................................................................9 4.2. Block Diagram of Test Set-up ....................................................................................9 4.3. Test Operation Mode and Test Software ...................................................................9 4.4. Special Accessories and Auxiliary Equipment ...........................................................9 4.5. Countermeasures to Achieve EMC Compliance........................................................9 5. EMISSION TEST RESULTS...........................................................................................10 5.1. Conducted Emission at the Mains Terminals Test...................................................10 5.2. Conducted RF Output Power...................................................................................15 5.3. Peak to Average Radio............................................................................................17 5.4. 99% & -26 dB Occupied Bandwidth.........................................................................21 5.5. Frequency Stability ..................................................................................................29 5.6. Conducted Out of Band Emissions ..........................................................................32 5.7. Conducted Out of Band Emissions ..........................................................................44 5.8. Transmitter Radiated Power (EIRP/ERP) ..................................................................49 5.9. Radiated Out of Band Emissions...............................................................................53 6. PHOTOGRAPHS OF TEST SET-UP..............................................................................61 6.1. Set-up for Conducted Emission Test .......................................................................61 6.2. Set-up for Radiated Emission Test ..........................................................................62 7. PHOTOGRAPHS OF THE EUT......................................................................................63 FCC ID: ROU00003 Keyway Testing Technology Co., Ltd. Report No. 13KWE07786F Page 3 of 67 Keyway Testing Technology Co., Ltd. Applicant: Address: SHENZHEN KTC TECHNOLOGY OO.,LTD Northern Wuhe Road, Gangtou, Buji,Longgang,Shenzhen, China Manufacturer: Address: SHENZHEN KTC TECHNOLOGY OO.,LTD Northern Wuhe Road, Gangtou, Buji,Longgang,Shenzhen, China E.U.T: 8′′ PAD Model Number: 800P***(* can be A-Z or 0-9 or blank to denote various customer demand) Trade Name: ------ Serial No.: ------ Date of Receipt: Jul. 3, 2013 Date of Test: Jul. 10~ 17, 2013 Test Specification: FCC CFR Title 47 Part 2: 2012 FCC CFR Title 47 Part22 Subpart H: 2012 FCC CFR Title 47 Part24 Subpart E: 2012 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jul. 22, 2013 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: ROU00003 Keyway Testing Technology Co., Ltd. Report No. 13KWE07786F Page 4 of 67 1. TEST SUMMARY Test Items Test Requirement Result Conducted Emission at the Mains Terminals 15.207 PASS RF Exposure (SAR) Part 1.1307 Part 2.1093 Passed* (Please refer to SAR Report) Conducted RF Output Power 2.1046 PASS Peak to average radio 24.232(d) , PASS 99% & -26 dB Occupied Bandwidth 2.1049, 22.917 24.238, PASS Frequency Stability 2.1055, 22.355 24.235, PASS Conducted Out of Band Emissions 2.1051,2.1057 22.917, 24.238 PASS Band Edge 2.1051,2.1057 22.917, 24.238 PASS Transmitter Radiated Power (EIPR/ERP) 22.913, 24.232 PASS…

Text truncated - open the document above for the full version.

Set-up for Conducted Emission Test Set-up for Radiated Emission Test
