RSFXC032CYYMicrowave Oven

Microwave Oven 350A4502P73305-12 ATS JES1295 Owner’s Manual www.GEAppliances.ca Safety Information . . . . . . . . .2–6 Operating Instructions Best Cooking Methods . . . . . . . .21 Combination Features . . . . . . . .18 Convection Features . . . . . . . . . .17 Convenience Features . . . . . .14-16 Cookware Tips . . . . . . . . . . . . . .22 Grill Feature . . . . . . . . . . . . . . . .19 Microwave Terms . . . . . . . . . . . .24 Other Features . . . . . . . . . . . . . .23 Oven Features . . . . . . . . . . . . . .7, 8 Power Levels . . . . . . . . . . . . . . . . .9 Roast Feature . . . . . . . . . . . . . . .20 Timed Features . . . . . . . . . . .10–13 Care and Cleaning . . . . . . . . . .25 Troubleshooting Tips . . . . .26-27 Things That Are Normal . . . . . .27 Consumer Support Product Registration . . . . . .29, 30 Warranty . . . . . . . . . . . . . . . . . . .31 Write the model and serial numbers here: Model # __________________ Serial # __________________ You can find them on a label inside the oven. with Convection and Grill Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips IMPORTANT SAFETY INSTRUCTIONS. READ ALL INSTRUCTIONS BEFORE USING. IMPORTANT SAFETY INSTRUCTIONS. When using electrical appliances basic safety precautions should be followed, including the following. Use this appliance only for its intended purpose as described in this Owner’s Manual. ■Read and follow the specific precautions in the Precautions to Avoid Possible Exposure to Excessive Microwave Energysection above. ■This appliance must be grounded. Connect only to a properly grounded outlet. See the Grounding Instructions section on page 5. ■Install or locate this appliance only in accordance with the provided installation instructions. ■This oven must be located at least 3 ft. (0.9 m) above floor level. ■Be certain to place the front surface of the door 3” (7.6 cm) or more back from the countertop edge to avoid accidental tipping of the appliance in normal usage. A minimum clearance of 3.0 inches (7.5 cm) is required between the oven and any adjacent walls, One side must be open. Leave a minumum clearance of 12.0 inches (30 cm) above the oven. ■Do not mount this appliance over a sink. ■Do not mount the microwave oven over or near any portion of a heating or cooking appliance. ■Do not store anything directly on top of the microwave oven surface when the microwave oven is in operation. ■Do not operate this appliance if it has a damaged power cord or plug, if it is not working properly or if it has been damaged or dropped. If the power cord is damaged, it must be replaced by General Electric Service or an authorized service agent using a power cord available from General Electric. ■Do not cover or block any openings on the appliance. ■Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This microwave oven is specifically designed to heat, dry or cook food, and is not intended for laboratory or industrial use. ■This microwave oven is not approved or tested for marine use. ■Do not store this appliance outdoors. Do not use this product near water—for example, in a wet basement, near a swimming pool, near a sink or in similar locations. ■Keep power cord away from heated surfaces. ■Do not immerse power cord or plug in water. ■Do not let power cord hang over edge of table or counter. ■To reduce the risk of fire in the oven cavity: — Do not overcook food. Carefully attend appliance when paper, plastic or other combustible materials are placed inside the oven while cooking. — Remove wire twist-ties and metal handles from paper or plastic containers before placing them in the oven. — Do not use the oven for storage purposes. Do not leave paper products, cooking utensils or food in the oven when not in use. — If materials inside the oven ignite, keep the oven door closed, turn the oven off and disconnect the power cord, or shut off power at the fuse or circuit breaker panel. If the door is opened, the fire may spread. ■See door surface cleaning instructions in the Care and cleaning of the microwave ovensection of this manual. ■This appliance must only be serviced by qualified service personnel. Contact nearest authorized service facility for examination, repair or adjustment. ■As with any appliance, close supervision is necessary when used by children. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. (a) Do Not Attemptto operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. ( b) Do Not Placeany object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do Not Operatethe oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The Oven Should Notbe adjusted or repaired by anyone except properly qualified service personnel. PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY SAVE THESE INSTRUCTIONS EN-2 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions www.GEAppliances.ca ARCING If you see arcing, press STOP/CLEARand correct the problem. Arcing is the microwave term for sparks in the oven. Arcing is caused by: ■The metal shelf installed incorrectly so it touches the microwave wall. ■Metal or foil touching the side of the oven. ■Foil not molded to food (upturned edges act like antennas). ■Metal, such as twist-ties, poultry pins or gold- rimmed dishes, in the microwave. ■Recycled paper towels containing small metal pieces being used in the microwave. FOODS ■When microwav…

Text truncated - open the document above for the full version.

Web Site: www.midea.com.cn No.6, Yong An Road, Beijiao, Shunde, Foshan E-Mail: [email protected] Guangdong, P.R. China Phone : +86-757-23606480 FAX : +86-757-26656995 AGENCY AUTHORIZATION LETTER FCC ID:RSFXC032CYY Date: 2015-3-9 To whom it may concern: We, the undersigned, hereby authorize ECMG to act on our behalf , as our agent ,in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to the matters. and any other lawful activity necessary to obtain such certification. Any act carried out by ECMG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date , if you have any question regarding the authorization , please don’t hesitate to contact us , thank you. Sincerely, Xue wenfei Guangdong Midea Kitchen Appliances Manufacturing Co.,Ltd. Phone : +86-757-26306480 FAX :+86-757-22607341 E-Mail: [email protected]

Date: 2015-3-9 FCC ID: RSFXC032CYY Federal communications commission Authorization and Evaluation Division Confidentiality Request Pursuant to section 0.457 and 0.459 of the commission’s rules, the applicant hereby requests confidential treatment of information accompanying this application as outline below: 1 Schematics 2 Block diagram 3 Operational description The above materials contain trade secrets and proprietary information not customarily released to the public, the public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application.

EUT Sample Photos for Model EC032CTC-S EUT Front View EUT Back View Door Opend View

ID Label&Location FCC ID:RSFXC032CYY FCC ID:RSFXC032CYY Label location

EUT Internal Photos for Model EC032CTC-S EUT Uncovered View Magnetron Front View Power Filter Board- Top View Power Filter Board- Bottom View Mother board Top View Mother board Bottom View

www.ecmg-global.net EMI TEST REPORT On Model Name: Microwave Oven Model Numbers: XC032CYY-S, XC034AYY-S Brand Name: FCC ID Number: RSFXC032CYY Prepared for Guangdong Midea Kitchen Appliances Manufacturing Co.,Ltd. According to FCC Part 18(2014) Industrial, Scientific and Medical Equipment FCC/OST MP-5(1986) FCC methods of measurements of radio noise emission from industrial, scientific and medical equipment Test Report #: GUA-1502-11291-FCC Prepared by: ECMG ViVi Huang/Assistant Company Name Reviewed by: ECMG Jawen Yin/Senior Engineer Company Name QC Manager: ECMG Swall Zhang/QC Manager Company Name Test Report Released by: May 6 th , 2015   Swall Zhang Date Test Location Tests performed in a Certified ANSI Semi-Anechoic Chamber and Shielded Room. Test Site Location : GD WITOL VACUUM ELECTRONIC EMC TEST LABORATORY BeiJiao,ShunDe,FoShan,GuangDong, 528311, China Tel : (86)-757-26326917 Fax : (86)-757- 22607341 Test Facility The test facility was recognized, certified, or accredited by the following organizations: FCC – Registration No.: 910385 GD WITOL VACUUM ELECTRONIC EMC TEST LABORATORY has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC was maintained in our files Table of Contents GOVERNMENT DISCLAIMER NOTICE _______________________________________________ 2 REPRODUCTION CLAUSE __________________________________________________________ 2 OPINIONS AND INTERPRETATIONS ________________________________________________ 2 STATEMENT OF MEASUREMENT UNCERTAINTY ____________________________________ 2 ADMINISTRATIVE DATA ___________________________________________________________ 3 EUT DESCRIPTION _________________________________________________________________ 4 EUT MODEL DERIVED ______________________________________________________________ 4 TEST SUMMARY ___________________________________________________________________ 5 LOAD FOR MICROWAVE OVEN _____________________________________________________ 6 EUT EXERCISE SOFTWARE _________________________________________________________ 6 EQUIPMENT MODIFICATION _______________________________________________________ 6 EUT SAMPLE PHOTOS FOR MODEL EC032CTC-S ___________________________________ 7 TEST SYSTEM DETAILS ___________________________________________________________ 12 CONFIGURATION OF TESTED SYSTEM ____________________________________________ 13 ATTACHMENT 1 –RADIATION HAZARD TEST _____________________________________ 14 ATTACHMENT 2 – INPUT POWER MEASUREMENT _________________________________ 16 ATTACHMENT 3 – RF OUTPUT POWER MEASUREMENT ____________________________ 18 ATTACHMENT 4 – OPERATING FREQUENCY MEASUREMENT _______________________ 20 ATTACHMENT 5 – CONDUCTED EMISSION TEST RESULTS _________________________ 23 ATTACHMENT 6 - RADIATED EMISSION TEST RESULTS____________________________ 28 FCC Test Report #: GUA-1502-11291-FCC Prepared for Guangdong Midea Kitchen Appliances Manufacturing Co.,Ltd. Prepared by ECMG Electronic Technical Testing Corp (Shenzhen). Page 1 of 32 List Attached Files Exhibit Type File Description File Name Test Report Test Report RSFXC032CYY _Test Report.pdf Operation Description Technical Description RSFXC032CYY _Operation Description.pdf External Photos External Photos RSFXC032CYY _External Photos.pdf Internal Photos Internal Photos RSFXC032CYY _Internal Photos.pdf Block Diagram Block Diagram RSFXC032CYY _Block Diagram.pdf Schematics Circuit Diagram RSFXC032CYY _Schematics.pdf ID Label/Location Label and Location RSFXC032CYY _Label & Location.pdf User Manual User Manual RSFXC032CYY _User’s Manual.pdf Test set-up photos Test set-up photos RSFXC032CYY _Test Set-up Photos FCC Test Report #: GUA-1502-11291-FCC Prepared for Guangdong Midea Kitchen Appliances Manufacturing Co.,Ltd. Prepared by ECMG Electronic Technical Testing Corp (Shenzhen). Page 2 of 32 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from ECMG Electronic Technical Testing Corp (Shenzhen). Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT).Without the permission of ECMG Electronic Technical Testing Corp (Shenzhen) Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. FCC Test Report #: GUA-1502-11291-FCC Prepared for Guangdong Midea Kitchen Appliances Manufacturing Co.,Ltd. Prepared by ECMG Electronic Technical Testing Corp (Shenzhen). Page 3 of 32 Administrative Data Test Sample : Microwave Oven Model Numbers : XC032CYY-S, XC034AYY-S Model Tested : EC032CTC-S Brand Name : Receipt…

Text truncated - open the document above for the full version.

Conducted Emission Test Set-up: Radiated Emission Test Set-up (30 -1,000MHz): Radiated Emission Test Set-up (1-25GHz):
