RSFXM131EYYMicrowave Oven

SAVE THESE INSTRUCTIONS CAREFULLY Read these instructions carefully before using your microwave oven, and keep it carefully. If you follow the instructions, your oven will provide you with many years of good service. INSTRUCTION MANUAL Model:EM131ENV Microwave Oven 2 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the: (1) DOOR (bent) (2) HINGES AND LATCHES (broken or loosened) (3) DOOR SEALS AND SEALING SURFACE (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. Specifications Model: Rated Voltage: Rated Input Power(Microwave): Rated Output Power(Microwave): Oven Capacity: Turntable Diameter: External Dimensions: Net Weight: EM131ENV 120V~ 60Hz 1100 W 1.1 Cu.ft.(31 L) Approx. 36.5 Lbs(16.5kg) 20.2X16.7X12.0 inch (513X425X305mm) 12.4 inch(315 mm) 1500 W 3 IMPORTANT SAFETY INSTRUCTIONS WARNING 1. Read all instructions before using the appliance. 2. Read and follow the specific: "PRECAU- TIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" found on page 2. 3. As with most cooking appliances, close supervision is necessary to reduce the risk of a fire in the oven cavity. 4.To reduce the risk of fire in the oven cavity: i). Do not overcook food. Carefully attend the appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking. ii).Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven. iii). If materials inside the oven ignite, keep the oven door closed. Turn the oven off, and unplug the appliance. Disconnect the power cord, shut off power at the fuse or circuit breaker panel. iv). Do not use the oven cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use. 5. This oven must be grounded. Connect only to properly grounded outlet. See "GROUNDING INSTRUCTIONS" found on page 5. 6. Install or locate this oven only in accordance with the installation instructions provided. 7. Some products such as whole eggs and sealed containers-for example, closed glass jars-are able to explode and should not be heated in the oven. To reduce the risk of burns, electric shock, fire,injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic safety precautions, including the following: 8. Use this appliance only for its intended uses as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This oven is specifically designed to heat or cook or dry food. It is not designed for industrial or laboratory use. 9. As with any appliance, close supervision is necessary when used by children. 10. Do not operate this oven if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped. 11. This appliance should be serviced only by qualified service technicians. Contact the nearest authorized service facility for examination, repair or adjustment. 12. Do not cover or block any openings on the oven. 13. Do not store or use this appliance outdoors. 14. Do not use this oven near water, for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations. 15. Do not immerse cord or plug in water. 16. Keep cord away from heated surfaces. 17. Do not let cord hang over edge of table or counter. 18. When cleaning surfaces of door and oven that comes together on closing the door, use only mild, nonabrasive soaps or detergents applied with a sponge or soft cloth. 4 i) Do not overheat the liquid. ii) Stir the liquid both before and halfway through heating it. iii) Do not use straight-sided containers with narrow necks. iv) After heating, allow the container to stand in the microwave oven for a short time before removing the container. v) Use extreme care when inserting a spoon or other utensil into the container. 19. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-pronged grounding plug, and a 3-slot receptacle that will accept the plug on the appliance. GROUNDING INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING DANGER Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance. Electric Shock Hazard Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded. (grounding) plug Three-pronged The marked rating of the extension cord shall be equal to or greater than the electrical rating of the appliance. 5 CAUTION Personal Injur…

Text truncated - open the document above for the full version.

Date: 2012-2-2 Federal communications commission Authorization and Evaluation Division FCC ID: RSFXM131EYY Confidentiality Request Pursuant to section 0.457 and 0.459 of the commission’s rules, the applicant hereby requests confidential treatment of information accompanying this application as outline below: 1 Schematics 2 Block diagram 3 Operational description The above materials contain trade secrets and proprietary information not customarily released to the public, the public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, xue wenfei Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd Phone : +86-757-26306480 FAX :+86-757- 22607341 E-Mail: [email protected]

Web Site: www.midea.com.cn No.6, Yong An Road, Beijiao, Shunde, Foshan E-Mail: [email protected] Guangdong, P.R. China Phone : +86-757-23606480 FAX : +86-757-26656995 AGENCY AUTHORIZATION LETTER FCC ID: RSFXM131EYY Date: 2012-2-2 To whom it may concern: We, the undersigned, hereby authorize ECMG to act on our behalf , as our agent ,in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to the matters. and any other lawful activity necessary to obtain such certification. Any act carried out by ECMG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date , if you have any question regarding the authorization , please don’t hesitate to contact us , thank you. Sincerely, Xue wenfei Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd Phone : +86-757-26306480 FAX :+86-757- 22607341 E-Mail: [email protected]

Internal photos EUT model: EM131EYY EUT Uncovered View Magnetron Front View Power Filter Board Top View Power Filter Board Bottom View Motherboard- Top View Motherboard- Bottom View

www.ecmg-global.net EMI TEST REPORT On Model Name: Microwave Oven Model Numbers: XM131EYY Brand Name: FCC ID Number: RSFXM131EYY Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd According to FCC Part 18(2010) Industrial, Scientific and Medical Equipment FCC/OST MP-5(1986) FCC methods of measurements of radio noise emission from industrial, scientific and medical equipment Test Report#: GUA-1201-10774-FCC Prepared by: Sewen Guo Reviewed by: Jawen Yin QC Manager: Swall Zhang Test Report Released by: February 15, 2012 ⎯⎯⎯⎯⎯⎯⎯⎯ ⎯⎯⎯⎯⎯⎯ Swall Zhang Date Test Location Tests performed in a Certified ANSI Semi-Anechoic Chamber and Shielded Room. Test Site Location : GD WITOL VACUUM ELECTRONIC EMC TEST LABORATORY BeiJiao,ShunDe,FoShan,GuangDong, 528311, China Tel : (86)-757-26326917 Fax : (86)-757- 22607341 Test Facility The test facility was recognized, certified, or accredited by the following organizations: FCC – Registration No.: 910385 GD WITOL VACUUM ELECTRONIC EMC TEST LABORATORY has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC was maintained in our files. Table of Contents GOVERNMENT DISCLAIMER NOTICE _______________________________________________ 2 REPRODUCTION CLAUSE __________________________________________________________ 2 OPINIONS AND INTERPRETATIONS ________________________________________________ 2 STATEMENT OF MEASUREMENT UNCERTAINTY ____________________________________ 2 ADMINISTRATIVE DATA ___________________________________________________________ 3 EUT DESCRIPTION _________________________________________________________________ 4 EUT MODEL DERIVED______________________________________________________________ 5 TEST SUMMARY ___________________________________________________________________ 6 LOAD FOR MICROWAVE OVEN _____________________________________________________ 7 EUT EXERCISE SOFTWARE _________________________________________________________ 8 EQUIPMENT MODIFICATION _______________________________________________________ 8 EUT SAMPLE PHOTOS FOR MODEL EM131EYY _____________________________________ 9 TEST SYSTEM DETAILS ___________________________________________________________ 13 CONFIGURATION OF TESTED SYSTEM ____________________________________________ 14 ATTACHMENT 1 –RADIATION HAZARD TEST _____________________________________ 15 ATTACHMENT 2 – INPUT POWER MEASUREMENT _________________________________ 17 ATTACHMENT 3 – RF OUTPUT POWER MEASUREMENT ____________________________ 19 ATTACHMENT 4 – OPERATING FREQUENCY MEASUREMENT _______________________ 22 ATTACHMENT 5 – CONDUCTED EMISSION TEST RESULTS_________________________ 25 ATTACHMENT 6 - RADIATED EMISSION TEST RESULTS____________________________ 29 FCC Test Report #: GUA-1201-10774-FCC Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co., Ltd Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 1 of 32 List Attached Files Exhibit Type File Description File Name Test Report Test Report RSFXM131EYY _Test Report.pdf Operation Description Technical Description RSFXM131EYY _Operation Description.pdf External Photos External Photos RSFXM131EYY _External Photos Internal Photos Internal Photos RSFXM131EYY _Internal Photos Block Diagram Block Diagram RSFXM131EYY _Block Diagram.pdf Schematics Circuit Diagram RSFXM131EYY _Schematics.pdf ID Label/Location Label and Location RSFXM131EYY _Label & Location.pdf User Manual User Manual RSFXM131EYY _User’s Manual.pdf Test set-up photos Test set-up photos RSFXM131EYY _Test Set-up Photos FCC Test Report #: GUA-1201-10774-FCC Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co., Ltd Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 2 of 32 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from ECMG Electronic Technical Testing Corp (Shenzhen). Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT).Without the permission of ECMG Electronic Technical Testing Corp (Shenzhen) Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. FCC Test Report #: GUA-1201-10774-FCC Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co., Ltd Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 3 of 32 Administrative Data Test Sample : Microwave Oven Model Numbers : XM131EYY Model Tested : EM131EYY Brand Name : Receipt Date : February 1, 2012 Date Tested : February 2, 2012 to February …

Text truncated - open the document above for the full version.

Test Photos Radiation Hazard Test Set-up: Input Power Test Set-Up : RF Output Power Test Set-Up : Operating Frequency Test Set-up: Conducted Emission Test Set-up: Radiated Emission Test Set-up (30~1000MHz): Radiated Emission Test Set-up (1~25GHz) :
