Dual-Band Wireless Adjustable Signal Booster / Kit x Dual Force™ Booster Dual Force Omni Kit, Dual Force- Panel Kits (D UAL FORCE) User Guide INTRODUCTION 2 THEORY OF OPERATION 2 SURECALL DUAL FORCE PACKAGES 3 DUAL FORCE BOOSTER HARDWARE 4 INSTALLATION 5 SITE SELECTION 5 INSTALLATION INSTRUCTIONS 6 LEDS 11 AUTOMATIC SHUTDOWN 12 TROUBLESHOOTING 13 FREQUENTLY ASKED QUESTIONS 15 OBTAINING TECHNICAL SUPPORT 15 WARRANTY 16 SPECIFICATIONS 18 SAFETY INFORMATION 19 INTRODUCTION SureCall Dual Force Cellphone-Mate, Inc. Page 2 All rights reserved. Introduction Congratulations on purchasing the SureCall Dual Force, the finest cellular signal booster available! SureCall adjustable cellular signal boosters and kits from Cellphone-Mate remove frustrations over dropped calls, limited range, and slow data rates by amplifying incoming and outgoing cellular signals in buildings, offices, and homes. The Dual Force is designed with leading-edge technologies to detect and amplify weak incoming signals your cellular device would otherwise miss and to broadcast a significantly stronger signal back to the cell tower. This guide contains all the information you need to get your SureCall Dual Force booster system up and running. Theory of Operation The SureCall Dual Force is a high-quality bidirectional signal booster that boosts cellular signals for areas prone to weak or shadowed cellular coverage. The Dual Force works with two antennas : x An i nside antenna that communicates with your cell phone. x An outside antenna that communicates with the cell tower. Signals sent from a cell tower are received by the outside antenna, amplified by the booster and then sent to your phone via the inside antenna. When your phone tr ansmits, the signal is sent to the inside antenna, and then sent to the cell tower via t he outside antenna. Some cell signal is required for the Dual Force to enhance cellular signal coverage. The weakest cell signal for the Dual Force to work is low -100dBm to high -90dBm. dBm is an abbreviation for the power ratio in decibels of the radio power per one milliwatt. To measure your existing cell signal on an Apple iPhone, dial *3001#12345#*and press Call. In the top-left corner, a number appears instead of bars. For Android devices, you can download several apps to measure exact signal strength. Look up check real signal strength to find a cell signal measurement app. INTRODUCTION SureCall Dual Force Cellphone-Mate, Inc. Page 3 All rights reserved. SureCall Dual Force Packages Dual Force - Antenna Kitting Information Component Product Number (Description) Gain/Loss Notes 800 MHz 1900 MHz Outdoor Antennas* CM288W 3 dBi 4 dBi CM230W 10 dBi 10 dBi Outdoor Cable* CM400-65NN (65 feet) –3.89 dB –5.43 dB 65 f eet or longer Indoor Antenna* CM248W 7 dBi 10 dBi CM222W 3 dBi 6 dBi Indoor Cable* CM400-40NN ( 40 feet) –2.63 dB –3.57 dB 40 f eet or longer * All equivalent antennas and cables are suitable for use with the Dual Force booster. Note: For the signal booster to work, the following items are required: x Outside antenna x Cable for connecting the outside antenna to the booster x Signal booster x Inside antenna x Cable for connecting the inside antenna to the booster x Power supply Warning: Unauthorized antennas, cables, and/or coupling devices are prohibited by FCC new rules. Please contact FCC for details: 1-888-CALL-FCC. Changes or modifications not expressly approved by Cellphone-Mate could void the user’s authority to operate the equipment. INTRODUCTION SureCall Dual Force Cellphone-Mate, Inc. Page 4 All rights reserved. Dual Force Booster Hardware The following figure shows the key hardware components on the SureCall Dual Force cellular signal booster. Refer to this figure as you install your SureCall Dual Force components. Power LED Outside Antenna Connector Inside Antenna Connector Four Switches: •PCS Uplink/Downlink (left) •Cellular Uplink/Downlink (right) INSTALLATION SureCall Dual Force Cellphone-Mate, Inc. Page 5 All rights reserved. Installation Unpack all package contents and check for damage. For missing or damaged items, contact your reseller. Keep the carton and packing material to store the product or if you need to return it. Site Selection For optimum performance, select a location for your booster th at : x Provides th e best si gnal strength possible. To measure your existing cell signal on an Apple iPhone, dial *3001#12345#*and press Call. In the top- left corner, a number appears instead of bars. For Android devices, you can download several apps to measure exact signal strength. Look up “check real signal strength“ to find a cell signal measurement app. x Avoids areas where wireless signals can b e bloc ked or reflected by buildings, walls, trees, hil ls , and other te rrain features. This can resu lt i n low signal strength. x Is not close to energy-efficient windows, which can af fect signal penetration into a home or off ice. Note: The cell phone tower site in relation to the location where you install your booster also deter mines signal strength. Although cell phone providers try to place towers for maximum cover age, local ordinances and terrain features can restrict tower locations, which can limit signal strength at your location. INSTALLATION SureCall Dual Force Cellphone-Mate, Inc. Page 6 All rights reserved. Installation Instructions The Dual Force signal booster is suited for installation in a building or home. Step 1. Connect the Outside Antenna 1. When mounting the outside antenna: x Find the wall or roof with the strongest signal, using a signal meter or any other cellular-frequency detector. x Mount an omnidirectional antenna mounted vertically or a directional Yagi antenna pointed directly (line of sight) at the cellular tower. x Attach a grounded lightning protector between the outdoor antenna and the booster. x Use caution when working in high areas to avoid falls and personal injury. x Do not touch live electrical wires or allow the antenna or cable to touch …

Text truncated - open the document above for the full version.

1 48346 Milmont Dr., Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com Antenna Kitting Information Dual Force Component Prod No. Description Gain/Loss Notes 800MHz 1900MHz Outdoor Antenna CM288W 3dBi 4dBi CM230W 10dBi 10dBi Outdoor Cable CM400-65NN 65Feet 3.89dB 5.43dB 65 Feet or longer Indoor Antenna CM248W 7dBi 10dBi CM222W 3dBi 6dBi Indoor Cable CM400-40NN 40Feet 2.63dB 3.57dB 40 Feet or longer Note1：Dual Indoor Antenna Kit Component Prod No. Description Quantity Notes Outdoor Antenna CM230W 1pcs Outdoor Cable CM400-65NN 65Feet 1pcs 65 Feet or longer Indoor Cable CM400-20NN 20Feet 1pcs 20 Feet or longer Splitter CM-WS-2 1pcs Cable After Splitting CM400-40NN 40Feet 2pcs 40 Feet or longer Indoor Antenna CM248W 2pcs Note2：Multiple Indoor antenna kits is also a option.

48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone-mate.com FCC Authorization 24 th January, 2014 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To Whom It May Concern: We, Cellphone-mate, the undersigned, hereby authorize CKC Certification Services, LLC to act on our behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by CKC Certification Services, LLC on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely yours, Hongtao Zhan, CEO Cellphone-Mate Inc. 1888 365 6283 ext. 301 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone-mate.com

48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone-mate.com FCC Confidential Authorization 20th January, 2014 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: RSNDUALFORCE In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Cellphone-mate hereby requests long- term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description  Parts list The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Sincerely Yours, Hongtao Zhan, CEO Cellphone-Mate Inc. 1888 365 6283 ext. 301

1 FCC§1.1307（b）(1)&§2.1091-RF EXPOSURE 1.1 Applicable Standard According to§1.1310 and §2.1091(Mobile Devices)RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Power Density (mW/cm²) Limits for General Population/Uncontrolled Exposure 0.3-1.34 *(100) 1.34-30 *(180/f²) 30-300 0.2 300–1,500 f/1500 1,500–100,000 1 Note: f= frequency in MHz *=Plane-wave equivalent power density 1.2 MPE Prediction 1.2.1 Calculation of MPE at 20 cm distance, Equation from OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G= maximum power gain of the antenna in the direction of interest relative to an isotropic radiator, subtract antenna’s cable loss, (result is in numeric form) R=distance to the center of radiation of the antenna (20cm in the following calculation) 1.2.2 Calculation formula of G（numeric ) G (numeric)=10 {Maximum Antenna Gain dBi () -Cable LossdB () } 1 10 Where: G（numeric）= Maximum power gain of the antenna in the direction of interest relative to an isotropic radiator, subtract antenna’s cable loss, (result is converted from decibel into numeric form with above equation) 1.3 Test Result Outdoor Antenna Outdoor Antenna Outdoor Antenna Gain At 1900MHz(dBi) At 800MHz(dBi) CM288W 4 3 CM230W 10 10 MAX GAIN 10 10 Outdoor Cable Outdoor Cable Outdoor Cable Loss At 1900MHz(dB) At 800MHz(dB) CM400-65NN 65Feet 5.43 3.89 MIN LOSS 5.43 3.89 Indoor Antenna Indoor Antenna Indoor Antenna Gain At 1900MHz(dBi) At 800MHz(dBi) CM222W 6 3 CM248W 10 7 MAX GAIN 10 7 Indoor Cable Indoor Cable Indoor Cable Loss At 1900MHz(dB) At 800MHz(dB) CM400-40NN 34Feet 3.57 2.63 MIN LOSS 3.57 2.63 Cellular Band UL: Maximum peak output power at antenna input terminal(dBm): 20.50 Maximum peak output power at antenna input terminal(mW): 112.20 Prediction distance(cm): 20 Prediction frequency(MHz): 832.17 Maximum Antenna Gain (dBi): 10 Cable Loss(dB): 3.89 G( numeric）: 4.08 Power density at predication frequency and distance(mW/cm²): 0.0912 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 0.5548 Cellular Band DL: Maximum peak output power at antenna input terminal(dBm): -6.10 Maximum peak output power at antenna input terminal(mW): 0.25 Prediction distance(cm): 20 Prediction frequency(MHz): 881.48 Maximum Antenna Gain (dBi): 7 Cable Loss(dB): 2.63 G( numeric）: 2.74 Power density at predication frequency and distance(mW/cm²): 0.0001 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 0.5877 PCS Band UL: Maximum peak output power at antenna input terminal(dBm): 18.60 Maximum peak output power at antenna input terminal(mW): 72.44 Prediction distance(cm): 20 Prediction frequency(MHz): 1877.30 Maximum Antenna Gain (dBi): 10 Cable Loss(dB): 5.43 G( numeric）: 2.86 Power density at predication frequency and distance(mW/cm²): 0.0413 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 1.0000 PCS Band DL: Maximum peak output power at antenna input terminal(dBm): 0.90 Maximum peak output power at antenna input terminal(mW): 1.23 Prediction distance(cm): 20 Prediction frequency(MHz): 1980.30 Maximum Antenna Gain (dBi): 10 Cable Loss(dB): 3.57 G( numeric）: 4.40 Power density at predication frequency and distance(mW/cm²): 0.0011 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 1.0000

This report contains a total of 28 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Cellphone-Mate, Inc. TEST REPORT FOR Dual Band Cellphone Signal Booster Model: Dual Force Tested To The Following Standards: FCC Part 24E Report No.: 95115-9 Date of issue: January 17, 2014 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 28 Report No.: 95115-9 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 24E .................................................................................................................................................. 7 2.1046 RF Power Output ........................................................................................................................................... 7 2.1047 Modulation Characteristics ............................................................................................................................ 7 2.1049 Occupied Bandwidth...................................................................................................................................... 8 2.1051 / Spurious Emissions at Antenna Terminals ................................................................................................ 16 2.1053 / Field Strength of Spurious Radiation ......................................................................................................... 19 2.1055 Frequency Stability ...................................................................................................................................... 26 Supplemental Information .......................................................................................................................... 27 Measurement Uncertainty ...................................................................................................................................... 27 Emissions Test Details .............................................................................................................................................. 27 Page 3 of 28 Report No.: 95115-9 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Cellphone-Mate, Inc. 48346 Milmont Ave. Fremont, CA 94538 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Hongtao Zhan Project Number: 95115 Customer Reference Number: CKC20131113 DATE OF EQUIPMENT RECEIPT: November 9, 2013 DATE(S) OF TESTING: November 9-December 18, 2013 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 28 Report No.: 95115-9 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Brea A US0060 SL2-IN-E-1146R 3082D-1 90473 A-0147 Page 5 of 28 Report No.: 95115-9 SUMMARY OF RESULTS Standard / Specification: FCC Part 2 / 24E Test Procedure/Method Description Results 2.1046 RF Power Output NA 2.1047 Modulation Characteristics…

Text truncated - open the document above for the full version.

This report contains a total of 26 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Cellphone-Mate, Inc. TEST REPORT FOR Dual Band Cellphone Signal Booster Model: Dual Force Tested To The Following Standards: FCC Part 22H Report No.: 95115-8 Date of issue: January 17, 2014 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 26 Report No.: 95115-8 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 22H ................................................................................................................................................. 7 2.1046 RF Power Output ........................................................................................................................................... 7 2.1047 Modulation Characteristics ............................................................................................................................ 7 2.1049 Occupied Bandwidth...................................................................................................................................... 8 2.1051 / 22.917(a) Spurious Emissions at Antenna Terminals ................................................................................ 16 2.1053 / 22.917(a) Field Strength of Spurious Radiation ........................................................................................ 19 2.1055 Frequency Stability ...................................................................................................................................... 24 Supplemental Information .......................................................................................................................... 25 Measurement Uncertainty ...................................................................................................................................... 25 Emissions Test Details .............................................................................................................................................. 25 Page 3 of 26 Report No.: 95115-8 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Cellphone-Mate, Inc. 48346 Milmont Drive Fremont, CA 94538 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Hongtao Zhan Project Number: 94297 Customer Reference Number: CKC20131113 DATE OF EQUIPMENT RECEIPT: November 9, 2013 DATE(S) OF TESTING: November 9 – December 18, 2013 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 26 Report No.: 95115-8 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Brea A US0060 SL2-IN-E-1146R 3082D-1 90473 A-0147 Page 5 of 26 Report No.: 95115-8 SUMMARY OF RESULTS Standard / Specification: FCC Part 2 / 22H Test Procedure/Method Description Results 2.1046 RF Power Output NA 2.1047 Modulation Characteristics NA 2.1049 …

Text truncated - open the document above for the full version.

48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com 1 Explanation of MSCL Mobile antenna Booster server antenna Mobile Booster MSCL Indoor Cable Loss Path loss Mobile Antenna Gain Indoor Antenna Gain spatial distance=d Figure 1 MSCL= Path loss + Indoor Cable Loss - Mobile Antenna Gain- Indoor Antenna Gain......① 1.1 Decibel version of free-space propagation loss equation: Path loss (dB) =20Lgf+20Lgd+32.45 ......② or Path loss (dB) =20Lgf+20LgD-27.55 ......③ f (MHz), d (km) , D(m), d=1000D 1.1.1 Operation Frequency At PCS (1850-1915MHz) f =1850MHz At Cellular (824-849MHz) f =824 MHz 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com 1.1.2 Minimum Separation Distances for MSCL base on FCC new rule D (m) Minimum Separation Distances for MSCL Calculation or Measurements D(m) Indoor server antenna types Minimum separation distances D (m) Ceiling Mounted (i.e., Dome-type) Antennas 2.0 Wall Mounted (i.e., Panel or other type) Antennas 1.0 or 2.0* Table Top Antennas 1.0 * Note: Wall Mounted (i.e., Panel or other type) Antennas: Alternatively, if a manufacturer clearly specifies a minimum separation distance to consumer devices in the installation manual or other user documentation provided with the booster, a reasonable minimum separation distance could be up to 6 feet (or 2 meters) horizontally removed from the antenna. In this case, the user would be required to ensure this minimum separation distance for all CMRS devices authorized for use with this booster. 1.2 Mobile Antenna Gain Mobile Antenna Gain=0dBi 1.3 Indoor Cable Loss And Indoor Antenna Gain Indoor Cable Loss and Indoor Antenna Gain are listed in the separate submitted file of Dual Force Antenna Kitting . 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com 2 MSCL Calculations Fixed booster Dual Force Indoor Antenna Indoor Antenna Indoor Antenna Gain At 1900MHz(dBi) At 800MHz(dBi) CM222W 6 3 CM248W 10 7 MAX GAIN 10 7 Indoor Cable Indoor Cable Indoor Cable Loss At 1900MHz(dB) At 800MHz(dB) CM400-40NN 40Feet 3.57 2.63 MIN LOSS 3.57 2.63 MSCL Calculations of fixed booster Dual Force MSCL Path Loss(dB) Indoor Antenna Gain(dBi) Indoor Cable Loss(dB) MSCL(dB) PCS(1850-1915MHz) 43.8 10 3.57 37.4 Cellular(824-849MHz) 36.8 7 2.63 32.4

This report contains a total of 73 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Cellphone-Mate, Inc. ADDENDUM TEST REPORT TO 95115-7A Dual Band Cellphone Signal Booster Model: Dual Force Tested To The Following Standards: FCC Part 20.21 Report No.: 95115-7B Date of issue: April 2, 2014 We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 73 Report No.: 95115-7B TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 20.21 ............................................................................................................................................................... 7 Clause 7.1 Authorized Frequency Band Verification ................................................................................................. 7 Clause 7.2 & 7.3 Power Gain ................................................................................................................................... 11 Clause 7.4 Intermodulation Product ........................................................................................................................ 18 Clause 7.5 Out of Band Emissions ............................................................................................................................ 27 Clause 7.7 Noise Limit ....................................................................................................…
