RUN-WCT-5W1COILTXWireless Charger Transmitter

Freescale Semiconductor Document Number: WCT1000SYSUG User Guide Rev. 3.1, 01/2014 © Freescale Semiconductor, Inc., 2014. All rights reserved. _______________________________________________________________________ WCT-5W1COILTX User Guide 1 Introduction This document describes how to use 5W low power wireless charger transmitter WCT-5W1COILTX designed by Freescale. Figure-1 WCT-5W1COILTX Contents 1 Introduction 1 2 System Features 2 3 Getting Started 2 4 Cautions 3 WCT-5W1COILTX Reference Design System User Guide, Rev. 3.1 2 Freescale Semiconductor 2 System Features The WCT-5W1COILTX reference board has following features: • Reference design compliant with low power WPC Qi version 1.1 Specification. • Integrated digital demodulation in chip. • Support multiple types Rx modulation signals (AC capacitor, AC resistor and DC resistor). • Support FOD. Support four types of Foreign Object protection. • Support Qi 1.1 receiver with 5 V DC@1A output power capability. • Super low standby power by Freescale touch technology. • Full bridge topology with freqency modulation power control strategy. • LED for RX and TX alignment indication. • Input voltage/current, coil current sensing for protection. 3 Getting Started WCT-5W1COILTX is easy to use, and can convenience to charging the mobile equipment that support the Qi wireless charging, below is the detail step to power up the system and use. Step 1: power on the Transmitter, plug the 5V adaptor to the AC power line, and plug the adaptor USB port to the transmitter input port, and the LED1 will be blanking. Figure-2 WCT-5W1COILTX power on Step 2: Place the wireless charging RX or some equipment that support the Qi wireless charger(such as cell phone, battery and so on ) on the WCT-5W1COILTX’s coil surface, then the transmitter will charge the equipment, under the normal charging states, LED1 will be turned on all the time, and LED2 will be blanking, and the RX will powered on the equipment normally. WCT-5W1COILTX User Guide Freescale Semiconductor 3 Figure-3 WCT-5W1COILTX charging the equipments Others Indicates: when the Transmitter get the end power communication information, it will stop the charging and wait until the RX is removed, under this states LED1 will be turned off, and LED2 will be turned on all the time. When some fault found, the transmitter will turn off LED1, and turn on LED2 until the fault is removed, fault include the FOD fault, OVP, OTP and so on. 4 Cautions • This device has been tested and found to comply with the limits pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. • If this equipment does cause harmful interference to other electronic equipments, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the equipment • Increase the separation • In order to use the equipment safely，please don’t open the case when powered on，and don’t touch the PCB and components with hand. • Don’t place some metal things between the TX surface and the RX surface, otherwise the metal things will be heated, it the temperature is too high, the Transmitter will shut down for protection. WCT-5W1COILTX Reference Design System User Guide, Rev. 3.1 4 Freescale Semiconductor This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. To satisfy FCC RF exposure requirements for mobile and base station transmission devices, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during operation. To ensure compliance, operation at closer than this distance is not recommended. The antenna(s) used for this transmitter must not be co -located or operating in conjunction with any other antenna or transmitter. Document Number: WCT1000SYSUG Rev. 3.1 12/2013 How to Reach Us: Home Page: www.freescale.com Web Support: www.freescale.com/support Information in this document is provided solely to enable system and software implementers to use Freescale products. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits based on the information in this document. Freescale reserves the right to make changes without further notice to any products herein. Freescale makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does Freescale assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. “Typical” parameters that may be provided in Freescale data sheets and/or specifications can and do vary in different applications, and actual performance may vary over time. All operating parameters, including “typicals,” must be validated for each customer application by customer’s technical experts. Freescale does not convey any license under its patent rights nor the rights of others. Freescale sells products pursuant to standard terms and conditions of sale, which can be found at the following address: freescale.com/SalesTermsandConditions. Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. ©2013 Fr ees…

Text truncated - open the document above for the full version.

Authority to Act as Agent Date: 2/25/2014 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Re: Obtaining FCC ID for Freescale Semiconductor, Inc.’s (Freescale) product WCT-5W1COIL Audix Technology(Shanghai)CO.,Ltd. is authorized to act as agent for Freescale Semiconductor, Inc. in connection with the above-referenced action. This authority is limited to actions required in order for Audix Technology(Shanghai)CO.,Ltd to obtain FCC ID RUN-WCT-5W1COILTX for Freescale product WCT- 5W1COIL. This authority does not extend to any other matters Freescale may have before the Commission. I certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Attached to this letter is Freescale’s request that the designated sections of its application for FCC ID RUN- WCT-5W1COILTX be permanently treated as confidential and not disclosed publicly. Thank you. By: __________________________ R.N. Fielding (Signature 1 ) (Print name) Title: Director, Governmental and Regulatory Affairs On behalf of: Freescale Semiconductor Inc. (Company Name) Telephone: 512-895-4601 Encl.: a/s 1 Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Request for Confidentiality Date: 2/25/2014 Subject: Confidentiality Request for: Freescale product WCT-5W1COIL to receive FCC ID RUN-WCT- 5W1COILTX Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 2 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual This request is being made in recognition of the fact that Freescale has spent substantial effort in developing this product, which is one of the first of its kind. Having the designated information easily available to Freescale competitors would negate the advantage Freescale has achieved by being early to market with this product. Losing this competitive advantage could adversely affect Freescale’s earnings from this product. Permanent Confidentiality: The applicant requests the exhibits designated above be treated as permanently confidential and withheld from public review as these materials contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 3 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Director, Regulatory & Governmental Affairs (Signature/Title 4 ) 2 The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 3 Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

FIGURE 1 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) GENERAL APPEARANCE (FRONT VIEW) F IGURE 2 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) GENERAL APPEARANCE (BACK VIEW) FIGURE 3 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) PORT VIEW F IGURE 4 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) MAIN BOARD (FRONT SIDE)

Label Location Information Refer to the below red arrow: (For example)

FIGURE 3 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) PORT VIEW F IGURE 4 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) MAIN BOARD (FRONT SIDE) FIGURE 5 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) MAIN BOARD (BACK SIDE) F IGURE 6 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) MAIN BOARD (COMPONENT SIDE) FIGURE 7 WIRELESS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) MAIN BOARD (SOLDERED SIDE) F IGURE 8 WIRLESSS CHARGER TRANSMITTER (M/N: WCT-5W1COILTX) CHIP ON MAIN BOARD

Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 1 of 12 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14034 Prepared For : Freescale Semiconductor, Inc. 6501 William Cannon Drive West Austin, Texas 78735 USA Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai 200233, China Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F14034 Date of Test : Feb. 24, 2014 Date of Report : Feb. 25, 2014 Application for FCC Certification On behalf of Freescale Semiconductor, Inc. Product Name: Wireless Charger Transmitter Model No.: WCT-5W1COILTX FCC ID: RUN-WCT-5W1COILTX (RF Exposure Report) Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 2 of 12 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14034 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 4 1.1 Description of Standards and Results ......................................................................................... 4 2 GENERAL INFORMATION .......................................................................................................... 5 2.1 Description of Equipment Under Test ........................................................................................ 5 2.2 Description of Test Facility ........................................................................................................ 6 3 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 7 3.1 Test Equipment ........................................................................................................................... 7 3.2 Test Setup ................................................................................................................................... 7 3.3 Applicable Standard ................................................................................................................... 7 3.4 Specification Limits ................................................................................................................... 8 3.5 Test Result .................................................................................................................................. 9 Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 3 of 12 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14034 TEST REPORT FOR HUMAN EXPOSURE Applicant : Freescale Semiconductor, Inc. Manufacturer : Trivo (Taicang) Technologies Co., Ltd. Factory : Trivo (Taicang) Technologies Co., Ltd. EUT Description : Wireless Charger Transmitter (A) Model No. : WCT-5W1COILTX (B) Power Supply : AC100~240V/50-60Hz (C) Test Voltage : AC 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 1 SECTION 1.1310 and KDB 680106 D01 v02 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the RF Exposure levels emanating from the device. The RF Exposure levels are compared to the FCC Part 1.1310. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. This report also shows that the EUT (M/N: WCT-5W1COILTX), which was tested on Feb. 24, 2014 is technically compliance with the FCC limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Feb. 24, 2014 Date of Report : Feb. 25, 2014 Producer : EMILY ZHU / Assistant Review : DIO YANG / Deputy Manager Signatory : SAMMY CHEN / Deputy Manager Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 4 of 12 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14034 1 SUMMARY OF STANDARDS AND RESULTS 1.1 Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below: Description of Test Item Standard Limits Results RF Exposure FCC RULES AND REGULATIONS PART 1.1310 AND KDB 680106 D01 V02 1.1310 Pass Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 5 of 12 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14034 2 GENERAL INFORMATION 2.1 Description of Equipment Under Test Description : Wireless Charger Transmitter Model Number : WCT-5W1COILTX Type of EUT : ; Production … Pre-product … Pro-type Charge Freq. : 110kHz – 205kHz Applicant : Freescale Semiconductor, Inc. 6501 William Cannon Drive West Austin, Texas 78735 USA Manufacturer : Trivo (Taicang) Technologies Co., Ltd. Building A10, Taicang Foreign Industry Park, No.105 East Shanghai Road, Taicang, Jiangsu, China, 215400 Factory : Trivo (Taicang) Technologies Co., Ltd. Building A10, Taicang Foreign Industry Park, No.105 East Shanghai Road, Taicang, Jiangsu, China, 215400 Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 6 of 12 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14034 2.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Mar 16, 2012 Renewed Federal Communications Commission FCC Engineering Laboratory 7435 Oakland Mills Road Columbia, MD 21046, USA Name of Firm : Audix Technology (Shanghai) Co., Ltd. Site Location : 3 F 34 Bldg 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai 200233, China FCC registration Number : 91789 Accredited by NVLAP, Lab Code : 200371-0 Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 7 of 12 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14034 3 SUMMARY OF STANDARDS AND RESULTS 3.1 Test Equipment The following test equipments are used during the conducted emission test in a shielded room: Item Type ManufacturerModel No.Serial No. Last Cal. Next Cal. 1. Broadband Field Meter NARDA NBM-550E-…

Text truncated - open the document above for the full version.

Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 1 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14027 Prepared For : Freescale Semiconductor, Inc. 6501 William Cannon Drive West Austin, Texas 78735 USA Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F and 4F, 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai 200233, China Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F14027 Date of Test : Dec 06, 2013 – Feb 08, 2014 Date of Report : Feb 11, 2014 Application for FCC Certificate On Behalf of Freescale Semiconductor, Inc. Wireless Charger Transmitter Model No.: WCT-5W1COILTX FCC ID : RUN-WCT-5W1COILTX Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 2 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14027 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 4 1.1 Description of Standards and Results ......................................................................................... 4 2 GENERAL INFORMATION .......................................................................................................... 5 2.1 Description of Equipment Under Test ........................................................................................ 5 2.2 Peripherals .................................................................................................................................. 5 2.3 Description of Test Facility ........................................................................................................ 6 2.4 Measurement Uncertainty .......................................................................................................... 6 3 CONDUCTED EMISSION TEST .................................................................................................. 7 3.1 Test Equipment ........................................................................................................................... 7 3.2 Block Diagram of Test Setup ..................................................................................................... 7 3.3 Conducted Emission Limit [FCC Part 18 Subpart C 18.307(b)] ............................................... 8 3.4 Test Configuration ...................................................................................................................... 8 3.5 Operating Condition of EUT ...................................................................................................... 8 3.6 Test Procedures .......................................................................................................................... 8 3.7 Test Results ................................................................................................................................ 9 4 RADIATED EMISSION TEST ..................................................................................................... 11 4.1 Test Equipment ......................................................................................................................... 11 4.2 Block Diagram of Test Setup ................................................................................................... 11 4.3 Radiated Emission Limit [FCC Part 18 Subpart C 18.305(b)]................................................. 12 4.4 Test Configuration .................................................................................................................... 13 4.5 Operating Condition of EUT .................................................................................................... 13 4.6 Test Procedures ........................................................................................................................ 13 4.7 Test Results .............................................................................................................................. 14 5 DEVIATION TO TEST SPECIFICATIONS .............................................................................. 16 Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 3 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14027 TEST REPORT FOR FCC CERTIFICATE Applicant : Freescale Semiconductor, Inc. Manufacturer : Trivo (Taicang) Technologies Co., Ltd. Factory : Trivo (Taicang) Technologies Co., Ltd. EUT Description : Wireless Charger Transmitter (A) Model No. : WCT-5W1COILTX (B) Power Supply : AC100~240V/50-60Hz (C) Test Voltage : AC 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 SUBPART C OCTOBER 2013 AND FCC OST/MP-5:1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 limits both radiated and conducted emissions. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. This report shows that the EUT (M/N: Refer to Sec 2.1) which was tested in 3m anechoic chamber Dec 06, 2013 – Feb 08, 2014 is technically compliance with the FCC official limits also. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Dec 06, 2013 – Feb 08, 2014 Date of Report : Feb 11, 2014 Producer : EMILY ZHU / Assistant Review : DIO YANG / Deputy Manager Signatory : SAMMY CHEN / Deputy Manager Freescale Semiconductor, Inc. FCC ID: RUN-WCT-5W1COILTX Page 4 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F14027 1 SUMMARY OF STANDARDS AND RESULTS 1.1 Description of Standards and Results The …

Text truncated - open the document above for the full version.
