RUNWCT-15W1COILTXQi medium power wireless charger

Freescale Semiconductor Document Number: WCT1012SYSUG User Guide Rev. 2, 1/2015 © Freescale Semiconductor, Inc., 2014. All rights reserved. _______________________________________________________________________ WCT- 15W1COILTX User Guide 1 Introduction This document describes how to use 15W medium power wireless charger transmitter WCT-15W1COILTX designed by Freescale. Figure-1 WCT-15W1COILTX Contents 1 Introduction 1 2 System Features 2 3 Getting Started 2 4 Cautions 3 WCT-15W1COILTX Reference Design System User Guide, Rev. 2 2 Freescale Semiconductor 2 System Features The WCT-15W1COILTX reference board has following features: • Compliant with WPC Qi specifications to support up to15W power transfer. • Compliant with WPC low power (5W) specification. • Integrated digital demodulation in chip. • Supports two-way communication, transmitter to receiver by FSK and receiver to transmitter by ASK. • Support multiple types RX modulation signals (AC capacitor, AC resistor and DC resistor). • Support low power FOD. • Super low standby power by Freescale touch technology. • Support various power control techniques: frequency control, duty cycle control, phase shift control and topology switch. • LED for RX and TX alignment indication. • Input voltage/current, coil current sensing for protection. • Free position charging. 3 Getting Started WCT-15W1COILTX is easy to use, and can convenience to charging the mobile equipment that support the Qi wireless charging, below is the detail step to power up the system and use. Step 1: power on the Transmitter, plug the 12V adaptor to the AC power line, and plug the adaptor output port to the transmitter input port, and the LED D4 will be blanking. Figure-2 WCT-15W1COILTX powered on Step 2: Place the wireless charging RX or some equipment that support the Qi wireless charger (such as cell phone, battery and so on) on the WCT-15W1COILTX’s coil surface, then the transmitter will charge WCT- 15W1COILTX User Guide Freescale Semiconductor 3 the equipment, under the normal charging states, LED D4 will be turned on all the time, and LED D3 will be blanking, and the RX will powered on the equipment normally. Figure-3 WCT-15W1COILTX charging the equipment Others Indicates: when the Transmitter get the end power communication information, it will stop the charging and wait until the RX is removed, under this state LED D3 will be turned off, and LED D4 will be turned on all the time. When some fault found, the transmitter will turn off LED D4, and turn on LED D3 until the fault is removed, fault include the FOD fault, OVP, OTP and so on. 4 Cautions • This device has been tested and found to comply with the limits pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. • If this equipment does cause harmful interference to other electronic equipments, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the equipment • Increase the separation WCT-15W1COILTX Reference Design System User Guide, Rev. 2 4 Freescale Semiconductor • In order to use the equipment safely，please don’t open the case when powered on，and don’t touch the PCB and components with hand. • Don’t place some metal things between the TX surface and the RX surface, otherwise the metal things will be heated, it the temperature is too high, the Transmitter will shut down for protection. This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Document Number: WCT1101SYSUG Rev. 2 11/2014 How to Reach Us: Home Page: www.freescale.com Web Support: www.freescale.com/support Information in this document is provided solely to enable system and software implementers to use Freescale products. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits based on the information in this document. Freescale reserves the right to make changes without further notice to any products herein. Freescale makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does Freescale assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. “Typical” parameters that may be provided in Freescale data sheets and/or specifications can and do vary in different applications, and actual performance may vary over time. All operating parameters, including “typicals,” must be validated for each customer application by customer’s technical experts. Freescale does not convey any license under its patent rights nor the rights of others. Freescale sells products pursuant to standard terms and conditions of sale, which can be found at the following address: freescale.com/SalesTermsandConditions. Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. ©2013 Freescale Semiconductor, Inc.

2015年2月28日OET Inquiry System Inquiry Tracking Number 747977 file:///C:/Users/Sammy-Chen/Downloads/OET%20Inquiry%20System%20Inquiry%20Tracking%20Number%20747977.htm1/3 Search|RSS |Updates |E-Filing |Initiatives |Consumers |Find People Office of Engineering and Technology FCC > FCC E-filing > Inquiry System Home Page > View InquiryFCC Site Map OET Home Page Site Options Basic KDB Search Advanced KDB Search Submit an Inquiry Reply to an Inquiry Response Category List FAQ Search Major Guidance Publications Draft Laboratory Division Publications Draft Laboratory Division Publications (Expired) Draft Publication Moderation Policy Related Sites Equipment Authorization Presentations Equipment Authorization System (EAS) Telecommunications Certification Bodies (TCB) Measurement Procedures Reply to an OET Inquiry Response Currently Displaying Inquiry Tracking Number: 747977 Contact Information: Customer First Name:Sammy Customer Last Name:Chen Telephone Number: 0086-21-64955500 Extension: E-mail Address: [email protected] Address: Line 1: Line 2: P.O. Box: City: State: Zip Code: Country: Inquiry Details on 01/04/2015: First category: RF Exposure * Second category: Test Procedures (RF Exposure) Third category: Subject:RF exposure evaluation for wireless charger Inquiry:Dear Sir I'd like to know if RF exposure evaluation is necessary for the wireless charging product below, and what the test requirements are if it is necessary: detail information of the product: 1.complete product description: There’s only single primary coil. There are 9 turns for each coil. About 3A capability for each coil. see attached please 2.the rule part(s) the device will operate in: FCC Part 18 3.planned equipment authorization procedure: FCC Certification 4.drawings: see attached please 5.frequencies: 110-205kHz 6. power: 15W rated 7.operating configurations: ? The product will be used on the desktop normally. The coupling surface area of the device is about 7cm^2) The EUT consists of two main major functional units, namely Power Conversion Unit and a Communications and Control Unit. - The Power Conversion Unit mainly comprises full bridge Inverter. The Inverter converts the DC input to an AC waveform that drives a resonant circuit. - The Communications and Control Unit comprises the digital logic part of the EUT. This unit receives and decodes unidirectional messages from the Power Receiver, configures the Coil Selection block to connect the appropriate Primary Coil, executes the relevant power control algorithms and protocols, and drives the frequency of the AC waveform to control the power transfer. Meantime the transmitter sends the messages to power receiver by FSK. I'd like to know if RF exposure evaluation is necessary and what the test requirements are if it is. Thank you. ---Reply from Customer on 01/07/2015--- 2015年2月28日OET Inquiry System Inquiry Tracking Number 747977 file:///C:/Users/Sammy-Chen/Downloads/OET%20Inquiry%20System%20Inquiry%20Tracking%20Number%20747977.htm2/3 Dear Sir, send attachment again FCC Response on 01/07/2015: Please answer the following questions: 1. Does this EUT utilizing an existing wireless power transfer specification? If so, which one? 2. Can you discuss how many receivers are capable of being charged from this device simultaneously? 3. The maximum output is 15W. Does this imply that a single receiver may receive 15W? If so, can you give examples of such receivers? ---Reply from Customer on 01/09/2015--- Dear Sir, Please check the following comments 1. Does this EUT utilizing an existing wireless power transfer specification? If so, which one? Yes, the EUT utilizes QI specification(Wireless Power Transfer Volume II: Medium Power). 2. Can you discuss how many receivers are capable of being charged from this device simultaneously? The EUT has only one primary coil and charge only one device simultaneously. 3. The maximum output is 15W. Does this imply that a single receiver may receive 15W? If so, can you give examples of such receivers? The EUT can used to charge medium power wireless receiver and receiver can receive up to 15W output power. For example, AVID QI Receiver Simulator attached can receive 15W output power. Thank you! FCC Response on 01/09/2015: Consistent with KDB Publication 680106 D01, this EUT will require an RF exposure evaluation report due to non-compliance with Section 5 of the aforementioned publication. Per Section 3(3), this EUT should be measured on all sides (including top) using an isotropic field probe under maximum power transfer conditions. Evaluation should be conducted assuming a user separation distance of 10 cm. Please provide documentary evidence that the E and H field measurements are taking place under maximum power transfer conditions. ---Reply from Customer on 01/14/2015--- Dear Sir, Please review the RF exposure report. The report is attached. Thank you FCC Response on 01/14/2015: Please clarify how the EUT was configuration for maximum power transfer during the testing process (i.e. what was power input into the EUT, was a dummy load used, etc.). ---Reply from Customer on 01/15/2015--- Dear Sir, I have retest with full load. Power input the EUT is 22W. The report has been updated. Thank you FCC Response on 01/15/2015: This EUT may be processed according to normal procedures by a TCB, if certification is required; or a recognized laboratory, if Declaration of Conformity is appropriate. Attachment List: Load Receiver picture of the product Enter any additional comments below: *(This is a text only field. Users will be able to upload attachments after clicking on the "Proceed" button 2015年2月28日OET Inquiry System Inquiry Tracking Number 747977 file:///C:/Users/Sammy-Chen/Downloads/OET%20Inquiry%20System%20Inquiry%20Tracking%20Number%20747977.htm3/3 below) <BODY> Proceed Clear Please use the Submit Inquiry link at www.fcc.gov/labhelp to send any comments or suggestions for this site Federal Communications Commission 445 12th Street, SW Washingt…

Text truncated - open the document above for the full version.

Freescale Semiconductor, Inc. 6501 William Cannon Drive West MD: OE58, Austin, TX 78735 www.freescale.com Authority to Act as Agent Date: 02/27/2015 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Re: Obtaining FCC ID for Freescale Semiconductor, Inc.’s (Freescale) product WCT-15W1COILTX Audix Technology (Shanghai) CO., Ltd. is authorized to act as agent for Freescale Semiconductor, Inc. in connection with the above-referenced action. This authority is limited to actions required in order for Audix Technology (Shanghai) CO., Ltd. to obtain FCC ID RUNWCT-15W1COILTX for Freescale product WCT-15W1COILTX. This authority does not extend to any other matters Freescale may have before the Commission. I certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Attached to this letter is Freescale’s request that the designated sections of its application for FCC ID RUNWCT-15W1COILTX be permanently treated as confidential and not disclosed publicly. Thank you. By: __________________________ R.N. Fielding Title: Director, Governmental and Regulatory Affairs On behalf of: Freescale Semiconductor Inc. Telephone: 512-895-3289 Encl.: a/s

Freescale Semiconductor, Inc. 6501 William Cannon Drive West MD: OE58, Austin, TX 78735 www.freescale.com Request for Confidentiality Date: 02-27-2015 Subject: Confidentiality Request for: Freescale product WCT-15W1COILTX to receive FCC ID RUNWCT-15W1COILTX Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual The applicant requests the exhibits checked above as permanently confidential be permanently withheld from public disclosure as the materials contain trade secrets and proprietary information not customarily released to the public. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” Freescale Semiconductor, Inc. 6501 William Cannon Drive West MD: OE58, Austin, TX 78735 www.freescale.com 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: __________________________ R.N. Fielding, Director, Regulatory & Governmental Affairs 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details.

FIGURE 1 QI MEDIUM POWER WIRELESS CHARGER (M/N: WCT-15W1COILTX) GENERAL APPEARANCE (FRONT VIEW) FIGURE 2 Q I MEDIUM POWER WIRELESS CHARGER (M/N: WCT-15W1COILTX) GENERAL APPEARANCE (BACK VIEW)

Label Location Information Refer to the below red arrow: (For example)

FIGURE 1 QI MEDIUM POWER WIRELESS CHARGER (M/N: WCT-15W1COILTX) COVER REMOVED FIGURE 1 QI MEDIUM POWER WIRELESS CHARGER (M/N: WCT-15W1COILTX) GENERAL APPEARANCE (FRONT VIEW) FIGURE 2 Q I MEDIUM POWER WIRELESS CHARGER (M/N: WCT-15W1COILTX) BACK VIEW

Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 1 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15016 Prepared For : Freescale Semiconductor, Inc. Corporate Headquarters, 6501 William Cannon Drive West Austin, Texas 78735 USA Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai 200233, China Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F15016 Date of Test : Jan 14, 2015 Date of Report : Jan 15, 2015 Application for FCC Certification On behalf of Freescale Semiconductor, Inc. Product Name: Qi medium power wireless charger Model No.: WCT-15W1COILTX FCC ID: RUNWCT-15W1COILTX (RF Exposure Report) Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 2 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15016 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 4 1.1 Description of Standards and Results ......................................................................................... 4 2 GENERAL INFORMATION .......................................................................................................... 5 2.1 Description of Equipment Under Test ........................................................................................ 5 2.2 Description of Test Facility ........................................................................................................ 6 3 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 7 3.1 Test Equipment ........................................................................................................................... 7 3.2 Test Setup ................................................................................................................................... 7 3.3 Applicable Standard ................................................................................................................... 7 3.4 Specification Limits ................................................................................................................... 8 3.5 Operating Condition of EUT ...................................................................................................... 8 3.6 Test Result .................................................................................................................................. 9 Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 3 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15016 TEST REPORT FOR HUMAN EXPOSURE Applicant : Freescale Semiconductor, Inc. Manufacturer : Freescale Semiconductor (China) Limited Suzhou Branch Factory : Trivo (Taicang) Technologies Co., Ltd. EUT Description : Qi medium power wireless charger (A) Model No. : WCT-15W1COILTX (B) Power Supply : DC 12V (C) Test Voltage : AC 120V/60Hz(with adaptor) Test Procedure Used: FCC RULES AND REGULATIONS PART 1 SECTION 1.1310 and KDB 680106 D01 v02 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the RF Exposure levels emanating from the device. The RF Exposure levels are compared to the FCC Part 1.1310. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. This report also shows that the EUT (M/N: WCT-15W1COILTX), which was tested on Jan 14, 2015 is technically compliance with the FCC limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Jan 14, 2015 Date of Report : Jan 15, 2015 Producer : ALAN HE / Assistant Review : SAMMY CHEN / Deputy Manager Signatory : BYRON KWO/Assistant General Manager Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 4 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15016 1 SUMMARY OF STANDARDS AND RESULTS 1.1 Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below: Description of Test Item Standard Limits Results RF Exposure FCC RULES AND REGULATIONS PART 1.1310 AND KDB 680106 D01 V02 1.1310 Pass Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 5 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15016 2 GENERAL INFORMATION 2.1 Description of Equipment Under Test Description : Qi medium power wireless charger Model Number : WCT-15W1COILTX Type of EUT :  Production  Pre-product  Pro-type Charge Freq. : 110-205 kHz Applicant : Freescale Semiconductor, Inc. Corporate Headquarters, 6501 William Cannon Drive West Austin, Texas 78735 USA Manufacturer : Freescale Semiconductor (China) Limited Suzhou Branch No. 288 Zhuyuan Road, Suzhou New District Factory : Trivo (Taicang) Technologies Co., Ltd. Building A10, Taicang Foreign Industry Park, No.105 East Shanghai Road, Taicang, Jiangsu, P.R.China. 2.2 Peripherals 2.2.1 Adapter Manufacturer : SCEPTRE POWER Model Number : PS-12030APL05 Input : 100-240V~, 47-63Hz 1.0A Output : 12.0V 3.0A Output Cable : Unshielded, Undetachable, 0.9m, with one core (Core: TC5B, 17*7*30mm, Three Core Electronics Co., Ltd.) 2.2.2 Qi Receiver Simulator (board with resistance) Manufacturer : AVID Technologies, Inc. Model Number : 102-03(501) Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 6 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15016 2.3 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Mar 16, 2012 Renewed Federal Communications Commission FCC Engineering Laboratory 7435 Oakland Mills Road Columbia, MD 21046, USA Name of Firm : Audix Technology (Shanghai) Co., Ltd. Si…

Text truncated - open the document above for the full version.

Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 1 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15017 Prepared For : Freescale Semiconductor, Inc. Corporate Headquarters, 6501 William Cannon Drive West Austin, Texas 78735 USA Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F and 4F, 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai 200233, China Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F15017 Date of Test : Jan 08, 2015 Date of Report : Jan 16, 2015 Application for FCC Certificate On Behalf of Freescale Semiconductor, Inc. Qi medium power wireless charger Model No.: WCT-15W1COILTX FCC ID : RUNWCT-15W1COILTX Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 2 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15017 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 4 1.1 Description of Standards and Results ......................................................................................... 4 2 GENERAL INFORMATION .......................................................................................................... 5 2.1 Description of Equipment Under Test ........................................................................................ 5 2.2 Peripherals .................................................................................................................................. 6 2.3 Description of Test Facility ........................................................................................................ 6 2.4 Measurement Uncertainty .......................................................................................................... 6 3 CONDUCTED EMISSION TEST .................................................................................................. 7 3.1 Test Equipment ........................................................................................................................... 7 3.2 Block Diagram of Test Setup ..................................................................................................... 7 3.3 Conducted Emission Limit [FCC Part 18 Subpart C 18.307(b)] ............................................... 8 3.4 Test Configuration ...................................................................................................................... 8 3.5 Operating Condition of EUT ...................................................................................................... 8 3.6 Test Procedures .......................................................................................................................... 8 3.7 Test Results ................................................................................................................................ 9 4 RADIATED EMISSION TEST ..................................................................................................... 11 4.1 Test Equipment ......................................................................................................................... 11 4.2 Block Diagram of Test Setup ................................................................................................... 11 4.3 Radiated Emission Limit [FCC Part 18 Subpart C 18.305(b)]................................................. 12 4.4 Test Configuration .................................................................................................................... 13 4.5 Operating Condition of EUT .................................................................................................... 13 4.6 Test Procedures ........................................................................................................................ 13 4.7 Test Results .............................................................................................................................. 14 5 DEVIATION TO TEST SPECIFICATIONS .............................................................................. 16 Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 3 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15017 TEST REPORT FOR FCC CERTIFICATE Applicant : Freescale Semiconductor, Inc. Manufacturer : Freescale Semiconductor (China) Limited Suzhou Branch Factory : Trivo (Taicang) Technologies Co., Ltd. EUT Description : Qi medium power wireless charger (A) Model No. : WCT-15W1COILTX (B) Power Supply : DC 12V (C) Test Voltage : AC 120V/60Hz (with adaptor) Test Procedure Used: FCC RULES AND REGULATIONS PART 18 SUBPART C OCTOBER 2013 AND FCC OST/MP-5:1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 limits both radiated and conducted emissions. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. This report shows that the EUT (M/N: Refer to Sec 2.1) which was tested in 3m anechoic chamber Jan 08, 2015 is technically compliance with the FCC official limits also. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Jan 08, 2015 Date of Report : Jan 16, 2015 Producer : ALAN HE / Assistant Review : SAMMY CHEN / Deputy Manager Signatory : BYRON KWO/Assistant General Manager Freescale Semiconductor, Inc. FCC ID: RUNWCT-15W1COILTX Page 4 of 16 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F15017 1 SUMMARY OF STANDARDS AND RESULTS 1.1 Description of Standards a…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test F RONT VIEW S IDE VIEW 2. Radiated Electromagnetic Emission Test (9kHz to 30MHz) HORIZONTAL POLARIZATION VERTICAL POLARIZATION 3. Radiated Electromagnetic Emission Test (30MHz to 1000MHz) FRONT VIEW OF RADIATED EMISSION TEST BACK VIEW OF RADIATED EMISSION TEST
