RV7-SD1087SkyExtender and SkyGateway units

Trilliant Networks, Inc.
SkyExtender and SkyGateway units - FCC ID RV7-SD1087 - Trilliant Networks, Inc.
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Nov 01, 2007
Application Purpose
Original Equipment
Date of Application
Nov 01, 2007
Equipment Note
SkyExtender and SkyGateway units
Frequency Range
4950.00000000 - 4980.00000000
Company
Trilliant Networks, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗
↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

SkyPilot SkyGateway/SkyExtender Installation Contents Contents 3 About This Guide 5 Audience and Purpose 6 How This Guide Is Organized 6 Conventions Used in This Guide 7 Introduction 9 Solution Overview 10 Mesh Network 10 SkyGateway 12 SkyExtender Devices 12 SkyConnector and SkyAccess DualBand 13 Your SkyGateway/SkyExtender Kit 15 Kit Contents 16 What Else You Need 17 Installing and Configuring the SkyGateway/SkyExtender 19 Planning your Installation 20 SkyGateway Installation 21 SkyExtender Installation 21 GPS and the SkyGateway/SkyExtender 21 Mounting 22 Cabling 23 Attaching Antennas 30 Powering Up 32 Making Power and Network Connections 32 Monitoring the Power-On Sequence 36 Configuring the SkyGateway/SkyExtender 40 Accessing the Command-Line Interface 41 Troubleshooting 41 Grounding Guidelines 43 General Grounding Strategy 43 Making Connections “Gas-Tight” 44 Checking Cold-Water Pipe Integrity 45 Measuring Resistance 45 Adding Surge Protection 45 Grounding Checklist 46 FCC Statements 47 FCC Class A Notice 47 FCC Class B Notice Error! Bookmark not defined. The SkyPilot SkyAccess DualBand Installation and Setup Guide 4 Maximum Permissible Exposure 47 IC RSS-210 statements 48 About This Guide This guide explains how to install and set up a SkyPilot™ SkyGateway™, SkyExtender™, SkyExtender DualBand, or SkyExtender TriBand device to provide wireless network access to users of a SkyPilot wireless mesh network. It assumes administrator-level knowledge of IP networks and a familiarity with configuring wireless devices. Chapter Highlights • Audience and purpose • How this guide is organized • Conventions used in this guide SkyPilot SkyAccess DualBand Installation 6 Audience and Purpose This guide provides directions for installing and setting up a SkyPilot SkyGateway, SkyExtender, SkyExtender DualBand, or SkyExtender TriBand device that can provide access to users of a SkyPilot wireless mesh network. This guide assumes administrator-level knowledge of IP networks and a familiarity with configuring wireless devices. How This Guide Is Organized This guide is organized as follows: • Chapter 1, “Introduction,” provides an overview of the SkyPilot Networks solution, describes the SkyPilot devices, and then illustrates how they combine to form a mesh network. • Chapter 2, “Your SkyGateway/SkyExtender Kit,” provides the information you need before you begin your installation. • Chapter 3, “Installing and Configuring the SkyGateway/SkyExtender,” provides instructions for the physical installation of the SkyGateway or SkyExtender as well as background information about configuration and references to associated procedures. • Appendix A, “Grounding Guidelines,” provides direction on protecting your SkyPilot device with proper grounding and surge protection. • Appendix B, “FCC Statements,” provides the FCC radio frequency interference statements for the SkyGateway and SkyExtender devices.. • Appendix C, “Pinouts,” provides pinouts for connectors and adapters to connect to the Ethernet interface port labeled “CPE” on the SkyGateway/SkyExtender power injector and the device’s serial interface.. SkyPilot SkyAccess DualBand Installation 7 Conventions Used in This Guide This section describes the text and syntax conventions used throughout this guide. Text Conventions This guide uses the following text conventions: • Italic is used to introduce new terms. • Bold is used to indicate what you click or type in a graphical user interface (for example, commands names or text being entered). In examples showing user interaction with the command-line interface, bold is used to indicate user input as opposed to command output. • A monospace font is used for code elements (variable names, data values, function names, and so forth), command lines, scripts, and source code listings. • Italic-monospace is used for replaceable elements and placeholders within code listings. Syntax Conventions This guide uses the following conventions when showing syntax: • Angle brackets, “<“ and “>”, enclose mandatory elements. You must enter these elements. For example: ping <IP-address> • Square brackets, “[“ and “]”, enclose optional elements. You can omit these elements. For example: show filter [filter-table-number] Square brackets are also used to show the current value of parameters in the output of some commands. • A vertical bar, “|”, separates choices. For example: show bridge [cache | port] SkyPilot SkyAccess DualBand Installation 9 Introduction This chapter provides an overview of the SkyPilot Networks solution, describes the SkyPilot devices, and then illustrates how they combine to form a mesh network. Chapter Highlights • Solution overview • Mesh network • SkyGateway • SkyExtender devices • SkyConnector 1 SkyPilot SkyAccess DualBand Installation 10 Solution Overview SkyPilot Networks delivers a wireless, end-to-end broadband solution that seamlessly supports high-capacity, high-coverage mesh networks. Designed for managed-access networks and service providers, the SkyPilot network takes broadband wireless the “last mile” with a cost- effective, robust infrastructure solution. Based on a high-performance architecture that deploys intelligent antenna arrays, the SkyPilot network delivers a dynamic broadband solution with significant advantages for business and home users. SkyPilot wireless devices are simple to install and easily fit into any type of wireless environment—metropolitan, business, or home. The auto-discovery and rapid provisioning features of a SkyPilot wireless mesh network can greatly reduce deployment and maintenance costs. Multiple topology options and network scalability create intriguing options for rapidly expanding a metro Wi-Fi customer base. SkyPilot devices’ multiple antenna configurations work within mixed- use environments of municipal applications and broadband Internet access, supporting public-private partnerships such as public safety services. Mesh Network The typical configuration for a SkyPi…

Text truncated - open the document above for the full version.

Users Manual

SkyPilot SkyAccess DualBand Installation 1 SkyPilot SkyGateway/SkyExtender SkyPilot SkyAccess DualBand Installation 2 Specifications This appendix provides technical specifications for the SkyPilot SkyGateway/SkyExtender Radios, Antennas, and Security 5 GHz mesh backhaul 802.11b/g AP Frequency band 4.960-4.980 GHz (center freq) 2.400-2.483 GHz Antennas 8-antenna array (360° coverage), Each antenna: 45° horizontal x 6° vertical, 17 dBi 1 external 7.4 dBi omnidirectional antenna EIRP 6.5W / 38.35 dBm peak EIRP 400 mW / 26 dBm radio Æ 2.2 W / 33.4 dBm EIRP Media access Time Division Duplex (TDD) IEEE 802.11b/g CSMA/CA Wireless Connectivity SkyGateways, SkyExtenders, and SkyConnectors IEEE 802.11b/g Wi-Fi clients Modulation technique OFDM OFDM (802.11g) DSSS (802.11b) Modulation rates 6 to 54 Mbps 802.11b: 1 to 11 Mbps 802.11g: 6 to 54 Mbps C SkyPilot SkyAccess DualBand Installation 3 Throughput Up to 20 Mbps UDP / up to 12 Mbps TCP Latency 10-12 ms roundtrip per hop Channel width 20 MHz 20 MHz Channel resolution 5 MHz frequency control 5 MHz frequency control Receive sensitivity -90 dBm at 6 Mbps modulation -98 dBm at 1 Mbps modulation Authentication MD5-based certificates RADIUS support for multiple servers 802.1x Encryption 128-bit AES encryption on all wireless links WEP, Dynamic WEP, & WPA (EAP- TTLS, EAP-PEAP/MSCHAPv2 with TKIP) Physical Specifications Connectors RJ-45: power & Ethernet (Power over Ethernet) RJ-45: RS-232 serial for local management Mounting Tower, utility pole, lampposts, building, or other infrastructure LEDs Wireless activity, wireless link Dimensions 33.0” (83.8 cm) H x 12.2” (31.0 cm) diameter Weight 15.0 pounds (6.75 kg) Operating temperature -40° to 131° F (-40° to 55° C) Wind loading Up to 100 mph (160 km/h) SkyPilot SkyAccess DualBand Installation 4 Enclosure/humidity NEMA-4X Power 110VAC, 50-60 Hz input; 11 Watts typical - 35 W Peak Certifications FCC Part 15/90, FCC 47 CFR Part 15, Class A USA; compliance with UL safety standards EMI and susceptibility FCC Part 15.107 and 15.109 SkyPilot SkyAccess DualBand Installation 5

Cover Letter(s)

© 2006 SkyPilot Networks, Inc. 2055 Laurelwood Road All rights reserved. Proprietary and Confidential. Santa Clara, CA 95054 1+408.764.8000 www.skypilot.com October 18, 2007 Attn: Reviewing Engineer MET Laboratories, Inc. 914 West Patapsco Ave, Baltimore, MD 21230 Re: Request for Confidentiality Applicant: SkyPilot Networks, Inc. FCC ID: FCC - RV7-SD1087 To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are request to be kept confidential: Schematics Block diagrams Operational description BOM/Part Lists Rationale for the request for confidentiality: SkyPilot Networks, Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. Please contact me if there is any information you may need. Sincerely, William G. Olsen, Director of RF Hardware

ID Label/Location Info

Frequency FCC ID: RV7-SD1087 BH : 4.950 – 4.980 GHz IC:5550A-SD1087 AP1: AP2: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Frequency FCC ID: RV7-SD1087 BH : 4.950 – 4.980 GHz IC:5550A-SD1087 AP1: AP2: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

ID Label/Location Info

14 3X 12 16 6 8 911 13 13 7 D C B A A B C D SkyPilot Networks Inc. 2055 Laurelwood Road Santa Clara, CA 95054 SCALE SIZE CAD FILE: DWG. NO. B SHEET 2 OF 3 REV. 1 2 3 4 5 6 7 8 8 7 6 5 4 32 1 705-00012-05R 4 TLA, SkyExtender DualBand 705-00012-05R 1:3

RF Exposure Info

Electromagnetic Compatibility SkyPilot Networks Intentional Radiators SkyExtender and SkyGateway units (RV7-SD1087) CFR Title 47, Part 90, Subpart Y & Part 15 Subpart B MET Report: EMCS80384-FCC22 © 2007, MET Laboratories, Inc. RF Exposure Requirements RF Exposure Requirements: §90.1217, §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 4940-4990 MHz ; highest conducted power = 21.35dBm (peak) therefore, Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 EUT maximum antenna gain = 18dBi. Equation from page 18 of OET 65, Edition 97-01 EUT with 18dBi Antenna S = PG / 4πR 2 or R = √PG / 4πS where, S = Power Density (1 mW/cm 2 ) P = Power Input to antenna (136.45mW) G = Antenna Gain (63.09 numeric) R = (136.45*63.09/4*3.14) 1/2 = (8609.155/12.56) 1/2 = 26.1cm _ in order to comply with 1 mW/cm 2

Test Report

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 33439 WESTERN AVENUE ! UNION CITY, CALIFORNIA 94587 ! PHONE (510) 489-6300 ! FAX (510) 489-6372 DOC-EMC700 7/9/04 Electromagnetic Compatibility Criteria Test Report For the SkyPilot Networks Model SkyExtender and SkyGateway units (RV7-SD1087) Tested under The FCC Verification Rules Contained in Title 47 of the CFR, Part 90, Subpart Y for Private Land Mobile Radio Services and Part 15, Subpart B for a Class A Digital Device MET Report: EMCS80384-FCC90 October 16, 2007 Prepared For: SkyPilot Networks 2055 Laurelwood Road, 2nd Fl Santa Clara, CA 95054 Prepared By: MET Laboratories, Inc. 4855 Patrick Henry Dr., Building 6 Santa Clara, CA 95054 Electromagnetic Compatibility SkyPilot Networks Cover Page SkyExtender and SkyGateway units (RV7-SD1087) CFR Title 47 Part 90 Subpart Y & Part 15 Subpart B MET Report: EMCS80384-FCC90 © 2007, MET Laboratories, Inc. Page ii of vi DOC-EMC700 7/9/04 Electromagnetic Compatibility Criteria Test Report For the SkyPilot Networks Model SkyExtender and SkyGateway units (RV7-SD1087) Tested under The FCC Verification Rules Contained in Title 47 of the CFR, Part 90, Subpart Y for Private Land Mobile Radio Services and Part 15, Subpart B for a Class A Digital Device MET Report: EMCS80384-FCC90 Shawn McMillen Jennifer Sanchez Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is / is not capable of operation in accordance with the requirements of Part 90, Subpart Y and Part 15, Subpart B of the FCC Rules under normal use and maintenance. Tony Permsombut, Lab Manager Electromagnetic Compatibility Lab Electromagnetic Compatibility SkyPilot Networks Report Status SkyExtender and SkyGateway units (RV7-SD1087) CFR Title 47 Part 90 Subpart Y & Part 15 Subpart B MET Report: EMCS80384-FCC90 © 2007, MET Laboratories, Inc. Page iii of vi DOC-EMC700 7/9/04 Report Status Sheet Revision Report Date Reason for Revision ∅ October 16, 2007 Initial Issue. Electromagnetic Compatibility SkyPilot Networks Terms and Abbreviations SkyExtender and SkyGateway units (RV7-SD1087) CFR Title 47 Part 90 Subpart Y & Part 15 Subpart B MET Report: EMCS80384-FCC90 © 2007, MET Laboratories, Inc. Page iv of vi DOC-EMC700 7/9/04 Table of Contents 1. Executive Summary .................................................................................................................................................... 1 1.1. Testing Summary ................................................................................................................................................... 2 2. Equipment Configuration........................................................................................................................................... 3 2.1. Overview................................................................................................................................................................ 4 2.2. Test Site ................................................................................................................................................................. 5 2.3. Description of Test Sample .................................................................................................................................... 5 2.4. Equipment Configuration....................................................................................................................................... 6 2.5. Support Equipment ................................................................................................................................................ 6 2.6. Ports and Cabling Information ............................................................................................................................... 7 2.7. Method of Monitoring EUT Operation ................................................................................................................ 10 2.8. Modifications ....................................................................................................................................................... 10 2.8.1. Modifications to EUT ....................................................................................................................... 10 2.8.2. Modifications to Test Standard ......................................................................................................... 10 2.9. Disposition of EUT .............................................................................................................................................. 10 3. Electromagnetic Compatibility Criteria for Unintentional Radiators ................................................................. 11 3.1. Conducted Emissions Limits................................................................................................................................ 12 3.2. Radiated Emissions Limits................................................................................................................................... 16 4. Electromagnetic Compatibility Criteria for Intentional Radiators ...................................................................... 19 4.1. Peak Power Output............................................................................................................................................... 23 5. Electromagnetic Compatibility Occupied Bandwidth Requirements...................................................................26 5.1. Occupied Bandwidth (Emission Masks) .....................…

Text truncated - open the document above for the full version.

Test Setup Photos

Electromagnetic Compatibility SkyPilot Networks Unintentional Radiators SkyExtender and SkyGateway units (RV7-SD1087) CFR Title 47 Part 90 Subpart Y & Part 15 Subpart B MET Report: EMCS80384-FCC22 © 2007, MET Laboratories, Inc. Conducted Emission Limits Test Setup Conducted Emissions Test Setup Electromagnetic Compatibility SkyPilot Networks Unintentional Radiators SkyExtender and SkyGateway units (RV7-SD1087) CFR Title 47 Part 90 Subpart Y & Part 15 Subpart B MET Report: EMCS80384-FCC22 © 2007, MET Laboratories, Inc. Radiated Emission Limits Test Setup Radiated Emission Limits Test Setup Electromagnetic Compatibility SkyPilot Networks Intentional Radiators SkyExtender and SkyGateway units (RV7-SD1087) CFR Title 47, Part 90, Subpart Y & Part 15 Subpart B MET Report: EMCS80384-FCC22 © 2007, MET Laboratories, Inc. Radiated Emissions Spurious Test Setup Radiated Emission Spurious Test Setup

Contact Information

Applicant

Daniel Tousignant(Certification & Compliance Eng.)
[email protected]1-450-915-1631Fax: 1-450-375-8746

Technical Contact

MET Laboratories, Inc.Shawn McMillen
[email protected]410-949-1914

914 W. Patapsco Ave · Baltimore, Maryland · United States

Non-Technical Contact

MET Laboratories, Inc.Jennifer Sanchez
[email protected]408-213-2359

Test Firm

MET LaboratoriesAlvin Ilarina
[email protected]408-919-3774Fax: 1234567890

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
1904.95 GHz - 4.98 GHz136.00 mW16MG7D0.0310000000 ppm
Confidentiality
Long Term
Grant Notes
Power Output Listed is peak Conducted. The antenna(s) used for this transmitter must be with a separation distance of at least 26.1 cm from all persons during normal operation. Operation is for use in the 4.9 GHz licensed band for point to point or point to multi point operation. The maximum antenna gain must not exceed 18dBi and must not be co-located or operating in conjunction with any other antenna or transmitter. End Users and Installers must be provided with antenna installation instructions and transmitter operation conditions for satisfying RF exposure compliance.
