RX2C2GWSU13RFID Reader

Marelli Europe S.p.A.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Apr 29, 2013
Application Purpose: Original Equipment
Date of Application: Apr 29, 2013
Equipment Note: RFID Reader
Frequency Range: 13.56000000 - 13.56000000
Company: Marelli Europe S.p.A.
Country: Italy

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Corbetta 23.12.2010 User Manual Statement Letter Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref.: FCC ID: RX2C2GWSU13 Radio equipment authorization by FCC in USA for Car sharing management device Car2Go WSU13 Dear Sirs The car sharing management device will be supplied as an original equipment device to the car manufacturer. According to 47 CFR 15.19 (Labeling requirements) the car manufacturer will print the following text in the appropriate User Manuel of the car: “This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” Sincerely, Magneti Marelli S.p.A.

Cover Letter(s)

Corbetta 05/11/2008 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Magneti Marelli S.p.A. would like the following documents regarding this submission for FCC ID: RX2C2GWSU13 to be kept confidential. . 1. Schematic diagram 2. Block diagram 3. Product description The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Magneti Marelli S.p.A.

Test Report

Test Laboratory: Borsigstr. 11 Germany 7Layers AG 40880 Ratingen Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender h Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr h VAT No.: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com FCC Measurement/Technical Report on C2GWSU13 RFID reader 13.56 MHz Report Reference: MDE_FAKT_1214_FCCc Test report Reference: MDE_FAKT_1214_FCCc Page 2 of 31 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 5 1.1 Testing Laboratory 5 1.2 Project Data 5 1.3 Applicant Data 5 1.4 Manufacturer Data 5 2 Test object Data 6 2.1 General EUT Description 6 2.2 EUT Main components 7 2.3 Ancillary Equipment 7 2.4 Auxiliary Equipment 7 2.5 EUT Setups 8 2.6 Operating Modes 8 2.7 Product labelling 8 3 Test Results 9 3.1 Spurious radiated emissions 9 3.2 Occupied bandwidth 14 3.3 Spectrum mask 16 3.4 Frequency tolerance 18 4 Test Equipment 21 5 Photo Report 28 6 Setup Drawings 28 7 FCC and IC Correlation of measurement requirements 29 8 Annex measurement plots 30 8.1 Occupied bandwidth: Reader 1 30 8.2 Occupied bandwidth: Reader 2 31 Test report Reference: MDE_FAKT_1214_FCCc Page 3 of 31 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for an intentional radiator operating at 13.560 MHz Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 (10-1-11 Edition) and 15 (10-1-11 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart C – Intentional Radiators § 15.205 Restricted bands of operation § 15.207 Conducted limits § 15.209 Radiated emission limits; general requirements § 15.215 Additional provisions to the general radiated emission limitations § 15.225 Operation within the band 13.110-14.010 MHz Note: Instead of applying ANSI C63.4–2003 which is referenced in the FCC Public Note, the newer ANSI C63.4–2009 is applied. Summary Test Results: The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. Test report Reference: MDE_FAKT_1214_FCCc Page 5 of 31 1 Administrative Data 1.1 Testing Laboratory Company Name: 7Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716. The test facility is also accredited by the following accreditation organisation: Laboratory accreditation no.: DAkkS D-PL-12140-01-01 Responsible for Accreditation Scope:Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Andreas Petz Dipl.-Ing. Marco Kullik Report Template Version: 2012-03-14 1.2 Project Data Responsible for testing and report: Dipl.-Ing. Carsten Steinröder Date of Test(s): 2012-11-21 to 2013-02-27 Date of Report: 2013-04-16 1.3 Applicant Data Company Name: FAKT S.r.l. Address: Via Lithos, 53 25086 Rezzato (BS) Italy Contact Person: Mr. Nicola Scartapacchio 1.4 Manufacturer Data Company Name: Magneti Marelli Address: V.le A. Borletti, 61/63 20011 Corbetta (MI) Italy Contact Person: please see the applicant data Test report Reference: MDE_FAKT_1214_FCCc Page 6 of 31 2 Test object Data 2.1 General EUT Description Equipment under Test RFID card reader Type Designation: C2GWSU13 Kind of Device: 13.56 MHz card reader Voltage Type: DC (from vehicle power supply) Voltage level: 12 V ± 3 V General product description: The EUT is a 13.56 MHz contactless RFID reader, part of the Signal Acquisition and Control Module Car2Go. The system consists of two main hardware units, the windshield (WSU) and the head unit (HU). Both components are connected via power, control and RF connectors. The power supply for both units is provided by the HU. Both 13.56 MHz transmitters are located in the WSU, their antennas in the HU. Specific product description for the EUT: On the Head Unit a special software was installed which allows to activate the different transmitters. After activating the wanted transmitter the Head Unit was switched off, because it’s active components are not part of the RFID System. The EUT provides the following ports: Ports Enclosure HF port to HU Power and control connector The main components of the EUT are listed and described in Chapter 2.2. Test report Reference: MDE_FAKT_1214_FCCc Page 7 of 31 2.2 EUT Main components Type, S/N, Short Descriptions etc. used in this Test Report Short Description Equipment under Test Type Designation Serial No. HW Status SW Status Date of Receipt EUT A (Code: DA212a01) Windshield Unit C2GWSU13 - PRS2 - - Remark: EUT A is equipped with a passive 125 kHz integral antenna. EUT B Code: DA210a01 Head Unit Car2Go (HU) HPV00LJC PRS4 - - Remark: EUT B is equipped with two passive 13.56 MHz integral antennas NOTE: The short description is used to simplify the identification of the EUT in this test report. 2.3 Ancillary Equipment For the purposes of this test report, ancillary equipment is defined as equipment which is used in conjunction with the EUT to provide operational and control features to the EUT. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Ancillary Equipment can influence the test results. Short Description Equipment under Test Type Designation Serial no. HW Status SW Status FCC ID - - - - - - - 2.4 Auxiliary Equipment For the purposes of this test report, auxiliary equipment is defined as equipment which is used temporarily to enable operational and control features especially used for the tests of the …
