RX2EN2Bluetooth Module

To Whom It May Concern: FCC ID: RX2EN2 IC: 4983A-EN2 The Bluetooth Module “EN2” is for OEM installation only. When integrating the Module into the end product, the final user manual of the end product will include the following statements for FCC approval: The end product has to be labeled as follows: CONTAINS FCC ID: RX2EN2 FCC § 15.19 Labelling requirements This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC § 15.21 Information to user Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure Requirements To comply with FCC RF exposure compliance requirements, the device must be installed to provide a separation distance of at least 20 cm from all persons. The Bluetooth Module “EN2” is for OEM installation only. When integrating the Module in the in the end product, the end product and the final user manual of the end product will include the following statements for Industry Canada approval: The end product has to be labeled as follows: CONTAINS IC: 4983A-EN2 INDUSTRY CANADA Statements Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. RF Exposure Requirements This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Déclaration d’exposition aux radiations: Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. i.A. Signature Abdellah Ahakki on behalf of Magneti Marelli S.p.A. 7Layers AG Viale C. Emanuele II, 150 Borsigstr.11 10078 Venaria 40880 Ratingen ITALY Germany

Bluetooth audio Overview ▷ Playback of music files from external devi‐ ces such as audio devices or mobile phones via Bluetooth is possible. ▷ The sound output is via the vehicle loud‐ speakers. ▷ The volume of the sound output depends on the device. If applicable, change volume set‐ tings on the device. ▷ Up to four external devices can be registered with the vehicle. Requirements ▷ Suitable device. Visit www.bmw.com/blue‐ tooth for more information. ▷ Device ready for operation. ▷ Ignition switched on. ▷ Bluetooth in the vehicle, see page 79, and device activated. ▷ Bluetooth presettings must be made on the device, for example connect without confir‐ mation or visibility, see Owner's Handbook of the device. ▷ A number with a minimum of 4 and a maxi‐ mum 16 positions is specified as the Blue‐ tooth passkey. Only required for non-recur‐ ring registration. ▷ Vehicle is at rest. Connecting Connecting the device Only connect the device when the vehicle is stationary. Otherwise, you may become dis‐ tracted and endanger the vehicle occupants and other road users.◀ 1. "Settings" 2. "Connections" 3. "Bluetooth" 4. "Add new device" The Bluetooth name of the vehicle is dis‐ played in the control display. 5. To perform other operations on the device; see the Owner's Handbook of the device: for example finding/connecting Bluetooth de‐ vice or new device. The Bluetooth name of the vehicle is shown on the display of the device. 6. Select the Bluetooth name of the vehicle on the display of the device. 7. Request using the iDrive or mobile phone to enter the same Bluetooth passkey. Enter and confirm passkey. Or Compare the control number in the vehicle display with the control number in the mo‐ bile phone display. Confirm the control num‐ ber in the mobile phone and on the vehicle. "OK" 8. Select functions for which the device is to be used, for example "Bluetooth audio". 9. "OK" If connection was successful, the device is shown as connected. White symbol: device active as audio source. If connection was unsuccessful: What to do if..., see page 62. Seite 60 EntertainmentExternal devices 60 Online Edition for Part no. 01 40 2 917 877 - II/13 Connecting a certain device An already connected device can be connected as an active audio source. Connection not possible if data is exchanged using a mobile phone equipped with Bluetooth. Requirements If necessary, activate the audio connection of the desired device from the list of connected devices. 1. "Settings" 2. "Connections" 3. "Bluetooth" 4. Call up "Options". 5. "Configure device" 6. "Audio" 7. "OK" Connecting a device 1. "Settings" 2. "Connections" 3. "Bluetooth" 4. Select the device to be connected. White symbol: device active as audio source. Playback General ▷ The following functions are dependent on the device: display of track information, fast forward/rewind, random playback. ▷ Can be operated using the device or iDrive. ▷ Playback is interrupted if data is exchanged using a mobile phone equipped with Blue‐ tooth. Starting play 1. Connecting a device. 2. "Multimedia" 3. "External devices" 4. Select the symbol. Playback is automatically started. Changing the track Not all functions may be available, depending on the device. SymbolFunction Next track Previous title Fast forward/rewind Keep button pressed. Random playback 1. "Multimedia" 2. "External devices" 3. Select the symbol. 4. Call up "Options". 5. "Random" Disconnecting audio connection 1. "Settings" 2. "Connections" 3. "Bluetooth" 4. Highlight the desired device. 5. Call up "Options". 6. "Configure device" Seite 61 External devicesEntertainment 61 Online Edition for Part no. 01 40 2 917 877 - II/13 7. "Audio" 8. "OK" Disconnecting a device 1. "Settings" 2. "Connections" 3. "Bluetooth" 4. Highlight the device to be disconnected. 5. Call up "Options". 6. "Delete device" What to do if... Visit www.bmw.com/bluetooth for more infor‐ mation on compatible devices. Device not supported by the vehicle. ▷ If applicable, perform a software update, see page 62. Device not registered or paired. ▷ Do the Bluetooth passkeys for device and vehicle match. Enter the same passkey on the device and using iDrive. ▷ Duration for passkey input longer than 30 seconds. Repeat the connection at‐ tempt. ▷ Is the mobile phone in power-save mode or is the battery low? Charge the mobile phone using the snap-in adapter or the charging cable. ▷ Is the device no longer responding. Switch the device off and on again. ▷ Repeat the connection attempt. No music can be played back. ▷ Start the program for playing back music files on the device and if necessary, select a track via the device. ▷ Switch the radio off and on again. Music files are played back, but only at low vol‐ ume. ▷ Adjust the volume controls on the device. Playback is disrupted when a button is pressed on the device or if other messages are issued via the device. ▷ Switch off keypad acknowledgement tones and other audio output at the device. Playback is interrupted by phone calls or traffic announcements and does not resume automat‐ ically. ▷ Switch the radio off and on again. Playback is not possible if the mobile phone is connected via Bluetooth Audio and via the USB interface or snap-in adapter at the same time. ▷ Disconnect one of the two pairing connec‐ tions, for example disconnect audio connec‐ tion, see page 61, and restart playback. If all the points on the list have been reviewed and the desired function cannot be run, contact Hotline or Service Centre. Seite 62 EntertainmentExternal devices 62 Online Edition for Part no. 01 40 2 917 877 - II/13 Telephone Vehicle Equipment This chapter describes all standard, national and special equipment provided in the model series. Therefore equipment not available in a vehicle is also described, for example the selected special equipment or national version. That also applies to safety-relevant functions and systems. Principle Mobiles or other external devices, for example audio player, can be connected to the v…

Text truncated - open the document above for the full version.

Antenna Information Antenna Type: External Cableantenna (2.4 GHz) Antenna Connector: Fakra (unique) Max. Gain: -2 dBi Manufacturer: Magneti Marelli Used for Bluetooth and WLAN

0,05,0 10,015,020,025,030,035,0 0 10 20 30 40 50 60 70 80 90 270 280 290 300 310 320 330 340 350 2,40GHz2,44GHz2,48GHzMittelwert BMW Antennenvermessung EI-41Messobjekt:BT Kabelantenne in MALMittelwert: 20,0dBμV 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 Mittelwert

Magneti Marelli S.p.A. Electronic Systems Centro Ricerca e Sviluppo Viale Carlo Emanuele II, 150 10078 Venaria (Torino) Tel. +39 011 68 79 111 Fax +39 011 6879199 Sede Legale: Viale Aldo Borletti 61/63 20011 Corbetta (MI) Cap. Soc. Euro 254.325.965 i.v. Reg. Imp. Milano, Cod. Fisc. e P. IVA 08082990014 R.E.A. Milano n. 1657773 Iscrizione UIC n. 40047 Direzione e coordinamento ex art. 2497 c.c. Fiat S.p.A. Electronic Systems Electronics and Components Entrynav Declaration We, Magneti Marelli S.p.A., declare that the product namedEN2is equivalent to Entrynav, as used in some parts of the documentation. Venaria, April 4 th , 2015 Declared by:_____________________________________ Franco Schinco EMC Manager Magneti Marelli S.p.A. - Infotainment & Telematics

Magneti Marelli S.p.A. Electronic Systems Centro Ricerca e Sviluppo Viale Carlo Emanuele II, 150 10078 Venaria (Torino) Tel. +39 011 68 79 111 Fax +39 011 6879199 Sede Legale: Viale Aldo Borletti 61/63 20011 Corbetta (MI) Cap. Soc. Euro 254.325.965 i.v. Reg. Imp. Milano, Cod. Fisc. e P. IVA 08082990014 R.E.A. Milano n. 1657773 Iscrizione UIC n. 40047 Direzione e coordinamento ex art. 2497 c.c. Fiat S.p.A. Electronic Systems Electronics and Components CommercialPower ofAttorney CommercialPower ofAttorneyfor the type approval/registrationof theproduct EN2 inseveral countries. The company 7 layers, D-40880 Ratingen, has beencontractedby Magneti Marelli S.p.A.to obtain „Radio Type Approvals“ for the following electroniccomponents, manufacturedand released by Magneti Marelli S.p.A.: EN2 Unlessfuturecorrespondencefrom Magneti Marelli S.p.A. directsotherwise,please extend your fullcooperationto 7 layers regarding mattersto the abovementionedproduct through end of the projectdate. Thankyou. Corbetta, 29/4/2015 .................................. Franco Schinco EMC Function Leader

RF_160, Issue 03 Declaration of Authorization We Name:Magneti Marelli S.p.A. Address:Viale A. Borletti, 61/63 City:20011 Corbetta Country:Italy Declare that: Name Representative of agents: Abdellah Ahakki / Carsten Steinröder / Imad Hjije Agent Company name:7Layers AG Address:Borsigstr.11 City:40880 Ratingen CountryGermany is authorized to apply for Certification of the following product(s): Product description: Bluetooth module Type designation:EN2 Trademark:Magneti Marelli on our behalf. Date:13 July 2015 City:Corbetta Name:Giuseppe Bergamaschi Function:BL Electronics Quality Director Signature:. Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Magneti Marelli S.p.A. Address : Viale Aldo Borletti 61/63 City: 20011 Corbetta Country: Italy To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: RX2EN2 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Above materials contain secrets, proprietary and technical information. Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Planned Release Date STC: 180 days (notes 2, 3, 4, 5) Date: 12.05.2015 Name and signature of applicant: Abdellah Ahakki Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Magneti Marelli S.p.A. Model: EN2 FCC ID: RX2EN2 IC: 4983A-EN2 This device complies with Part 15 of the FCC rules subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept all interference received, including interference that may cause undesired operation.

Ref Part Number NO_MOST Des 554551658200 C5119 520361522496 DNI C5212 520361312256 DNI C5409 520961322616 DNI C5410 520961322616 DNI C5636 520961900006 DNI P5600 520901909024520900909035 VAR5601520968060096 DNI VAR5602520968060096 DNI VAR5603520968060096 DNI VAR5604520968060096 DNI VAR5605520968060096 DNI VAR5606520968060096 DNI VAR5607520968060096 DNI VAR5608520968060096 DNI VAR5609520968060096 DNI VAR5610520968060096 DNI VAR5611520968060096 DNI VAR5624520968060096 DNI VAR5625520968060096 DNI VAR5626520968060096 DNI VAR5627520968060096 DNI Common Components List : Ref Part Number Des C5104 520361312256 C5105 520361312256 C5109 520361900846 C5110 520361321536 C5111 520361524736 C5112 520361321536 C5113 520361524736 C5114 520961322616 C5115 520961925046 C5116 520361312216 C5120 520361312256 C5129 520361900846 C5130 520361522496 C5200 520961322616 C5201 520961920396 C5202 520961920396 C5203 520361312256 C5204 520361522496 C5205 520961920396 C5206 520961920396 C5207 520361312256 C5208 520361312256 C5209 520961920566 C5210 520961925046 C5211 520961925046 C5214 520961925046 C5220 520361321536 C5221 520361321536 C5408 520361900846 C5414 520361312256 C5415 520361312256 C5416 520361321536 C5418 520961322616 C5450 520961362656 C5451 520961362656 C5452 520961362656 C5453 520961362656 C5454 520961362656 C5455 520961362656 C5456 520961362656 C5457 520961362656 C5620 520961900006 C5627 520361312136 C5628 520961900006 C5629 520961900006 C5630 520961900006 C5631 520961900006 C5632 520961900006 C5633 520961900006 C5634 520961900006 C5635 520961900006 C5637 520361312136 C5638 520961900006 C5639 520961900006 C5640 520961900006 C5641 520361312136 C5642 520961900006 C5643 520961900006 C5644 520961900006 C5645 520361312136 C5646 520961900006 C5647 520961900006 C5648 520961900006 C5649 520961900006 C5650 520961900006 C5651 520361513256 C5652 520961900006 D5102 520363005636 D5111 520363005656 D5200 520363005656 DZ5103 520963495086 DZ5201 520363495186 DZ5602 520363498246 DZ5603 520363498246 DZ5605 520363498246 DZ5606 520363498246 DZ5607 520363498246 DZ5608 520363498246 L5200 520968021856 Q5100 520963550236 Q5101 520963550236 Q5102 520363990086 Q5105 520368180036 Q5107 520368180026 Q5200 520368180036 Q5201 520363550836 R5100 520360215066 R5102 520360664816 R5103 520360662896 R5113 520360663856 R5114 520360684656 R5119 520360663856 R5125 520360663856 R5126 520360664816 R5127 520360664506 R5128 520360664816 R5129 520360664816 R5136 520360662896 R5200 520960992596 R5201 520360543506 R5202 520360664816 R5203 520360664816 R5204 520360541836 R5205 520360663856 R5206 520360542396 R5207 520360663856 R5208 520360662896 R5211 520960992596 R5212 520960992596 R5213 520960992596 R5214 520960992596 R5215 520360663856 R5219 520360663856 R5220 520360664816 R5221 520360664816 R5404 520360543506 U5100 520966010186 U5101 520966000796 U5400 520966091266 VAR5612520968060096 VAR5613520968060096 VAR5614520968060096 VAR5615520968060096 VAR5616520968060096 VAR5617520968060096 VAR5618520968060096 VAR5619520968060096 VAR5620520968060096 VAR5621520968060096 VAR5622520968060096 VAR5623520968060096

Abdellah Ahakki 10.07.15 Phone +49 (0) 2102 749 285 Fax +49 (0) 2102 749 350 FCC-ID : RX2EN2 Maximum Permissible Exposure calculation Dear Madams or Sirs, please find here our Maximum Permissible Exposure calculations for the EN2. Best Regards i.A. Abdellah Ahakki Telefication Edisonstr. 12a 6902 PK Zevenaar The Netherlands MDE_MAGNET_1408 - 2 - Maximum Permissible Exposure (as specified in Table 1B of 47 CFR 1.1310 – Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure) Frequency range (MHz) Power density (mW/cm²) 300 – 1,500 f/1500 1,500 – 100,000 1.0 Calculations 2400-2483.5 MHz band Maximum peak output power at antenna input terminal for Bluetooth/WLAN module: 0.062 W Prediction distance R: 20 cm Prediction frequency: 2.4 GHz Prediction Antenna Gain G: -2.0 dBi MPE limit S: 1 mW/cm² Equation OET bulletin 65, page 18, edition 97-01: S = P*G / (4 πR²) S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna Maximum permissible power density: 0.0001 mW/cm² => Delta to MPE Limit: 0.9999 mW/cm²

Final Report on EntryNav 2, EN2 MDE_MAGNET_1408_FCCa acc. Title 47 CFR chapter I part 15 subpart C Report Reference: May 26, 2015Date: Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H. Ansorge TAX No. 147/5869/0385 www.7Layers.com A Bureau Veritas Group Company Reference: MDE_MAGNET_1408_FCCa acc. Title 47 CFR chapter I part 15 subpart C 2.2 Detailed Description of OUT Samples Sample : aa02 OUT IdentifierEN2 FCC ID: RX2EN2 IC: 4983A-EN2 Sample DescriptionSample#6, EntryNav 2 Serial No.127/14/EMC HW StatusD5.2 SW StatusH14425A_D Low VoltageLow Temp.8 V-40 °C High Temp.High Voltage16 V+65 °C Normal Temp.Nominal Voltage12 V23 °C Parameter List: ValueParameter Description Parameter for Scope FCC_v2 Antenna Gain-2 (dBi) Frequency_high2480 (MHz) Frequency_low2402 (MHz) Frequency_mid2441 (MHz) Sample : ac02 OUT IdentifierEN2 FCC ID: RX2EN2 IC: 4983A-EN2 Sample DescriptionSample#8, EntryNav 2 Serial No.128/14/EMC HW StatusD5.2 SW StatusH14425A_D Low VoltageLow Temp.8 V-40 °C High Temp.High Voltage16 V+65 °C Normal Temp.Nominal Voltage12 V23 °C Parameter List: ValueParameter Description Parameter for Scope FCC_v2 Antenna Gain-2 (dBi) Frequency_high2480 (MHz) Frequency_low2402 (MHz) Frequency_mid2441 (MHz) Page 4 of 95 Reference: MDE_MAGNET_1408_FCCa acc. Title 47 CFR chapter I part 15 subpart C 2.3 OUT Features Features for OUT: EN2 FCC ID: RX2EN2 IC: 4983A-EN2 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 BTEUT supports Bluetooth data rate of 1 Mbps with GFSK modulation in the band 2400 MHz - 2483.5 MHz DCThe OUT is powered by or connected to DC Eantremovable antenna supplied and type tested with the radio equipment, designed as an indispensable part of the equipment EDR2EUT supports Bluetooth using data rate of 2 Mbps with PI/4 DQPSK modulation in the band 2400 MHz - 2483.5 MHz EDR3EUT supports Bluetooth using data rate of 3 Mbps with 8DPSK modulation in the band 2400 MHz - 2483.5 MHz PantCpermanent fixed antenna connector, which may be built-in, designed as an indispensable part of the equipment 2.4 Setups used for Testing For each setup a relation is given to determine if and which samples and auxiliary equipment is used. The left side list all OUT samples and the right side lists all auxiliary equipment for the given setup. Sample No.Sample DescriptionAE No.AE Description Setup No. List of OUT samplesList of auxiliary equipment AA02 aa02Sample#6, EntryNav 2Sample: AC02 ac02Sample#8, EntryNav 2Sample: Page 5 of 95 Reference: MDE_MAGNET_1408_FCCa acc. Title 47 CFR chapter I part 15 subpart C 3Results 3.1 General Available at the test laboratory. The results of the inspection are described on the following pages, where 'Conformity' or 'Passed' means that the certification criteria were verified and that the tested device is conform to the applied standard. In cases where 'Declaration' is printed, the required documents are available in the manufacturers product documentation. In cases where 'not applicable' is printed, the test case requirements are not relevant to the specific equipment implementation. Documentation of tested devices: Interpretation of the test results: 1. All tests are performed under environmental conditions within the requirements of the specifications. Environmental conditions are available at the laboratory. 2. The device is a hands-free kit containing a BT Transceiver operating in the 2.4 GHz ISM band. The EUT was controlled by the CBT via Bluetooth test mode. Note: 3.2 List of the Applicable Body (Body for Scope: FCC_v2) DesignationDescription Subpart C - Intentional Radiators; 15.247 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. FCC47CFRChIPART15c247RADIO FREQUENCY DEVICES 3.3 List of Test Specification Test Specification:FCC part 2 and 15 Version10-1-13 Edition Title:PART 2 - GENERAL RULES AND REGULATIONS PART 15 - RADIO FREQUENCY DEVICES Page 6 of 95 Reference: MDE_MAGNET_1408_FCCa acc. Title 47 CFR chapter I part 15 subpart C 3.4 Summary Test Case Identifier / Name SetupDate of TestResultTest (condition)Ref. Lab 15c.2 Spurious radiated emissions §15.247 (d), §15.35 (b), §15.209 15c.2; Frequency = 2402, Mode = BT transmit using 1 Mbps with GFSK modulation, Channel = low 2015/04/21AC02Lab 1Passed 15c.2; Frequency = 2402, Mode = BT transmit using 2 Mbps with PI/4 DQPSK modulation 2015/04/21AC02Lab 1Passed footnote: 1 15c.2; Frequency = 2441, Mode = BT transmit using 1 Mbps with GFSK modulation, Channel = mid 2015/04/21AC02Lab 1Passed 15c.2; Frequency = 2441, Mode = BT transmit using 2 Mbps with PI/4 DQPSK modulation 2015/04/21AC02Lab 1Passed footnote: 1 15c.2; Frequency = 2480, Mode = BT transmit using 1 Mbps with GFSK modulation, Channel = highest 2015/04/21AC02Lab 1Passed 15c.2; Frequency = 2480, Mode = BT transmit using 2 Mbps with PI/4 DQPSK modulation 2015/04/21AC02Lab 1Passed footnote: 1 15c.3 Occupied bandwidth §15.247 (a) (1) 15c.3; Frequency = 2402, Mode = BT transmit using 1 Mbps with GFSK modulation 2015/03/26AA02Lab 2Passed 15c.3; Frequency = 2402, Mode = BT transmit using 2 Mbps with PI/4 DQPSK modulation 2015/03/26AA02Lab 2Passed 15c.3; Frequency = 2402, Mode = BT transmit using 3 Mbps with 8DPSK modulation 2015/03/26AA02Lab 2Passed 15c.3; Frequency = 2441, Mode = BT transmit using 1 Mbps with GFSK modulation 2015/03/26AA02Lab 2Passed 15c.3; Frequency = 2441, Mode = BT transmit using 2 Mbps with PI/4 DQPSK modulation 2015/03/26AA02Lab 2Passed 15c.3; Frequency = 2441, Mode = BT transmit using 3 Mbps with 8DPSK…
