RXISBMBLEBLE Bike Sensors

RV-0000000 Project No.: 1402122 Page 2 of 5 Neutron Engineering Inc.

RV-0000000 Project No.: 1402122 Page 3 of 5 Neutron Engineering Inc. RV-0000000 Project No.: 1402122 Page 4 of 5 Neutron Engineering Inc. Antenna RV-0000000 Project No.: 1402122 Page 5 of 5 Neutron Engineering Inc.

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: RXISBMBLE Project No. : 1402122 Equipment : BLE Bike Sensors Model : SBM-BLE-SC Applicant : G.pulse Intl Co., Ltd. Address : 16-3,Lane 852, Tu Chen g Road,Ta Li Dist. Taichung City, Taiwan R.O.C. According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 Neutron Engineering Inc. GENERAL CONCULUSION: Table for Filed Antenna: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Printed N/A -5.31 Maximum measured transmitter power: Mode Output Power (dBm) Out Power (mW) Limit (mW) 1 MHz -1.6 0.7 10 According to FCC KDB447498, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The transmitter power is 0.7 mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 1 of 4 7 FCC ID: RXISBMBLE FCC Radio Test Report FCC ID: RXISBMBLE This report concerns (check one): Original Grant Class II Change Issued Date : Mar. 21, 2014 Project No. : 1402122 Equipment : BLE Bike Sensors Model Name : SBM-BLE-SC Applicant : G.pulse Int’l Co., Ltd. Address : 16-3,Lane 852, Tu Cheng Road,Ta Li Dist. Taichung City, Taiwan R.O.C. Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Feb. 18, 2014 Date of Test: Feb. 18, 2014 ~ Mar. 19, 2014 Testing Engineer : (Gary Chou) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 2 of 4 7 FCC ID: RXISBMBLE Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 3 of 4 7 FCC ID: RXISBMBLE Table of Contents Page REPORT ISSUED HISTORY 5 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 RADIATED EMISSION MEASUREMENT 15 4.1.1 RADIATED EMISSION LIMITS 15 4.1.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 16 4.1.3 TEST PROCEDURE 17 4.1.4 DEVIATION FROM TEST STANDARD 17 4.1.5 TEST SETUP 18 4.1.6 EUT OPERATING CONDITIONS 19 4.2.8 TEST RESULTS-BETWEEN 30MHZ AND 1000MHZ 20 4.1.7 TEST RESULTS (ABOVE 1000 MHZ) 22 5 . BANDWIDTH TEST 34 5.1 APPLIED PROCESURES / LIMIT 34 5.2 MEASUREMENT INSTRUMENTS LIST 34 5.3 TEST PROCEDURE 34 5.4 DEVIATION FROM STANDARD 34 5.5 TEST SETUP 34 5.6 EUT OPERATION CONDITIONS 34 5.7 TEST RESULTS 35 6 . MAXIMUM OUTPUT POWER TEST 37 6.1 APPLIED PROCEDURES / LIMIT 37 6.2 MEASUREMENT INSTRUMENTS LIST 37 6.3 TEST PROCEDURE 37 6.4 DEVIATION FROM STANDARD 37 6.5 TEST SETUP 37 6.6 EUT OPERATION CONDITIONS 37 6.7 TEST RESULTS 38 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 4 of 4 7 FCC ID: RXISBMBLE Table of Contents Page 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 39 7.1 APPLIED PROCEDURES / LIMIT 39 7.2 MEASUREMENT INSTRUMENTS LIST 39 7.3 TEST PROCEDURE 39 7.4 DEVIATION FROM STANDARD 39 7.5 TEST SETUP 39 7.6 EUT OPERATION CONDITIONS 39 7.7 TEST RESULTS 40 8 . POWER SPECTRAL DENSITY TEST 44 8.1 APPLIED PROCEDURES / LIMIT 44 8.2 MEASUREMENT INSTRUMENTS LIST 44 8.3 TEST PROCEDURE 44 8.4 DEVIATION FROM STANDARD 44 8.5 TEST SETUP 44 8.6 EUT OPERATION CONDITIONS 44 8.7 TEST RESULTS 45 9 . EUT TEST PHOTO 47 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 5 of 4 7 FCC ID: RXISBMBLE REPORT ISSUED HISTORY Issue No. Description Issued Date NEI-FCCP-1-1402122 Original Issue Mar. 21, 2014 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 6 of 4 7 FCC ID: RXISBMBLE 1. CERTIFICATION Equipment : BLE Bike Sensors Brand Name : GPULSE Model Name : SBM-BLE-SC Applicant : G.pulse Int’l Co., Ltd. Date of Test : Feb. 18, 2014 ~ Mar. 19, 2014 Standard(s) : FCC Part 15, Subpart C: 2012 (15.247) ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1402122) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 7 of 4 7 FCC ID: RXISBMBLE 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part 15, Subpart C: 2012 (15.247) Standard(s) SectionTest Item Judgment Remark 15.207 Conducted Emission - N/A 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.209/15.205 Radiated Spurious Emission PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS 1.1307 1.1310 2.1091 2.1093 RF Exposure Compliance PASS NOTE: (1)” N/A” denotes test is not applicable in this test report. (2) The test follows FCC KDB Publication No. 558074 D01 DTS Meas Guidance v03r01 (Measurement Guidelines of DTS) Neutron Engineering Inc. Report No.: NEI-F…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402122 Page 47 of 4 7 FCC ID: RXISBMBLE 9. EUT TEST PHOTO Radiated spurious emission test photos
