AM002 User's Guide Application 1. Public place: meeting, commercial speech, classroom teaching, training, exhibition, technology and teaching pavilion, interactive game etc. 2. Home use: family interactive learning, entertainment, browsing etc 3. Recreation place: Cafe, hotel, leisure game, multimedia entertainment etc. 4:Low Voltage Indication function, when battery voltage drops below 2.2V,LED will flash. 5:Compatible with WindowsXP / Windows Visita /Windows 7/ Mas OS X/ Linx/Android system. Appearance Thank you so much for using our product. For you to have a better experience to use wireless air mouse function, please refer to the instruction before using. 1: Plug and play USB receiver, compatible with USB1.1 and USB2.0 2:Can be applied in TV, Projector, PC, HTPC, Webcam STB and Android series product which is available for USB mouse. This is a wireless air mouse+keyboard, it is fully achieved the functionality of traditional mouse and mouse function. By waving the mouse in the air to respond quickly converted to move the cursor on the screen.It is using perfect combination of 3D and Gyro instrument,you can be 360 degrees arbitrarily accurate operation.Completely avoiding the traditional mouse's disadvantage to be operated on the still desktop, enable you to move freely and enjoy relaxed and comfortable life. 3:Use AAAx2 battery, advanced power-saving technology with less than 50mA operating current, less than 50uA standby current. LED Conditions 1: capital indicatio n LED:when press light on mean uppercase letters, light off mean lowercase letters. 2:FN state indication LED: when press Fn, light on Fn on, all the key change to the function of yellow code pointed on it, whenever matching, proofreading Fn LED always light up(more detail please check on the key combination instruction.) 3:power level indication LED: when the battery less than 2.2V LED will blinking, remind you change the new one. 4:voice ON/OFF indication LED: when voice activate LED light up, deactivated light off. (more detail please check on the key combination instruction.) Step1: installed USB receiver Find the USB receiver in the packing box, insert the USB into the device USB port. Step2: put the battery on two terminals of remote then shaking it you will find that cursor follow your mouse’s step. Step3: matching :Once the remote light on default the first minute be matching time, beyond one minute the remote control lose the function o plug the USB dongle into the computer, matching can completed in one Key location Key icon Key function A1Left key mouse A2Right key mouse A3Cursor lock (press activity press again cancel) A4Audio port A5Switch capital input A6Switch yellow print input A7Audio switch A8 A9Battery cover The red area is customized color, code, printing (IR deliver) Introductions: the keyboard default is pc application mode, can also change to Android application mode,IR remote control mode please refer to the driver description. A: press simultaneously buttons FN+P up to 3 seconds default the function of paired the remote to USB dongle. Once the remote light on default the first minute be matching time, beyond one minute the remote control lose the function of matching. press simultaneously buttons FN+P at least 3 second ,Fn direction light on. plug the USB dongle into the computer, matching can completed in one minute. The led flash 3 times means that complete matching successfully (default paired ok) 2: Press LED light up and all the letter key change to capital, other keys stay the same. 3:Left key of the air mouse:consistent with the functions of the standard left key,right key of the air mouse:consistent with the functions of the standard right key. 4: Press LED light up all the key change to “letter in yellow” function 5: Key combination description Keyboard side instruction: 1: On initial state, keyboard default is lowercase and the white code function of the key. A1,A2,A3 are standard keys of mouse (2.4G deliver) resolutionEquivalent up to 800DPI Location precision Single - pixel location in a row Use posturefree Resolution adjustment According to the screen pixel Sample rate8KHZ/16KHZ/32KHZ/48KHZ Pick up distance0-1M Data streamDual-channel pcm stream code senseomniderectional connectionRF2.4G Effective control distance 15M Frequency- hopping Fast frequency hopping avoids interference. Codes checkAutomatic pairing, saving communica tion key equal mouse left key, key equal mouse right key, key is cursor locking key Use it directly no need set-up. Technical Data mouse audio Mouse function instruction B: press simultaneously buttons FN+Y up to 5 second default the function of Proofing the cursor. This can be done anytime. pressing simultaneously buttons FN+P 5 seconds, Fn direction light flash means complete. C: press simultaneously buttons FN+I to lock/unlock the crusor D: press simultaneously buttons FN+Enter to switch keyboard mode E: press simultaneously buttons Fn+> to voice switch, light on means pronounce, light off mean turn voice off, when turn the voice on can chat on line. IR remote control function instruction: FCC Certification Requirements Caution: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reaso…
Text truncated - open the document above for the full version.
Shenzhen Anycon Electronices Technology Co.,Ltd. Room527, Mintai Building, Minkang Road, Minzhi, Longhua town, BaoAn District Shenzhen,China Confidentiality Request Letter Page 1 of 1 Rev 2.0 February 01, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Permanent Confidentiality Request Confidentiality Request regarding application for certification of FCC ID:RYGASNR-AM002 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Zhiqiang Zhang / QA Manager Contact information / address: Room527, Mintai Building, Minkang Road, Minzhi, Longhua town, BaoAn District Shenzhen,China TEL: 0769-87091688 FAX: 0769-87091686 E-mail: [email protected]
External Photo
FCC Certification Label FCC ID:RYGASNR-AM002 Label Location on EUT EUT Bottom View/ FCC ID Label Location
Internal Photo Antenna
FCC PART 15.249 EMI MEASUREMENT AND TEST REPORT For SHENZHEN ANYCON ELECTRONICES TECHNOLOGY CO.,LTD. Room527, Mintai Building, Minkang Road, Minzhi, Longhua town, BaoAn District Shenzhen,China FCC ID: RYGASNR-AM002 February 20, 2013 This Report Concerns: Original Report Equipment Type: RF 2.4G Remote control Test Engineer: Anna Lv Test Engineer of performing the tests: Hans Hu Report No.: BST12121070Y-1ER-3 Receive EUT Date/Test Date: January 23, 2013 / January 23, 2013- February 20, 2013 Reviewed By: Mike Moo Prepared By: Shenzhen BST Technology Co.,Ltd. 3F,Weames Technology Building, No. 10 Kefa Road, Science Park, Nanshan District,Shenzhen,Guangdong,China Tel: 0755-26747751-3 Fax: 0755-26747751-3 ext.826 Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of Shenzhen BST Technology Co.,Ltd. This report must not be used by the client to claim product certification,approval,or endorsement by NVLAP, NIST or any agency of the US Government. FCC ID: RYGASNR-AM002 BST12121070Y-1ER-3 Page 2/27 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................3 1.1. Report information ............................................................................................................3 1.2. Measurement Uncertainty .................................................................................................3 2. PRODUCT DESCRIPTION ......................................................................................................4 2.1. EUT Description ...............................................................................................................4 2.2. Block Diagram of EUT Configuration..............................................................................5 2.3. Support Equipment List ....................................................................................................5 2.4. Test Conditions .................................................................................................................5 3. TEST RESULTS SUMMARY ...................................................................................................6 Modifications ................................................................................................................................6 4. TEST EQUIPMENT USED .......................................................................................................7 5. ANTENNA REQUIREMENT ...................................................................................................8 5.1. Standard Applicable..........................................................................................................8 5.2. Antenna Connected Construction .....................................................................................8 5.3. Result ................................................................................................................................8 6. CONDUCTED POWER LINE TEST .......................................................................................9 6.1. Test Equipment .................................................................................................................9 6.2. Test Procedure ..................................................................................................................9 6.3. Test Setup..........................................................................................................................9 6.4. Conducted Power line Emission Limits............................................................................9 6.5. Conducted Power Line Test Result.................................................................................10 7. RADIATED EMISSION TEST ...............................................................................................11 7.1. Test Equipment ...............................................................................................................11 7.2. Test Procedure ................................................................................................................11 7.3. Radiated Test Setup ........................................................................................................11 7.4. Radiated Emission Limit.................................................................................................13 7.5. Radiated Emission Test Result .......................................................................................14 8. BAND EDGE .............................................................................................................................19 8.1. Test Equipment ...............................................................................................................19 8.2. Test Procedure ................................................................................................................19 8.3. Band Edge FCC 15.249(d) Limit ....................................................................................19 8.4. Band Edge Test Result ....................................................................................................20 9. 20-DB BANDWIDTH ...............................................................................................................24 9.1. Test Equipment ...............................................................................................................24 9.2. Test Procedure ................................................................................................................24 9.3. Limit................................................................................................................................24 9.4. Test Result /Plots ............................................................................................................24 FCC ID: RYGASNR-AM002 BST12121070Y-1ER-3…
Text truncated - open the document above for the full version.
Radiated emissions test
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |

Remote Control
Equipment Class
DTS - Digital Transmission System
Bluetooth Remote Control
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
