S3BNAV300-A1860IPortable GPS Navigation Device

Delphi NAV300 User’s Guide - 1 - Welcome Thank you for purchasing the Delphi NAV300 Portable GPS Navigation System. This lightweight, portable device can guide you quickly and reliably to your destination without leafing through thick folded maps. This advanced navigation system features true text-to-speech that speaks the street names while navigating; road signs and speed limit warnings on major highways; and point-of- interest icons for your favorite restaurants, gas stations, etc. With an easy, intuitive interface, the Delphi NAV300 displays maps with street- level detail, allowing door-to-door navigation. The maps include points of interest, such as parks, airports, restaurants and lodging. In addition, the Delphi NAV300 is Bluetooth® capable and, with an integrated microphone, can pair with Bluetooth-equipped phones. The NAV300 can also play audio (MP3 or wav) files and video (avi, MPEG4, Xvid) files, as well as display pictures (jpg, gif, png) enhancing the entertainment possibilities in your vehicle. For a complete list of compatible Bluetooth phones, go to www.shopdelphi.com. Delphi NAV300 Features x 400 MHz CPU for fast navigation calculations and map rendering x Bright, colorful, non-reflective touch screen LCD display x Fast-start, high speed SiRFStarIII™ GPS x Easy to use software based on Microsoft® Windows® CE x Navigation map files pre-installed on SD memory card (included) x RDS Real-Time Traffic ready (optional) x Built-in rechargeable battery Contacting Technical Support Contact Delphi at 1.877.667.8700 Monday – Friday, 8:00 am to 8:00 pm and Saturday, 10:00 am to 5:00 pm, Eastern Standard Time, or visit www.shopdelphi.com This is the safety alert symbol. It is used to alert you to potential injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Delphi NAV300 User’s Guide - 2 - Warning: DANGER OF ACCIDENT When using your Delphi NAV300 in a vehicle, it is your sole responsibility to install, secure and use the device in a manner that will not cause accidents, personal injury, or property damage, or in any manner obstruct your view or interfere with the operation of vehicle safety equipment. The user of this product is solely responsible for observing safe driving practices. Do not operate your Delphi NAV300 while driving. Park the vehicle first. Do not use the navigation system or entertainment features if it presents a risk to you or any other person or if it is a distraction. OBEY ALL TRAFFIC LAWS The user is solely responsible for obeying the local traffic laws and observing all road signs. Local traffic laws and actual traffic signs always have priority over the information and directions received from the navigation system. The navigation instructions might be inaccurate or incorrect due to detours and construction. DELPHI DISCLAIMS ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A WAY THAT MAY CAUSE ACCIDENTS, DAMAGE OR THAT MAY VIOLATE THE LAW. Caution: To avoid overheating of the unit, do not leave Delphi NAV300 on the dash or windshield while your vehicle is unattended, especially in strong sunlight. Do not use or handle Delphi NAV300 while it is hot. Let it cool away from heat sources before handling it. * Microsoft and Windows are trademarks of Microsoft Corporation. Delphi NAV300 User’s Guide - 3 - Table of Contents Welcome ..... ........................................................................................................1 Delphi NAV300 Features...................................................................................1 Contacting Technical Support ...........................................................................1 Section 1About GPS/NAV300 Introduction .................................................5 Section 2Unpacking the Delphi NAV300.....................................................7 Memory Cards...................................................................................................9 Accessories and Replacement Parts.................................................................9 Section 3Installing Delphi NAV300 in Your Vehicle .................................10 Section 4Features and Controls ................................................................11 NAV300 Receiver Controls .............................................................................11 Section 5Getting Started.............................................................................12 Powering Up....................................................................................................12 Inserting an SD Card.......................................................................................13 Home Screen ..................................................................................................14 Using the Keyboard.........................................................................................15 Other Common Keys ...................................................................................15 Section 6NavigationMode..........................................................................16 Driver Protection..............................................................................................16 Navigation – Main Menu..................................................................................17 Common On-Screen Icons ..........................................................................17 Navigation Settings.........................................................................................19 Settings Options ..........................................................................................19 Setting a New Destination ...............................................................................20 Entering a New Address ..............................................................................20 Searching for a Point-of-Interest (POI) ........................................................22 Directly Accessing NearbyPOI…
