S4L4EV42GPS Navigation system

User Guide GO | VIA 2 Welcome to TomTom 3 Getting started 11 Getting the most from your device 21 Keeping your device up-to-date 24 Troubleshooting 25 Addendum CONTENTS WELCOME TO THE WORLD OF TOMTOM TomTom’s award-winning software and innovative features mean groundbreaking new technology for the ultimate driving experience. Wherever life takes you, your TomTom GO is your guide. To get the most out of your TomTom device, here are a few things to know before you go. 2 1 Push the mount for your TomTom GO against the windshield in your car. GETTING STARTED MOUNTING YOUR DEVICE 3 2 Lock the mount by twisting the base 4 GETTING STARTED MOUNTING YOUR DEVICE 3 Place the device onto the mount. The mount’s magnets will hold the device securely in place. 4 Insert the car charger into your device. Magnets built into your charger will affix the charger to the device. Then insert the car charger into the charging socket of your car. 5 5 Switch your device on by pressing the On/Off button on top of your device. 6 You now have to answer some questions to set up your device. Tap the screen to answer the questions. 6 Positioning the mount Consider carefully where to attach the mount in your car. The mount should not block or interfere with any of the following: • Your view of the road • Any of the controls in your car • Any of your mirrors • The airbag When your navigation device is in the mount, you should be able to reach the device easily without leaning or stretching. The diagrams show where you can safely attach the mount. You can attach the mount to the windshield, side window or use the Adhesive Disk to attach the mount to your dashboard. TomTom also offers alternative mounting solutions for your TomTom navigation device. For more information about Adhesive Disks and alternative mounting solutions, go to www.tomtom.com/accessories. GETTING STARTED SAFETY 7 √ X X √ 8 Planning a route with your TomTom GO is easy. To plan a route, follow these easy steps. 1. Tap the screen to bring up the Main Menu. 2. Tap Navigate to... In this example, we will enter an address. 3. Tap Address. Note: The buttons on your navigation device are shown in full color unless a button is currently unavailable 4. Start to type the name of the town where you want to go. Tap the name when it is shown in the list. GETTING STARTED MAKING YOUR FIRST TRIP 9 Important: For safety reasons, you should always plan a route before you start your trip. 5. Start to type the street name. Tap the name when it is shown in the list. 6. Enter the house number and then tap Done. Your TomTom GO device begins to guide you to your destination. ROUTE SUMMARY After planning a route, you see a summary of your route. The route summary shows an overview map of your route and the total journey time including delays caused by both incidents and busy roads. You can see the route summary at any time by tapping the right side of the status bar. 10 GETTING THE MOST FROM YOUR DEVICE TRAFFIC UPDATES APPLIES TO: ALL TRAFFIC EDITION DEVICES USING TRAFFIC INFORMATION To view traffic information on your TomTom GO, connect the TomTom Car Charger with Integrated Traffic Receiver to your GO. Important: You will not recieve updates unless your car charger with integrated traffic receiver is connected to your vehicle, via the charging socket. The traffic sidebar is shown on the right side of the Driving view. The sidebar informs you about traffic delays while you drive, using glowing dots to show you where each traffic incident is located on your route. The top of the traffic sidebar represents your destination and shows the total time delay due to traffic jams and other incidents on your route. The central section of the traffic sidebar shows individual traffic incidents in the order they occur on your route. The bottom of the traffic sidebar represents your current location and shows the distance to the next incident on your route. Note: TomTom is not responsible for the availability or quality of traffic information provided by the Traffic Message Channel. 11 The color of the pointers, as shown below, gives you an instant indication of the type of incident: Unknown or undetermined situation. Slow traffic. Traffic lining up. Stationary traffic or road closure. 12 TAKING THE FASTEST ROUTE Your GO regularly looks for a faster route to your destination. If the traffic situation changes and a faster route is found, your GO will offer to re-plan your trip so you can use the faster route. You can also set your GO to automatically re-plan your trip whenever a faster route is found. To apply this setting, tap Traffic settings in the Traffic menu. MINIMIZING DELAYS You can use traffic updates to minimize the impact of traffic delays on your route. To minimize delays automatically, do the following: 1. Tap Services in the Main Menu. 2. Tap Traf fic. 3. Tap Traffic settings. 4. Choose between always taking the faster route automatically, being asked or never changing your route. 5. Tap Next and then Done. GETTING THE MOST FROM YOUR DEVICE TRAFFIC UPDATES 13 To manually minimize traffic delays at any time, do the following: 1. Tap the Traffic bar in the Driving View. 2. Tap Minimize traffic delays. Your GO plans the quickest route to your destination. The new route may include traffic delays and may remain the same as the original route. You can re-plan the route to avoid all delays, but this route is unlikely to be the quickest possible route. 3. Tap Done. 14 GETTING THE MOST FROM YOUR DEVICE THE DRIVING VIEW 1. Zoom button - tap the magnifying glass to show buttons for zooming in and out. 2. Your current position. 3. Road sign information or the next street name. 4. Traffic sidebar. 1 2 3 4 5 6 7 8 9 15 5. Microphone button for voice recognition. 6. The time, your current speed and the speed limit, if known. To see the difference between your preferred arrival time and your estimated arrival time, check the Leeway checkbox in the Status bar settings. Tap this part of the stat…

Text truncated - open the document above for the full version.

User Guide GO | VIA 2 Welcome to TomTom 3 Getting started 11 Getting the most from your device 21 Keeping your device up-to-date 24 Troubleshooting 25 Addendum CONTENTS WELCOME TO THE WORLD OF TOMTOM TomTom’s award-winning software and innovative features mean groundbreaking new technology for the ultimate driving experience. Wherever life takes you, your TomTom GO is your guide. To get the most out of your TomTom device, here are a few things to know before you go. 2 1 Push the mount for your TomTom GO against the windshield in your car. GETTING STARTED MOUNTING YOUR DEVICE 3 2 Lock the mount by twisting the base 4 GETTING STARTED MOUNTING YOUR DEVICE 3 Place the device onto the mount. The mount’s magnets will hold the device securely in place. 4 Insert the car charger into your device. Magnets built into your charger will affix the charger to the device. Then insert the car charger into the charging socket of your car. 5 5 Switch your device on by pressing the On/Off button on top of your device. 6 You now have to answer some questions to set up your device. Tap the screen to answer the questions. 6 Positioning the mount Consider carefully where to attach the mount in your car. The mount should not block or interfere with any of the following: • Your view of the road • Any of the controls in your car • Any of your mirrors • The airbag When your navigation device is in the mount, you should be able to reach the device easily without leaning or stretching. The diagrams show where you can safely attach the mount. You can attach the mount to the windshield, side window or use the Adhesive Disk to attach the mount to your dashboard. TomTom also offers alternative mounting solutions for your TomTom navigation device. For more information about Adhesive Disks and alternative mounting solutions, go to www.tomtom.com/accessories. GETTING STARTED SAFETY 7 √ X X √ 8 Planning a route with your TomTom GO is easy. To plan a route, follow these easy steps. 1. Tap the screen to bring up the Main Menu. 2. Tap Navigate to... In this example, we will enter an address. 3. Tap Address. Note: The buttons on your navigation device are shown in full color unless a button is currently unavailable 4. Start to type the name of the town where you want to go. Tap the name when it is shown in the list. GETTING STARTED MAKING YOUR FIRST TRIP 9 Important: For safety reasons, you should always plan a route before you start your trip. 5. Start to type the street name. Tap the name when it is shown in the list. 6. Enter the house number and then tap Done. Your TomTom GO device begins to guide you to your destination. ROUTE SUMMARY After planning a route, you see a summary of your route. The route summary shows an overview map of your route and the total journey time including delays caused by both incidents and busy roads. You can see the route summary at any time by tapping the right side of the status bar. 10 GETTING THE MOST FROM YOUR DEVICE TRAFFIC UPDATES APPLIES TO: ALL TRAFFIC EDITION DEVICES USING TRAFFIC INFORMATION To view traffic information on your TomTom GO, connect the TomTom Car Charger with Integrated Traffic Receiver to your GO. Important: You will not recieve updates unless your car charger with integrated traffic receiver is connected to your vehicle, via the charging socket. The traffic sidebar is shown on the right side of the Driving view. The sidebar informs you about traffic delays while you drive, using glowing dots to show you where each traffic incident is located on your route. The top of the traffic sidebar represents your destination and shows the total time delay due to traffic jams and other incidents on your route. The central section of the traffic sidebar shows individual traffic incidents in the order they occur on your route. The bottom of the traffic sidebar represents your current location and shows the distance to the next incident on your route. Note: TomTom is not responsible for the availability or quality of traffic information provided by the Traffic Message Channel. 11 The color of the pointers, as shown below, gives you an instant indication of the type of incident: Unknown or undetermined situation. Slow traffic. Traffic lining up. Stationary traffic or road closure. 12 TAKING THE FASTEST ROUTE Your GO regularly looks for a faster route to your destination. If the traffic situation changes and a faster route is found, your GO will offer to re-plan your trip so you can use the faster route. You can also set your GO to automatically re-plan your trip whenever a faster route is found. To apply this setting, tap Traffic settings in the Traffic menu. MINIMIZING DELAYS You can use traffic updates to minimize the impact of traffic delays on your route. To minimize delays automatically, do the following: 1. Tap Services in the Main Menu. 2. Tap Traf fic. 3. Tap Traffic settings. 4. Choose between always taking the faster route automatically, being asked or never changing your route. 5. Tap Next and then Done. GETTING THE MOST FROM YOUR DEVICE TRAFFIC UPDATES 13 To manually minimize traffic delays at any time, do the following: 1. Tap the Traffic bar in the Driving View. 2. Tap Minimize traffic delays. Your GO plans the quickest route to your destination. The new route may include traffic delays and may remain the same as the original route. You can re-plan the route to avoid all delays, but this route is unlikely to be the quickest possible route. 3. Tap Done. 14 GETTING THE MOST FROM YOUR DEVICE THE DRIVING VIEW 1. Zoom button - tap the magnifying glass to show buttons for zooming in and out. 2. Your current position. 3. Road sign information or the next street name. 4. Traffic sidebar. 1 2 3 4 5 6 7 8 9 15 5. Microphone button for voice recognition. 6. The time, your current speed and the speed limit, if known. To see the difference between your preferred arrival time and your estimated arrival time, check the Leeway checkbox in the Status bar settings. Tap this part of the stat…

Text truncated - open the document above for the full version.

Example of Agents letter (for TCB – TCB approval): TomTom International BV. Date 14-02-2011 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, TomTom International BV. hereby authorize Compliance Certification Services Inc. as our agent and Serhiy Tkachenko from TomTom International BV as the responsible person in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 14-06-2011. Sincerely, Contact Person: Gareth Weston Company: TomTom International BV TEL: +31 (0) 20 8500800 FAX: +31 (0) 20 8501099 E-mail: [email protected]

TomTom International BV. Date 14-02-2011 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: S4L4EV42 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bom Block Diagrams Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Contact Person: Serhiy Tkachenko Company: TomTom International BV TEL: +31 (0) 20 75 74 969 FAX: +31 (0) 20 757 57 50 E-mail: [email protected]

Example of Agents letter (for TCB – TCB approval): TomTom International BV. Date 14-02-2011 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, TomTom International BV. hereby authorize Compliance Certification Services Inc. as our agent and Serhiy Tkachenko from TomTom International BV as the responsible person in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 14-06-2011. Sincerely, Contact Person: Gareth Weston Company: TomTom International BV TEL: +31 (0) 20 8500800 FAX: +31 (0) 20 8501099 E-mail: [email protected]

TomTom International BV. Date 14-02-2011 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: S4L4EV42 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bom Block Diagrams Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Contact Person: Serhiy Tkachenko Company: TomTom International BV TEL: +31 (0) 20 75 74 969 FAX: +31 (0) 20 757 57 50 E-mail: [email protected]

TomTom International BV USA address: TomTom, Inc., 150 Baker Avenue Extension, Concord, MA 01742 Tel: 866 486-6866 option 1 (1-866-4-TomTom) Date: February 21, 2011 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: S4L4CT50 To Whom It May Concern: We , TomTom International BV, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely yours, Contact Person: Roberto Scandian Company: TomTom International BV E-mail: [email protected]

Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 1 Total Page: 26 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 2 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 3 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 4 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 5 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 6 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 7 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 8 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 9 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 10 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 11 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 12 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 13 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 14 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 15 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 16 Rev. 00

Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 1 Total Page: 26 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 2 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 3 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 4 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 5 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 6 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 7 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 8 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 9 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 10 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 11 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 12 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 13 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 14 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 15 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 16 Rev. 00

FCC ID:S4L4EV42 IC:5767A-4EV42 4EV4.001.02 Model: 4EV42 Z1230 LAUSANNE 4.3” ”PREMIUM” 4GB 09 08 02 1:1 : Lausanne LAUSANNE ARTWORK 01A01 16.12.10N.Evans A01 16.12.2010 First Release Part 1: Label recess (sticker) Part 2: Speaker area (in-mould) 100 mm ItemMaterialTextureColour Finish Comments Project: Catania 1:1 Label material: Silver metalic. Alternative (costdown) solution: Barcode window printed light grey HandsfreeNot handsfree 28mm F O R A P P L I C A B L E P O W E R S U P P L I E S S E E U S E R I N S T R U C T I O N S N 1 4 6 4 4 C a n a d a 3 1 0 5 V D C 1 A M A D E I N C H I N A F O R A P P L I C A B L E P O W E R S U P P L I E S S E E U S E R I N S T R U C T I O N S N 1 4 6 4 4 C a n a d a 3 1 0 5 V D C 1 A M A D E I N C H I N A (XXXX.XXX.XX) GO XXXX Model: XXXXX Z1230 IC:XXXXX-XXXX FCC ID:XXXXXXX C_NO:12345678901 (XXXX.XXX.XX) GO XXXX Model: XXXXX C_NO:12345678901 Part 2 Part 1

FCC ID:S4L4EV42 IC:5767A-4EV42 4EV4.001.02 Model: 4EV42 Z1230 /$86$11( ” ” 35(0,80 ” *%

FCC ID:S4L4EV42 IC:5767A-4EV42 4EV4.001.02 Model: 4EV42 Z1230 LAUSANNE 4.3” ”PREMIUM” 4GB 09 08 02 1:1 : Lausanne LAUSANNE ARTWORK 01A01 16.12.10N.Evans A01 16.12.2010 First Release Part 1: Label recess (sticker) Part 2: Speaker area (in-mould) 100 mm ItemMaterialTextureColour Finish Comments Project: Catania 1:1 Label material: Silver metalic. Alternative (costdown) solution: Barcode window printed light grey HandsfreeNot handsfree 28mm F O R A P P L I C A B L E P O W E R S U P P L I E S S E E U S E R I N S T R U C T I O N S N 1 4 6 4 4 C a n a d a 3 1 0 5 V D C 1 A M A D E I N C H I N A F O R A P P L I C A B L E P O W E R S U P P L I E S S E E U S E R I N S T R U C T I O N S N 1 4 6 4 4 C a n a d a 3 1 0 5 V D C 1 A M A D E I N C H I N A (XXXX.XXX.XX) GO XXXX Model: XXXXX Z1230 IC:XXXXX-XXXX FCC ID:XXXXXXX C_NO:12345678901 (XXXX.XXX.XX) GO XXXX Model: XXXXX C_NO:12345678901 Part 2 Part 1

FCC ID:S4L4EV42 IC:5767A-4EV42 4EV4.001.02 Model: 4EV42 Z1230 /$86$11( ” ” 35(0,80 ” *%

Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 17 Rev. 00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 18 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 19 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 20 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 21 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 22 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 23 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 24 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 25 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 26 Rev. 00

Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 17 Rev. 00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 18 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 19 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 20 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 21 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 22 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 23 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 24 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 25 Rev. 00 Compliance Certification Services Inc. Report No.: T110127002 Date of Issue: February 21, 2011 A1 - 26 Rev. 00

UNLESS OTHER SPECIFIED TOLERANCES ON： X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± INPAQ TECHNOLOGY CO., LTD. SCALE： UNIT：mm DRAWN BY：邱子紋 CHECKED BY：陳智崴 DESIGNED BY：陳俊達 APPROVED BY：蘇志銘 THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DOCUMENT SPEC REV. TITLE：Embedded Single-Band Antenna for WA-W-LA-00-001 NO. ENS000033640 A0 PAGE 1 OF 2 Embedded Single-Band Antenna for WA-W-LA-00-001 1. Explanation of part number : (1) (2) (3) (4) (5) (1) Product Type：Wireless Antenna (2) Material : Wire (3) Center Frequency/Band code :2.4~2.5GHz/ BT (4) Coaxial Cable Type : 00 (No Coaxial Cable) (5) Suffix : 001 2. Electrical Specification : These specifications are specially defined for TOMTOM_Catania(5”) model, and all characteristics are measured with the unit. 2-1 Frequency Band: Frequency MHz BT 2400~2500 2-2 Impedance 50 ohm nominal 2-3 Return Loss 2400 MHz 2450 MHz 2500 MHz -12.57 -17.85 -11.25 W A WL A00001 Unit: dB UNLESS OTHER SPECIFIED TOLERANCES ON： X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± INPAQ TECHNOLOGY CO., LTD. SCALE： UNIT：mm DRAWN BY：邱子紋 CHECKED BY：陳智崴 DESIGNED BY：陳俊達 APPROVED BY：蘇志銘 THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DOCUMENT SPEC REV. TITLE：Embedded Single-Band Antenna for WA-W-LA-00-001 NO. ENS000033640 A0 PAGE 2 OF 2 2-4 Antenna Efficiency and Gain Frequency(MHz) Peak Gain(dBi) Efficiency(％) 2400 -1.45 19.58 2410 -1.37 20.02 2420 -1.32 20.50 2430 -130 20.72 2440 -1.34 20.67 2450 -1.39 20.32 2460 -1.39 20.19 2470 -1.40 20.13 2480 1.57 19.22 2490 1.71 18.67 2500 1.87 18.03 3. Physical Specification: 3 1 2 AWG 32WG MATERIAL Stranded Tinned Copper COND.SIZE 7/0.08 導體 Stranded Dia.(mm) 0.24 MIN.THICKNESS 0.10mm MATERIAL NHFR COLOUR Blue 外皮（絕緣體） O.D 0.50±0.05mm Z X Y Unit: mm

UNLESS OTHER SPECIFIED TOLERANCES ON： X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± INPAQ TECHNOLOGY CO., LTD. SCALE： UNIT：mm DRAWN BY：邱子紋 CHECKED BY：陳智崴 DESIGNED BY：陳俊達 APPROVED BY：蘇志銘 THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DOCUMENT SPEC REV. TITLE：Embedded Single-Band Antenna for WA-W-LA-00-001 NO. ENS000033640 A0 PAGE 1 OF 2 Embedded Single-Band Antenna for WA-W-LA-00-001 1. Explanation of part number : (1) (2) (3) (4) (5) (1) Product Type：Wireless Antenna (2) Material : Wire (3) Center Frequency/Band code :2.4~2.5GHz/ BT (4) Coaxial Cable Type : 00 (No Coaxial Cable) (5) Suffix : 001 2. Electrical Specification : These specifications are specially defined for TOMTOM_Catania(5”) model, and all characteristics are measured with the unit. 2-1 Frequency Band: Frequency MHz BT 2400~2500 2-2 Impedance 50 ohm nominal 2-3 Return Loss 2400 MHz 2450 MHz 2500 MHz -12.57 -17.85 -11.25 W A WL A00001 Unit: dB UNLESS OTHER SPECIFIED TOLERANCES ON： X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± INPAQ TECHNOLOGY CO., LTD. SCALE： UNIT：mm DRAWN BY：邱子紋 CHECKED BY：陳智崴 DESIGNED BY：陳俊達 APPROVED BY：蘇志銘 THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DOCUMENT SPEC REV. TITLE：Embedded Single-Band Antenna for WA-W-LA-00-001 NO. ENS000033640 A0 PAGE 2 OF 2 2-4 Antenna Efficiency and Gain Frequency(MHz) Peak Gain(dBi) Efficiency(％) 2400 -1.45 19.58 2410 -1.37 20.02 2420 -1.32 20.50 2430 -130 20.72 2440 -1.34 20.67 2450 -1.39 20.32 2460 -1.39 20.19 2470 -1.40 20.13 2480 1.57 19.22 2490 1.71 18.67 2500 1.87 18.03 3. Physical Specification: 3 1 2 AWG 32WG MATERIAL Stranded Tinned Copper COND.SIZE 7/0.08 導體 Stranded Dia.(mm) 0.24 MIN.THICKNESS 0.10mm MATERIAL NHFR COLOUR Blue 外皮（絕緣體） O.D 0.50±0.05mm Z X Y Unit: mm

Compliance Certification Services Inc. Report No.: T100127002-RP1 FCC ID: S4L4EV42 Date of Issue: February 15, 2011 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 52 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For GPS Navigation system Model: 4EV42 Trade Name: TomTom Issued to TomTom International BV. Rembrandtplein 35 1017 CT Amsterdam The Netherlands Issued by Compliance Certification Services Inc. No. 11, Wu-Gong 6 th Rd., Wugu Industrial Park, Taipei Hsien 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Compliance Certification Services Inc. Report No.: T100127002-RP1 FCC ID: S4L4EV42 Date of Issue: February 15, 2011 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION ........................................................................................................................4 3. TEST METHODOLOGY .................................................................................................................6 3.1 EUT CONFIGURATION.....................................................................................................................6 3.2 EUT EXERCISE.................................................................................................................................6 3.3 GENERAL TEST PROCEDURES..........................................................................................................6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS......................................................7 3.5 DESCRIPTION OF TEST MODES........................................................................................................8 4. INS…

Text truncated - open the document above for the full version.
