S4LFF51WiFi/BT Module

产品承认书 SPECIFICATION AW869A DualbandWiFi6+BT5.2ModuleSpec 拟制 Design 审核 Check 批准 Approve 版本 Version 日期 Date V1.12023.03.13 产品承认书 SPECIFICATION 更改记录 ReversionHistory 版本 Version 日期 Date 更改内容 Modification 1.02023.02.22Firstrelease 1.12023.03.13 AddFCCwarnings 产品承认书 SPECIFICATION 目录 Contents 1.Overview...................................................................................................................................................1 2.Features...................................................................................................................................................1 3.BlockDiagram.........................................................................................................................................2 4.GeneralSpecification.............................................................................................................................2 5.RFSpecification......................................................................................................................................3 5.12.4GHzRFSpecification..........................................................................................................3 5.25GHzRFSpecification.............................................................................................................4 5.3BluetoothSection........................................................................................................................5 6.RecommendedOperatingRating........................................................................................................6 7.PhysicalDimensions..............................................................................................................................7 8.PinDescription........................................................................................................................................7 9.Suplier.......................................................................................................................................................9 10.Physicalphoto.....................................................................................................................................9 11.LayoutRecommendation................................................................................................................10 12.Baking&StorageTemperature&RecommendedReflowProfile............................................11 12.1Baking&StorageTemperature..............................................................................................11 12.2RecommendedReflowProfile................................................................................................12 13.Packinginformation..........................................................................................................................12 13.1CarriersizeDetail:....................................................................................................................12 13.2PackagingDetail.......................................................................................................................12 产品承认书 SPECIFICATION RFExposure FCCRFRadiationExposureStatement: 1.ThisTransmittermustnotbeco-locatedoroperatinginconjunctionwithanyother antennaortransmitter. 2.ThisequipmentcomplieswithRFradiationexposurelimitssetforthforan uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwitha minimumdistanceof20cmbetweentheradiatorandyourbody. ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe followingtwoconditions: 1)thisdevicemaynotcauseharmfulinterferenceand 2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay causeundesiredoperation. ApplicableFCCRules Thismodulehasbeentestedandfoundtocomplywiththefollowingrequirementsfor ModularApproval. Part15.247-Operationwithinthebands902-928MHz,2400-2483.5MHz, and5725-5850MHz. Part15.407–Generaltechnicalrequirements. Additionaltesting,Part15SubpartBdisclaimer ThemodulartransmitterisonlyFCCauthorizedforthespecificruleparts(i.e.,FCC transmitterrules)listedonthegrant,andthatthehostproductmanufactureris responsibleforcompliancetoanyotherFCCrulesthatapplytothehostnotcoveredby themodulartransmittergrantofcertification. ThefinalhostproductstillrequiresPart15SubpartBcompliancetestingwiththe modulartransmitterinstalled. TestModes Thisdeviceusesvarioustestmodeprogramsfortestsetupwhichoperateseparatefrom productionfirmware.Hostintegratorsshouldcontactthegranteeforassistancewithtest modesneededformodule/hostcompliancetestrequirements. Antennas ThisradiotransmitterhasbeenapprovedbytheFCCtooperatewiththeantennatypes listedbelowwiththemaximumpermissiblegainindicated.Antennatypesnotincluded inthislist,havingagaingreaterthanthemaximumgainindicatedforthattype,are strictlyprohibitedforusewiththisdevice. 产品承认书 SPECIFICATION Part15.21 Youarecautionedthatchangesormodificationsnotexpresslyapprovedbythepart responsibleforcompliancecouldvoidtheuser’sauthoritytooperatetheequipment. WirelessdeviceswithWLAN5GHz FCCregulationsrestricttheoperationofthisdevicetoindooruseonly. RadioAntennaTypeFreq.(MHz)Max.PeakAntennaGain(dBi) BluetoothFPC2402-24800.29 WiFi2.4GHzFPC2412-24620.29 RadioAntennaTypeFreq.(MHz)Max.PeakAntennaGain(dBi) WiFi5GHzFPC 5150~52500.45 5250~53501.85 5350~57252.78 5725~58501.55 产品承认书 SPECIFICATION Page1 1.Overview TheAW869AisahighlyintegratedmodulewithDualbandWiFi,BT5.2; combinationsolutiontosupport1×1IEEE802.11a/b/g/nWLANstandardsandBT 5.2enablingseamlessintegrationofWLAN/BTandlow-energytechnology. 2.Features ■Supportsalow-powerSDIO2.0interfaceforWLANandaHS-UARTinterfacefor BT ■ProvidesahighlyintegratedWLANsystem-on-chip(SoC)for2.4&5.8GHz 802.11n ■SupportsWLAN2.4&5.8GHz,20MHz/40MHz ■SupportsBT5.2,BLE,andANT+andbackwardcompatibilitywithBT1.xandBT 2.x+EnhancedDataRate ■Supportsasingle-endedRFportforcleanerandlowercostdesign ■SupportsSTA,AP,WiFiDirectmodesconcurrently 产品承认书 SPECIFICATION Page2 3.BlockDiagram AIC8800D 5G_RX DC/DC WL/BT_RF I/O port …

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: April 7, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i)&(ii) Filing FCC ID: S4LFF51 Statement for 47 CFR section 2.911(d)(5)(i) [TomTom International BV] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Statement for 47 CFR section 2.911(d)(5)(ii) [TomTom International BV] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: ____________________ Printed Name /Title: Barto Wijlens/ Head of Global Supply Chain Company Name: TomTom International BV

(Letter Head) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: March 9, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing TomTom International BV] (“the applicant”) certifies that, as of the date of the filing of the application, Americas Compliance Consulting LLc dba iCertifi. is our designated U.S. agent for service of process. TomTom International BV accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission‐related proceeding involving the equipment. Americas Compliance Consulting LLc dba iCertifi. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process. Sincerely, Designated U.S. Agent Information: FRN: 0033399411 Name: Americas Compliance Consulting LLc dba iCertifi Contact Person: Mr Paul A Preston Address: 1001 SW Disk Drive, ste 250 Office 3 Bend, OR 97702 United States Tel.: (866) 885‐4575 Email: [email protected] U.S. Agent Signature: Applicant: Company Name: TomTom International BV Grantee Code: S4L Contact Person: Fergus King Address: De Ruijterkade 154 1011 AC Amsterdam, The Netherlands Tel.: +31(0)207574992 Email: [email protected] Applicant Signature:

[此處請放 Letter Head] Date: March 9, 2023 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding FCC ID: S4LFF51 To whom it may concern: We, the undersigned, hereby authorize Jim Chang, SGS Taiwan Ltd. to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. [授權沒有指定效期可刪除] Agency Agreement Expiration Date: March 9, 2024 This authorization is valid until further written notice from the applicant. Sincerely, Signature: ____________________ Printed Name /Title: Barto Wijlens / Head of Global Supply Chain Company Name: TomTom International BV

[Letter Head] Date: March 9, 2023 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: S4LFF51 Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. We also request short-term confidentiality on certain exhibits until the intended date of marketing as outlined below. We request the exhibits be withheld from public view for a period of 180 days. We attest marketing of the product will only commence after the period of short-term confidentiality expires, or if marketing is to commence before the requested number of days listed above, the grantee will inform BABT to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. Exhibit Type of Confidentiality Requested Block Diagrams ☒ Permanent ☐ Short Term Operation Description ☒ Permanent ☐ Short Term Parts List & Placement/BOM ☒ Permanent ☐ Short Term Tune-Up Procedure ☐ Permanent ☐ Short Term Schematic Diagrams ☒ Permanent ☐ Short Term External Photos ------------------ ☒ Short Term Internal Photos ☐ Permanent* ☒ Short Term Test Setup Photos ------------------ ☒ Short Term User’s Manual ☐ Permanent* ☒ Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Signed: Printed name: Barto Wijlens Title: Head of Global Supply Chain Company Name: TomTom International BV

Antenna SPEC Customer：Apical Project Name：Belsito 7" （2139） Working Band: WiFi 2.4g+5g Mainboard Version：2139-MAIN-01C-1 2022-10-18 Sunnyway BOM SPEC-Type Sunnyway Antenna Customer Part Number WIFI Antenna SZ19444IW77 Change history Preparation/change date change content Changed by version 2022.11.23 First edition Yangxin A Sunnyway Countersign Column R&D ME： Audit： Quality Engineer： Approval： RF： Audit： Customer Countersign Column Electronic Engineer Project Manager Structural Engineer Quality Engineer Shanghai R&D Center: 1F, Building 4, No.99, Lane 215, Gaoguang Road, Qingpu District, Shanghai, 201799, PRC Shenzhen R&D Center: Room 405, Jinke Building, No.8, Qiongyu Road, Nanshan District, Shenzhen, 518057, PRC ChongQing R&D Center: 1F, ARM Ecological Industrial Park, 19 East Datugu Road, Xiantao, Yubei District, Chongqing, 401120, PRC Huizhou Factory: 4-5F, No.1, Central Village Road, Longhu Industrial Zone, Shuikou Town, Huicheng District, Huizhou, 516255, PRC TEL：021-60835368 E-mail：[email protected] Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification ITEM 1 PROJECT PICTURES 2 TEST FIXTURE 3 MATCHING CIRCUIT 4 S11 TEST 4.0 S11 test method 4.1 S11 parameter 4.2 Efficiency&Gain 5 CHAMBER TEST DATA 5.0 test equipment 5.1 Efficiency and Gain 5.2 Antenna 3D Radiation Pattern 5.3 Active test data 6 GROUND HANDLING 7 MASS PRODUCTION ANTENNA SPEC 8 Structural drawings 9 RELIABILITY TEST REPORT 10 PACKING INSTRUCTIONS Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 1. PROJECT PICTURES project pictures shown below： PS： To ensure that the antenna shipment quality, the final prototype Clients validated the antenna’s performance, should be kept in our company for at least a year time, facilitate solving antenna amount during abnormal situation, 2．TEST FIXTURE Purpose： To test antenna passive parameters as accurately as possible。 methods：the fixture is to use a 50 ohm coaxial cable, one end is connected to the pad after the antenna ‘s matching circuit (the front of the antenna switch) , and the other end is connected to the SMA connector. 3. MATCHING CIRCUIT Antenna matching did not modify Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 4. S11 test 4.0 S11 test method instructions Test equipment：LNA(Agilent E5071B) Test method：With a 50 ohm CABLE ,CABLE export from instrument testing port ，After the calibration with calibration Key, connected to the SMA connector，Records the return loss and VSWR of the related frequency points. Test schematic diagram is as follows： Test schematic diagram Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 4.1 S11 parameter WIFI ANT VSWR Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 5 CHAMBER TEST DATA Test equipment Test system: chamber Test environment: the temperature of 22 °C + 3 °C, humidity of 50% plus or minus 15% Test equipment: to test passive status , use Agilent 8960 Agilent E5071B to test active status, use CMW500 5.1 Efficiency and Gain Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 5.2 Antenna 3D Radiation Pattern 3D For 2450MHz Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 3D For 5550MHz Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 2D cross-sectional view Shenzhenshi Sunny-way Technology ltd. Company Antenna Specification 5.3 Active test data

LETTER HEAD WIFI Channel 12 & 13 Declaration Letter Date: 2023/3/9 To whom it may concern, we declare below featured for equipment authorization regarding FCC ID: SL4FF51 Please check ☐ Product hardware does not have the capability to operate on channel 12 & 13. ☒ Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels. ☐ Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. ☐ Others Pls explain detail here. Signature: Title / Name (Printed): Head of Global Supply Chain / Barto Wijlens

( LETTER HEAD) Modular Approval Request FCC (KDB 996369 D01 & Part 15.212) FCC ID: SL4FF51 Items to be covered by Single modular transmitters. Answer from applicant 1. The modular transmitter must have its own RF shielding. Yes, The EUT provides the RF shielding. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. The EUT has its buffered modulation. Please see the Schematic Diagram. 3. The modular transmitter must have its own power supply regulation. The EUT has its own power supply regulation. Please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(b)(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The EUT meets the FPC antenna requirements; unique antenna connector / permanently attached antenna Please refer to photo of antenna are shown in the test report. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The EUT was testes in a stand-alone configuration. Please see section photographs of test configuration in the test report. 6. The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number in accordance with 15.212 (a)(1)(vi)(A) / (B). Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions gives to the OEM on how to label the end product 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are given in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 1.1310, 2.1091, 2.1093, and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The EUT is compliant with RF exposure requirement. RF exposure is addressed in the RF exposure exhibition. Note: A limited modular approval (LMA) may be granted for single or split modular transmitters that comply partially with the requirements above. Name and surname of applicant (or authorized representative): TomTom International BV Date:March 9, 2023 Signature: ___________________________

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-A03 Rev.A/0 Page: 1 of 3 Appendix Internal Photos for FYCR2211000442AT FCC ID: S4LFF51 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-A03 Rev.A/0 Page: 2 of 3 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-A03 Rev.A/0 Page: 3 of 3 - End of the Appendix -

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-A03 Rev.A/0 Page: 1 of 3 Appendix Internal Photos for FYCR2211000442AT FCC ID: S4LFF51 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-A03 Rev.A/0 Page: 2 of 3 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-A03 Rev.A/0 Page: 3 of 3 - End of the Appendix -

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044205 Page: 1 of 15 Winkey Wang EMC Technical Manager RF EXPOSURE EVALUATION REPORT Application No.: FYCR2211000442AT Applicant:TomTom International BV Address of Applicant:De Ruijterkade 154 1011 AC Amsterdam, The Netherlands Manufacturer:TomTom International BV Address of Manufacturer:De Ruijterkade 154 1011 AC Amsterdam, The Netherlands Factory:Hunan Zhonglongtong Technology Co., Ltd Address of Factory:Floor 3, Building 1, Xiangjiang Kunpeng Industrial Park, No. 67, Ziyuan Road, Shixue Street, Yuelu District, Changsha City, Hunan Province, China Equipment Under Test (EUT): EUT Name:WiFi/BT Module Model No.: AW869A Trade Mark:TomTom FCC ID:S4LFF51 Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2022-11-07 Date of Evaluation: 2022-11-26 to 2022-12-06 Date of Issue: 2022-12-20 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044205 Page: 2 of 15 Revision Record VersionChapterDateModifierRemark 012022-12-20Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044205 Page: 3 of 15 2Contents Page 1Cover Page...............................................................................................................................................1 2Contents....................................................................................................................................................3 3General Information.................................................................................................................................4 3.1General Description of E.U.T.............................................................................................................4 3.2Details of E.U.T.................................................................................................................................4 3.3Separation Distance..........................................................................................................................6 3.4Test Location.....................................................................................................................................7 3.5Test Facility.......................................................................................................................................7 3.6Deviation from Standards..................................................................................................................7 3.7Abnormalities from Standard Conditions...........................................................................................7 4FCC Radiofrequency radiation exposure limits....................................................................................8 4.1Blanket 1 mW Blanket Exemption.....................................................................................................8 4.2MPE-based Exemption......................................................................................................................8 4.3SAR-based Exemption......................................................................................................................9 5Measurement and Calculation..............................................................................................................12 5.1Maximum transmit power................................................................................................................12 5.2RF Exposure Calculation.................................................................................................................14 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044205 Page: 4 of 15 3General Information 3.1General Description of E.U.T. Portable device Mobile device Product Type: Fixed device 3.2Details of E.U.T. Power supply:DC5V(Adapter or host equipment) For BT: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version:V5.2 Dual Mode Modulation Type:GFSK, pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing:1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type:FPC Antenna Gain:0.29dBi For BLE: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version:V5.2 Dual Mode Modulation Type:GFSK Number of Channels: 40 Channel Spacing:2MHz Antenna Type:FPC Antenna Gain:0.29dBi Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044205 Page: 5 of 15 For 2.4G: Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz;802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11;802.11n(HT40):7 Channel Spacing:5MHz Antenna Type:FPC Antenna Gain:0.29dBi For 5G: Operation Frequency (20MHz): U-NII-1: 5180-5240MHz; U-NII-2A: 5260-5320MHz; U-NII-2C: 5500- 5700MHz; U-NII-3: 5745-5825MHz Operation Frequency (40MHz): U-NII-1: 5190-5230MHz; U-NII-2A: 5270-5310MHz; U-NII-2C: 5510- 5670MHz; U-NII-3: 5755-5795MHz Modulation Type: 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK); 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM); 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) Channel Spacing:802.11a/n(HT20)/ac(HT20): 20MHz; 802.11n(HT40)/ac(HT40): 40MHz; DFS Function:Slave without Radar detection TPC Function:Without TPC function Antenna Type:FPC Antenna Gain: 5150-5250MHz: 0.45dBi; 5250-5350MHz: 1.85dBi; 5350-5725MHz: 2.78dBi; 5725-5850MHz: 1.55dBi Remark: The information in this section is provided by the applicant or manufacturer, CCS is not liable t…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044202 Page: 1 of 75 Winkey Wang EMC Technical Manager TEST REPORT Application No.: FYCR2211000442AT Applicant: TomTom International BV Address of Applicant: De Ruijterkade 154 1011 AC Amsterdam, The Netherlands Manufacturer: TomTom International BV Address of Manufacturer: De Ruijterkade 154 1011 AC Amsterdam, The Netherlands Factory: Hunan Zhonglongtong Technology Co., Ltd Address of Factory: Floor 3, Building 1, Xiangjiang Kunpeng Industrial Park, No. 67, Ziyuan Road, Shixue Street, Yuelu District, Changsha City, Hunan Province, China Equipment Under Test (EUT): EUT Name: WiFi/BT Module Model No.: AW869A Trade Mark: TomTom FCC ID: S4LFF51 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2022-11-07 Date of Test: 2022-11-24 to 2022-12-14 Date of Issue: 2022-12-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044202 Page: 2 of 75 Revision Record Version Chapter Date Modifier Remark 01 2022-12-20 Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044202 Page: 3 of 75 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221100044202 Page: 4 of 75 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1…

Text truncated - open the document above for the full version.
