S4L8RG0Golfer GPS watch

GOLFER GOLFER 6RG000100 QSG Golfer.indd 112/08/14 16:26 Golf Watch UG.book Page 2 Tuesday, August 12, 2014 10:09 AM 3 TomTom Golf Watch English4 Français8 Español12 Deutsch16 Italiano20 Nederlands24 Português28 Dansk32 Svenska36 Norsk40 Suomi44 Čeština48 Polski52 Português do Brasil56 简体中文 60 繁體中文 64 Golf Watch UG.book Page 3 Tuesday, August 12, 2014 10:09 AM 4 Getting started Before you start, it’s a good idea to charge your watch and download QuickGPSfix information, which helps your watch get a GPS fix and find your location quickly. 1. Download and install TomTom MySports Connect desktop application from tomtom.com/mysports/ getstarted/. 2. Place your watch in the USB dock and connect the dock to your computer. Follow the instructions that TomTom MySports Connect gives you. Tip: You can also get software updates using MySports Connect. Golf Watch UG.book Page 4 Tuesday, August 12, 2014 10:09 AM 5 EN Your watch Move up and down to select items in a menu. Move left to leave a menu. Move right to select an item and open the menu for that item. To select an option in a menu, make sure it is highlighted when you leave the menu. 1. Move Left - opens the status screen. 2. Move Down - opens the settings menu. 3. Move Right - opens the golf course menu. 4. GPS receiver. 5. Tap the three dots on the screen to turn on the backlight. Golf Watch UG.book Page 5 Tuesday, August 12, 2014 10:09 AM 6 Playing your first hole 1. From the clock, move Right. Your watch shows Please wait. When a GPS fix is found, you see a list of nearby golf courses. 2. Move Up or Down to select a course, then move Right to start a round. 3. The first hole is shown and you see the following information on your watch: •Hole number (next to the flag symbol). •Par for the hole. •Distance from your position to the back, center and front of the green. Note: Distance to the pin is not shown because pin placement may vary from day to day. •A bent arrow shows whether the hole has a dog leg or not. Tip: Move Right to see more information about the hole. Golf Watch UG.book Page 6 Tuesday, August 12, 2014 10:09 AM 7 EN 4. Take any practise strokes that you need. Play your first stroke and then walk to the location of your golf ball. The remaining distance to the hole is shown. 5. Play the remainder of the strokes for this hole until you hole out. 6. Move Right twice to enter the score for your first hole. 7. Walk to the second hole. Your watch updates or you can move Up or Down from the range screen to manually move to the second hole. Getting more help For support, more information and to download the Reference Guide, go to tomtom.com/support. Tip: The Reference Guide includes a glossary of golfing terms. Golf Watch UG.book Page 7 Tuesday, August 12, 2014 10:09 AM 8 Pour commencer Avant de commencer, nous vous recommandons de recharger votre montre et de télécharger les informations QuickGPSfix, ce qui permettra à votre montre de trouver un point GPS et de vous localiser plus rapidement. 1. Téléchargez et installez l'application de bureau TomTom MySports Connect à partir de la page tomtom.com/ mysports/getstarted/. 2. Placez votre montre dans le support USB et branchez ce dernier à votre ordinateur. Suivez les instructions données par TomTom MySports Connect. Conseil : vous pouvez aussi obtenir des mises à jour logicielles via MySports Connect. Golf Watch UG.book Page 8 Tuesday, August 12, 2014 10:09 AM 9 FR Votre montre Déplacez vers le haut ou vers le bas pour sélectionner des éléments d'un menu. Déplacez vers la gauche pour quitter un menu. Déplacez vers la droite pour sélectionner un élément et ouvrir le menu correspondant. Pour sélectionner une option dans un menu, assurez-vous qu'elle soit en surbrillance lorsque vous quittez le menu. 1. Vers la gauche : ouvre l'écran d'état. 2. Vers le bas : ouvre le menu Paramètres. 3. Vers la droite : ouvre le menu Parcours de golf. 4. Récepteur GPS. 5. Touchez les trois points à l'écran pour activer le rétroéclairage. Golf Watch UG.book Page 9 Tuesday, August 12, 2014 10:09 AM 10 Jouer votre premier trou 1. Depuis l'horloge, appuyez vers la droite. Votre montre afficheVeuillez patienter. Sitôt qu'un point GPS est détecté, une liste des parcours de golf situés à proximité s'affiche. 2. Appuyez vers le haut ou vers le bas pour sélectionner un parcours, puis appuyez vers la droite pour démarrer un tour de jeu. 3. Le premier trou s'affiche et vous pouvez lire les informations suivantes sur votre montre : •Numéro du trou (à côté du petit drapeau). •Par fixé pour le trou. •Distance de votre position par rapport au fond, au centre et à l'avant du green. Remarque : la distance par rapport au drapeau n'est pas indiquée, car le drapeau peut changer de position sur certains parcours. •Une flèche courbée s'affiche pour indiquer que la trajectoire jusqu'au trou est coudée. Golf Watch UG.book Page 10 Tuesday, August 12, 2014 10:09 AM 11 FR Conseil : appuyez vers la droite pour afficher plus d'informations sur le trou. 4. Faites autant de coups d'essai que vous le souhaitez. Frappez votre premier coup et marchez jusqu'à la balle. La distance restante jusqu'au trou s'affiche. 5. Jouez vos autres coups, jusqu'à ce que la balle reste dans le trou. 6. Appuyez vers la droite deux fois pour entrer votre score pour ce premier trou. 7. Marchez jusqu'au deuxième trou. Votre montre se met à jour. Vous pouvez aussi appuyer vers le haut ou le bas depuis l'écran affichant les informations sur le terrain pour passer manuellement au deuxième trou. Obtenir de l'aide Pour bénéficier d'une assistance, obtenir davantage d'informations et télécharger le guide de référence, rendez- vous sur tomtom.com/support. Conseil : le guide de référence comprend un glossaire des termes relatifs au golf. Golf Watch UG.book Page 11 Tuesday, August 12, 2014 10:09 AM 12 Primeros pasos Antes de comenzar, le recomendamos que cargue el reloj y que descargue la información de QuickGPSfix para que el reloj obtenga la señal GPS y encuentre su po…

Text truncated - open the document above for the full version.

TomTom International B.V. De Ruijterkade 154, 1011 AC Amsterdam, The Netherlands Letter of Authorization To whom it may concern, We the undersigned, hereby authorize SGS Taiwan Ltd. (134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan 24803, tel. +886-2-22993279) and Dr. Clement Magniez, Program Manager (e-mail: [email protected], tel. + 44 207 255 9164 office) of 8RG0 in TomTom International B.V. to act on our behalf in all manners relating to application for FCC equipment authorization, including signing of all documents relation to these matters. Any and all acts carried out by SGS Taiwan Ltd., on our behalf shall have the same effect as acts of our own. The authorization from TomTom International B.V. is valid until further notice from the data of this letter. Model No.: 8RG0 FCC ID: S4L8RG0 Sincerely, TomTom International BV Vince Wolfe / VP Product Development Telephone No: +31(0)20 8500800 Fax No: +31(0)20 8501099 Email: [email protected]

Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group APPENDIX 2 EXTERNAL PHOTOGRAPHS OF EUT Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group All View of EUT-1 All View of EUT-2 Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Front View of EUT Back View of EUT Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistric…

Text truncated - open the document above for the full version.

Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group APPENDIX 2 INTERNAL PHOTOGRAPHS OF EUT Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Front View of Battery Back View of Battery Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Open View of EUT-1 Open View of EUT-2 Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,W…

Text truncated - open the document above for the full version.

RF Exposure Standard Applicable: According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device with its physical nature to be used nearby, the distance between radiating structure and human is less than 20cm. As per KDB 447498 D01 $4.3.1, The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation Measurement Result: Step 1: (<50mW) This is a portable device and the Max avg output power is (0.78mW) lower than the threshold given and derived as formula given above, where =0.78 (mW)/5 (mm)*√2.480 (GHz) = 0.245050637< 3.0 Frequency (MHz) Avg Power (dBm) Output Power (W) Limit (W) 2442 -1.09 0.000778 1 Watt = 30 dBm As the result of calculation result indicates, the RF exposure generating from given transmitter (transmitter employed digital modulation) can be excluded from SAR measurement, and is deemed compliant with RF exposure as per FCC. The table of quick reference in terms of power threshold Note that the table present above is the table of quick reference, indexing the level of power threshold with respect to the corresponding frequency. The value of the index may be deviated, and therefore, the derivation of exemption based on KDB447498 D01 is used in this test report, relevantly.

Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Page: 1 of 51 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT AND INDUSTRY CANADA RSS 210 OF Product Name: TomTom Golfer GPS watch Brand Name: TomTom Model No.: 8RG0 Model Difference: N/A FCC ID: S4L8RG0 IC: 5767A-8RG0 Report No.: E2/2014/80005 Issue Date: Aug. 14, 2014 FCC Rule Part: §15.247, Cat: DTS IC Rule Part: RSS-210 issue 8 :2010, Annex 8 Prepared for: TomTom International B.V. De Ruijterkade 154, Amsterdam 1011 AC Netherlands Prepared by: SGS Taiwan Ltd. Electronics & Communication Laboratory No.2, Ke ji 1st Rd., Guishan Township, Taoyuan County, Taiwan 333 Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This doc- ument may be altered or revised by SGS Taiwan Ltd. per- sonnel only, and shall be noted in the revision section of the document. Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Page: 2 of 51 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group VERIFICATION OF COMPLIANCE Applicant: TomTom International B.V. De Ruijterkade 154, Amsterdam 1011 AC Netherlands Product Name: TomTom Golfer GPS watch Brand Name: To mTo m Model No.: 8RG0 Model Difference: N/A FCC ID: S4L8RG0 IC: 5767A-8RG0 File Number: E2/2014/80005 Date of test: Aug. 01, 2014 ~ Aug. 11, 2014 Date of EUT Received: Aug. 01, 2014 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. Electronics & Communication Laboratory The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and RSS-Gen. issue 3 the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247 and IC RSS 210 issue 8: 2010 Annex 8. The test results of this report relate only to the tested sample identified in this report. Test By: Date Aug. 14, 2014 Jazz Huang / Sr. Engineer Prepared By: Date Aug. 14, 2014 Violetta Tang / Clerk Approved By: Date Aug. 14, 2014 Jim Chang / Supervisor Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Page: 3 of 51 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all th…

Text truncated - open the document above for the full version.

Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group APPENDIX 1 PHOTOGRAPHS OF SET UP Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Radiated Emission Set up Photos (E2 PLAN) (Below 1GHz) Report No.: E2/2014/80005 FCC ID: S4L8RG0 Issue Date: Aug. 14, 2014 IC: 5767A-8RG0 Unless otherwise stated the results shown in this test report refer only to the sample(s) teste…

Text truncated - open the document above for the full version.
