S4LGO520PND (Personal Navigation Device)

What’s in the box 4 EN What’s in the box aYour TomTom AMicrophone BCharging light COn/Off button DLight sensor EReset button FSpeaker GMemory card slot HUSB connector ITomTom connector JExternal antenna connector KAudio out connector bCar chargercDocumentation pack dWindshield HoldereHome Dock fRDS-TMC Traffic Receiver * 520T & 720T only EN Before You Start... 5 Before You Start... Read the entire manual Important: You are currently reading the Quick Start Guide. There is a full version of the manual available as a PDF file on the CD. Battery notes We recommend that you fully charge your TomTom the first time that you connect it to the home dock. It takes up to 2 hours to charge the battery completely. Note: Your TomTom uses a small amount of battery power to remember the last screen being shown when the device is switched off. If you do not charge your GO for a prolonged period of time, the next time you start your GO it will show the default starting screen. All other device settings will still be maintained. Switching on and off To switch your TomTom on or off, press and hold the On/Off button for 2 seconds. The first time you switch on, it may take up to 20 seconds to start. If your GO is connected to a computer using the USB cable and you selected Yes when your GO asked if you want to connect to your computer, the device will automatically switch off if you do not tap the screen for three minutes. Note: In rare cases, your GO may not start correctly. If this happens, press the reset button (see What’s in the box on page 4) and switch on the device. Setting up To set up your TomTom you need to answer a few questions by tapping the screen. Note: Take care to select the correct language, since the language you choose will be used for all menus and written instructions. The Driving View is shown in black and white until your GO locates your current position. The buttons on your GO are shown in full color unless a button is currently unavailable. For example, the button named Find alternative is not available until you have planned a route using Navigate to.... Windshield Holder The windshield holder is used to install your TomTom inside your car. To learn how to attach the holder to your windshield, refer to the installation poster. Tips • Make sure your windshield is clean and dry before you attach the holder. • Place the holder so that it does not interfere with your view of the road. • Attach the holder to an area of the windshield where the glass is flat. Home Dock The home dock is used for charging your TomTom when it is not in the car and for connecting your GO to your computer. When connected to your computer, you can use TomTom HOME with your GO. For information about TomTom HOME, see Using TomTom HOME on page 13. EN Before You Start... 6 Back Up your TomTom Regularly make a backup of the files on your TomTom using TomTom HOME. For more information about TomTom HOME, see Using TomTom HOME on page 13. Everyone Loves TomTom Never leave your TomTom or accessories in view when you leave the car or they may become an easy target for thieves. Secure your TomTom You can set a password for your TomTom which must be entered every time you start your GO. You can set the password using TomTom HOME. Take care of your TomTom It is important to take care of your GO. • Your GO is not designed for use in extreme temperatures and any such exposure may cause permanent damage. • Do not open the casing of your GO under any circumstances. Doing so may be dangerous and will invalidate the warranty. • Wipe or dry the screen of your GO using a soft cloth. Do not use any liquid cleaners. • Do not use the memory card in any device other than a TomTom device. Improving reception If your TomTom takes longer than 5 minutes to find your current position, make sure that the device is in an open space away from tall objects such as buildings or trees. When you connect your TomTom to your computer, you can use TomTom HOME to download information about where the GPS satellites are going to be for the next 7 days. Important: Some vehicles have heat reflective shielding in the windshield. This may prevent your GO from locating your current position. The TomTom External Antenna Kit (available as an accessory) will help improve reception. Driving View When your TomTom starts, you are shown the Driving View which shows your immediate location on the current route. Note: The Driving View is shown in black and white until your GO locates your current position. ATap + and - to zoom in and out. BYour current position. CThe name of the next major road or road sign information, if applicable. EN Using TomTom HOME 7 DNavigation instruction for the road ahead. Tap this area to repeat the last spoken instruction and to change the volume. EThe name of the next street to turn on to. FInformation about your journey such as journey time, remaining distance and arrival time. To select what will be shown, tap Status bar preferences in the Preferences menu. GGPS signal strength. Using TomTom HOME Using TomTom HOME TomTom HOME is a free software program for your computer that enables you to: • Read the full version of the user manual. • Update your TomTom with the latest software and services automatically. • Make and restore backups of your GO. • Manage maps, voices, POIs and more. • Transfer music and photos to your GO. • Buy TomTom services and manage your subscriptions. Installing TomTom HOME There are two ways to install TomTom HOME on your computer. Internet installation: • Connect the Home Dock to your computer using the USB cable. • Place your TomTom in the Home Dock and connect your computer to the Internet. The installation will start automatically. CD installation: • Place the CD which came with your GO into your computer and follow the instructions. If the installation does not automatically start after you insert the CD, browse to the CD on your computer and double-click the file named Install TomTom HOME. Once installed…
