S4W1203NEON LIGHTING IN JUKEBOX

F F C C C C - - T T E E S S T T R R E E P P O O R R T T REPORT NO.: 39762/4/600F FCC – Test Report No. 39762/4/600F Date: 2004-12-09 Page 2 of 17 FCC listed testlab acc. to Section 2.948 of the FCC - Rules Product : Jukebox Radio with 3CD Player Product Class : - FM Broadcast Receiver and Class B Digital Devices and Peripherals (Part 15 Subpart B) - Part 18 Consumer Device Model : CR12-3 Brand name : CROSLEY Applicant : HONG KONG MODERN MARKETING MANUFACTURING LIMITED FCC – Test Report No. 39762/4/600F Date: 2004-12-09 Page 3 of 17 TABLE OF CONTENTS 1. Cover sheet 2. Introduction 3. Table of Contents 4. Laboratory Report 5. Summary of Testresults 6. Test Equipment List 7. Radiated Emission Testprocedure (> 30MHz) 8. Radiated Emission Testprocedure (9kHz-30MHz) 9. Interference Radiation (Datasheet) 10. Interference Radiation (Datasheet) 11. Interference Radiation (Datasheet) 12. Notes for Radiation Measurement 13. Interference Voltage (Datasheet) 14. Interference Voltage (Datasheet) 15. Interference Voltage (Datasheet) 16. Interference Voltage (Datasheet) 17. Notes for Voltage Measurement FCC – Test Report No. 39762/4/600F Date: 2004-12-09 Page 4 of 17 LABORATORY - REPORT APPLICANT: ADDRESS: HONG KONG MODERN MARKETING MANUFACTURING LIMITED Room 1024, 10/F., Beverley Commercial Centre 87-105 Chatham Road Tsimshatsui, Kowloon HONG KONG DATE OF SAMPLE RECEIVED: 2004-09-07 DATE OF TESTING: 2004-10-08 to 2004-10-11 DESCRIPTION OF SAMPLE: Product: Jukebox Radio with 3CD Player Product class: - FM Broadcast Receiver and Class B Digital Devices and Peripherals (Part 15 Subpart B) - Part 18 Consumer Device Model number: CR12-3 Brand name: CROSLEY Rating: AC 120V 60Hz INVESTIGATIONS REQUESTED: Measurements to the relevant clauses of F.C.C. Rules and Regulations : Part 15 Subpart B -- Unintentional Radiators Part 18 – Industrial, Scientific, and Medical Equipment RESULTS: See the attached test sheets CONCLUSIONS: From the measurement data obtained, the tested sample was considered to have COMPLIED with the requirements for the relevant clauses of Federal Communications Commission Rules as specified above. Note : The conducted emissions test (if applicable) has considered the limits in Sections 15.107 and 18.307 adopted under FCC 02-157 (ETDocket 98- 80). The product may be marketed after July 11, 2005, and is not affected by the 18.123 transition provisions. _________________________________ Authorized Signature Remark: Purpose of those tests in this report is to provide the applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under the FCC Equipment Authorization Program. The tests themselves are not Approval Tests FCC – Test Report No. 39762/4/600F Date: 2004-12-09 Page 5 of 17 Summary of Test Results Interference Radiation: Test result: O.K. Test data: See attached data sheet Interference Voltage: Test result: O.K. Test data: See attached data sheet PHOTOGRAPH OF THE SAMPLE FCC – Test Report No. 39762/4/600F Date: 2004-12-09 Page 6 of 17 TEST EQUIPMENT LIST Equipment Manufacturer Model Serial No. Remark Test Receiver Rohde & Schwarz ESH 3 863497/015 150KHz – 30MHz Test Receiver Rohde & Schwarz ESH 3 892580/006 9KHz – 30MHz Test Receiver Rohde & Schwarz ESVP 860688/022 25MHz – 1,000 MHz Test Receiver Rohde & Schwarz ESVP 863512/012 25MHz – 1,000 MHz Test Receiver Rohde & Schwarz ESHS30 839667/002 9KHz – 30MHz Test Receiver Rohde & Schwarz ESVS30 828525/006 25MHz – 1000MHz Spectrum Analyzer with Q. Peak Advantest R3132 140101852 9KHz – 3GHz Spectrum Analyzer with Q. Peak Tektronix 2712 B023006 0.15MHz – 1000MHz Interface for Spectrum 2712 Tektronix TD3F14A -- -- Impulse Limiter Rohde & Schwarz ESH-3-Z2 -- -- Artificial Mains Network (LISN) Schwarzbeck NSLK 8127 8127312 2 x 10A, 50Ω, 50μH 9KHz-30MHz Artificial Mains Network (LISN) Schwarzbeck NSLK 8127 8127309 2 x 10A, 50Ω, 50μH 9KHz-30MHz Antenna System Schwarzbeck BBA 9106 / UHALP 9107 -- 30MHz – 1000MHz Antenna Mast System Schwarzbeck AM9104 -- Max. 4 meters height Loop Antenna Rohde & Schwarz HFH2-Z2 871336/48 9KHz-30MHz Turntable with Controller Drehtisch DT312 -- φ120 cm FCC – Test Report No. 39762/4/600F Date: 2004-12-09 Page 7 of 17 Radiated Emission Test Procedure (> 30MHz) Equipment under test (on turntable) Test receiver ESVP R & S Required test distance: 3m Antenna system Schwarzbeck BBA 9106/ UHALP 9107 FCC – Test Report No. 39762/4/600F Date: 2004-12-09 Page 8 of 17 Radiated Emission Test Procedure ( 9kHz – 30MHz) Test distance : 3 m Loop antenna HFH2-Z2 Rohde & Schwarz Equipment under test (on turntable) Test Receiver ESH3 Rohde & Schwarz 141U1 Interference Radiation 30MHz to 1000MHzDate : 2004-12-09 According:FCC Part 15 Subpart BPage 9 of 17 IECC Ref:39762/4/200F Model:CR12-3Test Equipment Applicant:HONG KONG MODERN MARKETING Receiver: ESVP Rohde & Schwarz MANUFACTURING LIMITEDAntenna: Schwarzbeck BBA 9106 Ser.Nr.:1 and UHALP 9107 Oper. Mode:FM Mode InterFreq:10.7MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics Reading dBμV Polari- zation Correction - factor (dB) Testresult dBμV/m Limit dB(μV/m) 89.8100.5122H10.432.443.5 201.0220H16.536.543.5 301.5318H16.334.346.0 402.04<16H18.3<34.346.0 502.55<16H19.7<35.746.0 603.06<16H20.9<36.946.0 703.57<16H22.4<38.446.0 804.08<16H23.8<39.846.0 904.59<16H25.1<41.146.0 98.3109.0121H11.732.743.5 218.0220H17.037.046.0 327.0318H16.834.846.0 436.04<16H18.8<34.846.0 545.05<16H20.2<36.246.0 654.06<16H21.7<37.746.0 763.07<16H23.2<39.246.0 872.08<16H24.7<40.746.0 981.09<16H26.2<42.254.0 108.0118.7121H12.733.743.5 237.4220H17.437.446.0 356.1318H17.535.546.0 474.84<16H19.4<35.446.0 593.55<16H20.8<36.846.0 712.26<16H22.6<38.646.0 830.97<16H24.1<40.146.0 949.68<16H25.8<41.846.0 Remark:The above recorded data were the higher values of the horizontal (H) and vertical (V) polarity measurement. All frequencies in the required range were scanned and those significant readings were reported. All emissions not reported a…

Text truncated - open the document above for the full version.
