S5EAA70008BLUTAG

Satellite Tracking of People LLC User¶s Guide Version 6.2 Sixth Edition, Amendment 2 (November 2004) VeriTracksŒ, BluTag® and various software icons are worldwide registered trademarks of Satellite Tracking of People LLC (STOP). The software described herein has U.S. and Foreign Patents Pending. STOP provides this publication as is without warranty of any kind, expressedor implied, including, but not limited to, the implied warranties of merchantability or fitness for a particular purpose. This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information contained herein; these changes will be incorporated in new editions of the publication. STOP may make improvements and/or changes to the products described in this publication at any time. Reproduction of this document is expressly forbidden. © 2005 Satellite Tracking of People LLC. All rights reserved. VeriTracksŒ User¶s Manual Satellite Tracking Of Peopleiii Table of Contents Chapter 1: About VeriTracksŒ and BluTag®............................................ 1 About this document................................................................................. 1 Getting Help.............................................................................................. 2 Chapter 2: Getting Started.......................................................................... 3 System Requirements.............................................................................. 3 VeriTracksŒ Overview............................................................................. 4 BluTag®..................................................................................................... 5 Detailed System Processes..................................................................... 6 Logging In.............................................................................................. 6 Understanding the Menu Options........................................................ 7 Understanding Search and Data Entry Page Features..................... 9 User Discussion Forum...................................................................... 10 Chapter 3: Registering an Offender.......................................................... 11 Hardware Components........................................................................... 11 Enrolling a New Tracked Offender........................................................ 13 Offender Profile................................................................................... 13 Offender Addresses............................................................................ 14 Tracking Device.................................................................................. 15 Zones................................................................................................... 15 Preparing the BluTag® Device for Use................................................. 16 Chapter 4: Supervising an Offender......................................................... 17 Software Components............................................................................ 17 Searching for a Tracked Offender Record........................................ 17 Offender Status................................................................................... 18 Inventory.............................................................................................. 19 VeriTracksŒ User¶s Manual ivSatellite Tracking Of People Zones...................................................................................................20 Chapter 5: Conducting Searches..............................................................23 Incident Hit Search..................................................................................23 Incident Search........................................................................................24 Tracked Offender Search........................................................................24 Zone Search............................................................................................25 Zone Hit Search.......................................................................................25 Chapter 6: Understanding Reports............................................................27 The Report Frame...................................................................................27 Incident Hit Search Results....................................................................28 Incident Search Results..........................................................................29 Tracked Offender Search Results..........................................................31 Zone Search Results...............................................................................33 Zone Hit Search Results.........................................................................33 Chapter 7: Administration..........................................................................35 Incident.....................................................................................................35 Zone.........................................................................................................37 Preferences..............................................................................................39 Profile...................................................................................................40 Notifications.........................................................................................41 Map Preferences.................................................................................42 User Accounts.........................................................................................44 Chapter 8: Maps.........................................................................................47 Map Components....................................................................................47 Map Features.............…

Text truncated - open the document above for the full version.

Siemens Cellular Engine Hardware Interface Description Version 00.02 DocID: MC45_HD_01_V00.02a MC45 Hardware Interface Description P R E L I M I N A R Y MC45_HD_01_V00.02a Page 2 of 90 12.08.2002 Document Name: MC45 Hardware Interface Description Version: 00.02 Date: August 12, 2002 DocId: MC45_HD_01_V00.02a Status: PRELIMINARY General notes With respect to any damages arising in connection with the described product or this document, Siemens shall be liable according to the General Conditions on which the delivery of the described product and this document are based. This product is not intended for use in life support appliances, devices or systems where a malfunction of the product can reasonably be expected to result in personal injury. Siemens AG customers using or selling this product for use in such applications do so at their own risk and agree to fully indemnify Siemens for any damages resulting from illegal use or resale. Applications incorporating the described product must be designed to be in accordance with the technical specifications provided in these guidelines. Failure to comply with any of the required procedures can result in malfunctions or serious discrepancies in results. Furthermore, all safety instructions regarding the use of mobile technical systems, including GSM products, which also apply to cellular phones must be followed. Handheld applications such as mobile phones or PDAs incorporating the described product must be in accordance with the guidelines for human exposure to radio frequency energy. The Specific Absorption Rate (SAR) of the application must be evaluated and approved to be compliant with national and international safety standards or directives. Subject to change without notice at any time. Copyright notice Copying of this document and giving it to others and the use or communication of the contents thereof, are forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved in the event of grant of a patent or the registration of a utility model or design. Copyright © Siemens AG 2002 MC45 Hardware Interface Description P R E L I M I N A R Y MC45_HD_01_V00.02a Page 3 of 90 12.08.2002 Contents 0 Version History........................................................................................................... 7 1 Introduction ................................................................................................................ 9 1.1 Related documents ............................................................................................. 9 1.2 Terms and abbreviations....................................................................................10 1.3 Type approval ....................................................................................................13 1.4 Safety precautions .............................................................................................15 2 Product concept........................................................................................................17 2.1 MC45 key features at a glance...........................................................................18 2.2 Circuit concept ...................................................................................................21 3 Application Interface.................................................................................................22 3.1 Operating modes...............................................................................................23 3.2 Power supply.....................................................................................................25 3.2.1 Power supply pins on the board-to-board connector.............................25 3.2.2 Minimizing power losses.......................................................................26 3.2.3 Charging control ...................................................................................27 3.2.3.1 Battery pack characteristics ......................................................28 3.2.3.2 Recommended battery pack .....................................................29 3.2.3.3 Implemented charging technique ..............................................30 3.2.3.4 Operating modes during charging .............................................31 3.2.3.5 Charger requirements ...............................................................32 3.3 Power up / down scenarios ................................................................................33 3.3.1 Turn on MC45 ......................................................................................33 3.3.1.1 Turn on MC45 using the ignition line /IGT (Power on)...............33 3.3.1.2 Timing of the ignition process ...................................................34 3.3.1.3 Turn on MC45 using the POWER signal ...................................35 3.3.1.4 Turn on MC45 using the RTC (Alarm mode).............................35 3.3.2 Power saving ........................................................................................36 3.3.2.1 No power saving (AT+CFUN=1)................................................36 3.3.2.2 NON-CYCLIC SLEEP mode (AT+CFUN=0)..............................36 3.3.2.3 CYCLIC SLEEP mode (AT+CFUN=5, 6, 7 and 8).....................36 3.3.2.4 Timing of the /CTS signal in CYCLIC SLEEP modes................37 3.3.2.5 Wake up MC45 from SLEEP mode...........................................39 3.3.3 Turn off MC45 ......................................................................................40 3.3.3.1 Turn off MC45 using AT command ...........................................40 3.3.3.2 Emergency shutdown using /EMERGOFF pin...........................41 3.3.4 Automatic shutdown .............................................................................42 3.3.4.1 Temperature dependent shutdown............................................42 3.3.4.2 Undervoltage shutdown if battery NTC is present ...................…

Text truncated - open the document above for the full version.

Satellite Tracking of People LLC 4801 Woodway Drive, Suite 110W • Houston, Texas 77056 832-553.9500 • Fax 832-553-9530 • www.stopllc.com 23 rd March 2005 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom Subject: Certification Application FCC ID: S5EAA70008 The GSM Module used in the above device is a Siemens MC45, (FCC ID: QIPMC45).No changes have been made to this module and all information is as per the original filing. Yours sincerely Stephen Freathy

Satellite Tracking of People LLC 4801 Woodway Drive, Suite 110W • Houston, Texas 77056 832-553.9500 • Fax 832-553-9530 • www.stopllc.com 23 rd March 2005 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom Subject: Certification Application FCC ID: S5EAA70008 It is requested that the following information is to be held confidential on behalf of STOP LLC of 102 Woodmont Blvd. Suite 800 Nashville, TENNESSEE 37205 FCC Rules Part 0.459 refers. Exhibit Block Diagram (Number of files = 1 Number of pages per file = 1) Exhibit Schematics (Number of files = 1 Number of pages per file = 4) Exhibit Internal Photos (Number of files = 1 Number of pages per file = 4) Exhibit Parts List (Number of files = 1 Number of pages = 6) The reasons for withholding the above materials is that they are commercially confidential and their disclosure could result in competitive harm if they became public as they contain sufficient technical information to allow the construction of a replica device. None of the above information is available to the public and disclosure has been limited to those parties who require the information in order to provide a necessary service. We would require this confidentiality to be maintained for the life of the product. Yours sincerely Stephen Freathy

Exhibit 12 SATELLITE TRACKING OF PEOPLE LLC (STOP) Labelling for BluTag® (Version 1 – 16.03.05) LABEL DETAILS (NOT TO SCALE) LABEL & TEXT DIMENSIONS (MM) LENGTH = 35 WIDTH = 12 FONT HEIGHT OF BLUTAG NO = 3 FONT HEIGHT OF FCC ID = 2 FONT STYLE = ARIEL BLUTAG NO: 00001 FCC ID: S5EAA70008

Exhibit 5 SATELLITE TRACKING OF PEOPLE LLC (STOP) Operational Description of BluTag® BluTag® is a one-piece device, about the same size as a small PC mouse, comfortable to wear and weighs in at just 6 ounces. Typically, the device is strapped to the wearers ankle. The device uses a combination of GPS and GSM technologies to monitor the position of the wearer and pass location and status data to agency monitoring centers via GPRS communication. BluTag® has a fully rechargeable battery, tamper resistant strap, panic alarm, personal alarm notification; onboard management controls and is completely waterproof to 15 feet. Thanks to intelligent battery management software, the battery lasts in excess of 30 hours even when used in fully active tracking mode. BluTag® can be fully recharged in just 45 minutes.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Satellite Tracking of People LLC (STOP). BluTag. To: OET Bulletin 65 Supplement C: (2001-01) Measurements were performed on the DASY4 System Test Report Serial No: RFI/SARE1/RP46121JD27A Supersedes Test Report Serial No: RFI/SARE1/RP46121JD23A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: Tested By: Scott D'Adamo Checked By: Joe Lomako Report Copy No: PDF01 Issue Date: 06 April 2005 Test Dates: 04 April 2005 It should be noted that the standard, OET Bulletin 65 Supplement C: (2001-01) is not listed on RFI’s current UKAS schedule and is therefore “not UKAS accredited”. This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE1/RP46121JD27A Page 2 of 48 Issue Date: 06 April 2005 Test Of: Satellite Tracking of People LLC (STOP). BluTag. To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE1/RP46121JD27A Page 3 of 48 Issue Date: 06 April 2005 Test Of: Satellite Tracking of People LLC (STOP). BluTag. To: OET Bulletin 65 Supplement C: (2001-01) Table of Contents 1. Client Information .............................................................................................................4 2. Equipment Under Test (EUT) ...........................................................................................5 3. Test Specification, Methods and Procedures ................................................................8 4. Deviations from the Test Specification...........................................................................9 5. Operation of the EUT During Testing............................................................................10 6. Summary of Test Results ...............................................................................................11 7. SAR Measurement System.............................................................................................14 8. SAR Safety Limits ...........................................................................................................15 9. Details of SAR Evaluation ..............................................................................................16 10. Evaluation Procedures .................................................................................................17 11. System Validation .........................................................................................................18 12. Simulated Tissues ........................................................................................................19 13. Tissue Parameters ........................................................................................................20 14. DASY4 Systems Specifications ...................................................................................21 15. Validation Results – 1800 MHz Band (Body) ..............................................................22 16. Measurement Uncertainty ............................................................................................23 Appendix 1. Test Equipment Used ....................................................................................25 Appendix 2. SAR Distribution Scans ................................................................................26 Appendix 3. Test Configuration Photograph....................................................................27 Appendix 4. Calibration Data .............................................................................................29 Appendix 5. Photographs of EUT ......................................................................................31 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE1/RP46121JD27A Page 4 of 48 Issue Date: 06 April 2005 Test Of: Satellite Tracking of People LLC (STOP). BluTag. To: OET Bulletin 65 Supplement C: (2001-01) 1. Client Information Company Name: Satellite Tracking of People LLC (STOP). Address: 102 Woodmont Blvd., Suite 800 Nashville, TN 37205 USA Contact Name: Mr Stephen Freathy Test Laboratory Company Name: RFI Global Services Ltd. Address: Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ. Contact Name: Mr A Brown RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE1/RP46121JD27A Page 5 of 48 Issue Date: 06 April 2005 Test Of: Satellite Tracking of People LLC (STOP). BluTag. To: OET Bulletin 65 Supplement C: (2001-01) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Brand Name: STOP Model Name or Number: Blutag Unique type Identification: 36-0714 FCC ID Number: S5EAA70008 Serial Number: 36-0714 Battery Serial Number: None Stated Country Of Manufacture: UK Date Of Receipt: 04 April 2005 2.2. Accessories The following accessories were supplied with the EUT: Description: AC Adaptor Brand Name: MPW Model Name or Number: SA070810 Serial Number: R00040800174 Cable Length And Type: 1.5m 2 Core Connected to Port: DC Input Description: Strap Brand Name: None Sated Model Name or Number: None Sated Serial Number: None Sated Cable Length And Type: 0.27m Fibre Optic Strap Connected to Port: EUT Enclosure 2.3. Description of EUT The equipment under test is a personal tracking device exercised using 1900 MHz GPRS transmit. 2.4. Modifications Incorporated in the EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE1/RP46121JD27A Page…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Satellite Tracking of People LLC (STOP) BluTag To: FCC Part 24 Subpart E: 2004 Test Report Serial No: RFI\MPTE2\RP46121JD016A Supersedes Test Report Serial No: RFI\MPTE1\RP46121JD16A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: pp Tested By: Steven Wong pp Checked By: Tony Henriques pp Report Copy No: PDF01 Issue Date: 06 April 2005 Test Dates: 24 February 2005 to 02 March 2005 and 30 March 2005 to 01 April 2005 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be reproduced in full. Partial reproduction may only be made with the written consent of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP46121JD016A Page 2 of 42 Issue Date: 06 April 2005 Test of: Satellite Tracking of People LLC (STOP) BluTag To: FCC Part 24 Subpart E: 2004 This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP46121JD016A Page 3 of 42 Issue Date: 06 April 2005 Test of: Satellite Tracking of People LLC (STOP) BluTag To: FCC Part 24 Subpart E: 2004 Table of Contents 1. Client Information .............................................................................................................4 2. Equipment Under Test (EUT) ...........................................................................................5 3. Test Specification, Methods and Procedures ................................................................7 4. Deviations from the Test Specification...........................................................................8 5. Operation of the EUT During Testing..............................................................................9 6. Summary of Test Results ...............................................................................................10 7. Measurements, Examinations and Derived Results ....................................................11 8. Measurement Uncertainty ..............................................................................................30 9. Measurement Methods ...................................................................................................31 Appendix 1. Test Equipment Used ....................................................................................39 Appendix 2. Test Configuration Drawings........................................................................40 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP46121JD016A Page 4 of 42 Issue Date: 06 April 2005 Test of: Satellite Tracking of People LLC (STOP) BluTag To: FCC Part 24 Subpart E: 2004 1. Client Information Company Name: Satellite Tracking of People LLC (STOP) Address: 102 Woodmont Blvd. Suite 800 Nashville TN 37205 USA Contact Name: Mr Stephen Freathy RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP46121JD016A Page 5 of 42 Issue Date: 06 April 2005 Test of: Satellite Tracking of People LLC (STOP) BluTag To: FCC Part 24 Subpart E: 2004 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Brand Name: STOP Model Name or Number: BluTag Serial Number: 62 FCC ID Number: S5EAA70008 Country of Manufacture: UK Date of Receipt: 24 February 2005 Brand Name: STOP Model Name or Number: BluTag Serial Number: 18-9770 FCC ID Number: S5EAA70008 Country of Manufacture: UK Date of Receipt: 29 March 2005 Note: The Blutag 18-9770 unit was used for the following tests: Transmitter Effective Isotropic Radiated Power (EIRP), Transmitter Occupied Bandwidth, Transmitter Out of Band Radiated Emissions and Transmitter Band Edge Radiated Emissions. 2.2. Accessories The following accessories were supplied with the EUT: Description: AC Charger Brand Name: MPW Model Name or Number: SA070810 Serial Number: None stated Cable Length and Type: 2 Core, 1.6m Connected to Port: AC Charger Port 2.3. Description of EUT The equipment under test is a personal tracking device incorporating GSM 1900 technology 2.4. Modifications Incorporated in EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP46121JD016A Page 6 of 42 Issue Date: 06 April 2005 Test of: Satellite Tracking of People LLC (STOP) BluTag To: FCC Part 24 Subpart E: 2004 2.5. Additional Information Related to Testing Power Supply Requirement: Nominal 110V 60 Hz AC Mains supply via the AC Charger (charges integral 4.2 VDC Li-ion battery) Intended Operating Environment: Within GSM Network Coverage Equipment Category: GSM 1900 Type of Unit: Portable (Standalone battery powered device) Interface Ports: AC Charger Connector Transmit Frequency Range: 1850.2 MHz to 1909.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1850.2 Middle 660 1879.8 Transmit Channels Tested: Top 810 1909.8 Receive Frequency Range: 1930.2 MHz to 1989.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1930.2 Middle 660 1960.0 Receive Channels Tested: Top 810 1989.8 Maximum Power Output (EIRP) 30.0 dBm 2.6. Support Equipment No support equipment was used to exercise the EUT during testing, only a GPRS/GSM signal simulator as test equipment. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP46121JD016A Page 7 of 42 Issue Date: 06 April 2005 Test of: Satellite Tracking of People LLC (STOP) BluTag To: FCC Part 24 Subpart E: 2004 3. Test Specification, Methods and Procedures 3.1. Test Specifications Reference: FCC Part 24 Subpart E: 2004 (Broadband PCS) Title: Code of Federal Regulations, Part 24 (4…

Text truncated - open the document above for the full version.
