S5SDR18608COMMUNICATION TRANSMITTER

1 Repeater USER’S Guide On/Off Switch Indicator led 2 . Please follow the FDA Food Code and your local Health departments rules and regulations when installing any device in your establishment. W hen installing your D-Mometer®232T please follow all of the recommendations: 1) Place on a clean, dry and level surface. ( not closer than 12 inches from the floor) Do Not place on floor. 2) Surface of shelf must be of approved surface and construction by FDA Food Code and your local Health Department’s rules and regulations. 3) Do Not install near sprinkle system heads , or fan , air conditioning fan . 4) Place in an area that can have a clear unobstructed view of the D-Mometer ®232T front, top and sides. 5) Do Not place in area or space that blocks or obstructs both sides and back of the device 6) Do Not have anything touching sides, top, or back. The D-Mometer® Repeater must have a minimum clearance of 3 inches on both sides and 4 inches on back. 7) Do Not place on door, moving parts, moving shelves, on top of food or food container. 8) plug in the Ac power adaptor into wall outlet and small end into the D-Mometer repeater device . Turn the device to the On position and then the device is ready to work . the top indictor lights will flash informing the user that the device is operating and communicating . Care and Maintenance For proper use and function of your D-Mometer Repeater please follow the manufacturer’s guidelines. 1) Check battery power adaptor on a regular basis (daily). 2) Make sure device is clean and dry. Do not expose to liquids. Do not expose to humidity. 3) Make sure there are no liquid or solid materials on or near device. 4) Wipe with soft towel and keep level. 5) Do not place any items on the D-Mometer ® Repeater. 7) Do not drop, or hit with any objects or cause damage to the D-Mometer ® Repeater. 8) Do not allow liquids to go inside the D-Mometer® Repeater Water or any liquid will damage the device and void the warranty. Installation and Use 3 9) Do not tamper with device, or open casing, remove or replace labels, stickers, wires or components. This will void warranty. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits of a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the device. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Limited Warranty If within 30 days of original purchase, this device is defective or does not work properly, RMD Technologies, LLC will repair or replace the device providing customer has registered the device within 30 days of original purchase, has original purchase documents and has a confirmed registration of warranty. Please visit www.D-Mometer.com for additional details and product warranty information request form and submittal. Address for returning your device: RMD Technologies, LLC, 635 West Michigan Street, Orlando FL. 32805 Attention returns department Preparation for shipping your product: Please repack your device in a durable box, preferably in the original carton, and send it prepaid and adequately insured. Include the original invoice and documentation of product registration along with description of issue, or a copy of the product return form from our website. For further 4 information please send all inquiries to [email protected]. The D-Mometer ® Repeater has a 1 year Limited Warranty. The 1 year Limited Warranty of this product is from date of its original purchase. This warranty does not cover: damage or failure caused by or attributable to abuse, misuse, water or moisture damage, failure to follow instructions in the user’s guide, failure to adhere to manufacturers recommendation’s for placement and use, failure to adhere to manufacturer’s recommendation’s, improper installation or maintenance, any alteration or accidental damage, Acts of God (such as floods, or lightning) or excess voltage or current. damage due to any type of liquid or solid material, consumables such as batteries, wear and tear, or cosmetic damage, transportation, shipping or insurance costs, costs of product removal, installation, set-up service, adjustments or reinstallation, and claims by any other person other than original purchaser. Should a problem occur that is covered by this limited warranty, RMD Technologies, LLC will, at its option, repair or replace the device. RMD Technologies, LLC Expressly disclaims all warranties and conditions not stated in this limited warranty. Any implied warranties that may be imposed by law, including the implied warranty of merchantability and, if applicable, the implied warranty of fitness for a particular purpose, shall expire on the expiration of the stated warranty period. Except as described above, RMD Technologies, LLC shall have no liability or responsibility to the purchaser of the product or any other person or entity with respect to any liability, loss or damage caused directly or indirectly by use or performance of the product or arising out of any breach of this warran…

Text truncated - open the document above for the full version.

1 Photographs- EUT Constructional Details Test Model No.: D-Mometer Repeater

Label was printed on the appearance of the product , the size is 16*50mm D-MOMETER® REPEATER FCC ID S5SDR18608 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RMD Technologies LLC www. D- MOMETER. com

1 Photographs- EUT Constructional Details Test Model No.: D-Mometer Repeater

SGS-CSTC Standards Technical Services Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM140100041401 Page: 1 of 24 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. ′′This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.′′ 1 Cover Page FCC REPORT Application No.: SZEM1401000414RF(SGS GZ No.:GZEM1401000388RF) Applicant: Guangzhou Wong Da Hardware & Knitwear co., Ltd. Manufacturer: Guangzhou Wong Da Hardware & Knitwear co., Ltd. Factory: Guangzhou Wong Da Hardware & Knitwear co., Ltd. Product Name: D-Mometer Repeater Model No.(EUT): D-Mometer Repeater FCC ID: S5SDR18608 Standards: 47 CFR Part 15, Subpart C (2013) Date of Receipt: 2014-03-20 Date of Test: 2014-03-28 to 2014-04-08 Date of Issue: 2014-04-09 Test Result: PASS * . * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM140100041401 Page: 2 of 24 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203 ANSI C63.10(2009) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10(2009) PASS Field Strength of the Fundamental Signal 47 CFR Part 15, Subpart C Section 15.231 (b) ANSI C63.10(2009) PASS Spurious Emissions 47 CFR Part 15, Subpart C Section 15.231 (b)/15.209 ANSI C63.10(2009) PASS 20dB Bandwidth 47 CFR Part 15, Subpart C Section 15.231 (c) ANSI C63.10(2009) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.231 (a) ANSI C63.10(2009) PASS NOTE: The receiver portion of this transmitting device has be tested and passed by Verification procedure. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM140100041401 Page: 3 of 24 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prio…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup Test Model No.: D-Mometer Repeater 1.1 Conducted Emission Test Setup 1.2 Spurious Emission
