S5V-D10A2X10.1 inch Tablet PC

User’s Manual Tablet A1X PLUS Read this manual before in stallation and use. We would like you to have a safe and enjoyable experience. Please read the following instructions and notices before using the tablet. Avoid using the tablet in extremely hot, cold, dusty, damp or wet environments. The tablet is not moisture/water-resistant. Avoid using the tablet around sources of water. Avoid dropping or forcibly placing the tablet onto a hard surface. This may damage the screen or internal electronic components. Do not use alcohol, thinner or benzene to clean the surface of the tablet. Use only cleaning products designed for computer tablet devices Do not use the tablet while walking or driving. Excessive use of earphones at high volume may lead to hearing impairment. Limit earphone usage, and adjust the volume to a moderate level when doing so. The images in this manual may vary slightly from the actual product. Charge the tablet battery under any the following circumstances: 1.The battery level icon indicates low power, by showing a drained, red battery icon. 2.The tablet powers-off automatically, and continues to do even after restarting. 3.On-screen keys do not work. Do not suddenly disconnect the tablet when formatting, uploading or downloading data. This can lead to program errors(e.g.,system or screen “freezing”.) Static discharge in the cable, while it is con- nected to a computer, may corrupt files or damage the memory of the tablet. Dismantling the tablet will void the manu- facture’s warranty. If experiencing problems, review the Troubleshooting section of this manual. The tablet functions, hardware, software, and warranty information may be improved or modified by the manufacturer or their respec- tive owners, and is subject to change without notice. 2 Important Safety lnstructions and Notices Features 8 768 Wifi b/g/n . Play many formats of music, video and picture formats, Supports resolution up to 1080P. Micro SD card slot for data storage and transfer. Energy-saving brightness control and sleep functions. Supports multiple languages. USB 2.0 high-speed transfer. APK program installation using the Applnstaller. Supports firmware upgrades. G-Sensor function: Detects the environment, orientation and position of the tablet, to provide input for various applications. Camera: Front (facing user)0.3MP; Rear 2.0MP The AX1 8" tablet AC Adapter x1 User ’s Manual USB Cable " X1024 HD capacitive touch screen. x1 x1 3 Features/What’s In the Box What’s in the Box Powering ON/OFF To power ON/OFF the tablet, press and hold the Power button for about 3 seconds. When turning the tablet ON, you will go to the initial Startup screen and have the option of unlocking it and going to the Home screen, or directly to the Camera app, When turning OFF the tablet, a window will open, verifying your action. 4 Basic Operations Touching and Typing The NB7850S tablet screen is designed for you to touch it to move, select and manipulate information. To select an item on the screen, simply tap it Stand-by Mode If you do not want to power-off the tablet, you can opt to deactivate just the LCD screen. This will keep the tablet in Stand-by mode. To deactivate the screen, quickly press and release the Power button. The screen will go black. To reactivate, simply press and release the Power button again. (You may have to unlock the tablet in order to use it, depending on your security settings.) once with your fingertip or stylus. Some items may require you to”double-tap”. To type into on text field(i.e.,when inputting your name, or a web address),tap the text field. The on-screen keyboard will appear, and allow you to type the information you wish to enter. Other common finger gestures include: Touch and Hold: Touching and keeping your finger on an on-screen item, until a light glow appears around it, may activate a separate menu or other options for that item. This is often used for deleting an item from the tablet. Drag: To move an object, or activate functionality, Touch and Hold an item until it glows, then “drag”it to another location on the screen without lifting your finger or stylus. 5 Swipe/Slide: A motion often used to move through menus, pictures or multiple options. This is done with a light tap or flick of the finger/stylus into the direcion you want the item, menu or screen to move toward. Double-Tap: Some items will require two taps in order to activate, zoom-in, zoom-out. Pinch: In some apps (such as Maps, Brower, and Gallery), you can zoom in and out by placing two fingers on the screen at once, and pinching them together (to zoom out) or spreading them apart(to zoom in.) Changing the screen orientation First, makes sure the “Auto-rotate screen”option is selected in the Settings menu(Settings> Accessibility). With this option selected, the screen will automatically rotate based on the vertical/ horizontal orientation it is being held in. To“lock” an orientation, simple deselect the“Auto-rotate screen” option. Resetting the Tablet if the tablet is unresponsive to either touch input or function keys, use a paperclip or similarly-sized pin and press the Reset button located in the reset aperture. This reset will clear the memory and reboot the tablet.(it is not the same as a factory reset; your personal information, apps, settings etc. will be retained.) Conserving Power To conserve tablet battery power, set the brightness and sleep functions at reasonable levels. These functions can be found in the Settings menu(Settings>Dispay). 6 Charging the Tablet It is best to charge the tablet before the battery icon is fully drained, or when the tablet pop-up indicates that it needs charging. To charge the tablet, plug in the AC adapter to a convenient outlet, then plug in the tablet to the AC adapter. If the tablet is on, the battery icon will pulse, showing that it is being charged. If is fully charged when an icon of a full battery is displayed on the screen. Connecting to a Computer for File Transfer The …

Text truncated - open the document above for the full version.

PROEXPRESS DISTRIBUTOR LLC Feb. 04, 2015 Federal Communications Commission Authorization and Evaluation Division FCC ID: S5V-D10A2X Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information applied this application as outlined below: Schematic Theory of Operation Block Diagram Tune Up The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely Yuchun.Zheng General Manager PROEXPRESS DISTRIBUTOR LLC Phone: +86-15820777766 Fax: +86-301-670-7338 E-mail:[email protected].

PROEXPRESS DISTRIBUTOR LLC Date: Fed 04, 2015 Subject: Ad Hoc Mode Function Declaration FCC ID: S5V-D10A2X To Whom it may concern, This device is operated for 2.412~ 2.462GHz only and Ad Hoc Mode Function cannot work on non-US frequencies. The country code is not available for the end user. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Sincerely Yuchun.Zheng General Manager PROEXPRESS DISTRIBUTOR LLC Phone: +86-15820777766 Fax: +86-301-670-7338 E-mail:[email protected].

WIFI/BT Antenna WIFI/BT Chip

Conducted Emission Radiated Emission below 1GHz Radiated Emission above 1GHz
