S5V-N27Smart Watch

N27 SMART WATCH V1.0 USER MANUAL Smart Watch x1 Magnetic USB Cable x1 User Manual x1 Extended Warranty Card x1 What’s in the Box N27 SMART WATCH USER MANUAL 01 Charging and Activating Charge the device to activate it before using it for the first time. To charge your device, simply connect the charging cable to either the adapter or USB port on your computer. Tip: When charging the smart wacth, please keep the magnetic charging cable away from any metal conductor to avoid a short circuit. 02 Full screen touchable Power (MENU) Button Power on or off the watch Heart rate & Blood oxygen sensor Sport Button Product Introduction Charging port Speaker Air Pressure Hole Microphone 03 Status/ Operation Power (MENU) Button: Long press for 3 seconds Function Power on Button Operation Power (MENU) Button: Long press for 3 seconds Power off Power (MENU) Button: Short-press Screen on Power (MENU) Button: Short-press Screen off Power (MENU) Button: Short-press Enter Sport mode Power (MENU) Button: Short-press Enter the function interface Sport Button: Short-press Enter the exercise list 04 Da Fit You can download the App in the following two ways. 1. Scan the following QR code to download and install the App. 2. Enter "DA FIT" in App Store or Google Play to download the App. Downloading the App Download on the App Store GET IT ON Google Play 05 TIPS: 1. To avoid pairing failure due to insufficient battery, it is important to keep the watch's battery level above 20% before initiating pairing. 2. During the process of pairing and connection, ensure that your mobile phone's Bluetooth is turned on and within the effective connection range of the watch. 3. This device requires a system version of Android 6.0 or higher, or iOS 9 or higher. 4. When using Da fit for the first time, please grant it access to Bluetooth, location services, and any other necessary permissions on your compatible smartphone. The MAC address found on the "Settings" "About" page can assist in scanning QR codes and identifying your device on the scanning list. Pairing Open the App and set up your profile Go to "Device", and tap "Add A Device" Choose your device on the scanning list Complete 06 1. Set up your profile2. Go to “Device”, and tap “Add A Device” 3. Choose your device on the scanning list Android Phone 07 4. Confirm Connected5. Select “Allow access to your contacts and call history”, then tap "Pair" to confirm pairing Notes: It takes 3-5 seconds before you can access the pairing interface. 01 08 iOS Phone 1. Set up your profile2. Go to “Device”, and tap “Add A Device” 3. Choose your device on the scanning list 02 09 4. Confirm Connected5. Tap “Pair” the in Bluetooth pairing request page to enable Bluetooth 6. Select “Allow” to allow N27 to receive your iPhoto notifications 03 10 Note: After successfully connecting your smartwatch to the App, please follow these steps to enable Bluetooth calling in case you cannot find the Bluetooth pairing request or accidentally tapped "CANCEL". Tip: This feature is specifically designed for Android and iOS phones. 1. Find the Bluetooth function in your phone's settings page, toggle the switch to turn it on, then select the N27 device to establish a connection 2. Select "Allow access to your contacts and call history", then tap "Pair" to confirm pairing 04 11 3. Bluetooth connected4. The watch features a phone call function that is readily available 05 12 Messages Feature pagesMenu Control Center Use the Touch Screen Swipe Up Swipe Left Swipe Right Swipe Down 06 13 1. To enter the selection dial interface, long-press the main interface for 3 seconds. Slide left or right to navigate through the available options, and click to confirm your selection. 2. Find more dials: Enter the “Da fit” App and tap “dial selection” > more dial settings. Main Interface Switching 07 14 Activity When wearing the watch regularly, it will provide you with real-time information about your exercise progress including steps taken, distance covered, and calories burned. Note: This data is updated daily before 12:00 a.m., reflecting the activities of the previous day. Sleep If you keep wearing Smart Watch during your sleep, it can provide you with valuable information about your sleep duration and quality. This data is conveniently displayed on both the device's screen and the App. Note: Sleep stats reset to zero at 8:00 pm. Smart Watch Features 08 15 Call Bluetooth connection Turn on the Smartwatch, and the “N27” Bluetooth pairing will pop up automatically in your phone. Please tap "Pairing" to establish the connection. When Bluetooth is connected to your phone, you can use the watch to dial, control the mobile phone to make a call, listen to music, and view the call record information on the watch. Phone Call function Add contacts: Open Dafit from your phone to tap “Favorite Contacts” "Add quick newsletter". You can add up to 8 contacts. 09 16 Exercise 107 sports modes to choose from, including walking, running, cycling, basketball, football, badminton, skipping, and rope exercises. To activate a sport mode, simply turn it on and swipe left to select the option to pause or end the exercise. If you wish to add a new sport mode, scroll down to the bottom and click "Add" to select your desired option. Heart Rate Test The Smart Watch could record your heart rate all day. You can also tap on the page to start measuring your heart rate. Blood Pressure Test Tap on the blood pressure page to start measuring your blood pressure. On the blood pressure page, you can access the recently measured data of your blood pressure. 10 17 Swipe Up SpO2 Test Tap the SpO2 page to start measuring your SpO2. On the SpO2 page, you can access the recently measured data of your SpO2. Weather It can show the weather info including location, and sunrise, and sunset. After connecting to the app, the weather information is synced and will not update if there is a long period of disconnection. Slide up the weather interface to view the weather con…

Text truncated - open the document above for the full version.

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Proexpress Distributor LLC Grantee code: S5V FCC ID: S5V-N27 Contact Name: Sindy Chan Address: 7668 standish place, STE B, Rockville, Maryland, 20855, United States Telephone: 301-670-7335-101 Fax: 301-859-0491 E-mail: [email protected] i. [Proexpress Distributor LLC] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Proexpress Distributor LLC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Proexpress Distributor LLC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/07/24 Applicant’s Name: Sindy Chan Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Proexpress Distributor LLC Product Similarity Declaration Company: Proexpress Distributor LLC Address: 7668 standish place, STE B, Rockville, Maryland, 20855, United States Product Name: Smart Watch Model Number: N27 D1, D2, D2P, D3, D5, D7, D7P, D8, D9, N20, N21, N23, N25, N26, N28, N29, T1, T2, T3, T5, T6, T7, T8, T9, T20, T21, T23, T25, T26, T27, T28, T29, F1, F2, F3, F5, F6, F7, F8, F9, il, i2, i3, i5, i6, i7, i8, i9, J1, J2, J3, J5, J6, J7, J9 FCC Identifier: S5V-N27 We (Proexpress Distributor LLC ) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Name: Sindy Chan Date: 2023-07-21 Title: Manager Signature of applicant:

Proexpress Distributor LLC 1/1 Letter of Authorization Company: Proexpress Distributor LLC Address: 7668 standish place, STE B, Rockville, Maryland, 20855, United States Product Name: Smart Watch Model Number: N27 D1, D2, D2P, D3, D5, D7, D7P, D8, D9, N20, N21, N23, N25, N26, N28, N29, T1, T2, T3, T5, T6, T7, T8, T9, T20, T21, T23, T25, T26, T27, T28, T29, F1, F2, F3, F5, F6, F7, F8, F9, il, i2, i3, i5, i6, i7, i8, i9, J1, J2, J3, J5, J6, J7, J9 FCC Identifier: S5V-N27 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Sindy Chan Date: 2023-07-24 Title: Manager Signature of applicant:

Proexpress Distributor LLC 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-07-24 Subject: Request for Confidentiality FCC ID: S5V-N27 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Sindy Chan Date: 2023-07-24 Title: Manager Signature of applicant:

Size:8*6mm M/N: N27 IC: 22901-N27 FCC ID: S5V-N27 Label location

ANT

FCC ID: S5V-N27 RF Exposure Evaluation According to KDB 447498 D01 V06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Here, For EDR Field strength (dBuV/m) EIRP (dBm) Max tune-up (mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit 84.7 -10.5 0.089 2402 5 0.028 3.0 So a SAR test is not required

Summary Antenna Specification ITEMANT SPEC Model Name2.4G ANT MAX. Gain 1.08dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length38.20mm Manufacture Proexpress Distributor LLC ÏÚ 2 ‹ Œøº∑ø ̈∑±≤ Ω∏øÆøΩ ̈ªÆ∑≠ ̈∑Ω≠ ±∫ ø≤ ̈ª≤≤ø PHI 0° PHI90° THETA90 ° Frequency VNA (MHz) Gain (Peak) (dBi) 2400MHz0.0403503 2410MHz0.0886264 2420MHz0.267381 2430MHz0.193012 2440MHz0.26366 2450MHz0.0723139 2460MHz0.36895 2470MHz0.551525 2480MHz0.640702 2490MHz1.05232 2500MHz1.08443 Unit:dB

Test Report Number: BTF230718R02001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 1 o f 40 FCC Part 15C Test Report FCC ID: S5V-N27 Applicant: Proexpress Distributor LLC Address: 7668 standish place, STE B, Rockville, Maryland, 20855, United States Manufacturer: Proexpress Distributor LLC Address: 7668 standish place, STE B, Rockville, Maryland, 20855, United States EUT: Smart Watch Trade Mark: ALKAI Model Number: N27 D1, D2, D2P, D3, D5, D7, D7P, D8, D9, N20, N21, N23, N25, N26, N28, N29, T1, T2, T3, T5, T6, T7, T8, T9, T20, T21, T23, T25, T26, T27, T28, T29, F1, F2, F3, F5, F6, F7, F8, F9, il, i2, i3, i5, i6, i7, i8, i9, J1, J2, J3, J5, J6, J7, J9 Date of Receipt: Jun. 29, 2023 Test Date: Jun. 29, 2023 - Jul. 06, 2023 Date of Report: Jul. 06, 2023 Prepared By: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.249 ANSI C63.10:2013 Test Result: Pass Report Number: BTF230718R02001 Project Engineer: Elma.yang EMC Manager: Ryan.CJ This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of BTF Testing Lab (Shenzhen) Co., Ltd. Test Report Number: BTF230718R02001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 2 o f 40 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 10 3.1.3 DEVIATION FROM TEST STANDARD 10 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 15 3.2.5 EUT OPERATING CONDITIONS 16 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 17 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 18 3.2.8 TEST RESULTS (1GHZ~25GHZ) 20 3.3 RADIATED BAND EMISSION MEASUREMENT 23 3.3.1 TEST REQUIREMENT: 23 3.3.2 TEST PROCEDURE 23 3.3.3 DEVIATION FROM TEST STANDARD 23 3.3.4 TEST SETUP 23 3.3.5 EUT OPERATING CONDITIONS 24 4 . BANDWIDTH TEST 28 4.1 APPLIED PROCEDURES / LIMIT 28 4.1.1 TEST PROCEDURE 28 4.1.2 DEVIATION FROM STANDARD 28 4.1.3 TEST SETUP 28 4.1.4 EUT OPERATION CONDITIONS 28 Test Report Number: BTF230718R02001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 3 o f 40 Table of Contents Page 4.1.5 TEST RESULTS 29 5 . ANTENNA REQUIREMENT 32 5.1 STANDARD REQUIREMENT 32 5.2 EUT ANTENNA 32 6 . TEST SEUUP PHOTO 33 7 . EUT PHOTO 35 Test Report Number: BTF230718R02001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 4 o f 40 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205(a), 15.209(a) 15.249(a), 15.249(c) Fundamental &Radiated Spurious Emission Measurement PASS 15.249(d) Band Edge Emission PASS 15.215(c) 20dB Bandwidth PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 20dB Bandwidth ±0.2MHz Test Report Number: BTF230718R02001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 5 o f 40 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Smart Watch Trademark ALKAI Model No.: N27 D1, D2, D2P, D3, D5, D7, D7P, D8, D9, N20, N21, N23, N25, N26, N28, N29, T1, T2, T3, T5, T6, T7, T8, T9, T20, T21, T23, T25, T26, T27, T28, T29, F1, F2, F3, F5, F6, F7, F8, F9, il, i2, i3, i5, i6, i7, i8, i9, J1, J2, J3, J5, J6, J7, J9 Model Difference The product's different for model number and appearance color. Operation Frequency: 2402~2480MHz Channel numbers: 79 Channels Channel separation: 1M Modulation technology: GFSK, PI/4 DQPSK, 8DPSK Antenna Type: Built-in antenna Antenna gain: 1.08dBi Power supply: DC 3.8V from battery DC 5V from charger Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. Test Report Number: BTF230718R02001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 6 o f 40 3. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 2477 22 242…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
