UserManualforHFReaderDEMOV4.0 1 / 71 SoftwareUserManual HFReaderTestingDemo (ISO14443A/B,MIFAREDESFire,ISO15693) (Version1.1) *Allrightsreserved,andthecontentsmayberevisedwithoutnotice FCC statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. UserManualforHFReaderDEMOV4.0 2 / 71 Contents 1.Introduction ............................................................................................................................................ 4 2.OperationFeatures ............................................................................................................................... 4 2.1Hardwareconnection ......................................................................................................................... 4 2.2Softwareconnection .......................................................................................................................... 5 2.3Systemcommand ............................................................................................................................... 6 2.3.1SetBaudrate .................................................................................................................................... 6 2.3.2SetLED ............................................................................................................................................. 7 2.3.3SetBUZ ............................................................................................................................................ 8 2.3.4SetANT ............................................................................................................................................. 9 2.4Auto-ListCard ................................................................................................................................... 10 2.5ISO14443A-3/4 ................................................................................................................................. 11 2.5.1Requestcard .................................................................................................................................. 11 2.5.2SendRATS ..................................................................................................................................... 12 2.5.3SendAPDU .................................................................................................................................... 13 2.5.4APDUChannel ............................................................................................................................... 14 2.6MIFAREClassic ................................................................................................................................ 14 2.6.1MIFAREClassic-Requestcard ................................................................................................ 15 2.6.2MIFAREClassic-APDUChannel .............................................................................................. 16 2.6.3MIFAREClassic-KeyAuthenticate .......................................................................................... 17 2.6.4MIFAREClassic-ReadBlock .................................................................................................... 18 2.6.5MIFAREClassic-WriteBlock ..................................................................................................... 19 2.6.6MIFAREClassic-ReadAllBlocks ............................................................................................. 20 2.6.7MIFAREClassic-E-wallet ........................................................................................................... 21 2.7Ultralight/C ....................................................................................................................................... 22 2.7.1Ultralight/C-Active/RequestCard ............................................................................................. 22 2.7.2Ultralight/C--APDUChannel ...................................................................................................... 23 2.7.3UltralightCAuthenticate ............................................................................................................ 24 2.7.4UltralightCChangeKey .................................................................................…

Text truncated - open the document above for the full version.

UserManualforHFReaderDEMOV4.0 40 / 71 2.8.9.4PICCLevel-DeleteApplication ThiscommandistodeletetheapplicationIDorIDs,theallapplicationIDswillbelistingonleftsidebox. UserManualforHFReaderDEMOV4.0 41 / 71 2.8.9.5PICCLevel-FormatPICC ThiscommandreleasesthePICCusermemoryandnoparameterarepassedwiththiscommand UserManualforHFReaderDEMOV4.0 42 / 71 2.8.10DESFireCard-ApplicationLevel WhenenterintoApplicationLevel,itmustdoSelectAPP-->AuthenticateMasterKeyfirstly. UserManualforHFReaderDEMOV4.0 43 / 71 2.8.10.1ApplicationLevel-GetFileIDs ThiscommandreturnstheFileIDsofallactivefileswithinthecurrentlyselectedapplication UserManualforHFReaderDEMOV4.0 44 / 71 2.8.10.2ApplicationLevel-GetFileSetting ToGetinformationonthepropertiesofaspecificfile,andtheFileIDneedtobeselectedwhenproceeding UserManualforHFReaderDEMOV4.0 45 / 71 2.8.10.3ApplicationLevel-ChangeFileSettings Thisistochangetheaccessparametersofanexistingfile. Parameterstobechanged: FileID:filenumberwithincurrentlyselectedapplication,Onebyte Communicationway:newcommunicationsettings,Onebyte Accessright:newaccessrights,Twobyte Moredetailsinformation,pleaserefertodatasheetofusingcardaccordingly UserManualforHFReaderDEMOV4.0 46 / 71 2.8.10.4ApplicationLevel-CreateStdDataFile/CreateBackupDatafile Thisisusedtocreatefilesforthestorageofplainunformatteduserdatawithinanexistingapplicationon thePICC,andCreateBackupDataFilesupportingthefeatureofanintegratedbackupmechanism. Parameterstobecreated: FileID:Filenumberofthenewfileandrangefrom0x00to0x0F,ONEbyte Communicateway:Communicationsetting,ONEbyte Accessright:Accessrightforthenewfile,TWObyte Filesize:thefileofthefileinbyte,THREEbyte Moredetailsinformation,pleaserefertodatasheetofusingcardaccordingly UserManualforHFReaderDEMOV4.0 47 / 71 2.8.10.5ApplicationLevel-DeleteFile Thiscommandistopermanentlydeactivateafilewithinthefiledirectoryofcurrentlyselectedapplication Thisoperationinvalidatesthefiledirectoryentryofthespecifiedfilewhichmeansthatthefilecan’tbe accessedanymore. UserManualforHFReaderDEMOV4.0 48 / 71 2.8.10.6ApplicationLevel-ReadData ToreaddatafromStandardDataFilesorBackupDataFiles Parameterstobeoperated: FileID:thefilenumbertobereadfrom,ONEbyte Address:thestartingpositionforthereadoperation,THREEbyte,rangefrom0x000000to0xFFFFFF Length:thenumberofdatabytestoberead,THREEbyte,andrange0x000000to0xFFFFFF UserManualforHFReaderDEMOV4.0 49 / 71 2.8.10.7ApplicationLevel-WriteData TowritedatatoStandardDataFilesandBackupDataFiles Parameterstobeoperated: FileID:thefilenumbertobewritteninto,ONEbyte Address:thestartingpositionforthewritingoperation,THREEbyte,rangefrom0x000000to0xFFFF FF Length:thenumberofdatabytestoberead,THREEbyte,andrange0x000000to0xFFFFFF Data: Moredetailsinformation,pleaserefertodatasheetofusingcardaccordingly UserManualforHFReaderDEMOV4.0 50 / 71 2.8.11ApplicationLevel-ValueFile 2.8.11.1ValueFile-CreateValueFile Tocreatefilesorthestorageandmanipulationof32bitsignedintegervaluewithinanexistingapplication onthePICC Moredetailsinformation,pleaserefertodatasheetofusingcardaccordingly UserManualforHFReaderDEMOV4.0 51 / 71 2.8.11.2ValueFile-GetValue ItallowstoreadthecurrentlystoredvaluefromValueFile UserManualforHFReaderDEMOV4.0 52 / 71 2.8.11.3ValueFile-Transactionsoperation Thetransactionsareincluding: Credit:increaseavaluestoredinaValueFile Debit:decreaseavaluestoredinaValueFile CommitTransaction:ValidateallpreviouswriteaccessonBackupDataFile,ValueFilesandRecord Fileswithinoneapplication AbortTransaction:invalidateallpreviouswriteaccessonBackupDataFile,ValueFilesandRecord Fileswithinoneapplication LimitCredit:limitedincreaseofavalueinaValueFilewithouthavingfullRead&Writepermissionto thefile Moredetailsinformation,pleaserefertodatasheetofusingcardaccordingly UserManualforHFReaderDEMOV4.0 53 / 71 2.8.12ApplicationLevel-RecordFile 2.8.12.1RecordFile-CreateLinear/CyclicRecordFile Thisisusedtocreatefilesformultiplestorageofstructuraldata,forexampleforloggingtransactions, Moredetailsinformation,pleaserefertodatasheetofusingcardaccordingly UserManualforHFReaderDEMOV4.0 54 / 71 2.8.12.2RecordFile-ReadRecord ToreadoutasetofcompleterecordsfromaCyclicorLinerRecordFile Parameterstoberead: FileID:thefilenumbertobereadfrom,ONEbytelength RecordNo:theoffsetofthenewestrecordwhichisreadout,THREEbyteslong RecordNumber:thenumberofrecordstobereadfromPICC UserManualforHFReaderDEMOV4.0 55 / 71 2.8.12.3RecordFile-WriteRecord TowritedatatoaCyclicorLinerRecordFile Parameterstobewritten: FileID:thefilenumbertobewrittenintoandhastoberangefrom0x00to0x07,ONEbytelength Address:theoffsetwithinonesinglerecord,andrangefrom0x00000000torecordsize-1 UserManualforHFReaderDEMOV4.0 56 / 71 2.9ISO14443B 2.9.1ISO14443B-Active-TypeB ToactiveISO14443TypeBcards/tag UserManualforHFReaderDEMOV4.0 57 / 71 2.9.2ISO14443B-4APDU UserManualforHFReaderDEMOV4.0 58 / 71 2.9.3ISO14443B-4APDUChannel ThisistransferchanneltosendanyavailablecommandstothecarddirectlythroughRFchipset. DetailscommandspleaserefertoISO14443B-4Standard. UserManualforHFReaderDEMOV4.0 59 / 71 2.10ISO15693 2.10.1ISO15693-Inventory TogettheUIDofISO15693standardcards/tags. Whenisselected,itcanbereadmultiplecardsinonetime,andtheallUID numberswillbelistingonleftsidebox. UserManualforHFReaderDEMOV4.0 60 / 71 2.10.2ISO15693-Selectcard Toselectthecardforfurtherread/writeoperations,whentherearemultiplecards,pleaseselecttheright oneonUIDnumberlistsafterinventory. UserManualforHFReaderDEMOV4.0 61 / 71 2.10.3ISO15693-StayQuiet Tomakethecardtobeslept UserManualforHFReaderDEMOV4.0 62 / 71 2.10.4ISO15693-APDU ThisistransferchanneltosendanyavailablecommandstothecarddirectlythroughRFchipset. AndThefirstCMDbeforetransfermustbeISO15693_Inventory,thiswillsetthereader(ormodule)gointo ISO15693mode,DetailscommandspleaserefertoISO15693Standard. UserManualforHFReaderDEMOV4.0 63 / 71 2.10.5ISO15693-ReadBlock Toreadthedatainspecificblockaddress Parameterstobeoptional: Flag:0x22or0x02,refertodatasheetofusingcard BlockAddr:theblockaddresstoberead UserManualforHFReaderDEMOV4.0 64 / 71 2.10.6ISO15693-Write…

Text truncated - open the document above for the full version.

FCC-ID: S6A-IDT305MT Page 1 of 2 Report No.: CTL2103112031-WF External and Internal Photos of the EUT FCC-ID: S6A-IDT305MT Page 2 of 2 Report No.: CTL2103112031-WF

FCC-ID: S6A-IDT305MT Page 1 of 1 Report No.: CTL2103112031-WF FCC-ID Label Information 1. Label location: FCC ID: S6A-IDT305MT

FCC-ID: S6A-IDT305MT Page 1 of 2 Report No.: CTL2103112031-WF External and Internal Photos of the EUT FCC-ID: S6A-IDT305MT Page 2 of 2 Report No.: CTL2103112031-WF

version01 iDTRONIC GmbH Donnersbergweg 1, 67059 Ludwigshafen am Rhein, Germany Tel: +49 621 66 900940 Fax: +49 621 66 900949 Declaration concerning Antenna Specification It is hereby declared that the product Model No.: IDT305MT , IDT301MT, OEM-DES-M900 FCC ID: S6A-IDT305MT fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for External Antenna antenna type(s) described below: Model No. of antenna: NA Type of antenna: External Antenna Gain of the antenna: 0.0 dBi Frequency range: 13.56 MHz Mo The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: iDTRONIC GmbH Address: Donnersbergweg 1, 67059 Ludwigshafen am Rhein, Germany City: Rhein ZIP / Postal code: Country: Germany Place: Managing Director Date: 2021.5.17 Signature:

FCC ID: S6A-IDT305MT RF EXPOSURE EVALUATION EUT Specification EUT HF RFID MODULE Model Name IDT305MT Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(13.56MHz) Device category Portable (<20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 88.66 dBuV/m (-6.6dBm)(0.2188mW) Antenna gain 0 dBi Evaluation applied MPE Evaluation SAR Evaluation Standard Requirement Portable Device According to §15.247(i) and §1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance V6, section 4.3.1. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances  50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] [ f(GHz)]  3.0 for 1-g SAR and  7.5 for 10-g extremity SAR, 16 where
f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is  50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID:S6A-IDT305MT Measurement Result Channel Frequency (MHz) Max Output power (dBm) Max Output power (mW) Calculation Value (Note 1) Threshold Value 13.56 -6.6 0.2188 0.0049 3.0 EIRP=E-104.8+20logD=88.66-104.8+20log3=-6.6dBm Note 1: Calculation Value =[(max. power of channel, mW)/(min. test separation distance, mm)] [ f(GHz)]. Fox example: 0.2188/5* 0.01356=0.0049  3.0 According to KDB447498 D01 V6, threshold at which no SAR required is ≤3.0 for 1-g SAR, separation distance is 5mm, and no simultaneous SAR measurement is required.
