S79FD-4000Digital Door Lock

Operating Instructions for FD-4000/R Digital Door Lock This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Ru les. These limits are designed to provide reasonable protection against harmful interfer ence in a residential installation. This equipment generates, uses, and can radiate radi o frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a articular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not c ause harmful interference, and (2) this device must accept any interference received, incl uding interference that may cause undesired operation. Digital Door Lock I N D E X 1. Name of parts 3 2. Specifications 4 3. Features 5 4. Operating instruction 6 5. How to add or delete the cards 8 6. Cautions 11 7. How to install 11 Digital Door Lock 1 . Name of part 1) Outer body 2) Inner body Sliding Cover Emergency Ports Key Sensor Keypads LED Handle Lock Button Battery Cover Battery Cover Screw Open/Close Button Manual Override Handle Double Locking Key Handle Card Setup Buttons PIN Setup Button Digital Door Lock 2. Specifications Specifications(Main) Model No. FD-4000 Inner: 299(H) x 76(W) x 33(D) mm Size Outer: 309(H) x 76(W) x 47(D) mm Power DC 6V(8 alkaline ‘AA’ batteries) Battery life 1 year (assuming 10 open/close a day) Material Die Casti ng (aluminum), PC, ABS Reading Range Within 30mm Available digits of PIN 3-20 digits Number of cards to register 1-50 cards Door thickness for installation 35-45mm Power (for emergency) DC 9V (not included) Digital Door Lock 2. Specifications Specifications(Remote control) Model No. FD-4000R Size 120mm(H) x 30mm(W) x 17(D)mm Power DC 3V(2 alkaline ‘AAA’ batteries) Battery life 1 year (assuming 10 open/close a day) Material ABS Reading Range Within 60m Output Power Max 5 ㎽ Band Width Max 8.5 ㎑ Operating Frequency 447.650 ㎒ ±3 ㎑ Digital Door Lock 3. Features - Imaginary numbers before the real PIN Pressing imaginary numbers (how many digits you want) before the real PIN prevents people who spy out your PIN. - Setting and modification of password (3~20 digits) You can set and modify your password at any time. -Backlighting system This feature allows you to see the keypad in low light or dark conditions than ks to self-illumination of the buttons. -Auto re-lock function If enabled, this function will lock the door within six seconds after being cl osed. The users do not have to bother locking the door after opening. -Low battery warning Red light flashes with an alarm sound to let user know when the battery is running low. Digital Door Lock -Tamper proof All functions will stop for 30 seconds if you enter the wrong password more than three times by mistake. -Easy installation The installation of this lock is simple and, in most cases, the existing keyhole can be used. Full installation instruction is supplied. -PIN memory Once the PIN is set, it will not be changed or erased even when the ba tteries are changed. -Indoor double lock system The product has an indoor double lock system preventing someone opening the door from the outside. If this function is activated, no one, even with the correct PIN, can open the door from outside. -Outdoor double lock system The user can use this feature from the outside. If the “Lock Button” is held down for 3 seconds after locking the door, no one can open the door from inside. Digital Door Lock 4. Operating instruction -How to set up Personal Identification Number ※ NOTE: All procedures have to be done in 8 seconds. Digital Door Lock -How to open the door using PIN from outside (when the sliding cover is closed) -How to open the door using PIN from outside (when the sliding cover is open) Digital Door Lock -How to open the door from inside Press Open/Close button to Open the door “Ding Dong Dang” Digital Door Lock -How to close the door when Auto-relock is activated The lock will automatically lock t he door after being closed thanks to the magnetic sensor. NOTE: The lock will lock the door 6 seconds af ter the valid PIN or smart key are input. -How to close the door when Auto-relock is not activated Digital Door Lock -How to set automatic lock option -How to set on/off double lock from inside The door remains locked despite of inputting PIN or smart keys Digital Door Lock -How to set on/off double lock from outside *How to set on 1) Press the “Lock Button” on outer body for 5 seconds 2) Press PIN or place the smart keys near to the reader, then press key 3) The double locking function will be activated and the open/close key in the inner side will not work. *How to set off It will open only by PIN or smart key from the outside. *** This function is especially good when no one is in or going out for a long time. -Ports for emergency In case of emergency situation when the battery power is run ou t, you can run to the convenient store near by and buy a 9V battery, then contact it to the emergency contact points as shown below, located on the outside body of the door lock, to open the door lock usi ng PIN or smart cards. Digital Door Lock -How to set the buzzer on/off Digital Door Lock 5. How to add or delete the cards You can open this lock by cards, key tags or “pass-watch” supplied with the system. -How to register the smart keys (up to 50 smart keys) -How to add the smart keys (up to 50 smart keys) Digital Door Lock -How to delete all the pre-enrolled smart keys -How to open the door using smart keys Place the smart keys near to the “Key Sensor” on outer …

Text truncated - open the document above for the full version.

FIRSTECH I&C CO.,LTD. #1506,B1 B-dong, Woolim Lion’s Valley, 371-28, Gasan-dong Geumcheon-gu, Seoul,Korea Oct 11, 2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize IST Co., Ltd., to act on our behalf in all manners relating toapplication for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by IST Co., Ltd. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing IST Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; FIRSTECH I&C CO.,LTD. #1506,B1 B-dong, Woolim Lion’s Valley, 371-28, Gasan-dong Geumcheon-gu, Seoul,Korea i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, FIRSTECH I&C CO.,LTD. #1506,B1 B-dong, Woolim Lion’s Valley, 371-28, Gasan-dong Geumcheon-gu, Seoul,Korea

#1506,B1 B-dong, Woolim Lion’s Valley, 371-28, Gasan-dong Geumcheon-gu, Seoul, Korea TEL No : 082-02-2026-4800 FAX No : 082-02-2026-4882 July 13, 2006 Federal Communications Commision Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : FIRSTECH I&C CO., LTD. FCC ID : S79FD-4000 Request for Confidentiality Gentlemen : In accordance with 0.457 and 0.459 of CFR 47, FIRSTECH I&C CO., LTD. Hereby requests confidentiality of the Schematics, the Part list, Block diagram and Operational description of the attached test report. These documents contain detailed system and equipment description and related information about the product which FIRSTECH I&C CO., LTD.Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, FIRSTECH I&C CO., LTD.Considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely,

1 Helen Zhao Subject: FW: FIRSTECH I&C CO.,LTD., FCC ID: S79FD-4000, Assessment NO.: AN06T6256, Notice#1 Agent Authorization Letter.pdf... FD-4000_manual.p df FD-4000_report.pd f FD-4000_Schematic s Diagram.pdf... From: Soo-Gil, Kim To: Helen Zhao Subject: RE: FIRSTECH I&C CO.,LTD., FCC ID: S79FD-4000, Assessment NO.: AN06T6256, Notice#1 Dear Helen, My answers are followins, 1) The modified letter is attached to this email. 2) The revised manual is attached. 3) The updated test report is attached. 4) The re-scaned schematics diagram is attached. If you need more action from me, please don't hesitate to contact me. Best regards, Soo-Gil, Kim -----Original Message----- Sent: Monday, October 30, 2006 6:10 PM Subject: FIRSTECH I&C CO.,LTD., FCC ID: S79FD-4000, Assessment NO.: AN06T6256, Notice#1 Question #1: Please submit an Agency Authorization letter. The letter in the filing is a request for confidentiality letter. Question #2: Please revise the user manual to include user information as specified in FCC15.21. Question #3: The limits shown on the test report page 7 are incorrect. Please check 30m vs. 3m. By the way, based upon FCC15.31(f)(2) "the results shall be extrapolated by using the square of an inverse linear distance extrapolation factor (40 dB/decade)." So if the limit at 30m is 83.9dBuV/m, the limit at 3m should be 123.9dBuV/m. Question #4: Please resubmit the schematics diagram, the one in the filing contains unrecognized characters. Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, 2 please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

Sample Label & Location Model Name: Digital Door Lock Model: FD-4000 Power: 6V , 150mA (Alkaline battery 1.5V x 8EA) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions; (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation FCC ID: S79FD-4000 Freq. Band: 13.56MHz FIRSTECH I&C CO., LTD.

IST Co., Ltd EMC LABORATORY(Registration Number:468536) FCCID:S79FD-4000 TEST REPORT NO. : 06-IST-0392(V1.0) 1 of 16 This Report shall not be reproduced except in full without the written approval of IST EMC Laboratory. Certification of Compliance CFR 47 Part 15 Subpart C Test Report File No. : 06-IST-0392 Date of Issue : Oct 02, 2006 Model(s) : FD-4000 Kind of Product : Digital Door Lock FCC ID : S79FD-4000 Applicant : FIRSTECH I&C CO.,LTD. Address : #1506,B1 B-dong, Woolim Lion’s Valley, 371-28, Gasan-dong Geumcheon-gu, Seoul,Korea Manufacturer : FIRSTECH I&C CO.,LTD. Address : #1506,B1 B-dong, Woolim Lion’s Valley, 371-28, Gasan-dong Geumcheon-gu, Seoul,Korea Registration Number 468536 Test Result ■ Positive □ Negative Reviewed By Approved By S.J.CHO / EMC Group Manager J.H.LEE / Chief Comment(s) - Investigations requested : Measurement to the relevant clauses of FCC rules and regulations Part 15 Subpart C. - The test report with appendix consists of 16 pages. - The test result only responds to the tested sample. - This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4: 2003 I assume full responsibility for accuracy and completeness of these data. IST Co., Ltd EMC LABORATORY(Registration Number:468536) FCCID:S79FD-4000 TEST REPORT NO. : 06-IST-0392(V1.0) 2 of 16 This Report shall not be reproduced except in full without the written approval of IST EMC Laboratory. TABLE OF CONTENTS Table of contents 2 Information of test laboratory, Environmental conditions, Power used, Product information 3 Descriptions of Test 4 - Radiated Emission(30MHz to 1000MHz) 4 - Radiated Emission, 9KHz to 30MHz(Magnetic Field Test) 5 Measurement Uncertainty Calculations 5 Equipment Under Test 5 Test Set-Up (Figure) 6 Summary 7 ■ Test and Data - Emissions ◆ Radiated Emissions 8 Radiated Electric Field Emission-15.225(a) 9 Radiated Electric Field Emission-15.225(b)(c) 10 Radiated Electric Field Emission-15.225(d) 11 Frequency Stability -15.225(e) 12 ◆ ANTENNA REQUIREMENT 13 Appendix A. The Photos of Test Setup 14 -15 B. The Photos of Equipment Under Test 16 Note: IST Co., Ltd EMC LABORATORY(Registration Number:468536) FCCID:S79FD-4000 TEST REPORT NO. : 06-IST-0392(V1.0) 3 of 16 This Report shall not be reproduced except in full without the written approval of IST EMC Laboratory. INFORMATIONS OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. (FCC Filing Lab.) 80, Jeil-Ri, Yangji-Myun, Yongin-City Kyonggi-Do, 449-860, Korea TEL : +82 31 333 9018 FAX : +82 31 333 9019 ENVIRONMENTAL CONDITIONS Temperature 20 °C Humidity 43 % Atmospheric pressure 1013 mbar POWER SUPPLY SYSTEM USED Power supply system DC 6V(Built-in AA Size Battery 8EA) (Refer to the product information) PRODUCT INFORMATION The Equipment Under Test(EUT) is Digital Door Lock of FIRSTECH I&C CO.,LTD. (FCC ID : S79FD-4000) a)Type of EUT Digital Door Lock b)Model No. FD-4000 c)Working Frequency 13.56MHz(1 channel) d)Power Supply DC 6V(Built-in AA Size Battery 8EA) - EMC suppression device is not used during the test . - Please refer to user’s manual. IST Co., Ltd EMC LABORATORY(Registration Number:468536) FCCID:S79FD-4000 TEST REPORT NO. : 06-IST-0392(V1.0) 4 of 16 This Report shall not be reproduced except in full without the written approval of IST EMC Laboratory. DESCRIPTION OF TEST Radiated Emissions(30MHz~1000MHz): The measurement was performed over the frequency range of 30MHz to 1GHz using antenna as the input transducer to a Spectrum analyzer or a Field Intensity Meter. The measurement was made with the detector set for "quasi-peak" within a bandwidth of 120KHz. - Procedure of Test Preliminary measurements were made at 3 meter using bi-log antennas, and spectrum analyzer to determine the frequency producing the max. emission in anechoic chamber. Appropriate precaution was taken to ensure that all emission from the EUT were maximized and investigated. The system configuration, mode of operation, turn-table azimuth and height with respect to the antenna were noted for each frequency found. The spectrum was scanned from 30MHz to 1000MHz using bi-log antenna. Above 1GHz, linearly polarized double ridge horn antennas were used. Final measurements were made at open site with 3-meters test distance using bi-log antenna or horn antenna. The OATS have been verified in regular for its normalized site attenuation. The test equipment was placed on a wooden table. Sufficient time for the EUT, peripheral equipment, and test equipment was allowed in order for them to warm up to their normal operating condition. Each frequency found during pre-scan measurements was re-examined by manual. The detector function was set to CISPR quasi-peak mode and the bandwidth of the receiver was set to 120kHz or 1MHz depending on the frequency of type of signal. The EUT, peripheral equipment and interconnecting cables were re-configured to the set-up producing the max. emission for the frequency and were placed on top of a 0.8-meter high nonmetallic 1 x 1.5 meter table. The EUT, peripheral equipment, and interconnecting cables were re-arranged and manipulated to maximize each emission. The turntable containing the system was rotated; the antenna height was varied 1 to 4 meters and stopped at the azimuth or height producing the maximum emission. Each emission was maximized by: varying the mode of operation to the EUT and/or peripheral equipment and changing the polarity of the antenna, whichever determined the worst-case emission. IST Co., Ltd EMC LABORATORY(Registration Number:468536) FCCID:S79FD-4000 TEST REPORT NO. : 06-IST-0392(V1.0) 5 of 16 This Report shall not be reproduced except in full without the written approval of IST EMC Laboratory. Radiated Emissions Test,9kHz to 30MHz(Magnetic Field Test) 1. The preliminary radiated measurements were performed to determine the frequency producing th…
