S79FD-4000RRemote Control

Operating Instructions for FD-4000/R Digital Door Lock This equipment has been tested an d found to comply with the lim its for a Class B digital device, pursuan t to Part 15 of the FCC Rules. T hese limits are designed to provide reasonable protection against harmful i nterference in a residential installation. Th is equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accord ance with the instructions, it may cause harmful interference to radio co mmunications. However, there is no guarantee th at interference will not occur in a articular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the eq uipment off and on, the user is encouraged to try to correct the interferen ce by one or more of the following measures: This device complies with Part 15 of the FCC Rules. Operation i s subject to the following two conditions : (1) This device may not cause harmful interference, and (2) this devic e must accept any interference received, including interference that ma y cause undesired operation. Digital Door Lock I N D E X 1. Name of parts 3 2. Specifications 4 3. Features 5 4. Operating instruction 6 5. How to add or delete the cards 8 6. Cautions 11 7. How to install 11 Digital Door Lock 1 . Name of part 1) Outer body 2) Inner body Sliding Cover Emergency Ports Key Sensor Keypads LED Handle Lock Button Battery Cover Battery Cove r Screw Open/Close Button Manual Override Handle Double Locking Key Handle Card Setup Buttons PIN Setup Button Digital Door Lock 2. Specifications Specifications(Main) Model No. FD-4000 Inner: 299(H) x 76(W) x 33(D) mm Size Outer: 309(H) x 76(W) x 47(D) mm Power DC 6V(8 alkaline ‘AA’ batteries) Battery life 1 year (assuming 10 open/close a day) Material Die Casting (aluminum), PC, ABS Reading Range Within 30mm Available digits of PIN 3-20 digits Number of cards to register 1-50 cards Door thickness for installation 35-45mm Power (for emergency) DC 9V (not included) Digital Door Lock 2. Specifications Specifications(Remote control) Model No. FD-4000R Size 120mm(H) x 30mm(W) x 17(D)mm Power DC 3V(2 alkaline ‘AAA’ batteries) Battery life 1 year (assuming 10 open/close a day) Material ABS Reading Range Within 60m Output Power Max 5 ㎽ Band Width Max 8.5 ㎑ Operating Frequency 447.650 ㎒ ±3 ㎑ Digital Door Lock 3. Features - Imaginary numbers before the real PIN Pressing imaginary numbers (how many digi ts you want) before the real PIN prevents people who spy out your PIN. - Setting and modification of password (3~20 digits) You can set and modify your password at any time. -Backlighting system This feature allows you to see the keypad in low li ght or dark conditions thanks to self-illumination of the buttons. -Auto re-lock function If enabled, this function will lock the door within si x seconds after being closed. The users do not have to bother locking the door after opening. -Low battery warning Red light flashes with an alarm sound to let user know when the battery is running low. Digital Door Lock -Tamper proof All functions will stop for 30 seconds if you ent er the wrong password more than three times by mistake. -Easy installation The installation of this lock is simple and, in most cases, the existing keyhole can be used. Full installation instruction is supplied. -PIN memory Once the PIN is set, it will not be changed or erased even when the batteries are changed. -Indoor double lock system The product has an indoor double lock system preventing someone opening the door from the outside. If this function is activated, no one, ev en with the correct PIN, can open the door from outside. -Outdoor double lock system The user can use this feature from the outside. If the “Lock Button” is held down for 3 seconds after locking the door, no one can open the door from inside. Digital Door Lock 4. Operating instruction -How to set up Personal Identification Number ※ NOTE: All procedures have to be done in 8 seconds. Digital Door Lock -How to open the door using PIN from outside (when the sliding cover is closed) -How to open the door using PIN from outside (when the sliding cover is open) Digital Door Lock -How to open the door from inside Press Open/Close button to Open the door “Ding Dong Dang” Digital Door Lock -How to close the door when Auto-relock is activated The lock will automatically lock the door after being closed thanks to the magnetic sensor. NOTE: The lock will lock the door 6 seconds after the valid PIN or smart key are input. -How to close the door when Auto-relock is not activated Digital Door Lock -How to set automatic lock option -How to set on/off double lock from inside The door remains locked despite of inputting PIN or smart keys Digital Door Lock -How to set on/off double lock from outside *How to set on 1) Press the “Lock Button” on outer body for 5 seconds 2) Press PIN or place the smart keys near to the reader, then press key 3) The double locking function will be activated and the open/close key in the inner side will not work. *How to set off It will open only by PIN or smart key from the outside. *** This function is especially good when no one is in or going out for a long time. -Ports for emergency In case of emergency situation when the battery power is run ou t, you can run to the convenient store near by and buy a 9V battery, then contact it to the emergency contact points as shown below, located on the outside body of the door lock, to open the door lock usi ng PIN or smart cards. Digital Door Lock -How to set the buzzer on/off Digital Door Lock 5. How to add or delete the cards You can open this lock by cards, key tags or “pass-watch” supplied with the system. -How to register the smart keys (up to 50 smart keys) -How to add the smart keys (up to 50 smart keys) Digital Door Lock -How to delete all the pre-enrolled smart keys -How to open the door using smart keys Place the smart keys near to the“Key Sensor” …

Text truncated - open the document above for the full version.

BWS TECH Inc. 1 of 4 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea Appendix 3. External Photographs of EUT BWS TECH Inc. 2 of 4 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea BWS TECH Inc. 3 of 4 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea BWS TECH Inc. 4 of 4 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea

BWS TECH Inc. 1 of 1 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea Appendix 2. FCC ID Label and location Product Label Sample with FCC ID Label information Following is a sample copy of the label that will be placed on the rear cabinet of the product. The FCC identifier is marked in the product label. The warning statement and information to the user are described in the user manual. Label Location The label shown above shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) FIRSTECH I&C CO., LTD. REMOTE CONTROL Model : FD-4000R FCC ID : S79FD-4000R Label

BWS TECH Inc. 1 of 2 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea Appendix 4. Internal Photographs of EUT BWS TECH Inc. 2 of 2 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea

BWS TECH Inc. 1 of 1 #611-1 Maesan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do 449-853, Korea Appendix 1. Test Setup Photos
