S7USBPB1137Multimedia Equipment

FCC Statement Changes or modifications not expressly approved by Sling Media Inc., could void the user’s authority to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. 11 Product Specifications Product NameSlingbox Personal Broadcaster Model #SBPB1 Dimensions10.6"(w) x 1.6"(h) x 4" (d) Weight~1.5 lbs. Power requirements6V/1.6A InputsRCA audio (L/R) Composite video S-video RF/Coaxial OutputsRCA audio (L/R) Composite video S-video Device controlIR emitter NetworkRJ-45 Ethernet Display (3) front panel LEDs:Status Network Power TV tunerNTSC (built-in) SBPB-QSG-01 12 Power Adapter Specifications MakeHon-Kwang Electric Model #HK-A112-A06 Input Voltage Range100VAC to 240VAC Input Frequency Range47 Hz to 63 Hz Input In-rush Current50A Max Input Current0.45A Max Output Voltage+6V Output Regulation5.7~6.3V Output Load Range0~2.0A Output Ripple & Noise60mVMax @20MHz BANDWIDTH

Sling Box PB - Block Diagram Rev 0.0 Confidential Feb 2005 SlingMedia Private Ltd Page 1 of 1 Preliminary Information Audio Left- IN Audio Left- out Audio Right-out SAA7173 Video Decoder CVBS SIF I2C Bus RF TMS320DM641 DSP S-Video JACK RCA JACK RCA JACK RCA JACK 656 vid 8bit M A C I2S 4MB Flash MK5-Tuner 16 MB SDRAM 32bit ICS1893BF LAN PHY RJ45 conn I2C Video Audio EMIF EMIF EMAC UART IR Blaster Circuit Video- Buffer Audio- Pass- Through IR-OUT RCA JACK S-Video JACK RCA JACK RCA JACK CVBS-IN S-Video-IN S- Video-OUT CVBS-OUT 32.11 MHz 50MHz OSC 8.0MH z Xtal 25.00 MHz

TÜV RHEINLAND Product Safety GmbH Am Grauen Stein D-51105 Köln External Photos Documentation for Sling Media , Inc. 901, Mariners Island Blvd. Suite 300, San Mateo CA 94404 USA Of Multimedia Equipment Model: SBPB1 FCC ID: S7USBPB1137 This documentation consists of 5 pages include this cover page. Model: SBPB1 FCC ID: S7USBPB1137 Page 2 of 5 Over view Front view Model: SBPB1 FCC ID: S7USBPB1137 Page 3 of 5 Rare view Side view Model: SBPB1 FCC ID: S7USBPB1137 Page 4 of 5 Side view Bottom view Model: SBPB1 FCC ID: S7USBPB1137 Page 5 of 5 SMPS front view SMPS rare view

FCC ID : S7USBPB1137

LABEL LOCATION Applicant: Sling Media, Inc. Item: Multimedia equipment Model: SBPB1 FCC ID: S7USBPB1137

TÜV RHEINLAND Product Safety GmbH Am Grauen Stein D-51105 Köln Internal Photos Documentation for Sling Media , Inc. 901, Mariners Island Blvd. Suite 300, San Mateo CA 94404 USA Of Multimedia Equipment Model: SBPB1 FCC ID: S7USBPB1137 This documentation consists of 4 pages include this cover page. Model: SBPB1 FCC ID: S7USBPB1137 Page 2 of 4 Over view without top enclosure PCB component side Model: SBPB1 FCC ID: S7USBPB1137 Page 3 of 4 PCB solder side Partial view on component side Model: SBPB1 FCC ID: S7USBPB1137 Page 4 of 4 Partial view on component side

Sling Box PB – Write_up Rev 0.0 Confidential Feb 2005 SlingMedia Private Ltd Page 1 of 1 Preliminary Information The Slingbox TM Personal Broadcaster by Sling Media, Inc. is a breakthrough consumer electronics device that transforms today's television viewing experience. The Slingbox TM enables consumers to watch their TV programming from wherever they are by turning virtually any laptop or Internet-connected device into a personal TV. The Slingbox TM redirects, or "placeshifts," the TV signal from any cable box, satellite receiver, or personal video recorder to a viewer's location and device of choice - whether in another room in the home or anywhere in the world with a high-speed Internet connection. SlingBox personal broadcaster would allow anyone to stream personal digital content (audio, video or both) to multiple clients (Windows Desktops, Notebook PCs, smart phones among others). The streaming is achieved in real time over wired network. The clients can reside on the same network or can access the SlingBox from an external network. SlingBox supports a cable tuner and streaming over 10/100 Ethernet interface. The product is built on the TI DSP TMS320DM640 and uses the Windows Media 9 encoder for audio/video compression.

Produktsicherheit und –qualität Product Safety and Quality FCC ID: S7USBPB1137 Prüfbericht - Nr.: Test Report No. 02421235 001 Seite Page 1 von of 21 Auftraggeber: Client: Sling Media, Inc. 901, Mariners Island Blvd. Suite 300, San Mateo CA 94404 USA Gegenstand der Prüfung: Test item: Multimedia equipment Bezeichnung: Identification: SBPB1 Serien-Nr.: Serial No. proto type FCC1 Wareneingangs-Nr.: Receipt No.: 1403001852 Eingangsdatum: Date of receipt: 18th March 2005 Prüfort: Testing location: refer to section 2.1 Prüfgrundlage: Test specification: FCC Title 47, Part 15, Subpart B 2001(class B) The test procedures are followed as give in the standard ANSI C63.4 2003, EIA/TIA 603 and MP-5. Prüfergebnis: Test Result Der vorstehend beschriebene Prüfgegenstand wurde geprüft und entspricht oben genannter Prüfgrundlage. The a. m. test item passed. Prüflaboratorium / Testing Laboratory: TÜV Rheinland (India) Pvt., ltd zusammengestellt/ compiled by:B.S. Ravindra Kumar kontrolliert/ Reviewed by: G. Kalyan Varma 9 th April 2005 Datum Unterschrif Date Signature 11th April 2005 Datum Unterschrift Date Signature Sonstiges / Other Aspects: remarks Abkürzungen: ok / P = entspricht Prüfgrundlage fail / F = entspricht nicht Prüfgrundlage n.a. / N = nicht anwendbar Abbreviations: ok / P = passed fail / F = failed n.a. / N = not applicable Dieser Prüfbericht bezieht sich nur auf den o.g. Prüfgegenstand und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. This test report relates to the a. m. test item. Without permission of the test center this test report is not permitted to be duplicated in extracts. TÜV Rheinland Product Safety GmbH û Am Grauen Stein û D - 51105 Köln û Tel.: +49 221 806-1371 û Fax: +49 221 806-3909 Produktsicherheit und –qualität Product Safety and Quality FCC ID: S7USBPB1137 Prüfbericht - Nr.: Test Report No. 02421235 001 Seite Page 2 von of 21 TEST SUMMARY 5.1.1 MAINS TERMINAL CONTINUOUS DISTURBANCE VOLTAGE RESULT: PASS 5.2.1 RADIATED EMISSION (RE) RESULT: PASS Produktsicherheit und –qualität Product Safety and Quality FCC ID: S7USBPB1137 Prüfbericht - Nr.: Test Report No. 02421235 001 Seite Page 3 von of 21 Contents 1. GENERAL REMARKS................................................................................................4 1.1 COMPLEMENTARY MATERIALS.................................................................................4 1.2 FCC CROSS-REFERENCE TABLE..............................................................................4 2. TEST SITES.............................................................................................................5 2.1 TEST FACILITIES......................................................................................................5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS......................................................5 3. GENERAL PRODUCT INFORMATION...........................................................................6 3.1 PRODUCT FUNCTION AND INTENDED USE..................................................................6 3.2 RATINGS AND SYSTEM DETAILS...............................................................................6 3.3 INDEPENDENT OPERATION MODES...........................................................................6 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS...............................................6 3.5 SUBMITTED DOCUMENTS.........................................................................................6 4. TEST SET-UP AND OPERATION MODES.....................................................................7 4.1 PRINCIPLE OF CONFIGURATION SELECTION...............................................................7 4.2 PHYSICAL CONFIGURATION FOR TESTING..................................................................7 4.3 TEST OPERATION AND TEST SOFTWARE...................................................................7 4.4 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT..................................................8 4.5 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE................................................8 5. TEST RESULTS EMISSION.............................................................................9 5.1 EMISSION IN THE FREQUENCY RANGE UP TO 30 MHZ................................................9 5.1.1 Mains Terminal Continuous Disturbance Voltage...................................................................9 5.2 EMISSION IN THE FREQUENCY RANGE ABOVE 30 MHZ.............................................14 5.2.1 Radiated Emission (RE)........................................................................................................14 6. PHOTOGRAPHS OF THE TEST SET-UP.....................................................................18 7. LIST OF TABLES....................................................................................................20 8. LIST OF FIGURES...................................................................................................21 9. LIST OF PHOTOGRAPHS.........................................................................................21 Produktsicherheit und –qualität Product Safety and Quality FCC ID: S7USBPB1137 Prüfbericht - Nr.: Test Report No. 02421235 001 Seite Page 4 von of 21 1. General Remarks 1.1 Complementary Materials All attachments are integral parts of this test report. 1.2 FCC Cross-reference Table The results of emission measurements and product related information contained in this test report and the attached materials relate to the contents of the FCC standard report in the following way: FCC § / heading 1.1 Product Description Refer user manual attachment 1.2 Related Submittals ---- 1.3 Tested System Details Refer user manual attachment 1.4 Test Methodology see 5.1, 5.2 1.5 Test Facility see 2.1 2.1 FCC ID Label Refer label attachment 2.2 Location of Label on EUT Refer labellocation attachment 3.1 Justification see 4.1 3.2 EUT Exercise Software see 4.3 3.3 Speci…

Text truncated - open the document above for the full version.

TÜV RHEINLAND Product Safety GmbH Am Grauen Stein D-51105 Köln Test setup Photo Documentation for Sling Media , Inc. 901, Mariners Island Blvd. Suite 300, San Mateo CA 94404 USA Of Multimedia Equipment Model: SBPB1 FCC ID: S7USBPB1137 This documentation consists of 4 pages include this cover page. Model: SBPB1 FCC ID: S7USBPB1137 Page 2 of 4 Conducted emission on mains Model: SBPB1 FCC ID: S7USBPB1137 Page 3 of 4 Radiated Emission in Ahechoic chamber Model: SBPB1 FCC ID: S7USBPB1137 Page 4 of 4 Radiated Emission at OATS
