S8UPT718Personal Tracker

Sinocastel Co.,Ltd.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Oct 23, 2014
Application Purpose: Original Equipment
Date of Application: Oct 23, 2014
Equipment Note: Personal Tracker
Frequency Range: 1850.20000000 - 1909.80000000
Company: Sinocastel Co.,Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Sinocastel Co.,Ltd. PT-718 Personal Tracker Guide Sinocastel Co.,Ltd 1 Content 1. Summarize ................................................................................................................................................. 2 2. Overview ..................................................................................................................................................... 2 3. Accessories ................................................................................................................................................ 2 4. LED Status ................................................................................................................................................. 3 5. Buttons ........................................................................................................................................................ 4 6. Interfaces .................................................................................................................................................... 4 7. Features ...................................................................................................................................................... 5 8. APP Download& Installation ................................................................................................................... 5 9. APP Operation of Personal User ............................................................................................................ 6 9.1 Registration ..................................................................................................................................... 6 9.2 Log in ............................................................................................................................................... 6 9.3 Account Safety ............................................................................................................................... 7 9.4 Bound Equipment .......................................................................................................................... 7 9.5 Tracker Parameters Setting ......................................................................................................... 8 9.6 Synchronization between Tracker and APP .............................................................................. 8 9.7 Others .............................................................................................................................................. 9 Claim ................................................................................................................................................................. 11 Sinocastel Co.,Ltd 2 1. Summarize PT-718 is an individual GPS tracker developed by CASTEL. It adopts 2 communication modes: GPRS and SMS. PT-718 can be precisely located, easily operated. It is easy to take with good appearance. It adopts terminal+ APP+ cloud system to manage GPS data scientifically, which suits for the old& children in family, community and school. 2. Overview 3. Accessories Micro USB data cable: Use it to connect device with PC, by which you can upgrade its firmware or charge the battery. Strap: To adorn tracker. Quick start guide Sinocastel Co.,Ltd 3 4. LED Status Power LED: Red Solid on: Battery charging/GPS& GSM signal searching Off: Battery charged/Device working(GPS&GSM LED are on) Quick flashing: SOS alarm, 1s flashing, 20s duration Slow flashing: low battery, 8s flashing GPS LED: Green Off: Power off/Positioning Flashing: GPS located, 2s flashing GSM LED: Yellow Off: SIM card in tracker is registering to network. Flashing: SIM card has registered to network, 2s flashing. It means tracker can upload relative GPS data to APP and cloud. Sinocastel Co.,Ltd 4 5. Buttons SOS button: If meets emergency situation and needs assistance, user can press SOS button for 3s, then red LED will flash per 1 second and last for 20 seconds. At the same time, tracker will send emergency alarm to relative emergency contactor, which is preset by user when registers the APP account. In alarm, position is included so that emergency contactor can locate users quickly. Power button: To power on/off the tracker. Long press it until red LED turns on, tracker is powered on; Long press it until all LED turns off, tracker is powered off. 6. Interfaces Micro USB: Battery charge/firmware upgrade. Connect with PC to upgrade firmware, connect with mobile phones power adaptor to charge battery. Sinocastel Co.,Ltd 5 SIM card slot: It supports Micro SIM card only, or it will be damaged; It does not support CDMA card. 7. Features Timing positioning: In normal working mode, tracker can upload GPS information to APP& cloud by preset time interval. The emergency contactor bound with tracker can monitor in real time. Geo-fencing: To monitor the activity range of carrier, PT-718 provide geo-fencing service. User can specify a point and an effective radius to set a circle fence. When carrier moves out the circle area, tracker will send SMS remind to emergency contactor and send alarm to APP& cloud at the same time; The SMS contains current position of tracker and time so that user can locate carrier in real time. History tracking: When GSM signal is good, tracker’s position information will be uploaded to APP& cloud; Otherwise, tracker will record position information and re-upload by sequence after GSM network recovers. Therefore, all location information of the past one month will be stored in device, user can inquiry history tracking by input time condition if necessary. Parameter setting: Main parameters of PT-718 are: emergency contactor, positioning time interval, details please see APP introduction. 8. APP Download& Installation Family users can download CASTEL APP to manage the tracker. Scan below QR code to follow CASTEL Wechat public account, you can download APP and get all required tracker services. Sinocastel Co.,Ltd 6 9. APP Operation…

Text truncated - open the document above for the full version.

Cover Letter(s)

Sinocastel Co.,Ltd. DATE：2014-9-16 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Zhongjian Nanfang Testing Co.,Ltd.; 1st Floor, Block No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Sinocastel Co.,Ltd. 5/F,5th Building,Software Park,No.2 Gaoxin C. 3rd Road,Hi-Tech. Industrial Park, Shenzhen, China

External Photos

ID Label/Location Info

Label and Label location Label Size：35*20*0.1mm Label location Label location

Internal Photos

Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 39 of 44 Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 40 of 44 Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 41 of 44 Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 42 of 44 Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 43 of 44 Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 44 of 44 ------End of report------

Parts List/Tune Up Info

Tune Up Procedure During manufacturing each device is individually calibrated. Measurement is performed in a fully calibrated setup using an Agilent 8960 base station simulator (system tester). Measurement procedure is outlined below: Measurement Procedure: 1. Set the device to operational voltage and on a predefined channel in a special test mode. 2. The actual output power is measured at several power levels. 3. The gain factors of each individual device are adjusted until the target value is met. The appropriate gain control settings for each output power level are stored in each device individually (for each power level). The user has no possibility to change these settings later on. 4. The maximum gains of each individual device are adjusted and measured until the target value is met. The production target power with tolerance compiles with the maximum power in test report. Maximum Target Power for Production Unit Mode GSM 850 GSM 1900 GSM/PCS 31.5±1 dBm 28.5±1 dBm GPRS 8 (1 Uplink) CS1 31.5±1 dBm 28.5±1 dBm GPRS 10 (2 Uplink) CS1 31.5±1 dBm 29.0±1 dBm GPRS 11 (3 Uplink) CS1 30.5±1 dBm 27.0±1 dBm GPRS 12 (4 Uplink) CS1 28.5±1 dBm 25.0±1 dBm Power unit: dBm Then these appropriate gain settings are stored in each device individually. The user has no possibility to change these settings later on, and during manufacturing each device will be individual calibrated in this range. The measurement is done in a fully calibrated setup, which is based on the base station simulator. Furthermore, the highest power level is verified afterwards in a call measurement on three channels (low, middle and high).

RF Exposure Info

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS14080069701 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: Sinocastel Co., Ltd. Address of Applicant: 5/F,5th Building, Software Park,No.2 Gaoxin C. 3rd Road, Hi- Tech. Industrial Park, Shenzhen, China Equipment Under Test (EUT) Product Name: Personal Tracker Model No.: PT-718 FCC ID: S8UPT718 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 04 Sep., 2014 ~ 05 Sep., 2014 Test Result: Maximum Reported 1-g SAR Maximum Reported 10-g SAR Body: 1.226 (W/kg) Extremity : 1.713 (W/kg) Report No: CCIS14080069701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800697RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 109 2 Version Version No. Date Description 00 28 Sep., 2014 Original Prepared by: Date: 28 Sep., 2014 Report Clerk Reviewed by: Date: 28 Sep., 2014 Project Engineer Report No: CCIS14080069701 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800697RF No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 109 3 Contents 1 COVER PAGE ................................................................................................................................................... 1 2 VERSION ........................................................................................................................................................... 2 3 CONTENTS ....................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ............................................................................................................................. 5 5 GENERAL INFORMATION .............................................................................................................................. 6 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 6 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 6 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 7 5.4 ENVIRONMENT OF TEST SITE ......................................................................................................................................................... 7 5.5 TEST LOCATION ............................................................................................................................................................................. 7 6 INTRODUCTION ............................................................................................................................................... 8 6.1 INTRODUCTION ............................................................................................................................................................................... 8 6.2 SAR DEFINITION ............................................................................................................................................................................ 8 7 RF EXPOSURE LIMITS .................................................................................................................................... 9 7.1 UNCONTROLLED ENVIRONMENT ..................................................................................................................................................... 9 7.2 CONTROLLED ENVIRONMENT ......................................................................................................................................................... 9 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................... 9 8 SAR MEASUREMENT SYSTEM ................................................................................................................... 10 8.1 E-FIELD PROBE ........................................................................................................................................................................... 11 8.2 DATA ACQUISITION ELECTRONICS (DAE) .................................................................................................................................... 11 8.3 ROBOT ............................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS14080069601 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT Applicant: Sinocastel Co.,Ltd. Address of Applicant: 5/F, 5th Building, Software Park, No.2 Gaoxin C. 3rd Road, Hi- Tech. Industrial Park, Shenzhen, China Equipment Under Test (EUT) Product Name: Personal Tracker Model No.: PT-718 FCC ID: S8UPT718 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part22 Subpart H FCC CFR Title 47 Part24 Subpart E Date of sample receipt: 18 Aug., 2014 Date of Test: 19 Aug., to 21 Oct., 2014 Date of report issued: 21 Oct., 2014 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 44 2. Version Version No. Date Description 00 21 Oct., 2014 Original Prepared by: Date: 21 Oct., 2014 Report Clerk Reviewed by: Date: 21 Oct., 2014 Project Engineer Report No: CCIS14080069601 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140800696RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 44 3. Contents Page 1. COVER PAGE .............................................................................................................................................................. 1 2. VERSION ....................................................................................................................................................................... 2 3. CONTENTS ................................................................................................................................................................... 3 4. TEST SUMMARY ......................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................ 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST MODES .......................................................................................................................................................... 7 5.4 RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................................... 7 5.5 TEST METHODOLOGY ............................................................................................................................................ 7 5.6 LABORATORY FACILITY.......................................................................................................................................... 7 5.7 LABORATORY LOCATION ....................................................................................................................................... 7 5.8 TEST INSTRUMENTS LIST ....................................................................................................................................... 8 6. SYSTEM TEST CONFIGURATION .......................................................................................................................... 9 6.1 EUT CONFIGURATION ........................................................................................................................................... 9 6.2 EUT EXERCISE ...................................................................................................................................................... 9 6.3 CONFIGURATION OF TESTED SYSTEM .................................................................................................................. 9 6.4 DESCRIPTION OF TEST MODES ............................................................................................................................. 9 6.5 CONDUCTED OUTPUT POWER ............................................................................................................................ 10 6.6 OCCUPY BANDWIDTH .......................................................................................................................................... 12 6.7 MODULATION CHARACTERISTIC .......................................................................................................................... 18 6.8 OUT OF BAND EMISSION AT ANTENNA TE…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Guangqi Yuan

[email protected]15279524917Fax: 15279524917

Test Firm

Shenzhen Zhongjian Nanfang Testing Co.,LtdBruce Zhang

[email protected]86-755-23118282Fax: 86-755-23116366

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	153.00 mW	250KGXW	0.06 ppm

Confidentiality

Long Term

Grant Notes

Power listed is ERP for part 22 and EIRP for part 24. SAR compliance for body worn operating configurations must be restricted to accessories described in this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for body, and extremity (hand) exposure conditions are 1.23 W/kg, and 1.71 W/kg, respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations.
