The Ruckus ZoneFlex 2942 is the first centrally managed, multimedia 802.11g Wi-Fi access point that delivers industrial-strength features and functionality not available in any low-end consumer AP or high-end WLAN system. Together with the Ruckus ZoneDirector central WLAN controller, Ruckus ZoneFlex APs plug-and-play with minimum operational overhead. Ideal for hotels, schools, airports and small-to-medium businesses (SMBs) with little or no IT staff and a limited budget, the Ruckus ZoneFlex 2942 is also perfect for hot spot operators that want to deliver business class hot spot services – such as voice over Wi-Fi, IP-based video or secure enterprise access. The ZoneFlex 2942 implements Ruckus patented BeamFlex™ smart antenna technology that enables consistent, high performance, extended coverage and multimedia support as it automatically tunes itself to adapt to constant changes in the environment. This means fewer APs, more satisfied users, and a cost effective system that can be installed anywhere by non-wireless experts. A Web-based wizard allows any computer user to configure ZoneFlex 2942s through the ZoneDirector – creating a secure and sophisticated WLAN in a matter of minutes. Ruckus ZoneFlex 2942s simply plug into any Ethernet network and automatically discover the ZoneDirector. No RF tuning. No client configuration. A true plug-and-play multimedia WLAN that is ready to use. Smart Wi-Fi 802.11g Multimedia Access Point No RF experts required Smart antenna array eliminates AP placement issues and minimizes adjacent AP interference while ZoneDirector controls dynamic channel assignment and power management Breakthrough user performance and density Advanced antenna array and precision QoS software delivers 20 concurrent voice call, 50 simultaneous data users or 20 Mbps of sustained video quality throughput per access point Extended coverage means fewer APs Directional, high-gain antennas dynamically combined to give hotspot operators and SMBs two to four times the coverage over typical consumer and enterprise APs Optimized for voice over Wi-Fi Specialized antenna design, dynamic signal path selection and precision QoS software optimize delay-sensitive, high-density Vo-Fi applications. Power Save (UAPSD) maximizes handset battery life Proven video streaming support Ruckus smart antenna system and video QoS already proven for real time IP video streaming applications deployed by over 100 IPTV operators worldwide “IT lite” configuration and management Web-based wizard enables configuration of multiple APs across the entire WLAN in minutes. Once configured the WLAN manages itself Enables business class hot spot services New revenue opportunities for operators such as Voice- over-WLAN services, extended enterprise access, IP video applications and tiered service classes BENEFITS ZoneFlex ™ 2942 The First Centrally Managed, Multimedia W-Fi Solution for the Small Business and Hot Zone Introducing the Ruckus ZoneFlex 2942 The Ruckus ZoneFlex 2942 fills the gap between low end, feature-sparse consumer AP and expensive, complex enterprise-class WLANs. It is the first truly-affordable, centrally-managed 802.11g multimedia access point specifi- cally designed for hot zone operators and SMBs. Working in concert with the ZoneDirector system, the Ruckus ZoneFlex 2942 delivers a complete, plug- and-play, secure and robust WLAN solution without the cost or complexity of high-end systems. High performance and cost effective The Ruckus ZoneFlex 2942 is built on patented BeamFlex Smart antenna technology that automatically adapts to the RF environment by steering Wi-Fi signals on the best path and rejecting interference in real time. Each Ruckus ZoneFlex 2942 comes equipped with a state-of-the-art, high-gain smart an- tenna array designed to deliver unsurpassed density and range. Supporting up to 50 simultaneous data users or 20 concurrent voice calls while its superior coverage reduces the number of APs required by a factor of two or more, the Ruckus ZoneFlex 2942 gives hot zone operators and SMBs the most cost-ef- fective multimedia Wi-Fi solution. IT “lite” deployment The self-optimizing BeamFlex technology allows the Ruckus ZoneFlex 2942 to be installed without site survey and RF planning. Simply plug any Ruckus ZoneFlex 2942 into an Ethernet and it automatically discovers the Ruckus ZoneDirector and self-configures. The Ruckus ZoneFlex 2942 and ZoneDirector system seamlessly integrate with existing security systems such as firewalls, intrusion detection system and authentication servers including RADIUS and ActiveDirectory. An internal au- thentication database allows SMBs to implement user authentication without the expenses and complexity associated with external authentication servers. Minute configuration Ruckus ZoneFlex 2942 APs are automatically configured by the Ruckus Zone- Director. A network of APs can be centrally configured in a matter of minutes through the ZoneDirector’s web-based wizard. Automatic user security Used with the Ruckus ZoneDirector, the Ruckus ZoneFlex 2942 provides first- of-its-kind automatic, robust user security enforcement . Provisioning secure wireless access often involves configuring all the client devices with wireless setting such as an SSID and encryption key. Typically organizations use a single pre-shared key for all employees. This is a security problem and is an ongoing operational headache. A state-of-the-art smart antenna array integrates six high-gain vertically polarized and six hortizontally polarized antenna elements. This enables up to 4096 potential antenna combinations and up to 7 dBi gain thereby delivering unprecedented range extension and Wi-Fi signal reliability. Expert control software selects the best antenna elements to use at any given moment for any given packet and any given client based on changing environmental conditions Ruckus ZoneFlex 2942 Smart Wi-Fi 802.11g Multimedia Access Point Centralized configuration and RF management of Z…

Text truncated - open the document above for the full version.

Elliott TCB 684 West Maude Ave. Sunnyvale, CA 94085 July 20, 2007 Dear Examiner: In reference to the application under FCC ID: S9G2XX2-XXX, this device operates in only the 2.4Ghz band and not the 5Ghz band. There is circuitry included on the PCB for future expansion into the 5Ghz band. However, this circuitry will be disabled for this product. Sincerely, Craig Owens Director, Hardware Engineering 880 West Maude Avenue, Suite 101 TEL + .650.265.4200 Sunnyvale, CA 94085 USA FAX +.480.738.2065 www.ruckuswireless.com

Elliott TCB 684 West Maude Ave. Sunnyvale, CA 94085 June 13, 2007 Gentlemen: This is your letter of authorization to accept our appointment of Elliott Laboratories, Inc. as our Agent for Ruckus Wireless, 880 W. Maude Ave, Suite 101, Sunnyvale, CA 94085, to sign applications before Elliott TCB and to make representations to you on our behalf. Elliott Laboratories, Inc. is to receive and exchange data between our company and Elliott TCB. Sincerely, Craig Owens Director, Hardware Engineering 880 West Maude Avenue, Suite 101 TEL + .650.265.4200 Sunnyvale, CA 94085 USA FAX +.480.738.2065 www.ruckuswireless.com

Elliott TCB 684 West Maude Ave. Sunnyvale, CA 94085 July 20, 2007 Re: Request for Confidentiality Dear Examiner: In reference to the application under FCC ID: S9G2XX2-XXX, and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block diagram Theory of Operation Antenna specifications The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments: Internal and External Photographs Test Configuration Photographs It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Craig Owens Director, Hardware Engineering 880 West Maude Avenue, Suite 101 TEL + .650.265.4200 Sunnyvale, CA 94085 USA FAX +.480.738.2065 www.ruckuswireless.com

Federal Communicatiosn Commission 7435 Oakland Mills Road Columbia MD 21046 USA Date : 05 November 2007 FCC ID : S9G2XX2-XXX Subject : Supersede file after grant Dear Sir/Madam, The uploaded exhibit Internal Photos are/were not the correct Internal photos. We hereby ask to supersede the file Internal Photos uploaded on 03 August 2007 and to replaces it by the file “internal photos revised1r.pdf” as uploaded today 05 November 2007. Yours sincerely, Bert Vos Telefication B.V. Edisonstraat 12a, 6902PK Zevenaar, The Netherlands Tel: +31 316-583-162 Fax: +31 316-583-189 Email: [email protected] website: www.telefication.com

Telefication Edisonstraat 12a 6902 PK Zevenaar The Netherlands November 5, 2007 RE: Temporary Confidentiality Dear Examiner. In reference to the application under FCC ID: S9G2XX2-XXX, and pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an additional period of 45 days: External Photos Internal Photos Test Setup Photos Ruckus Wireless understands that the original temporary confidentiality expired and the documents became visible on September 17, 2007 and the documents are still currently available to the public. They state they have not yet marketed the product and wish to reinstate the temporary confidentiality. Regards, David Guidotti Senior Documentation Specialist Elliott Laboratories, Inc.

ZF2942 NOTES: 1. MATERIAL: White Mylar 2. THICKNESS: 0.18mm 3. COLOR AND FINISH: Background-white/Finish-0.076mm Fine Textured Lexan 4. ADHESIVE: 3M-467MP 5. INTERPRET DRAWING PER ANSI Y14.5M-1994 6. TREAT CAD FILE AS MASTER DATABASE - DRAWING SHOWS CRITICAL TO FUNCTION DIMENSIONS 7. ALL DIMENSIONS SHOWN ARE SUBJECT TO FIRST ARTICLE INSPECTION REPORT VERIFICATION - 3 SAMPLES MINIMUM 8. ALL PART AND MATERIALS TO BE COMPLIANT WITH EU RoHS DIRECTIVE 2002/95/EC Replace “XXX” with the country of manufacture. Made in XXX Colors: BLACK PMS 021C 860-76136-001 P/N S/N MAC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Model: 2942 FCC ID:S9G2XX2-XXX IC:5912A-2XX2 Radio Module Inside Complies with CANADA RSS-210 POWER RATING: 12VDC/1.0A ZoneFlex 2942 Wireless AP Default IP Address: 192.168.0.1 User name=admin Password=password

LABEL

Ruckus Wireless Confidential Tomahawk Antenna Patterns Engineer Manager 6/27/2007 6/27/2007 Ruckus Wireless Inc. 880 West Maude Ave. Suite 101 Sunnyvale, CA 94085, USA Tel: (650) 265-4200 Fax: (408) 738-2065 Ruckus Wireless Confidential Highest gain patterns: -30 -25 -20 -15 -10 -5 0 5 10 2437 HP 2slices plate pat # 14 001110 interference rejection >- 26dBi intf rejection threshold gain angle theshold pattern dBi Highest pattern gain 6.5dBi HORIZONTAL POLARIZATION -30 -25 -20 -15 -10 -5 0 5 10 2437 HP 2slices plate pat # 14 001110 interference rejection >- 26dBi intf rejection threshold gain angle theshold pattern dBi Highest pattern gain 6.5dBi HORIZONTAL POLARIZATION -30 -25 -20 -15 -10 -5 0 5 10 VP pat # 33 100001 interference rejection >-38dBi antenna gain >10 dBi VC33 max intf rejection threshold gain angle theshold pattern Highest pattern gain 8.7dBi VERTICAL POLARIZATION -30 -25 -20 -15 -10 -5 0 5 10 VP pat # 33 100001 interference rejection >-38dBi antenna gain >10 dBi VC33 max intf rejection threshold gain angle theshold pattern Highest pattern gain 8.7dBi VERTICAL POLARIZATION Ruckus Wireless Confidential Each polarization on the antenna is capable of 64 different element combinations with horizontal polarization peak gain of 6.5dBi and vertical polarization peak gain of 8.7dBi. Conclusion: Antenna patterns we measured in an anechoic chamber and it was determined that the highest gain for all possible antenna patterns was 8.7dBi.

Wires are evil. Metrix Communication LLC HomeLog In Antennas-> |_ Directional |_ Laptop Mount |_ Omni Directional |_ Rubber Duckies-> |_ Reverse Polarity SMA: RP-SMA |_ Reverse Polarity TNC: RP-TNC |_ Type N Male |_ Sector Cable Assemblies/Pigtails Ethernet Cables and Accessories Power / Power Over Ethernet Single Board Computers-> Test Equipment VOIP Kits Wireless Cards/Adapters-> Wireless Kits-> Specials ... New Products ... Featured Products ... All Products ... Categories n About Us n Shipping & Returns n Privacy Notice n Contact Us n Site Map n Gift Certificate FAQ n Newsletter Unsubscribe Information Home :: Antennas :: Rubber Duckies :: Reverse Polarity SMA: RP- SMA :: 9dbi Omni Rubber Duck RP-SMA Reverse Polarity SMA: RP-SMA 9dbi Omni Rubber Duck RP-SMA $20.00 Looking to give your existing access point extra punch? These 9dbi omni antennas will make a great replacement for the standard 2dbi antennas that come with most of the shelf access points. Equipped with a RP-SMA connector, tilt and swivel action. These antennas will connect directly to any access point or wireless device with an RP-SMA jack. Features: n RP-SMA (reverse polarity)connector n 9dBi gain n 2.4Ghz Compatible with the following RP-SMA equipped devices: n Actiontec n R3010WAP Access Point n GT701AP Access Point n AU802C Access Point n GT704-WR Wireless Router n R3010SUW Wireless Router n R3010UW Wireless Router n Aercomm n ConnexLink CL5124-200-232 n Amtron n MW251 n Aruba Networks n AP 70 n Belkin n F5D6001 PCI Card n F5D7001 PCI Card n F5D7000 PCI Card n Blitzz n BWA611 NetWave n BWA611B NetWave n BWA711 Super G n BWA721G larger image Metrix Mark I Kit $325.00 Featured [more] n Professional Services n Metrix Training n Custom Hardware n Pyramid Linux Metrix Services Action Pics Got a picture of Metrix gear in action? Join our Flickr Group www.flickr.com Page 1 of 59dbi Omni Rubber Duck RP-SMA [MET-ANT-OMNI-W9-RPSMA] - $20.00 : Metrix C... 6/27/2007http://metrix.net/9dbi-omni-rubber-duck-rpsma-p-51.html n BWI605 NetWave n BWI715 Super G n Breezecom / Alvarion n AP/SA/WB-10D n Buffalo n AirStation™ WHR-G54S n AirStation™ WHR-HP-G54S n AirStation™ WLI-TX4-G54HP n Wireless-G MIMO Performance Router n AP WHR-HP-G54 n Cnet n CWP-854 Wireless-G PCI Adapter n Colubris n CN320 n CN330 n CN1250 n CN-3300 n MAP-320 n MAP-330 n MSC-3200 n MSC-3300 n MGW-1250 n Dlink n Air DWL-520, DWL-900AP n DI-713 n DI-714 n DI-614 n PCI 520+ n DI-524 AirPlus™ G n DI-514 n DI-714P+ n DI-824VUP n DWL-800AP+ n DWL-810+ n DWL-G700AP n DWL-G800AP n DI-624 n DGL-4300 n DPG-2000W n DWL-G810 n DWL-G510 n DWL-G520 n DWL-1000AP+ n DWL-2000AP n DWL-2100AP n DWL-3200AP n DWL-8200AP n DI-514 n DI-714P n DI-824VUP n DWL-800AP+ n DWL-810+ n DWL-G700AP n DWL-G800AP n DIR-625 RangeBooster N™ Router n DIR-635 RangeBooster N™ 650 Router n DWA-542 RangeBooster N™ Desktop Adapter n DWA-547 RangeBooster N™ 650 Desktop Adapter n Draydek n Vigor2600VGi Page 2 of 59dbi Omni Rubber Duck RP-SMA [MET-ANT-OMNI-W9-RPSMA] - $20.00 : Metrix C... 6/27/2007http://metrix.net/9dbi-omni-rubber-duck-rpsma-p-51.html n Vigor2600We n Edimax n EW-7207APb Access Point n EW-7207APg Access Point n EW-7206APb Access Point n BR-6104Wb Wireless Router n BR-6114Wg Wireless Router n EW-7126 PCI Card n EW-7128g PCI Cards n Enterasys n RoamAbout AP4102 Access Point n RoamAbout AP1602 Access Point n Senao/Engenius n EUB-362 EXT Wireless USB Adapter n Fortinet n FortiWiFi-60 Access Point n Hawking n HWR54G n HWBA54G n HWP54G n HP n ProCurve® 420NA Access Point n ProCurve® 420WL Access Point n ProCurve® 420WW Access Point n Intel n PRO/Wireless AP WPCI5000 n Linksys n WET11 n WET54G n WMP11 PCI Card n WPS11 n WMP54G n WMP54GS n WRT54GC n Netgear n FM114P n FVM318 n FWG114P n MA311 n ME101 n ME103 n WG302 n WG311 n Nomadix n AG-2000-w - Wireless Gateway n QPCOM n QP-W102 (11b access point) n QP-WR804B (11b wireless internet router) n QP-WR914G (11g wireless internet router) n Siemens n SpeedStream® SS1024 n CONNECT2AIR™ AP-600RP-USB n CONNECT2AIR™ E-1100 PCI Card n Gina 2015 AP/Bridge n QP-W2400GP (11g PCI adapter) n QP-WP2000 ( 11b PCI adapter) n QP-WA252G (54 Mbps Wireless AP) n QP-WR254G (54 Mbps Wireless Router) n QP-W2400GP+ (54 Mbps Wireless PCI adapter) n SMC Page 3 of 59dbi Omni Rubber Duck RP-SMA [MET-ANT-OMNI-W9-RPSMA] - $20.00 : Metrix C... 6/27/2007http://metrix.net/9dbi-omni-rubber-duck-rpsma-p-51.html n SMC2552W-G n SMC2582W-B n SMC2586W-G n SMC2602W n SMC2802W n BARRICADE SMC2804WBR n BARRICADE SMC2804WBRP-G n Sputnik n Sputnik AP 160™ n Symbol n AP-5131 Access Point n Trendnet n TEW-203PI n TEW-228PI n TEW-403PI n TEW-423PI n TEW-231BRP and TEW-431BRP Wireless Routers n TEW-2K1 Wireless Router / PC Card Kit n TEW-435BRM Wireless Firewall Router n US Robotics n USR 8022 n USR2216 n USR5416 n USR5430 n USR5450 n USR8054 n USR9106 n Zyxel n ZyAIR® B-1000 Access Point n ZyAIR® B-2000 Access Point n ZyAIR® B-3000 Access Point n ZyAIR® G-2000 Access Point Add to Cart: 1 n Model: MET-ANT-OMNI-W9-RPSMA Page 4 of 59dbi Omni Rubber Duck RP-SMA [MET-ANT-OMNI-W9-RPSMA] - $20.00 : Metrix C... 6/27/2007http://metrix.net/9dbi-omni-rubber-duck-rpsma-p-51.html Home Your IP Address is: 67.107.177.194 Copyright © 2007 Metrix Communication LLC Customers who bought this product also purchased... EUB-362 EXT 802.11b/g 200mw detachable antenna Page 5 of 59dbi Omni Rubber Duck RP-SMA [MET-ANT-OMNI-W9-RPSMA] - $20.00 : Metrix C... 6/27/2007http://metrix.net/9dbi-omni-rubber-duck-rpsma-p-51.html

Wires are evil. Metrix Communication LLC HomeLog In Antennas-> |_ Directional |_ Laptop Mount |_ Omni Directional |_ Rubber Duckies-> |_ Sector Cable Assemblies/Pigtails Ethernet Cables and Accessories Power / Power Over Ethernet Single Board Computers-> Test Equipment VOIP Kits Wireless Cards/Adapters-> Wireless Kits-> Specials ... New Products ... Featured Products ... All Products ... Categories n About Us n Shipping & Returns n Privacy Notice n Contact Us n Site Map n Gift Certificate FAQ n Newsletter Unsubscribe Information Home :: Antennas :: Directional :: 2.4GHZ Mobile Patch, V-POL 8DBI W/Suction Cup Base Directional Product 1/4 2.4GHZ Mobile Patch, V-POL 8DBI W/Suction Cup Base $34.00 n Frequency: 2.4-2.5GHz n Gain: 8dBi n Polarization: Vertical n Horizontal Beamwidth: 65 degree n Vertical Beamwidth: 55 degree n Front to Back Ratio: > 20dB n VSWR: < 1.5 : 1 n Max Power: 10 watts n Standard Connector: N-type female (50 ohm) n Dimensions (without bracket): 3.1 x 3.1 x 0.6in (8 x 8 x 1.5cm) n Weight (with bracket): 5.7oz (160g) n Cable Length (RG-58/U): 12in (30cm) n Includes pivoting, suction-cup base larger image Add to Cart: 1 n Model: MET-ANT-9DBI-MOBILE-PATCH Customers who bought this product also purchased... Metrix Mark I $325.00 Featured [more] n Professional Services n Metrix Training n Custom Hardware n Pyramid Linux Metrix Services Action Pics Got a picture of Metrix gear in action? Join our Flickr Group www.flickr.com Page 1 of 22.4GHZ Mobile Patch, V-POL 8DBI W/Suction Cup Base [MET-ANT-9DBI-MOBILE-... 6/27/2007http://metrix.net/24ghz-mobile-patch-vpol-8dbi-wsuction-cup-base-p-66.html Home Your IP Address is: 67.107.177.194 Copyright © 2007 Metrix Communication LLC MMCX Right Angle to N-Male LMR-100 1ft Ubiquiti Extreme Range 5 ( XR5 ) 5ghz 400mw MINI PCI Ubiquiti Super Range 2 Mini Outdoor 12dbi Patch Antenna Ubiquiti Extreme Range 2 ( XR2 ) Page 2 of 22.4GHZ Mobile Patch, V-POL 8DBI W/Suction Cup Base [MET-ANT-9DBI-MOBILE-... 6/27/2007http://metrix.net/24ghz-mobile-patch-vpol-8dbi-wsuction-cup-base-p-66.html

MPE Exposure Formula: S = ( P X G ) / ( 4 X p X d^2 ) where: S = power density P = transmitter conducted power in (mW) G = antenna numeric gain d = distance to radiation center (m) or (.02^2 ) = .020 m 2412 MHz (802.11b) Gain =7.9NumericEUT ant.:9dBi Power = 195.0mWEUT power:22.9dBm Frequency =2412MHzMPE limit:1mW/cm^2 Cable Loss =dB EIRP =1548.82mW1548.82mW R (cm) = S (20cm) = 2437 MHz (802.11b) Gain =7.9NumericEUT ant.:9dBi Power = 204.2mWEUT power:23.1dBm Frequency =2437MHzMPE limit:1mW/cm^2 Cable Loss =dB EIRP =1621.81mW1621.81mW R (cm) = S (20cm) = 2462 MHz (802.11b) Gain =7.9NumericEUT ant.:9dBi Power = 169.8mWEUT power:22.3dBm Frequency =2462MHzMPE limit:1mW/cm^2 Cable Loss =dB EIRP =1348.96mW1348.96mW R (cm) = S (20cm) = 11.36043780.323 Enter Data in Linear Units 10.36084240.268 Enter Data in Linear Units 0.30811.1018427 Enter Data in Linear Units 2412 MHz (802.11g) Gain =7.9NumericEUT ant.:9dBi Power = 158.5mWEUT power:22dBm Frequency =2412MHzMPE limit:1mW/cm^2 Cable Loss =dB EIRP =1258.93mW1258.93mW R (cm) = S (20cm) = 2437 MHz (802.11g) Gain =7.9NumericEUT ant.:9dBi Power = 173.8mWEUT power:22.4dBm Frequency =2437MHzMPE limit:1mW/cm^2 Cable Loss =dB EIRP =1380.38mW1380.38mW R (cm) = S (20cm) = 2462 MHz (802.11g) Gain =7.9NumericEUT ant.:9dBi Power = 131.8mWEUT power:21.2dBm Frequency =2462MHzMPE limit:1mW/cm^2 Cable Loss =dB EIRP =1047.13mW1047.13mW R (cm) = S (20cm) = 10.48081530.275 Enter Data in Linear Units 9.12840850.208 Enter Data in Linear Units 10.00910090.250 Enter Data in Linear Units

File: R68367 Rev 1 Page 1 of 21 2016-01 Electromagnetic Emissions Test Report and Application for Grant of Equipment Authorization Certification pursuant to Industry Canada RSS-Gen Issue 1 / RSS 210 Issue 7 FCC Part 15 Subpart C on the Ruckus Wireless Transmitter Model: 2231, 2232, 2241, 2242, 2252, 2292, 2932, 2942, 2952, 2962 UPN: 5912A-2XX2-XXX FCC ID: S9G2XX2-XXX GRANTEE: Ruckus Wireless 880 West Maude Ave. Suite 101 Sunnyvale, CA 94085 TEST SITE: Elliott Laboratories, Inc. 684 W. Maude Ave Sunnyvale, CA 94086 REPORT DATE: June 25, 2007 FINAL TEST DATE: May 21, May 24, June 7, June 13 and June 14, 2007 AUTHORIZED SIGNATORY: ______________________________ Juan Martinez Senior EMC Engineer Elliott Laboratories, Inc. is accredited by the A2LA, certificate number 2016-01, to perform the test(s) listed in this report. This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories, Inc. Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: June 25, 2007 File: R68367 Rev 1 Page 2 of 21 pages REVISION HISTORY Revision # Date Comments Modified By 1 July 13, 2007 Initial Release David Guidotti Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: June 25, 2007 File: R68367 Rev 1 Page 3 of 21 pages TABLE OF CONTENTS COVER PAGE..................................................................................................................................................................................1 REVISION HISTORY.....................................................................................................................................................................2 TABLE OF CO…
