T350c Access Point Quick Setup Guide NOTE: The minimum softwar e revision for the T350c is ZoneDirector (ZD) 10.5 or later, or SmartZone (SZ) 6.0 or later. This Quick Setup Guide provides step-by-step instructions on ho w to field- install the RUCKUS T350c access point (AP). For detailed information on planning the installation, performing a site survey, and operating the T350c, refer to the RUCKUS Outdoor Access Point User Guide, available at https://support.ruckuswireless.com. WARNING! Only trained and qualified per sonnel should be allowed to install, replace, or service this equipment. WARNING! Inst allation of this equipment must comply with local and national electrical codes. CAUTION! Form a 80-mm to 130-mm (3-in. to 5-in.) drip loop in any c able that is attached to the AP or the building. This will prevent water from running along the cable and entering the AP or the building where the cable terminates. CAUTION! Be sure tha t grounding is available and that it meets local and national electrical codes. For additional lightning protection, use lightning rods and lightning arrestors. CAUTION! Make sur e that proper lightning surge protection precautions are taken according to local electrical code. CAUTION! RUCKUS s trongly recommends that you wear eye protection before mounting the T350c. Before You Begin Bef ore deploying RUCKUS products, please check for the latest software and the release documentation. •Release Notes and other user documentation are available at http:// support.ruckuswireless.com/documents. •Software upgrades are available at http://support.ruckuswireless.com/ software. •Software license and limited warranty information are available at http://support.ruckuswireless.com/warranty. •Before deploying your RUCKUS Access Point, verify that all items listed in Package Contents are included in the package. If any item is damaged or missing, notify your authorized RUCKUS sales representative. Also, make sure that you have the required hardware and tools. This Guide in Other Languages •请从以下网站获得该指南的简体中文版 https:// support.ruck uswireless.com. •Vous trouverez la version française de ce guide à l'adresse suivante https://support.ruckuswireless.com. •このガイドの日本語版は https://support.ruckuswireless.com でご覧 ください。 •이 가이드의 한국어 버전은 웹 사이트 (https:// support.ruckuswireless.com) 에서 확인하시기 바랍니다. •Veja a versão em português (Brasil) deste guia em https:// support.ruckuswireless.com. •Puede ver la versión en español (América Latina) de esta guía en https://support.ruckuswireless.com. Required Hardware and Tools •No. 2 Phillips screwdriver •Small flat-blade screwdriver •Wide flat-blade screwdriver •Torque wrench or torque screwdriver with sockets •Long-nose pliers •Electrical wire-stripping and terminal-crimping pliers •Pipe or pole, or a sturdy flat surface •Electric drill with drill bits and customer-supplied wall anchors, flat washers, and hex nuts for flat-surface mount Package Contents A complete T350c field-installation package includes all of the following items: •T350c Access Point •M25 data cable gland •Ground wire with lug •Pole/Wall Mount Bracket Kit •Two steel pipe clamps •Declaration of Conformity/Regulatory Statement FIGURE 1 T350c Package Contents 1.T350c Access Point 2.M25 data cable gland 3.Ground wire with lug 4.Pole/Wall Mount Bracket Kit Mounting Instructions Connecting and Sealing the RJ-45 Cables WARNING! Do not use any PoE injector not tested and approved by RUCKUS to power the T350c Access Point. FIGURE 2 T350c LEDs and Ports 1.Feed the end of the cable through the sealing nut, rubber O-ring, clamping ring assembly, and c able gland base, as shown in Figure 3. NOTE: Do not seat the clamping ring and rubber O-ring in to the gland body until the gland body has been torqued to specifications. Copyright © 2021 CommScope, Inc. All rights reserved.Page 1 of 3 Published May 2021, Part Number 800-72679-001 Rev A FIGURE 3 RJ-45 Cable and Gland Assembly 1.Cable gland base 2.Clamping ring 3. Rubber O-ring 4.Sealing nut 2.Use a wide flat-blade screwdriver to remove the required (PoE IN) blanking cap from the AP. 3.Connect the cable to the Ethernet port on the AP. 4.Tighten the cable gland base into the AP chassis to 7 N.m or 62 in-lbs. 5.Wrap the clamping ring assembly around the rubber O-ring. Make sure that the clamping ring assembly fully encloses the rubber O-ring. 6.Seat the clamping ring assembly and rubber O-ring in the cable gland base. 7.Hand-tighten the sealing nut. Attaching the Mounting Bracket to a Flat Surface 1.The AP mounting bracket attaches to the AP using a captive screw. Use a medium flat-blade or No. 2 Phillips screwdriver to loosen the captive screw, as shown in Figure 4, and pull up on the end of the bracket to remove the bracket from the AP, as shown in Figure 4. FIGURE 4 Removing the Mounting Br acket 1.Loosen the captiv e screw 2.Pull up on the end of the bracket 2.Using either of the two options shown in Figure 5, hold the mounting bracket at the location on the mounting surface where you want to mount the AP. Use the holes on the mounting bracket as a template to mark the locations of the mounting holes. NOTE: The mounting brack et can be mounted to a vertical or horizontal surface to support the AP in the required orientation. FIGURE 5 Mounting Brack et on a Flat Surface 1.Horizontal mounting2.Vertical mounting 3.Remove the mounting bracket from the mounting surface. 4.Drill holes required for the customer-supplied mounting hardware. 5.Attach the mounting bracket to the flat surface using the mounting hardware. 6.Using the mounting hardw are instructions, tighten the hardware to secure the mounting bracket. 7.Continue with Mounting the AP on page 2. Attaching the Mounting Bracket to a Pole 1.The AP mounting bracket attaches to the AP using a captive screw. Loosen the screw and pull up on the end of the bracket to remove the bracket from the AP, as shown in Figure 4 on page 2. 2.Insert the open end of one steel clamp into two of the slots on the mounti…
