S9GR710R710 Access Point

Page 1 Federal Communications Commission Notices This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications to this equipment that have not been approved by Ruckus Wireless may void the user's authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Industry Canada Statement Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall comply with the e.i.r.p. limit; and the maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate. Le dispositif de fonctionnement dans la bande 5150-5250 MHz est réservé à une utilisation en intérieur pour réduire le risque d'interférences nuisibles à la co-canal systèmes mobiles par satellite, le gain d'antenne maximal autorisé pour les appareils dans les bandes 5250-5350 MHz et 5470-5725 MHz doit se conformer à la pire limite, et le gain d'antenne maximal autorisé pour les appareils dans la bande 5725-5825 MHz doivent être conformes avec le pire limites spécifiées à point-à-ponctuelles et non point-à-point de fonctionnement selon qu'il convient. Operation in the 5600-5650 MHz band is not allowed in Canada. High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Opération dans la bande 5600-5650 MHz n'est pas autorisée au Canada. Haute puissance radars sont désignés comme utilisateurs principaux (c.-à- utilisateurs prioritaires) des bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer des interférences et / ou des dommages à dispositifs LAN-EL. Radiation Exposure Statement The device has been found to be compliant to the requirements set forth in CFR 47 Sections 2.1091 and Industry Canada RSS-102 for an uncontrolled environment. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Le dispositif a été jugé conforme aux exigences énoncées dans les articles 47 CFR 2.1091 et Industrie Canada RSS-102 pour un environnement non contrôlé. L'antenne (s) utilisée pour ce transmetteur doit être installé pour fournir une distance de séparation d'au moins 20 cm de toutes les personnes et ne doit pas être co-localisés ou fonctionner en conjonction avec une autre antenne ou transmetteur. Mexico Statement “La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.” Page 2 Professionally Installed Products The product is to be installed according to the installa…

Text truncated - open the document above for the full version.

Copyright © 2015 Ruckus Wireless, Inc. Page 1 of 4 Published 10 February 2015, Part Number 800-70766-001 Rev B R710 Access Point Quick Setup Guide This Quick Setup Guide provides step-by-st ep instructions on how to set up your Ruckus Wireless R710 Dual Band 802.11ac Multimedia Wi-Fi Access Point ( AP). After completing the steps described in this Guide, you will be able to place the R710 at your site and provide wireless network access to users. The rest of this document refers to the R710 as the AP.Figure 1. Ruckus Wireless R710 Access Point This Guide in Other Languages请从以下网站获得该指南的简体中文版 https://support.r uckuswireless.com . Vous trouverez la version française de ce guide à l'adresse suivante https://support.r uckuswireless.com . このガイドの日本語版は https://support.r uckuswireless.com でご覧ください。 이 가이드의 한국어 버전은 웹 사이트 ( https://support.r uckuswireless.com ) 에서 확인하시기 바랍니다 . Veja a versão em português (Brasil) deste guia em https://suppo rt.ruckuswireless.com. Puede ver la versión en español (América Latina) de esta guía en https://suppo rt.ruckuswireless.com. Before You BeginBefore deploying Ruckus Wireless products, please check for the latest software and the release documentation.• User Guides and Release Notes are available at http://support .ruckuswireless.com/documents . • Software Upgrades are available at http://support .ruckuswireless.com/software . • Open Source information is available athttp://opensource.ruckuswireless.com . • Software License and Limite d Warranty are available at http://support .ruckuswireless.com/warranty . Package Contents• R710 Access Point • One T-bar mounting assembly kit, including:• One T-bar bracket (2 separate plastic parts) • Two each 1.0" L x No. 8 steel Phillips panhead mounting screws and plastic wall anchors • Regulatory flyer • Product warra nty statement • Declaration of Conformity, if required •This Quick Setup Guide C ONFIGURING THE AP Continue with the following steps:• Step 1: Collecting Setup Requirements, Hardware, and Tools • Step 2: Connecting Your Computer to the AP • Step 3: Preparing Your Computer for AP Setup • Step 4: Logging Into the AP • Step 5: Customizing the Wireless Settings • Step 6: Placing the AP in Your Site • Step 7: Verifyin g the Installation Step 1: Collecting Setup Requirements, Hardware, and Tools • A computer running Windows 7 (procedures for common operating systems are similar). • One Cat 5e (or better) Ethernet cable. • A Ruckus Wireless 902-0169-xx00 AC power adapter (sold separately) --OR-- an 802.3at-compliant Power over Ethernet (PoE) switch or PoE injector. Optional hardware and tools: • Customer-supplied small padlock with a 3.5mm (0.14”) or smaller shackle, used to fasten the AP to the secure mounting bracket or the T-bar bracket. • Customer-ordered Ruckus Wireless 902-0120-0000 secure mounting bracket kit:• If you are mounting the AP on a flat surface using the secure mounting bracket kit, th en you need an electric drill with 4.75mm (3/16”) drill bits. • If you are mounting the AP on a pipe or pole using the secure mounting bracket kit, then you will also need a 38.1mm to 63.5mm (1.5" to 2.5") pipe or pole, two included stainless steel clamp s, and hand tools to tighten the clamps. Continue with Step 2: Connecting Your Computer to the AP . Step 2: Connecting Your Computer to the AP1 After removing your AP from its package, place it next to your computer. 2 Using an Ethernet cable, connect your computer’s network port to the 10/100/1000 POE In port on the AP (A in Figure 2 ). 3 Using an AC adapter (sold separately), connect the AP 12VDC port (B in Figure 2 ) to a convenient (and protected) power source. Alternatively, conn ect the 10/100/1000 POE In port to a PoE injector or switch for both power and network connectivity. Figure 2. AP ports 4 Verify that the PWR LED on the AP is a steady green. Continue with Step 3: Preparing Your Computer for AP Setup . Step 3: Preparing Your Computer for AP Setup1 On your Windows 7 computer, configure your network adapter from the Local Area Connection settings as follows: • Start > Control Panel > Network and Sharing Center > Change Adapter Settings 2 Edit the TCP/IPv4 addre ss settings as follows: • Local Area Connection > Properties > Internet Protocol Version 4 (TCP/IPv4) > Properties The Internet Protocol Version 4 (TCP/IPv4) Properties dialog box appears. 3 Select Use the following IP address (if it is not already selected) and then make the following entries: • IP address : 192.168.0.22 (or any avai lable address in the 192.168.0.x network, except 192.168.0.1) • Subnet mask : 255.255.255.0 • Default gateway : 192.168.0.1 Leave the DNS server fields empty. Note: The minimum software revision for the AP is base image 100.0.2 or later, RuckOS 3.2 or later, or ZoneFlex 9.12 or later. Note: The following procedures assume that Windows 7 is the operating system. Procedures fo r other operating systems are similar.Important! Write down all of the currently active settings so you can restore your computer to its current configuration later (when this process is complete). A B Copyright © 2015 Ruckus Wireless, Inc. Page 2 of 4 Published 10 February 2015, Part Number 800-70766-001 Rev B 4 Click OK to save your changes. Your changes are put into effect immediately. Continue with Step 4: Logging Into the AP . Step 4: Logging Into the APAs specified in Step 3: Preparing Your Computer for AP Setup , the computer should be di rectly connected to your AP through one of the Ethernet ports and powered on, ready for setup. 1 On your computer, open a Web browser window. 2 In the browser, type this URL to connect to the AP: https://192.168.0.1 3 Press <Enter> to initiate the connect ion. When a security alert dialog box appears, click OK/Yes to proceed. 4 When the Ruckus Wireless Admin login page appears, enter the following: • Username : super • Password : sp-admin 5 Click Login . Continue with Step 5: Customizing the Wireless Settings . Step 5: Customizing the Wireless Settings1 On the We…

Text truncated - open the document above for the full version.

2/2/2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: DFS Channels for FCC ID: S9GR710 Ruckus Wireless, Inc. hereby declares that the device FCC IS: S9GR710 will not operate outside the bands of approval. Operation on DFS bands is disabled for initial DTS and NII approval. A Class Two Permissive Change (CLIIPC) will be pursued to gain approval in the DFS bands. Operation on DFS bands will remain disabled until approved by the FCC. Sincerely, Clinton Bradley / Compliance Engineer 350 West Java Drive, Sunnyvale, CA 94089 [email protected] / 408-636-4368

2/18/2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Professional Installation for FCC ID: S9GR710 Ruckus Wireless, Inc. hereby declares that the device FCC ID: S9GR710 will only be installed by a professional installer. The product is only sold through Authorized Partners. The R710 is not for sale to the general public. Professional installation is guaranteed based on the use of only Authorized Partners and distribution channels. Professional training and support is provided as part of the Authorized Partner programs. Sincerely, Clinton Bradley / Compliance Engineer 350 West Java Drive, Sunnyvale, CA 94089 [email protected] / 408-636-4368

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2/2/2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: S9GR710 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram / R710 Block Diagram.pdf - Schematics / R710 Schematic.pdf - Operational Description / R710 Radio Theory of Operation.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Clinton Bradley / Compliance Engineer 350 West Java Drive, Sunnyvale, CA 94089 [email protected] / 408-636-4368

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 2/2/2015 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Ruckus Wireless, Inc., hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): FCC ID: S9GR710 Product Description: R710 Access Point Model: R710 We affirm that between SIEMIC, Inc. and Ruckus Wireless, Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Clinton Bradley / Compliance Engineer 350 West Java Drive, Sunnyvale, CA 94089 [email protected] / 408-636-4368

3/4/2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Declaration for Short-Term Confidentiality for FCC ID: S9GR710 Ruckus Wireless, Inc. would like to apply short-term confidentiality to some of the exhibits that were previously uploaded to FCC under FCC ID: S9GR710. We hereby declare that we understand these documents were made available to the public when the FCC grants were issued on 2/20/2015. We also understand that there is a risk that these documents may have been seen or acquired by the public before applying the short-term confidentiality to them. Please let me know if you have any questions. Thank you for your kind attention! Sincerely, Clinton Bradley / Compliance Engineer 350 West Java Drive, Sunnyvale, CA 94089 [email protected] / 408-636-4368

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 3/4/2015 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: S9GR710 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - User Manual - User Manual Insert - Test Setup Photos - External Photos - Internal Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Sincerely, Clinton Bradley / Compliance Engineer 350 West Java Drive, Sunnyvale, CA 94089 [email protected] / 408-636-4368

Test report No. Ext-Pic_SL14121601-RUC-016 Page 1 of 1 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 Visit us at: www.siemic.com; Follow us at: EUT Photos - External Top View Bottom View Front View Rear View Left Side View Right Side View

Label & location

Test report No. Int-Pic_SL14121601-RUC-016 Page 1 of 1 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 Visit us at: www.siemic.com; Follow us at: EUT Photos - Internal EUT Main PCBA Top View EUT Main PCBA Bottom View Test report No. Int-Pic_SL14121601-RUC-016 Rev1.0 Page 1 of 2 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 Visit us at: www.siemic.com; Follow us at: EUT Photos - Internal EUT Main PCBA Top View EUT Main PCBA Bottom View Shielding Area Close View-1 Shielding Area Close View-2 Shielding Area Close View-3 Shielding Area Close View-4 Test report No. RF_SL14110501-LHS-001_FCC-IC Page 2 of 2 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 Visit us at: www.siemic.com; Follow us at: Shielding Area Close View-5

MPE CALCULATION FCC ID: S9GR710 RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 EUT Frequency Band: 2412 - 2462 MHz; 5180 – 5240 MHz, 5745 - 5825MHz Limits for General Population/Uncontrolled Exposure in the band of: 1500 - 100,000 MHz Power Density Limit: 1 mW / cm 2 Equation: S = PG / 4R 2 or R = √PG / 4S Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ______________________________________________________________________________________________________________________ Prediction distance 20cm EUT: R710 (UNII Band): Power = 27.34dBm, Antenna Gain = 6.5 dBi, Power density = 0.482 mW/ cm 2 (2.4GHz Band): Power = 28.375dBm, Antenna Gain = 5.5 dBi, Power density = 0.486 mW/ cm 2 Total Ratio= (P 2.4GHz /1) + (P 5GHzUNII /1) = 0.486 mW/ cm 2 + 0.482 mW/ cm 2 = 0.968 mW/ cm 2 The Above Result had shown that the Device complied with MPE requirement. Completed By: David Zhang SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 Date: Feb 17th, 2015

775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 Visit us at: www.siemic.com Report No.: FCC_RF_SL14 121601 Supersede Report No.: FCC_RF_SL14 Applicant : Product Name : Model No. : Test Standard : Test Method : FCC ID : IC ID : Dates of test : Issue Date : Test Result : Equipment complied with the specification Equipment did not comply with the specification This Test Report is Issued Under the Authority of: Ricky Wang Test Engineer This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only 775 Montague Expressway, Milpitas, 95035 CA RF TEST REPORT 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 www.siemic.com; Follow us at: 121601-RUC-016_UNII Rev2.0 FCC_RF_SL14121601-RUC-016_UNII Ruckus Wireless, Inc. Access Point R710 47 CFR 15.407 ANSI C63.4: 2014 789033 D02 General UNII Test Procedures New Rules v01 S9GR710 5912A4R710 01/09/2015 to 01/28/2015 03/18/2015 ☒ Pass ☐ Fail [X] Equipment did not comply with the specification [ ] This Test Report is Issued Under the Authority of: David Zhang Engineer Reviewer This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued By: SIEMIC Laboratories 775 Montague Expressway, Milpitas, 95035 CA • Facsimile (+1) 408 526 1088 789033 D02 General UNII Test Procedures New Rules v01 Engineer Reviewer 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 Visit us at: www.siemic.com Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent test and certification facilities providing customers with one In addition to testing and certification, SIEMIC provides initial design reviews and extensive experience with China, Asia Pacific fastest, most cost effective way to attain regulatory compliance for the Accreditations for Conformity Assessment Country/Region Accreditation Body USA Canada Taiwan Hong Kong Australia Korea Japan VCCI, JATE, TELEC, RFT Mexico NOM, COFETEL, Caniety Europe Israel Accreditations for Product Certifications Country Accreditation Body USA Canada Singapore EU Japan Hong Kong Test report No. FCC_RF_SL14121601 Page 2 of 59 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 www.siemic.com; Follow us at: Laboratory Introduction headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent test and certification facilities providing customers with one4stop shop services for Compliance Testing and Global Certifications. , SIEMIC provides initial design reviews and compliance management Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Accreditation Body Scope FCC, A2LA EMC, RF/Wireless IC, A2LA, NIST EMC, RF/Wireless BSMI, NCC, NIST EMC, RF, Telecom OFTA, NIST RF/Wireless, Telecom NATA, NIST EMC, RF, Telecom KCC/RRA, NIST EMI, EMS, RF, Telecom, Safety VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom NOM, COFETEL, Caniety Safety, EMC, RF/Wireless, Telecom A2LA, NIST EMC, RF, Telecom MOC, NIST EMC, RF, Telecom, Safety Accreditations for Product Certifications Accreditation Body Scope FCC TCB, NIST EMC, RF, Telecom IC FCB, NIST EMC, RF, Telecom iDA, NIST EMC, RF, Telecom NB EMC & R&TTE Directive MIC (RCB 208) RF, Telecom OFTA (US002) RF, Telecom RF_SL141216014RUC4016_UNII Rev2.0 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing stop shop services for Compliance Testing and Global Certifications. compliance management throughout a project. Our compliance requirements, assures the Scope EMC, RF/Wireless, Telecom EMC, RF/Wireless, Telecom EMC, RF, Telecom, Safety Telecom EMC, RF, Telecom, Safety , Telecom, Safety EMI, RF/Wireless, Telecom , RF/Wireless, Telecom EMC, RF, Telecom, Safety EMC, RF, Telecom, Safety Scope , Telecom , Telecom , Telecom EMC & R&TTE Directive , Telecom , Telecom 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 Visit us at: www.siemic.com CONTENTS 1 REPORT REVISION HISTORY ................................ 2 EXECUTIVE SUMMARY ................................ 3 CUSTOMER INFORMATION ................................ 4 TEST SITE INFORMATION ................................ 5 MODIFICATION ................................ 6 EUT INFORMATION ................................ 6.1 EUT Description ................................ 6.2 Radio Description ................................ 6.3 EUT Photos 4 External ................................ 6.4 EUT Photos 4 Internal ................................ 6.5 EUT Test Setup Photos ................................ 7 SUPPORTING EQUIPMENT/SOFTWARE AND CABLIN 7.1 Supporting Equipment ................................ 7.2 Cabling Description ................................ 7.3 Test Software Description ................................ 8 TEST SUMMARY ................................ 9 MEASUREMENT UNCERTAINTY ................................ 10 MEASUREMENTS, EXAMINATION AND DERIVED RE 10.1 Conducted Emissions ................................ 10.2 26 dB Bandwidth & 6 dB Bandwidth 10.3 Peak Output Power ................................ 10.4 Peak Spectral Density ................................ 10.5 Radiated Emissions below 1GHz 10.6 Radiated Spurious Emissions between 1GHz 10.7 Radiated Spurious Emissions above ANNEX A. TEST INSTRUMENT ................................ ANNEX B. SIEMIC ACCREDITATION ............…

Text truncated - open the document above for the full version.

Test report No. Setup-Pic_SL14121601-RUC-016 Page 1 of 1 775 Montague Expressway, Milpitas, CA 95035, USA • Phone: (+1) 408 526 1188 • Facsimile (+1) 408 526 1088 Visit us at: www.siemic.com; Follow us at: Test Setup Photos AC Line Conducted Emissions – Front View AC Line Conducted Emissions – Rear View Radiated Emissions (<1GHz) – Front View Radiated Emissions (<1GHz) – Rear View Radiated Emissions (>1GHz) – Front View Radiated Emissions (>1GHz) – Rear View
