S9GZF7055ZoneFlex 7055 Access Point

Page 1 Federal Communications Commission Notices This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications to this equipment that have not been approved by Ruckus Wireless may void the user's authority to operate this equipment. For Class B Equipment: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. For Class A Equipment: Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Industry Canada Statement Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall comply with the e.i.r.p. limit; and the maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate. Le dispositif defonctionnementdans la bande 5150-5250MHz est réservé àune utilisation en intérieurpour réduire le risqued'interférences nuisiblesà la co-canal systèmes mobiles par satellite, le gain d'antenne maximalautorisépour les appareilsdans les bandes 5250-5350MHz et 5470-5725 MHzdoitse conformer à lapirelimite, et le gain d'antennemaximal autorisépour les appareilsdans la bande5725-5825 MHzdoivent être conformesavec lepirelimites spécifiées àpoint-à-ponctuelles et non point-à-point de fonctionnement selon qu'il convient. Operation in the 5600-5650 MHz band is not allowed in Canada. High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Opération dans la bande 5600-5650 MHz n'est pas autorisée au Canada. Haute puissanceradarssontdésignés comme utilisateurs principaux(c.-à- utilisateurs prioritaires) des bandes5250-5350 MHz et5650-5850MHzet queces radars pourraientcauser des interférenceset /ou des dommages àdispositifs LAN-EL. Radiation Exposure Statement The device has been found to be compliant to the requirements set forth in CFR 47 Sections 2.1091 and Industry Canada RSS-102 for an uncontrolled environment. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Le dispositif a été jugé conforme aux exigences énoncées dans les articles 47 CFR 2.1091 et Industrie Canada RSS-102 po…

Text truncated - open the document above for the full version.

Date: January 16, 2013 GENERAL DECLARATION We, Ruckus Wireless, Inc. declares that device does not have “Ad Hoc on non-US frequencies” while applying for the follow product. FCC ID: S9GZF7055 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely, Clinton Bradley Compliance Engineer 1- 408-636-4368 [email protected]

350 West Java Drive TEL + .650.265.4200 Sunnyvale, CA 94089 USA FAX +.480.738.2065 www.ruckuswireless.com FCC Software Configuration Control Declaration Date: January 31, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product/ Model Number: ZoneFlex 7055; FCC ID: S9GZF7055 Regarding FCC Country Code Selection guidelines identified in KDB 594280 "Country Code Selection". “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Clinton Bradley Compliance Engineer [email protected] [email protected]

Date: January 16, 2013 FCC ID: S9GZF7055 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: o Schematics o Block Diagram o Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Clinton Bradley Compliance Engineer 1- 408-636-4368 [email protected]

Date: January 16, 2013 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: S9GZF7055 Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until 2013/3/30 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: o External Photos o Test Setup Photos o User’s Manual o Internal Photo Thank you! Sincerely yours, Clinton Bradley Compliance Engineer 1- 408-636-4368 [email protected]

Date: January 16, 2013 To whom it may concern: We, the undersigned, Ruckus Wireless, Inc. hereby authorize Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C+15E approval and any communication needed with the national authority for the FCC ID listed below. Any and all acts carried out by Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. on our behalf shall have the same effects as acts of our own. FCC ID: S9GZF7055 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, Clinton Bradley Compliance Engineer 1- 408-636-4368 [email protected]

Report No.: 121114E06 Page 1 CONSTRUCTION PHOTOS OF EUT Model : ZoneFlex 7055

This telecommunication equipment conforms to NTC technical requirement E315548Type Approved No.: ESD-XXXXXXXX XXXXXXXXXXXXX XXXX FCC ID: S9GZF7055 IC: 5912A-ZF7055 CMIIT ID: XXXXDJXXXX India: XXXXXXXXX POWER RATING: 48VDC 500mA USI-SZ Made in China 0560 N420 ZoneFlex 7055 Access Point IDA: NXXXX-XX TRA: XXXXXXXXX KC C-CMM -R CK-ZF7055 CCAIXXXXXXXXXX XXX-XXXXXX ANATEL: XXXX-XX-XXXX Model: ZoneFlex 7055 CNCXX-XXXX SUBTELXXXXX MOC XXXXXXXXX MTCXXXXXX SUTEL XXXX-XXXX OFCA:HK001YYXXXXX COFETEL NO.:XXXXXXXXX-XXXX ICT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Width*Height: 50*40mm DXXXXX

FCC ID：S9GZF7055 LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No.: 121114E06 Page 2 Model : ZoneFlex 7055 Report No.: 121114E06 Page 3 Report No.: 121114E06 Page 4 Report No.: 121114E06 Page 5 Report No.: 121114E06 Page 6 Report No.: 121114E06 Page 7 Report No.: 121114E06 Page 8 Report No.: 121114E06 Page 9 Report No.: 121114E06 Page 10 Report No.: 121114E06 Page 11 Report No.: 121114E06 Page 12

Report No.: SA121114E06B 1 of 6 Report Format Version 5.0.0 Reference No.:121115E11 RF EXPOSURE REPORT REPORT NO.: SA121114E06B MODEL NO.: ZoneFlex 7055 FCC ID: S9GZF7055 RECEIVED: Nov. 14, 2012 TESTED: Nov. 22 to 23, 2012 ISSUED: Dec. 18, 2012 APPLICANT: Ruckus Wireless, Inc. ADDRESS: 350 West Java Drive, Sunnyvale, CA 94089 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA121114E06B 2 of 6 Report Format Version 5.0.0 Reference No.:121115E11 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA121114E06B 3 of 6 Report Format Version 5.0.0 Reference No.:121115E11 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA121114E06B Original release Dec. 18, 2012 Report No.: SA121114E06B 4 of 6 Report Format Version 5.0.0 Reference No.:121115E11 1. CERTIFICATION PRODUCT: ZoneFlex 7055 Access Point BRAND NAME: Ruckus Wireless MODEL NO.: ZoneFlex 7055 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Ruckus Wireless, Inc. TESTED DATE: Nov. 22 to 23, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: ZoneFlex 7055) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Dec. 18, 2012 ( Midoli Peng, Specialist ) APPROVED BY : , DATE: Dec. 18, 2012 ( May Chen, Deputy Manager ) Report No.: SA121114E06B 5 of 6 Report Format Version 5.0.0 Reference No.:121115E11 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA121114E06B 6 of 6 Report Format Version 5.0.0 Reference No.:121115E11 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 422.726 3.2 20 0.17571 1 For 15.247(5GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 313.537 5.4 20 0.43253 1 For 15.407(5GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 47.989 5.4 20 0.03310 1 CONCLUSION: Both of the 2.4GHz and 5GHz WLAN can transmit simultaneously, the formula of calculated the MPE is: CPD 1 / LPD 1 + CPD 2 / LPD 2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.17571 / 1 + 0.43253 / 1 = 0.608, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit. --- END ---
