Copyright © 2009 Ruckus Wireless, Inc. Published September 2009, Part Number 800-70242-001 REV A ZoneFlex 73437363802.11n Indoor Access Point Quick Setup Guide This Quick Setup Guide provides step-by-step instructions on how to set up your Ruckus Wireless ZoneFlex Access Point. After completing the steps described in this Guide, you will be able to place the Access Point (AP) at your site and provide wireless network access to users. BEFORE YOU BEGIN Before deploying Ruckus Wireless products, please check for the latest software and the release documentation. •Release Notes are available at http://support.ruckuswireless.com/documents. •User Guides are available at http://support.ruckuswireless.com/documents. •Software Upgrades are available at http://support.ruckuswireless.com/software. •Open Source information is available at http://support.ruckuswireless.com/open_source. PACKAGE CONTENTS •One ZoneFlex 7343/7363 Access Point •One AC power adapter •One mounting template •This Quick Setup Guide •One Cat5 Ethernet cable SETUP REQUIREMENTS •A computer with Windows 2000, XP or Vista installed •One or more of the following: •A modem (DSL or cable), E1/T1 router, or other device provided by your Internet Service Provider, that brings Web access to your site. •A network switch or a DSL/Internet gateway device. STEP 1: CONNECT THE AP TO YOUR COMPUTER 1After removing your Ruckus Wireless AP from its package, place it next to your computer. 2Temporarily disconnect your computer from any local net- work, if connected. 3Using an Ethernet cable, connect your computer’s network port to one of the three ports on the AP. •7343/7363: (pictured below): 10/100/1000 PoE, or 10/ 100 FE. 4Using the AC adapter included in the package, connect the AP to a convenient (and protected) power source. Alternatively, connect the POE port to a PoE (Power over Ethernet) switch for power and network connectivity. 5After a minute, verify that the PWR LED on the external enclosure is a steady green. STEP 2: PREPARE YOUR COMPUTER FOR AP SETUP 1On your Windows computer, open the Network Connections (or Network and Dial-up Connections) control panel according to how the Start menu is set up: Start > Settings > Network Connections Start > Control Panel > Network Connections 2When the Network Connections window appears, right- click the icon for Local Area Connection, and then click select Properties. 3When the Local Area Connection Properties dialog box appears, select Internet Protocol (TCP/IP) from the scroll- ing list, and then click Properties. The TCP/IP Properties dialog box appears. 4Select Use the following IP address option (if it is not already selected), and then make the following entries: •IP address: 192.168.0.22 (or any address in the 192.168.0.x network) •Subnet mask: 255.255.255.0 •Default gateway: 192.168.0.1 •Preferred DNS server: 192.168.0.1 Leave the Alternate DNS server field empty. 5Click OK to save your changes, exit first the TCP/IP Prop- erties dialog box, and then the Local Area Connection Properties dialog box. Your changes are put into effect immediately. STEP 3: LOG INTO THE AP As specified earlier, the AP should be directly connected to your computer (through one of the LAN ports), and have been powered on, ready for setup. 1 On your computer, open a Web browser window. 2In the browser, type this URL to connect to the AP: https://192.168.0.1 3Press <Enter> to initiate the connection. When a security alert dialog box appears, click OK/Yes to proceed. 4When the Ruckus Wireless Admin login page appears, enter the following: •Username: super •Password: sp-admin 5Click Login. IMPORTANT! If the AP is deployed with a ZoneDirector, follow the ZoneDirector Quick Setup Guide, and connect the AP to your Ethernet network. IMPORTANT! Make sure you do not open the Properties dialog box for the wireless network. IMPORTANT! Write down all of the currently active settings so you can restore your computer to its current configuration later (when this process is complete). Default AP Settings (For Your Reference) Network Names (SSIDs)Wireless# (e.g., Wireless1) Security (Encryption method) Disabled for each wireless interface Default Management IP Address 192.168.0.1 Copyright © 2009 Ruckus Wireless, Inc. Published September 2009, Part Number 800-70242-001 REV A STEP 4: CUSTOMIZE THE WIRELESS SETTINGS 1Log in to the ZoneFlex Web interface. For single band AP (ZoneFlex 7343): •On the Web interface menu, click Configuration > Wireless. The Configure::Wireless::Common options appear. •Verify that the following options are active: •Wireless Mode: Auto-select •Channel: SmartSelect •Country Code: If you are not located in the United States, select your current country. For dual band AP (ZoneFlex 7363): •On the Web interface menu, click Configuration > Radio 2.4G or Configuration > Radio 5G. •Verify that the following options are active: •Wireless Mode: Radio 2.4G or Radio 5G •Channel: SmartSelect •Country Code: If you are not located in the United States, select your current country. 2Click Update Settings if you made any changes. 3Click any of the “Wireless #” tabs near the top of the screen. 4In Wireless Availability, click Enabled. 5Delete the text in the SSID field, and then type the name of your network. If your network does not have a “name”, type a short name that will help your users identify the AP in their wireless network connection application. 6Click Update Settings to save your changes. 7Repeat Steps 4-7 for each Wireless # interface that you want to enable. 8Click Logout to exit the Ruckus Web Admin interface. 9When the Web Admin login page reappears, you can exit your browser. 10Disconnect the AP from the computer and from the cur- rent power source, and then restore your computer to the normal network connections. STEP 5: RESTORE YOUR COMPUTER’S NETWORK S ETTINGS 1Click Start > Settings > Network Connections. (If Windows 2000, click Start > Settings > Network and Dial-up Connections.) 2When the Network C…

Text truncated - open the document above for the full version.

February 24, 2010 FCC ID: S9GZF7363 DECLARATION LETTER To whom it may concern: We, Ruckus Wireless, Inc., declare that the device does not have “Ad Hoc on non-US frequencies” and/or “on DFS frequencies” while applying for the following product. Trademark: Ruckus Model Name: ZF7363 Product Name: ZoneFlex 7363 Access Point FCC ID: S9GZF7363 If you have any questions regarding the authorization, please do not hesitate to contact us. Thank you! Sincerely, Craig Owens Director, Hardware Engineering 880 West Maude Avenue, Suite 101 TEL + .650.265.4200 Sunnyvale, CA 94085 USA FAX +.480.738.2065 www.ruckuswireless.com

FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 March 2, 2010 Re: Request for Confidentiality Dear Examiner: In reference to the application under FCC ID: S9GZF7363, and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block diagram Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until August 29, 2010: Internal and External Photographs Test Configuration Photographs It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Craig Owens Director, Hardware Engineering 880 West Maude Avenue, Suite 101 TEL + .650.265.4200 Sunnyvale, CA 94085 USA FAX +.480.738.2065 www.ruckuswireless.com

880 West Maude Avenue, Suite 101 TEL + .650.265.4200 Sunnyvale, CA 94085 USA FAX +.480.738.2065 www.ruckuswireless.com February 17, 2010 Agency Authorization Letter We, the undersigned Ruckus Wireless, Inc., hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15 and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely, Craig Owens Director, Hardware Engineering

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

1. Replace “XXX” with the country of manufacture 2. Dielines/cutlines do not print 3. P/N 877-76271-001 Rev. E 4. Colors: BLACK PMS 021C

Label Location FCC ID: S9GZF7363

Page 4 Page 5 Page 6 Page 7 Page 8 Page 9

FCC ID: S9GZF7363 Report No.: SA981021L10B Report Format Version 3.0.1 Reference No.: 990210L03 1 RF EXPOSURE REPORT REPORT NO.: SA981021L10B MODEL NO.: ZF7363 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Ruckus Wireless, Inc. ADDRESS: 880 West Maude Ave. Suite 101 Sunnyvale California United States 94085 FCC ID: S9GZF7363 MANUFACTURER’S COMPANY: Senao Networks, Inc. MANUFACTURER ADDRESS: 3F, No. 529, Chung Cheng Rd., Hsintien, Taipei, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. FCC ID: S9GZF7363 Report No.: SA981021L10B Report Format Version 3.0.1 Reference No.: 990210L03 2 RF EXPOSURE MEASUREMENT (MOBILE DEVICE) 1. INTRODUCTION In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF EXPOSURE LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) (A)LIMITS FOR OCCUPATIONAL / CONTROL EXPOSURES 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: S9GZF7363 Report No.: SA981021L10B Report Format Version 3.0.1 Reference No.: 990210L03 3 3. FRIIS FORMULA Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT OPERATING CONDITION The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: S9GZF7363 Report No.: SA981021L10B Report Format Version 3.0.1 Reference No.: 990210L03 4 6. TEST RESULTS 6.1 ANTENNA GAIN The maximum Gain measured in Fully Anechoic Chamber are 2dBi or 1.585(numeric) (for 2.4GHz antenna); 2dBi or 1.585(numeric) (for 5.0GHz). 6.2 OUTPUT POWER INTO ANTENNA & RF EXPOSURE VALUE AT DISTANCE 20cm: For 2.412 ~ 2.462GHz band: POWER OUTPUT (dBm) CHAIN 0 CHAIN 1 TOTAL POWER (mW) TOTAL POWER (dBm) POWER DENSITY (mW/ cm 2 ) LIMIT OF POWER DENSITY (mW/ cm 2 ) 19.6 21.1 219.0 23.4 0.069 1.000 For 5.180 ~ 5.240GHz band: POWER OUTPUT (dBm) CHAIN 0 CHAIN 1 TOTAL POWER (mW) TOTAL POWER (dBm) POWER DENSITY (mW/ cm 2 ) LIMIT OF POWER DENSITY (mW/ cm 2 ) 13.7 14.2 49.4 16.9 0.017 1.000 For 5.745 ~ 5.825GHz band: POWER OUTPUT (dBm) CHAIN 0 CHAIN 1 TOTAL POWER (mW) TOTAL POWER (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/ cm 2 ) 18.2 18.2 130.8 21.2 0.042 1.000 CONCULSION: Both of the WLAN 2.4G & 5.0G can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density 1. WLAN 2.4G + WLAN 5.0G = 0.111 Therefore, the maximum calculation of this situation is 0.111, which is less than the “1” limit.

Report No.: RF981021L10B 1 Report Format Version 3.0.1 Reference No.: 990210L03 FCC TEST REPORT (15.247) REPORT NO.: RF981021L10B MODEL NO.: ZF7363 RECEIVED: Oct. 21, 2009 TESTED: Oct. 23 ~ Oct. 29, 2009 ISSUED: Feb. 22, 2010 APPLICANT: Ruckus Wireless, Inc. ADDRESS: 880 West Maude Ave. Suite 101 Sunnyvale California United States 94085 FCC ID: S9GZF7363 MANUFACTURER’S COMPANY: Senao Networks, Inc. MANUFACTURER ADDRESS: 3F, No. 529, Chung Cheng Rd., Hsintien, Taipei, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. This test report consists of 128 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF981021L10B 2 Report Format Version 3.0.1 Reference No.: 990210L03 TABLE OF CONTENTS 1. CERTIFICATION........................................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY ............................................................................... 6 3. GENERAL INFORMATION ........................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 7 3.2 DESCRIPTION OF TEST MODES ............................................................................... 9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 11 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 16 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 16 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND)................................................. 17 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 17 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 17 4.1.2 TEST INSTRUMENTS................................................................................................ 18 4.1.3 TEST PROCEDURES ................................................................................................ 19 4.1.4 DEVIATION FROM TEST STANDARD....................................................................... 19 4.1.5 TEST SETUP.............................................................................................................. 20 4.1.6 EUT OPERATING CONDITIONS ............................................................................... 20 4.1.7 TEST RESULTS ......................................................................................................... 21 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 35 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 35 4.2.2 TEST INSTRUMENTS................................................................................................ 35 4.2.3 TEST PROCEDURES ................................................................................................ 36 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 36 4.2.5 TEST SETUP.............................................................................................................. 37 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 37 4.2.7 TEST RESULTS ......................................................................................................... 38 4.3 6dB BANDWIDTH MEASUREMENT.......................................................................... 42 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................... 42 4.3.2 TEST INSTRUMENTS................................................................................................ 42 4.3.3 TEST PROCEDURE................................................................................................... 42 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 42 4.3.5 TEST SETUP.............................................................................................................. 43 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 43 4.3.7 TEST RESULTS ......................................................................................................... 44 4.4 MAXIMUM OUTPUT POWER .................................................................................... 48 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT..................................... 48 4.4.2 INSTRUMENTS .......................................................................................................... 48 4.4.3 TEST PROCEDURE................................................................................................... 48 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 49 4.4.5 TEST SETUP.............................................................................................................. 49 4.4.6 EUT OPERATING CONDITIONS ............................................................................... 49 4.4.7 TEST RESULTS .......................................................................................…
