Copyright © 2013 Ruckus Wireless, Inc.Page 1 of 4 Published March 2013, Part Number 800-70494-001 ZoneFlex 7372-E 802.11n Multimedia Wi-Fi Access Point Quick Setup Guide This Quick Setup Guide provides step-by-step instructions on how to set up your Ruckus Wireless ZoneFlex Access Point. After completing the steps described in this Guide, you will be able to place the Access Point (AP) at your site and provide wireless network access to users. BEFORE YOU BEGIN Before deploying Ruckus Wireless products, please check for the latest software and the release documentation. •User Guides and Release Notes are available at http://support.ruckuswireless.com/documents. •Software Upgrades are available at http://support.ruckuswireless.com/software. •Open Source information is available at http://opensource.ruckuswireless.com. •Software License and Limited Warranty available at http://support.ruckuswireless.com/warranty. PACKAGE CONTENTS •ZoneFlex 7372-E Access Point •Mounting screws and anchors (2) •Security screw (1) •Regulatory flyer •Declaration of Conformity (country-dependent) •Product Warranty Statement •This Quick Setup Guide SETUP REQUIREMENTS •A computer running Windows 7 (procedures for other OS’s are similar) •One or more of the following: •A modem (DSL or cable), broadband router, or other device provided by your Internet Service Provider that brings Internet access to your site. •A network switch or a DSL/Internet gateway device. •Two Ethernet cables (Cat5e or better for PoE in) •An AC power adapter (sold separately), or •An 802.3af or 802.3at -compliant Power over Ethernet (PoE) switch or PoE injector STEP 1: CONNECT THE AP TO YOUR COMPUTER 1After removing your Ruckus Wireless AP from its package, place it next to your computer. 2Using an Ethernet cable, connect your computer’s network port to the 10/100/1000 port on the AP. 3Using the AC adapter (sold separately), connect the AP to a convenient (and protected) power source. •Alternatively, connect the 10/100/1000 port to a PoE injector or PoE switch for both power and network con- nectivity. 4Verify that the Power LED on the external enclosure is a steady green. STEP 2: PREPARE YOUR COMPUTER FOR AP S ETUP 1On your Windows 7 computer, configure your network adapter from the Local Area Connection settings as follows: • Start > Control Panel > Network and Sharing Center > Change Adapter Settings 2Edit the TCP/IPv4 address settings as follows: • Local Area Connection > Properties > Internet Protocol Version 4 (TCP/IPv4) > Properties The TCP/IPv4 Properties dialog box appears. 3Select Use the following IP address (if it is not already selected) and then make the following entries: • IP address: 192.168.0.22 (or any address in the 192.168.0.x network) • Subnet mask: 255.255.255.0 • Default gateway: 192.168.0.1 Leave the DNS server fields empty. 4Click OK to save your changes. Your changes are put into effect immediately. STEP 3: LOG INTO THE AP As specified earlier, the AP should be directly connected to your computer (through the Ethernet port) and powered on, ready for setup. 1On your computer, open a Web browser window. 2In the browser, type this URL to connect to the AP: https://192.168.0.1 3Press <Enter> to initiate the connection. When a security alert dialog box appears, click OK/Yes to proceed. 4When the Ruckus Wireless Admin login page appears, enter the following: • Username: super • Password: sp-admin 5Click Login. IMPORTANT! If the AP is deployed with a ZoneDirector, follow the ZoneDirector Quick Setup Guide, and connect the AP to your local network. NOTE: The following procedures assume Windows 7 as the operating system. Procedures for other OS’s are similar. IMPORTANT! Write down all of the currently active settings so you can restore your computer to its current configuration later (when this process is complete). Copyright © 2013 Ruckus Wireless, Inc.Page 2 of 4 Published March 2013, Part Number 800-70494-001 STEP 4: CUSTOMIZE THE WIRELESS SETTINGS 1On the Web interface menu, click Configuration > Wire- less (Configuration > Radio 2.4G or Configuration > Radio 5G). The Configure :: Wireless :: Common options appear. 2Verify that the following options are active: • Channel: SmartSelect • Country Code: If you are not located in the United States, select your current country. • External Antenna: Enable the check box and enter the external antenna gain in the field provided. 3Click Update Settings if you made any changes. 4Click any of the eight “Wireless #” tabs at the top of the page. 5In Wireless Availability, click Enabled. 6Delete the text in the SSID field, and then type a name for your network that will help your users identify the AP in their wireless network connection application. 7Click Update Settings to save your changes. 8Repeat Steps 4-7 for each Wireless # interface that you want to enable. 9Click Logout to exit the Web interface. 10Disconnect the AP from the computer and from the current power source, and then restore your computer to its original network connection configuration. STEP 5: PLACE THE AP IN YOUR SITE 1Move the AP to its permanent location (accessible to both AC power and network connection). 2Use an Ethernet cable to connect the 10/100/1000 port of the AP to your network. 3Connect the AC power adapter (or PoE power supply) to the AP, then to a convenient power source. 4Verify that the 10/100/1000 port LED is lit. 5Connect external antennas to the RP-SMA connectors on the 7372-E enclosure. Note that each connector is a dual- band (2.4 GHz & 5 GHz) spatial stream. •Ruckus Wireless offers two different antenna kits as sep- arately orderable accessories, certified for use with the 7372-E: •911-0303-VP02 (articulating direct-mount antenna pair) •911-0505-DP01 (2-stream sector antenna panel) After a short pause to re-establish the Internet connection, you can test the AP. STEP 6: VERIFY THE INSTALLATION 1Using any wireless-enabled computer or mobile device, search for and select the wireless network yo…
