SA5YLT-5CRemote Controller

Instruction of Remote Controller 1. Brief Account: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. The Device Data: Model designation: YLT-5C Power: 12V battery Frequency: 315 MHz 3. Use Description: Each of receiver’s individual function (normal open、2 hour setting、4 hour setting、6 hour setting 、8 hour setting 、nature lighting activation、 off and waiting )can be turned into active status by pressing transmitter’s corresponding function key “ON、 2 、4、 6 、8、 ¤、 OFF”. The status of receiver’s each individual function can also be distinguished by observ -ing its corresponding indicator (ON、 2、 4、 6、8、 ¤ 、ON flashing). 1>Press the transmitter key “ON” can turn into active the receiver corresponding function indicator“ON”，normal open. 2>Press the transmitter key “2” can turn into active the receiver corresponding function indicator“2”，2 hour setting. 3>Press the transmitter key “4” can turn into active the receiver corresponding function indicator“4”，4 hour setting. 4>Press the transmitter key “6” can turn into active the receiver corresponding function indicator“6”，6 hour setting. 5>Press the transmitter key “8” can turn into active the receiver corresponding function indicator“8”，8 hour setting. 6>Press the transmitter key “¤” can turn into active the receiver corresponding function indicator“¤”，nature lighting activation. 7>Press the transmitter key “OFF” can turn into active the receiver corresponding function indicator“ON Flashing”，off and waiting. Regarding the device parts detail, please read the parts description as below (Figure 1). This device can automatically deactivate the transmitter within not more than 5 seconds of being released. 4. Parts Description Figure 1 1: 4 hour setting 2: 6 hour setting 3: 8 hour setting 4: nature lighting activation 5: 2 hour setting 6: OFF 7: ON 8: indicator light 9: battery compartment 10: battery 11: battery cover 5. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 6 3 2 8 4 7 9 10 11 1 5

F IGURE 1 REMOTE CONTROLLER (M/N: YLT-5C) G ENERAL A PPEARANCE (F RONT V IEW ) F IGURE 2 REMOTE CONTROLLER (M/N: YLT-5C) G ENERAL A PPEARANCE (R EAR V IEW )

Label Location Information Refer to the below red arrow: (For example)

F IGURE 1 REMOTE CONTROLLER (M/N: YLT-5C) C OVER R EMOVED F IGURE 2 REMOTE CONTROLLER (M/N: YLT-5C) M AIN B OARD (C OMPONENT S IDE ) F IGURE 3 REMOTE CONTROLLER (M/N: YLT-5C) M AIN B OARD (S OLDERED S IDE )

Instruction of Remote Controller 1. Brief Account: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. The Device Data: Model designation: YLT-5C Power: 12V battery Frequency: 315 MHz 3. Use Description: Each of receiver’s individual function (normal open、2 hour setting、4 hour setting、6 hour setting 、8 hour setting 、nature lighting activation、 off and waiting )can be turned into active status by pressing transmitter’s corresponding function key “ON、 2 、4、 6 、8、 ¤、 OFF”. The status of receiver’s each individual function can also be distinguished by observ -ing its corresponding indicator (ON、 2、 4、 6、8、 ¤ 、ON flashing). 1>Press the transmitter key “ON” can turn into active the receiver corresponding function indicator“ON”，normal open. 2>Press the transmitter key “2” can turn into active the receiver corresponding function indicator“2”，2 hour setting. 3>Press the transmitter key “4” can turn into active the receiver corresponding function indicator“4”，4 hour setting. 4>Press the transmitter key “6” can turn into active the receiver corresponding function indicator“6”，6 hour setting. 5>Press the transmitter key “8” can turn into active the receiver corresponding function indicator“8”，8 hour setting. 6>Press the transmitter key “¤” can turn into active the receiver corresponding function indicator“¤”，nature lighting activation. 7>Press the transmitter key “OFF” can turn into active the receiver corresponding function indicator“ON Flashing”，off and waiting. Regarding the device parts detail, please read the parts description as below (Figure 1). This device can automatically deactivate the transmitter within not more than 5 seconds of being released. 4. Parts Description Figure 1 1: 4 hour setting 2: 6 hour setting 3: 8 hour setting 4: nature lighting activation 5: 2 hour setting 6: OFF 7: ON 8: indicator light 9: battery compartment 10: battery 11: battery cover 5. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 6 3 2 8 4 7 9 10 11 1 5

Instruction of Remote Controller 1. Brief Account: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1). This device may not cause harmful interference, and (2). This device must accept any interference received, including interference that may cause undesired operation. 2. The Device Data: Model designation: YLT-5C Power: 12V Battery Frequency: 315MHz 3. Parts Description Figure 1 1: 4 hour working 2: 6 hour working 3: 8 hour working 4: nature lighting activation 5: 2 hour working 6: OFF 7: ON 8: indicator light 9: battery compartment 10: battery 11: battery cover 4. Use Description: The EUT is a wireless remote controller. It can control the photoelectric switch. If users press the keys (Please see the Parts Description above), the photoelectric switch will make 6 kinds of indicator lights shine individual and working till end the site time each other. Each of receiver’s individual function (normal open、2 hour setting、4 hour setting、8 hour setting、nature lighting activation、off and waiting) can be turned into active status by pressing transmitter’s corresponding function key “ON、2、 4、6、8、 、OFF”. The status of receiver’s each individual function can also be distinguished by observing its corresponding indicator (ON、2、4、6、8、 、 ON flashing). 1> Press the transmitter key “ON” can turn into active the receiver corresponding function indicator “ON”, normal light open. 2> Press the transmitter key “2” can turn into active the receiver corresponding function indicator “2”, and let it working 2 hours. 3> Press the transmitter key “4” can turn into active the receiver corresponding function indicator “4”, and let it working 4 hours. 4> Press the transmitter key “6” can turn into active the receiver corresponding function indicator “6”, and let it working 6 hours. 5> Press the transmitter key “8” can turn into active the receiver corresponding function indicator “8”, and let it working 8 hours. 6> Press the transmitter key “ ” can turn into active the receiver corresponding function indicator “ ”, nature lighting activation. 7> Press the transmitter key “OFF” can turn into active the receiver corresponding function indicator “ON Flashing”, off and waiting. Regarding the device parts detail, please read the parts description as above. This device can automatically deactivate the transmitter within not more than 5 seconds of being released. 5. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Schematics YLT-5C component rating: Component Model Rating C1 CB104 332/25V C3 CB4 4P/25V C4 CB12 15P/25V C5 CB103 103/25V IC EM78P153 EM78P153 Q S9018 S9018 D1 Ф3 D2 5.6V/0.5W DY HD R315M R RTX 10Ω-1/8W±10% R1 RTX RTX-47KΩ-1/8W±10% R2 RTX RTX-47Ω-1/8W±10% R4 RTX RTX-240KΩ-1/8W±10% L Ф 0.7/2.5T,Φ3.2 D3 IN4148 IN4148 PWB YLT-5-A 15823A,94 V-0 Enclosure(top) ABS L=70mm W=42mm Enclosure(bottom) ABS L=62mm W=42mm Battery cover ABS L=29mm,W=21mm Internal wire 20mm, Φ1,24AWG Battery 25A,12V Screw 1 2.5*8 Screw 2 2.5*5 Keyboard Ningbo mingxin

Test Set-Up Photos 1. Radiated Emission Test FRONT VIEW OF TEST (2 TEST MODE) BACK VIEW OF TEST (2 TEST MODE) SETUP WITH MAXIMUM DETECTED EMISSION AT HORIZONTAL POLARIZATION (2 TEST MODE) SETUP WITH MAXIMUM DETECTED EMISSION AT VERTICAL POLARIZATION (2 TEST MODE) 2. Fundamental And Spurious Emissions Test L YING DIRECTION SIDE DIRECTION S TAND DIRECTION HIGH FREQUENCY AT HORIZONTAL POLARIZATION HIGH FREQUENCY AT VERTICAL POLARIZATION
