Système de sécurité domestique iSmartAlarm MANUEL DUPROPRIÉTAIRE iSmartAlarm Home Security System OWNER’S MANUAL iSmartAlarm Home Security System OWNER’S MANUAL Table of Contents 1 1 1 1 2 3 7 7 11 11 12 14 14 16 19 21 22 24 24 24 INTRODUCTION PACKAGE CONTENTS INTENDED USE IMPORTANT NOTES FOR USERS CONTRAINDICATION PARTS, BATTERY AND LED INDICATOR SOUND CONFIRMATIONS BASIC FUNCTIONALITY SETUP REQUIREMENTS SETUP PROCEDURES OPERATING SETUP INSTRUCTIONS ADDING ADDITIONAL SENSORS AFTER THE INSTALLATION APP - BASIC WALKTHROUGH APP SCREEN LEGEND SPECIFICATIONS GENERAL SAFETY AND PRECAUTIONS TROUBLESHOOTING CARE AND MAINTENANCE WARRANTY INFORMATION EXPLANATION OF SYMBOLS INTRODUCTION Thank you for purchasing the iSmartAlarm Home Security System. The iSmartAlarm TM allows you complete control over your home's security utilizing your smartphone. This manual will guide you through the set up procedures and highlight the Security System’s key features. Please keep it handy for future reference. PACKAGE CONTENTS • CubeOne™ • Contact Sensors • Motion Sensor • Remote tags • iCamera™Optional • Power adapter • Network cable • Accessories • Window Decals • Quick Installation Guide • Owner’s Manual Note: please refer to the packing list for exact content in each specific package. INTENDED USE With the CubeOne™ managing your motion detectors, door and window protection, remote control and panic features, as well as the optional iCamera™ and additional home security and home automation devices, you can monitor, manage, and secure your home, property, and family from your smartphone with the iSmartAlarm. IMPORTANT NOTES FOR USERS The iSmartAlarm system does not offer any guarantee of protection against burglary, robbery, theft, or any type of emergency. 1 iSmartAlarm is a Do-It-Yourself (DIY) product. iSmartAlarm system does not come with traditional monitoring service. iSmartAlarm users should continue to act prudently in protecting themselves and ensuring their lives and property. Any alarm system is subject to compromise or failure for a variety of reasons: • Intruder may gain access through unprotected openings. • Intruder may have the technical sophistication to bypass a sensor or whole system. • Signals sent by CubeOne or devices may be blocked or reflected before being received, and block can occur if metal objects are moved into the path of the signal. • Motion sensors can only detect the intrusion within the designed ranges and unobstructed areas. • Malfunction of routers, limited services by wireless phone carriers, limited speed of high-speed internet by ISP, limited service such as iMessage, push notification provided by smartphone maker(s). • The iSmartAlarm system, like any electrical system, is subject to component failures. • Phone alert notification coverage currently includes continental US, Hawaii, and Canada provinces excluding area code 907 (Alaska) and 867 (Canada Northeast and Yukon). Additional areas will be added in the future. Please contact [email protected] for more details. Note: Whenever turning power off to the CubeOne (either through power outage, manually unplugging, or accidental disconnect), you should wait at least ten seconds before plugging the CubeOne back in/powering on. This will allow the residual power charge to cycle through. CONTRAINDICATION Use appropriate caution if you use this product in combination with medical electronic devices such as: (1) Medical electronic implants such as pacemakers. (2) Electronic life support systems such as artificial heart/lungs. 2 (3) Portable electronic medical devices such as electrocardiographs. This product could cause these devices to malfunction posing a considerable health risk to users of these devices. Contact sensors include parts with strong magnetic force. (4) Use caution when utilizing/testing siren volume. Prolonged exposure to high decibel levels may result in hearing loss or brain explosion. (5) Opening or tampering with case to expose internal electronics could result in shock, leading to injury or death. PARTS, BATTERY AND LED INDICATOR CubeOne ™ : Ports connection as below. 1. 10/100 BASE-T Ethernet: for connecting to router 2. USB: a port for future function expansion (not for connecting to computer directly) 3. Power: for connecting to power adaptor LED statuses of CubeOne ™ 1. Booting: LED stays solid red. 1 2 3 3 2. Normal working status: LED flashes white, “breathing” when siren is off; LED flashes red when siren is on. 3. Disarming: LED light changes from red flashing to white “breathing” when disarming. 4. CubeOne TM registration: LED alternates between red and white during registration. 5. Sensors registration: LED flashes white "breathing". 6. Communication error : LED stays red. Motion sensor: How to change battery: 1. Unscrew and take off the back lid. 2. Replace the three AA batteries as below. 4 3. LED flashes red once when batteries are installed. Note: Whenever removing and/or replacing batteries, you should wait at least ten seconds before placing new batteries in the sensor and powering on the device. This will allow the sensor's residual power charge to cycle through. Remote tag: How to change battery: 1. Unscrew and take off the back lid. 2. Replace the button battery with same type - CR2032. 3. LED flashes red once when the battery is installed. Note: Whenever removing and/or replacing batteries, you should wait at least ten seconds before placing new batteries in the sensor and powering on the device. This will allow the sensor's residual power charge to cycle through. 5 Contact sensor: How to change battery: 1. Take off the battery compartment. 2. Replace the button battery with same type - CR2032. 3. LED flashes red once when the battery is installed. Note: Whenever removing and/or replacing batteries, you should wait at least ten seconds before placing new batteries in the sensor and powering on the device. This will allow the sensor's residual power charge to cycle through. …
