TMANIII/ISI_1 TrackMan™ “TMAN III” Installation and Safety Instructions Issue 1, December 2012 Page 1 of 12 TrackMan™ Radar Unit Installation and Safety Instruction Model: TMAN III TMANIII/ISI_1 TrackMan™ “TMAN III” Installation and Safety Instructions Issue 1, December 2012 Page 2 of 12 Contents 1 INTRODUCTION ...................................................................................................................... 3 2 SAFETY INSTRUCTIONS .......................................................................................................... 4 2.1 Regulatory Notice ......................................................................................................... 4 2.2 Warning: Radiation Hazard .......................................................................................... 5 2.3 Caution: Safety precautions .......................................................................................... 6 3 INSTALLATION INSTRUCTIONS ............................................................................................... 7 3.1 System description ........................................................................................................ 7 3.2 System specifications ................................................................................................... 7 3.3 Setting up the system .................................................................................................. 10 4 WARRANTY COMMENTS ...................................................................................................... 12 TMANIII/ISI_1 TrackMan™ “TMAN III” Installation and Safety Instructions Issue 1, December 2012 Page 3 of 12 1 Introduction This document provides instructions and warning in order to safely install and operate the TrackMan III Radar Unit This document provides also instructions on how to make basic setup of the TrackMan™ system. This document does not describe the TrackMan™ application software and how to operate it. This is provided in separate document. TMANIII/ISI_1 TrackMan™ “TMAN III” Installation and Safety Instructions Issue 1, December 2012 Page 4 of 12 2 Safety Instructions 2.1 Regulatory Notice FCC compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TC technician for help. Caution Never try to open or repair the device yourself. Any changes or modifications not expressly approved by TrackMan A/S could void the user’s authority to operate the device. TMANIII/ISI_1 TrackMan™ “TMAN III” Installation and Safety Instructions Issue 1, December 2012 Page 5 of 12 2.2 Warning: Radiation Hazard Radiation Safety Warning. This device radiates a low level of microwave electromagnetic radiation from the front window when in use. The radiated power is significantly lower the international safety standards for microwave frequencies. However, the user should maintain a minimum distance of 20 cm from this device during operation. TMANIII/ISI_1 TrackMan™ “TMAN III” Installation and Safety Instructions Issue 1, December 2012 Page 6 of 12 2.3 Caution: Safety precautions Use the following safety instructions to ensure your own personal safety and to help protect the TrackMan™ radar unit. General • Do not attempt to service the device yourself. Always follow installation instructions closely. • Only use cables and accessories approved by TrackMan A/S together with your TrackMan™ Radar Unit. • The AC adaptor may become hot during normal operation of the TrackMan™ system. Use care when handling the adaptor during or immediately after operation. • If the TrackMan™ system has been used in wet weather, clean all items with a dry cloth after use. Power • The TrackMan™ Radar Unit has a build in battery for stand-alone operations • Do NOT cover the TrackMan™ Radar Unit while in use • Only use the AC adaptor supplied with the TrackMan™ Radar Unit for battery charging. Use of another adaptor may cause fire or explosion. • Before you connect the TrackMan™ Radar Unit to an electrical outlet, check the AC adaptor voltage rating to ensure that the required voltage and frequency match the available power source. • To help prevent electric shock, plug the AC adaptor and device power cables into properly grounded power sources. These power cables may be equipped with 3-prong plugs to provide an earth grounding connection. Do not use adaptor plugs or remove the grounding prong from the power cable plug. If you use a power extension cable, use the appropriate type, 2-prong or 3-prong, to mate the AC adaptor power cable. • Make sure that the computer and AC adaptor connected to the TrackMan™ Radar Unit are connected to the same power outlet. Failure to comply with this requirement could cause electrical shock and create permanent damage on both the TrackMan™ Rad…
Text truncated - open the document above for the full version.
TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk March 21, 2012 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: Confidentiality request for TMAN III , FCCid: SFX-TMANIII To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We request that all the schematic diagrams, block diagram and operational and technical description required to be submitted with this application be permanently withheld from public review. These named sections contain information that is trade secrets and proprietary. If made public, this information might be used to the disadvantage of the applicant in the market place. It is noted that one of the chassis assembling screws is covered with the type/sn. label, to avoid unauthorized access to the inside of the device. The device can only be opened by breaking the label. Finally it is written in the general terms of the contract with the customer, that any attempt to access the inside of the device will terminate any warranty agreement immediately. Please contact me if there is any information you may need. Sincerely, TrackMan A/S Fredrik Tuxen, CTO
TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk March 21 2012 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: Short term Confidentiality request for TMAN III , SFX-TMANIII In accordance with sections 0.457 and 0.459 of CFR 47, TrackMan A/S requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which TrackMan A/S considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, TrackMan A/S feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, TrackMan A/S Fredrik Tuxen, CTO
TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk TMA3A, External seen from front TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk TMA3A, External seen from back
Designed and assembled in Denmark by TrackMan A/S. Input power: DC IN 10– 30V, Max 65W. This device complies with Part 15 of the FCC Rules. Operation is subject to the following 2 conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. FCC ID: SFX-TMAN lll, IC: 10140A-TMAN lll This device may be covered by one or more of the following patents ZL200580022298.5, US8085188, ZL200680006869.0, EP1698380, EP1853362, JP2008-538085A, KR10-0947898 as well as pending patents. © 2012 TrackMan A/S. All Rights Reserved.
TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk TMA3A, Internal antenna plate (antenna side) TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk TMA3A , Internal antenna plate (circuit side) Unit: 4RCM2001C Comprising: EU33 2001C and EU12 1001A uEYE Camera EU13 1001A LiION battery TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk TMA3A, Antenna plate mounted in cabinet (front cover removed) EU13 1010A (not visible) Motorized leg uEYE Camera Patch antenna TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk EU 33 2001C seen from BOTTOM side EU12 1001A EU33 2001C Integrate unit is 4RCM2001C TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk EU33 2001C seen from TOP side TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk EU12 1001A TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk EU13 1010A TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk EU13 1010A TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk uEYE Camera
TrackMan A/S · Stubbeled 2 · DK-2950 Vedbæk · Denmark Telephone +45 45 74 00 33 · [email protected] · www.trackman.dk Maximum permissible emissions (MPE) As outlined in the “TMAN installation and operation manual” the user is typically located 2-3 meter in front of the TrackMan™ Radar Unit. The TrackMan™ Radar Unit can easily be re-located, so it is classified as a mobile device. The transmitting power Ptx is nominal 2 * 14dBm = 17dBm.The transmitting antenna gain Gtx is at maximum direction 15dB.The maximum equivalent isotropic radiated power EIRP of the TMAN consequently: EIRPmax = ∗ = 32dBm (1.6W) From the EIRP the power density can be calculated using the equation below: = ∗ ∗ [1] where D is the distance from the transmitting antenna. Equation [1] assumes that the distance D is large enough to be in the far field of the antenna. In the near field of the antenna, the power density will be less than what is obtained from equation [1]. The far field distance (Rayleigh distance) of the antenna is about 0.45 m ( ≫ ∗ ) Using equation [1] with the nominal EIRP of 32dBm at distance greater than 36 cm, the maximum power density is below 0.1mW/cm 2 . At the normal operating distance of 2.5 meter, the maximum power density is 0.002 mW/ cm 2 . The MPE of the TMAN is consequently far under the limit specified in FCC OET bulletin 65 of 5 mW/ cm 2 and 1 mW/cm 2 for both controlled and uncontrolled exposure respectively.
